Fujitsu Stylistic 3400 User manual

Stylistic 3400 is a trademark of Fujitsu PC Corporation © 2000 Fujitsu PC Corp.
2/00 Page 1 of 1 58-0713-00A
FMWAC6A ●FMWAC6B ●FMWAC6C
AC Adapter
Operating Instructions
These instructions provide details on using the
Fujitsu FMWAC6A (US), FMWAC6B (UK), and
FMWAC6C (Euro) AC adapters.
Note: The only difference between the three AC adapter
models is a variation in the supplied AC power
cords. These operating instructions are applicable
to all three adapter models.
The AC adapter is designed for use with your
Stylistic 3400 pen tablet. Note that the AC adapter
can also be used with external battery chargers,
docking stations, port replicators, and cradles
designed for use with the system.
0
AC Adapter Features
0
Caution
• This AC adapter is for indoor use only. Do not
use where exposure to water or excessive
moisture is possible.
• This AC adapter generates a magnetic field
that can damage your floppy disk drive.
Maintain a safe minimum distance (about 3
inches or 8 centimeters) between the AC
adapter and your floppy disk drive.
AC Adapter Module
AC Power Cord
DC Power Cord (to system) (to AC outlet)
Connecting the AC Adapter 0
To connect the AC adapter to your system:
1. Plug the DC power cord into the DC input
connector on your pen tablet, port replicator,
docking station, or cradle.
2. Plug the AC power cord into the AC adapter.
3. Plug the other end of the AC power cord into
your AC wall outlet.
4. Confirm that the AC adapter is now supplying
power to your pen tablet system or other device.
Refer to the user documentation for your system,
if necessary, to determine how your pen tablet
indicates external power is connected.
You can now use your system with external power
supplied by the AC adapter.
Disconnecting the AC Adapter 0
To disconnect the AC adapter:
1. Disconnect the DC output cord from your pen
tablet system or other device.
2. Unplug the AC adapter from your AC wall
outlet.
Troubleshooting 0
If the AC adapter is not supplying power to your
pen tablet system, check the following:
• Ensure that power is supplied to your AC wall
outlet.
• Ensure that the AC power cord is firmly plugged
into the AC adapter and the AC wall outlet.
• Ensure that the DC Power Cord is firmly seated in
the DC input connector.
Specifications 0
Specifications for the AC adapter are shown in the
following table.
AC Adapter Specifications
Input 100-240 VAC
50-60 Hz
1.2 A max
Output 16 VDC, 3.36 A max
DC output plug polarity Center: positive (+)
Sleeve: negative (-)
