FujiFilm X-S10 User manual

New Features Guide
Version 3.00
Features added or changed as a result of rmware updates may no
longer match the descriptions in the documentation supplied with
this product. Visit our website for information on the updates avail-
able for dierent products:
https://fujifilm-x.com/support/download/firmware/cameras/
BL00005270-200 EN

Contents
X-S10 rmware version 3.00 adds or updates the features
listed below. For the latest manuals, visit the following
website.
https://fujifilm-dsc.com/en/manual/
No. Description X-S10
P
See
PVer.
11
Touch zoom is now available with compatible lenses. A
TOUCH ZOOM option has consequently been added to
DBUTTON/DIAL SETTING> TOUCH SCREEN SETTING
in the setup menu.
24
227
1
15 2.50
22
Added support for the optional XLR microphone adapt-
er, resulting in the addition of XLR MIC ADAPTER
SETTING options under BMOVIE SETTING >
AUDIO SETTING in the photo menus and under
PAUDIO SETTING in the movie menus. A 4ch
AUDIO PLAYBACK option has also been added under
DSOUND SET-UP in the setup menus.
50
153
176
212
2
3
4
2.30
33
The camera now supports instax mini Link and instax
Link WIDE smartphone printers, resulting in changes
to the instax PRINTER PRINT item in the playback
menu. In addition, the DCONNECTION SETTING>
instax PRINTER CONNECTION SETTING item in
the setup menu has been renamed instax PRINTER
SETTING and its content has been changed.
202
236
289
290
293
5
8
34
2.10
44
An bAREA SETTING option has been added under
D USER SETTING in the setup menu, resulting in a change
to the basic setup procedure and adjustments to TIME
DIFFERENCE. In addition, DATE/TIME now offers a 24-hour
clock.
207 10 3.00
55The items listed in the setup menu under
D USER SETTING>
RESET have changed. 210 11 3.00

No. Description X-S10
P
See
PVer.
66
The D CONNECTION SETTING> Bluetooth SETTINGS
item in the setup menu has been renamed Bluetooth/
SMARTPHONE SETTING and now offers an IMAGE
TRANSFER WHILE POWER OFF option. In addition, AUTO
IMAGE TRANSFER and SMARTPHONE SYNC. SETTING
have respectively been renamed AUTO IMAGE TRANSFER
ORDER and SMARTPHONE LOCATION SYNC.
234 18 3.00
77
Upload timing has changed. Pictures can now be uploaded not
only during playback or when the camera is off but also while
shooting is in progress.
234 18 3.00
88
D CONNECTION SETTING> GENERAL SETTINGS has
been reorganized as follows:
•
LOCATION INFO has been moved to D SCREEN
SET-UP,
• rBUTTON SETTING has been moved to
D BUTTON/DIAL SETTING and renamed aISO
BUTTON SETTING,
• GEOTAGGING has been moved to D
SAVE DATA
SET-UP, and
• NAME and RESIZE IMAGE FOR SMARTPHONE
Hhave been moved to Bluetooth/
SMARTPHONE SETTING.
220
226
233
234
11
12
18
3.00
99The procedure for connecting wirelessly to smartphones has
changed. 278 30 3.00
1010
Digital zoom lenses equipped with lens function buttons
are now supported. A POWER ZOOM LENS FUNCTION
(Fn) SETTING option has consequently been added to
DBUTTON/DIAL SETTING in the setup menu. In addition,
the roles that can be assigned to the function buttons have
changed.
223
252
256
263
13
23
25
26
29
2.50
1111
A LENS ZOOM/FOCUS SETTING item has been added to
DBUTTON/DIAL SETTING in the setup menu to control
the behavior of digital zoom lenses equipped with lens func-
tion buttons.
225 13 2.50

No. Description X-S10
P
See
PVer.
1212
FOCUS RING has consequently been renamed FOCUS RING
ROTATE and has, together with FOCUS RING OPERATION,
been moved to LENS ZOOM/FOCUS SETTING.
225 13 2.50
1313 A LOCK item has been added to DBUTTON/DIAL
SETTING in the setup menu. 228 17 2.00
1414
A Bluetooth DEVICE LIST item has been added to
D CONNECTION SETTING > Bluetooth SETTINGS in
the setup menu.
234 18 2.60
1515
A NETWORK SETTING item has been added to
DCONNECTION SETTING in the setup menu, al-
lowing wireless LAN settings to be adjusted for use with
wireless tethered shooting.
235 20 2.00
1616
The DCONNECTION SETTING > INFORMATION
item in the setup menu now shows the IP address in
addition to the MAC and Bluetooth addresses.
239 20 2.00
1717
The DCONNECTION SETTING > CONNECTION
MODE item has been modified to support not only
photo upload, RAW conversion, and the upload and
download of camera settings, but also such features as
tethered still photography and movie recording.
237 21 2.00
1818 The TG-BT1 tripod grip has been added to the optional
accessory list. 292 34 2.60

1
Changes and Additions
Changes and additions are as follows.
X-S10 Owner’s Manual: P24 Ver. 2.50
Shooting Touch Controls
Touch Zoom
If the lens supports touch zoom, you can
zoom in and out by touching the display.
Tap the touch zoom button in the display
to enable touch zoom.
Touch zoom is controlled using the but-
tons in the display.
ButtonButton DescriptionDescription
Touch zoomTouch zoom Enable touch zoom.
Zoom inZoom in Zoom in or out.Touch and hold to zoom in or out at a constant
speed.
Zoom outZoom out
Rocker switchRocker switch Swipe to choose a zoom position. Touch and hold to zoom in
or out at a speed corresponding where you put your finger.
DisableDisable Disable touch zoom.

2
X-S10 Owner’s Manual: P50 Ver. 2.30
Recording Movies
Using an External Microphone
Sound can be recorded with external micro-
phones that connect using jacks 3.5mm in di-
ameter; microphones that require plug-in pow-
er cannot be used. See the microphone manual
for details.
XLR Microphone Adapters
The camera can be used with TEAC TASCAM CA-XLR2d-F XLR microphone
adapters. For more information, visit the TASCAM website.
https://tascam.jp/int/product/ca-xlr2d/#CA-XLR2d_Website

3
X-S10 Owner’s Manual: P153, 176 Ver. 2.30
XLR MIC ADAPTER SETTING
Adjust microphone input channel settings and the like for use
with XLR microphone adapters.
OptionOption DescriptionDescription
MIC INPUT CHANNEL
Record four-channel (quadraphonic) sound with the
help of the camera’s built-in microphone, or two-channel
(stereo) sound using only a microphone connected via the
XLR microphone adapter.
• 4ch XLR+CAMERA: Record four-channel sound with
the help of the camera’s built-in microphone.
•
2ch XLR ONLY: Record two-channel sound using
only an external microphone connected via the XLR
microphone adapter.
4ch AUDIO MONITORING
Choose the source of sound output to headphones or
other audio monitors during movie recording.
• XLR: Monitor sound from external microphones con-
nected via the XLR microphone adapter.
•
CAMERA: Monitor sound from camera’s built-in mi-
crophone.
HDMI 4ch AUDIO
OUTPUT
Choose source of audio output to the HDMI connector.
• XLR: Audio from external microphones connected via
the XLR microphone adapter is output to the HDMI con-
nector.
•
CAMERA: Audio from camera’s built-in microphone is
output to the HDMI connector.
N
• If an external microphone is connected to the camera’s microphone
jack, audio will be recorded not via the camera’s built-in microphone
but via the external microphone instead.
• Four-channel recording is available only when MOV/H.264 LPCM is
selected for BMOVIE SETTING> FILE FORMAT.

4
X-S10 Owner’s Manual: P212 Ver. 2.30
4ch AUDIO PLAYBACK
Adjust audio settings for use when viewing 4ch movies.
OptionOption DescriptionDescription
XLR
The camera plays audio recorded via external micro-
phones connected via the XLR microphone adapter.
CAMERA
The camera plays audio recorded via the camera’s built-in
microphone or external microphones connected via the
microphone jack.

5
X-S10 Owner’s Manual: P202, 290 Ver. 2.10
instax PRINTER PRINT
Printing Pictures
Pictures can be printed using optional printers in the instax
Link and instax SHARE series. The printer must rst paired with
the camera using DCONNECTION SETTING > instax PRINTER
SETTING.
instax Link Series Printers
1 Turn the printer on.
2 Select instax PRINTER PRINT in
the playback menu, then highlight
instax Bluetooth CONNECTION and
press MENU/OK.
PRINTER PRINT
Wi-Fi CONNECTION
Bluetooth CONNECTION
EXIT
3 The camera will connect to the printer.
FUJIFILM-CAMERA-1234
CONNECTING
CANCEL
PRINTER PRINT
instax-12345678

6
4 Use the focus stick (focus lever) to
display the picture you want to print,
then press MENU/OK.
100-0020
SET CANCEL
instax-12345678
PRINTER PRINT
N
• Pictures taken with other cameras cannot be printed.
•
Pictures are cropped and printed at a size selected automatical-
ly by the printer, and consequently not all the picture appears
in the printed copy.
•
When using instax WIDE lm, you can choose the crop be-
fore printing pictures shot with an option other than O3:2,
P3:2, or Q3:2 selected for HIMAGE QUALITY SETTING>
IMAGE SIZE.
•
The displays may vary depending on the printer connected.
5 The picture will be sent to the printer and printing will start.
O
The camera cannot connect to a smartphone while connected to a
printer.
instax Image Quality Mode
In addition to the existing “instax-Natural Mode”, the instax IMAGE
QUALITY MODE item in the instax PRINTER SETTING menu oers an
“instax-Rich Mode” featuring vibrant colors for use with instax Link WIDE
printers.
N
These options are also available when the camera is connected to
the printer.

7
instax SHARE Series Printers
1 Turn the printer on.
2 Select instax PRINTER PRINT in
the playback menu, then highlight
instax Wi-Fi CONNECTION and press
MENU/OK.
PRINTER PRINT
Wi-Fi CONNECTION
Bluetooth CONNECTION
EXIT
3 The camera will connect to the printer.
FUJIFILM-CAMERA-1234
CONNECTING
CANCEL
PRINTER PRINT
instax-12345678
4 Use the focus stick (focus lever) to
display the picture you want to print,
then press MENU/OK.
100-0020
SET CANCEL
instax-12345678
PRINTER PRINT
N
• Pictures taken with other cameras cannot be printed.
•
Pictures are cropped and printed at a size selected automatical-
ly by the printer, and consequently not all the picture appears
in the printed copy.
•
When using instax SQUARE lm, you can choose the crop be-
fore printing pictures shot with an option other than O1:1,
P1:1, or Q1:1 selected for HIMAGE QUALITY SETTING>
IMAGE SIZE.
•
The displays may vary depending on the printer connected.
5 The picture will be sent to the printer and printing will start.

8
X-S10 Owner’s Manual: P236, 289 Ver. 2.10
instax PRINTER SETTING
Establishing a Connection
Adjust settings for connection to optional Fujilm printers in the
instax Link and instax SHARE series.
instax Link Series Printers
1 Select
D CONNECT SETTING> instax
PRINTER SETTING> instax PRINTER
CONNECTION SETTING, then high-
light instax Bluetooth CONNECTION
and press MENU/OK.
PRINTER CONNECTION SETTING
Wi-Fi CONNECTION
Bluetooth CONNECTION
N
Before connecting to an instax mini Link printer, conrm that
printer rmware is version “0104” or later. You can view the rm-
ware version and update the printer rmware from the instax mini
Link app. For more information, see “Q. I want to update to the
latest rmware.” at the link below.
https://instax.com/mini_link/en/support/faq/
2 Highlight PAIRING REGISTRATION,
press MENU/OK, and then turn on the
printer to initiate pairing.
Bluetooth CONNECTION
PAIRING REGISTRATION
DELETE PAIRING REG.
PAIRING INFORMATION
N
• To delete pairing data for printers with which the camera is cur-
rently paired, select DELETE PAIRING REG..
•
To view data for printers with which the camera is currently
paired, select PAIRING INFORMATION.

9
3 To complete the pairing process, press MENU/OK in the pairing
display.
instax SHARE Series Printers
Select
D CONNECTION SETTING> instax
PRINTER SETTING > instax PRINTER
CONNECTION SETTING, then highlight
instax Wi-Fi CONNECTION, press MENU/OK,
and enter the printer SSID and password.
PRINTER CONNECTION SETTING
Wi-Fi CONNECTION
Bluetooth CONNECTION
The Printer Name (SSID) and Password
The printer name (SSID) can be found on the
bottom of the printer; the default password is
“1111”. If you have already chosen a dierent
password to print from a smartphone, enter
that password instead.

10
X-S10 Owner’s Manual: P207 Ver. 3.00
bAREA SETTING
Adjust settings for your current time zone.
AREA SETTING
Choose your time zone from a map.
DAYLIGHT SAVINGS
Turn daylight saving time on or o.
OptionOption DescriptionDescription
ON Daylight saving time on.
OFF Daylight saving time off.
X-S10 Owner’s Manual: P207 Ver. 3.00
TIME DIFFERENCE
Switch the camera clock instantly from your home time zone to
the local time at your destination when traveling. To specify the
dierence between your local and home time zone:
O
Use bAREA SETTING to choose your home time zone before select-
ing a local time zone using gLOCAL.
1 Highlight gLOCAL and press MENU/OK.
2 Use the focus stick (focus lever) to choose the local time
zone. Press MENU/OK when settings are complete.
N
Select ON to enable daylight saving time.
To set the camera clock to local time, highlight gLOCAL and
press MENU/OK. To set the clock to the time in your home time
zone, select hHOME.
OptionsOptions
gLOCAL hHOME
N
If gLOCAL is selected, gwill be displayed in yellow for about three
seconds when the camera is turned on.

11
X-S10 Owner’s Manual: P210 Ver. 3.00
RESET
Reset shooting or setup menu options to default values.
1 Highlight the desired option and press MENU/OK.
OptionOption DescriptionDescription
STILL MENU RESET
Reset all photo menu settings other than custom white
balance and custom settings banks created using EDIT/
SAVE CUSTOM SETTING to default values.
MOVIE MENU RESET Reset all settings other than custom white balance op-
tions selected using FWHITE BALANCE.
SET-UP RESET
Reset all setup menu settings other than DATE/TIME,
bAREA SETTING, TIME DIFFERENCE, and
COPYRIGHT INFO to default values.
INITIALIZE Reset all settings other than custom white balance to
default values.
2 A conrmation dialog will be displayed; highlight OK and
press MENU/OK.
X-S10 Owner’s Manual: P220 Ver. 3.00
LOCATION INFO
Select ON to display location info downloaded from a smart-
phone.
OptionsOptions
ON OFF

12
X-S10 Owner’s Manual: P226 Ver. 3.00
aISO BUTTON SETTING
Choose the role performed by the ISO button during playback.
OptionOption DescriptionDescription
aSMARTPHONE
TRANSFER ORDER
Pressing the button marks the current picture for transfer. If the
camera is not currently paired with a smartphone, Bluetooth/
SMARTPHONE SETTING options will be displayed.
dSELECT &
SMARTPHONE
TRANSFER ORDER
Pressing the button displays a dialog where pictures can be
selected for upload to a smartphone with which the camera is
paired. If the camera is not currently paired with a smartphone,
Bluetooth/SMARTPHONE SETTING options will be dis-
played instead.
rWIRELESS
COMMUNICATION The button can be used for wireless connections.
X-S10 Owner’s Manual: P233 Ver. 3.00
GEOTAGGING
If ON is selected, location data downloaded from a smartphone
will be embedded in pictures as they are taken.
OptionsOptions
ON OFF

13
X-S10 Owner’s Manual: P223 Ver. 2.50
POWER ZOOM LENS FUNCTION (Fn) SETTING
Choose the roles played by the function buttons available on
some power zoom lenses.
X-S10 Owner’s Manual: P225 Ver. 2.50
LENS ZOOM/FOCUS SETTING
Adjust settings for compatible lenses with focus rings or power zoom.
FOCUS RING ROTATE
Choose the direction in which the focus ring is rotated to in-
crease the focus distance.
OptionsOptions
XCW (clockwise) YCCW (counterclockwise)
FOCUS RING OPERATION
Choose how the camera adjusts focus in response to the move-
ment of the focus ring.
OptionOption DescriptionDescription
NONLINEAR Focus is adjusted at the same rate as the ring is rotated.
LINEAR
Focus is adjusted linearly according to the amount the ring is rotated,
but the focusing speed is unaffected by the speed the ring is rotated.
F CONSTANT SPEED FOCUS (Fn)
Choose the rate at which the focus distance changes when adjust-
ed using function buttons during manual focus with compatible
power zoom lenses. The higher the number, the higher the rate.
OptionsOptions
1(SLOW) 2 3 4 5 6 7 8(FAST)

14
CONSTANT SPEED ZOOM (Fn)
Choose the rate at which compatible power zoom lenses can be
zoomed in or out using function buttons. The higher the number, the
higher the rate.
OptionsOptions
1(SLOW) 2 3 4 5 6 7 8(FAST)
CONSTANT SPEED ZOOM/FOCUS (Fn) OPERATION
Choose whether the function buttons on compatible power
zoom lenses need only be pressed once to start and stop power
focus or power zoom.
OptionOption DescriptionDescription
START/STOP
SWITCH
The operation starts when the button is pressed and stops when
it is pressed a second time.
ACTIVE WHILE
PRESSING
The operation continues while the button is pressed and stops
when the button is released.
ZOOM RING ROTATE
Choose whether to reverse the rotation of the zoom ring on com-
patible power zoom lenses.
OptionsOptions
XCW (clockwise) YCCW (counterclockwise)
ZOOM/FOCUS CONTROL RING
Choose role played by the zoom/focus control ring on compati-
ble power zoom lenses.
OptionsOptions
ZOOM FOCUS

15
X-S10 Owner’s Manual: P227 Ver. 2.50
TOUCH SCREEN SETTING
Enable or disable touch-screen controls.
xTOUCH SCREEN SETTING
OptionOption DescriptionDescription
ON The LCD monitor functions as a touch screen during shooting.
OFF Touch controls disabled.
xDOUBLE TAP SETTING
OptionOption DescriptionDescription
ON Tap the LCD monitor twice to zoom in on your subject during
shooting.
OFF Touch zoom disabled.
cTOUCH FUNCTION
OptionOption DescriptionDescription
ON Enable touch-function gestures.
OFF Disable touch-function gestures.
TOUCH ZOOM
OptionOption DescriptionDescription
ON If the lens supports touch zoom, you can zoom in and out by
touching the LCD monitor.
OFF Touch zoom disabled.
aTOUCH SCREEN SETTING
OptionOption DescriptionDescription
ON The LCD monitor functions as a touch screen during playback.
OFF Touch controls disabled.

16
EVF TOUCH SCREEN AREA SETTINGS
Select the area of the LCD monitor used for touch controls while
the viewnder is active. The area used for touch controls can be
selected from:
OptionOption DescriptionDescription
6All.
0Right half.
2Top right quarter.
4Bottom right quarter.
1Left half.
3Top left quarter.
5Bottom left quarter.
OFF Touch controls disabled.
