FujiFilm FinePix F30 User manual

6.3 million pixels
1/1.7-inch Super CCD HR
Still image:2,848×2,136 / 3,024×2,016 /2,048×1,536 /
1,600×1,200 / 640×480
pixels
Movie:640×480 / 320×240 pixels (30frames/sec.) with monaural sound
Internal memory(approx. 10MB), xD
_
Picture CardTM (16MB - 1GB)
Still image: JPEG (Exif Ver 2.2**)
Movie: AVI (Motion JPEG), WAV
(Design rule for Camera File system compliant / DPOF
_
compatible)
FUNCTIONS
SPECIFICATIONS
For more information on the full range of Fujifilm digital products, please visit
our Website: http://home.fujifilm.com/products/digital
Ref. No. EB-600E (SK・06・02・F2586・F9711) Printed in Japan 2006 Fuji Photo Film Co., Ltd.
c
LCD Monitor
Lens / Lens Cover
Microphone
Exposure Compensation
Button
Strap Mount
Power Button
AF Assist Illuminator/
Self-timer Lamp
Flash
Speaker
Shutter Button
Mode Dial
MENU/OK Button
Playback Button
Zoom Button
DIGITAL CAMERA FinePix F30
Number of effective pixels*
CCD sensor
Number of recorded pixels
Storage media
File format
Lens
Lens focal length
Focus
Focus distance
Shutter speed
Aperture
Sensitivity
Exposure control
Exposure mode
White balance
LCD monitor
Flash
Self-timer
Video output
Digital interface
Power Source
Dimensions
Weight
Camera functions
Digital zoom
LCD brightness
Shooting modes
Color modes
Voice Memo
Playback
Auto Playback
Fujinon 3×optical zoom lens, F2.8- F5.0
f=8.0-
24.0mm (Equivalent to 36- 108mm on a 35mm camera)
AutoFocus(Center,Multi,Continuous)
AFassistilluminatoravailable
Normal: Approx. 60cm / 2.0ft. to infinity
Macro: Wide-angle: Approx. 5cm / 2.0in. to 80cm / 2.6ft.
Telephoto: Approx. 30cm / 1.0ft. to 80cm / 2.6ft.
3 sec. to 1/2000 sec. depend on shooting mode. 15 sec. at long exposure mode.
F2.8 -F8 (1/3 EV step) at Wide-angle, F5.0 -F8 (1/3 EV step) at Telephoto
AUTO / Equivalent to ISO 100 / 200 / 400 / 800 / 1600 / 3200
256
_
zone TTL metering - Multi / Spot /Average
Programmed AE, Shutter priority AE, Aperture priority AE
Automatic scene recognition / Preset (Fine, Shade, Fluorescent light (Daylight),
Fluorescent light (Warm White), Fluorescent light (Cool White), Incandescent light) /Custom
2.5-inch TFT (Approx. 230,000 pixels), approx. 100% coverage
Auto flash
Effective range: Wide angle: approx. 0.6m - 6.5m (2.0ft. -21.3ft.)
Telephoto: approx. 0.6m - 3.5m (2.0ft. -11.5ft.)
Macro:approx.0.3m-0.8m(1.0ft.-2.6ft.)
Flash mode:Auto, Red-eye Reduction, Forced Flash, Suppressed Flash,
Slow Synchro, Red-eye Reduction + Slow Synchro
Approx. 10 sec. / 2 sec. delay
NTSC / PAL selectable
USB2.0 High-speed
NP-95 Rechargeable Battery or AC Power Adapter AC-5VC (included)
92.7 (W)×56.7 (H)×27.8 (D) mm / 3.6 (W)×2.2 (H)×1.1 (D)in.
Approx. 155g / 5.5oz. (excluding battery and media)
Approx. 6.2×(3×opticalzoomlensisusedtogether:Max.zoomscale:18.6×)
Auto brightness up function plus low light view button
Normal: Auto, Scene Position (Natural Light, Natural Light & with Flash, Portrait,
Landscape, Sport, Night, Fireworks, Sunset, Snow, Beach,
Underwater, Museum, Party, Flower Close-Up, Text)
Continuous: 1.Top-3
:
max. 2.2 frames/sec., up to 3 frames
2.Final-3
:
max. 2.2 frames/sec., up to 3 frames
3.Long-period: Depend on Memory size. 1.5 sec.
intervals at 6M(N) depending on quality level
High speed shooting
B&W / CHROME / STANDARD
Up to 30 sec. WAVformat
Single frame, 9 Multi-frame, Day sorting display, Image rotation,
Post shot assist window (3 frames)
Single image, multiple images, fade-in, with clock
Microsoft, Windows, and Windows logo are trademarks, or registered trademarks of Microsoft Corporation in the United
States and/or other countries. Macintosh and Mac OS are trademarks of Apple Computer, Inc., registered in the U.S. and
other countries. All other trademarks are the property of their respective holders.
＊
Number of effective pixels: The number of pixels on the image sensor which receive input
＊＊
Exif 2.2 is a newly revised digital camera file format that contains
a variety of shooting information for optimal printing.
＊＊＊
''CIPA DC-002-2003 'Standard Procedure for Measuring Digital Still Camera Battery Consumption' '' (extract)
Pictures shall be taken at a temperature of 23°C, with the LCD monitor turned on, the zoom moved from
full wide-angle to full telephoto (or vice-versa) and back again to its original position every 30 seconds,
the flash used at full power every second shot and the camera turned off and then on again once every 10 shots.
light through the optical lens, and which are effectively reflected
in the final output data of the still image.
Windows XP compatible World standard PictBridge compatible
R
Specifications are subject to change without notice.
Simulated LCD display image
Indicator Lamp
Photo Mode ( ) Button
Number of images / recording time
Modes
Quality
Number of recorded pixels
16MB
32MB
64MB
128MB
256MB
512MB
1GB
The number of images and recording time will vary slightly depending on the type of subject.
Still image
6M
(
Normal
)
2848 × 2136
10
20
42
84
169
339
680
6M(Fine)
2848 × 2136
5
10
21
42
85
170
341
6M(3:2)
3024 × 2016
10
20
42
84
169
339
680
3M
2048 × 1536
19
40
81
162
325
651
1305
2M
1600 × 1200
25
50
101
204
409
818
1639
0.3M
640 × 480
122
247
497
997
1997
3993
7995
640
640 × 480
Approx. 13 sec.
Approx. 27 sec.
Approx. 55 sec.
Approx. 111 sec.
Approx. 223 sec.
Approx. 7.4 min.
Approx. 14.9 min.
320
320 × 240
Approx. 26 sec.
Approx. 54 sec.
Approx. 109 sec.
Approx. 219 sec.
Approx. 7.3 min.
Approx. 14.6 min.
Approx. 29.3 min.
Movie
Terminal Cover
DC IN 5V (Power Input)/
A/V OUT( Audio Visual Output )/
USB Socket
4-direction Button
(Macro/Flash/Self-timer/
Low Light View Button)
The number of frames per charge will decrease in High Speed Shooting mode.
According to the Camera & Imaging Products Association (CIPA) standards*** :
The storage media should be xD-Picture Card. The battery (NP-95) is supplied with the camera.
Guide to the number of available frames for battery operation
Battery
NP-95 LCD monitor status
LCD monitor ON Number of frames Approx. 500 frames
Battery Cover
DISP (Display)/Back Button
Accessories included
Optional accessories
NP-95 Rechargeable Battery,
AC Power Adapter AC-5VC,
Hand strap,
USB cable,
A/V cable,
CD-ROM: FinePixViewer
xD-Picture CardTM: 64MB, 128MB, 256MB, 512MB, 1GB
PC Card Adapter DPC-AD
CompactFlashTM Card Adapter DPC-CF
Image Memory Card Reader DPC-R1
AC Power Adapter AC-5VX
Rechargeable Battery NP-95
Battery charger BC-65S
Soft Case SC-FXF30
Waterproof Case WP-FXF30
The Evolution of Real Photo Technology
World’s First Digital Compact with ISO 3200 Sensitivity*
ISO3200
3.0x Optical Zoom
2.5inch LCD
6.3MegaPixels
Capture the moment as your eye sees it!
The future of digital photography has arrived. Equipped with a new “eye” and “brain”, the new generation
of Real Photo Technology from Fujifilm captures the images you really want – with greater ease, in more
situations, and with higher quality.
The new 6th Generation Super CCD HR captures more light from the superb Fujinon lens more
efficiently with less light loss, and sends the image to the processor with less noise. The new RP
Processor II featuring enhanced double noise reduction lets users take full advantage of the phenomenal
ISO 3200 sensitivity of the FinePix F30. Other improvements include “Intelligent Flash” and
upgraded signal processing for more accurate color reproduction.
All these enhancements add up to more stunning photos every time you press the shutter.
Real Photo
Technology
FUJINON
LENS
RP
PROCESSOR
II
SUPER CCD
HR
GENERATION
6
th
FLASH
INTELLIGENT
*As of January 2006, ISO 3200 at full 6.3 megapixel resolution.

Underwater Sunset Snow Fireworks Party Museum
ScenePositions
Museum
With a choice of 15 Scene Positions, you can quickly select exactly the right setting for every situation.
New
More Sensitivity with Less Noise
6.3MegaPixelsISO3200
Other Features
Sample photos are simulated images.
2.5 inch LCD
With its high resolution of 230,000 pixels and convenient features like Auto
Brightness and the new anti-glare, low-reflection CV (Clear View) Film developed
by fujifilm, the big 2.5 inch LCD monitor provides comfortable composition and
viewing of photos whether in dim interiors or under bright sunlight.
Approx. 500 Shots Per Charge
Enjoy 500 shots on a full charge! You can
take hundreds of photos at a holiday or
business trip destination without
recharging.
Clear View LCD
The responsive FinePix F30 is ready when you are!
•Super-fast start-up time of only 1.4 sec.
•Shooting interval of 1.5 sec.
•Shutter release time lag of minimum 0.01 sec.*
No flash means no “red eye” phenomenon. Use Natural Light mode to record your visit to a
museum or aquarium.
Flashless means no awakened babies nor bothering
others in a restaurant. Just priceless results.
FinePix F30
FinePix F30
Less camera shake blur, but still subject
movement blur. Blur from bothcamera shake and subject movement.
Natural Light
mode
PS (Picture Stabilization)
mode
With its distinctive “L-shaped” rear cover,
FinePix F30 makes a sleek and stylish
statement to express the cutting-edge
functionality and performance of a new
generation of Real Photo Technology inside.
From the elegant logo design to the simple
control layout, FinePix F30 is designed and
engineered for performance and ease of use.
“L”Form Body
0.01sec Shutter Response
Slide ShowDate-stamped album playback Post Shot Assist Window
From full AUTO for quick and easy shooting to Manual for hands-on creativity,
just turn the mode dial! Fujifilm makes it easy to take great pictures.
Versatile Shooting modes
Aperture-priority Auto
Auto
Automatic setting for easy point and shoot.
M
Manual
•White Balance ••Exposure Compensation
•Exposure Control ••AF Mode
A/S
Shutter-priority Auto
Aperture-priority Auto
“A” mode to increase/decrease depth of field.
“S” mode to freeze motion or create motion blur.
Prevent blur caused by subject movement or camera shake.
Natural Light / Natural Light & with Flash / Portrait / Landscape /
Sport / Night / Fireworks / Sunset / Snow / Beach / Underwater**/
Museum / Party / Flower Close-Up / Text
Movie
Video record/playback with monaural sound*
max. 29.3 min. at 320×240 pixels, or max. 14.9 min. at 640×480 pixels.
Other modes : Continuous, Macro, Slow Synchro
/SP
Scene
Position
Stabilization
* When using a 1GB xD-Picture Card
TM
.
**Waterproof Case WP-FXF30 is required.
A
Conventional digital camera
Conventional digital camera (ISO100, 1/100 sec., F2.8, with flash)
FinePix F30 (ISO1600, 1/100 sec., F2.8, with “Intelligent Flash”)
In low-light situations where flash is prohibited or undesirable,
you can still take beautiful photos with the "Natural Light" mode.
The latest evolutionary leap in Real Photo Technology means
that you enjoy astounding photos even when taking photos
with 6.3 million effective pixels of resolution at the highest
sensitivity of ISO 3200. With the heightened sensitivity, you
can use a high-speed shutter to prevent camera shake or freeze
subject movement, keeping blur to a minimum. Also photos
taken in dimly lit conditions capture the entire background
beautifully and naturally.
Perfect to prevent blurring due to a fast-moving subject or camera shake, this PS mode
automatically sets the optimum ISO sensitivity and shutter speed to beautifully freeze the
moment forever in sharp detail.
*After AF/AE locked
FinePix F30
-
even closer to the human eye.
The human eye sees things in motion in sharp detail. It instantly adjusts to low light and captures the entire scene. At Fujifilm, we seek to match
these capabilities in our cameras, and the new FinePix F30 has brought us even closer to this goal with two remarkable achievements: super high
sensitivity up to ISO 3200 – the first time ever offered in a compact digital camera*, and ”Intelligent Flash” – a newly developed program to
control flash output! These new features work in concert to take beautiful photos under all lighting conditions. Even photos taken in low light
capture the entire background without unnatural overexposure of the subject. Fujifilm invites you to experience the next stage of sensitivity!
Conventional
digital camera Conventional digital camera
■3xOpticalZoom
■10MBinternalmemory
■ FinePixPhotoButtonforone-touchaccesstofrequentlyusedsettings
(imagesize,ISOsensitivitysettingandFinePixColormode)
■USB2.0High-speedconnectivity
■Videooutput(NTSC/PAL)
■PictBridgecompatibility
ISO1600, 1/100sec., F2.8,with flash
– Background is captured
but subject is “washed out”
ISO1600, 1/100sec., F2.8,
with new
 Intelligent Flash 
– Both subject and background
come out bright and clear
Comparison of photos taken at ISO 1600
ISO100, 1/100sec., F2.8,with flash
– No background detail
and subject is “washed out”
Intelligent Flash
When using high sensitivity, the innovative
”Intelligent Flash” feature automatically
controls flash output to an appropriately
low setting. This smart flash control
technology recognizes scene conditions
and determines the optimum flash output
to give you superb results.
FinePix F30 Conventional digital camera Conventional digital camera
When flash is unwanted!When flash is not allowed!No “red eye”!
230,000 pixels
230,000230,000 pixelspixels
