Fujitsu UTY-TFSXZ1 Service manual

OPTIONAL PART
Wireless LAN adapter
DESIGN & TECHNICAL MANUAL
WIRELESS LAN
ADAPTER
UTY-TFSXZ1
UTY-TFSXZ2
UTY-TFSXZ4
DR_OP003EX_06
2019.03.28

Notices:
• Product specifications and design are subject to change without notice for future improvement.
• For further details, please check with our authorized dealer.
Trademarks
The following term and logo are trademarks of Fujitsu General Limited in the United States, other countries
or both:
FGLair™
Android and Google Play are trademarks of Google Inc.
App Store is a service mark of Apple Inc., registered in the U.S. and other countries.
IOS is a trademark or registered trademark of Cisco in the U.S. and other countries and is used under
license.
Copyright © 2017, 2019 Fujitsu General Limited. All rights reserved.

CONTENTS
WIRELESS LAN ADAPTER..................................................................1
1. Model lineup ..................................................................................................2
1-1. Applicable indoor units.....................................................................................................2
2. Overview ........................................................................................................3
2-1. Wireless LAN control .......................................................................................................4
3. Specifications................................................................................................6
3-1. Wireless LAN adapter ......................................................................................................6
4. Wiring design ................................................................................................7
4-1. System diagram...............................................................................................................7
5. Installation .....................................................................................................9
5-1. Precautions......................................................................................................................9
5-2. Installation procedure.....................................................................................................10
6. Initial setup ..................................................................................................11
6-1. Mobile app installation and user registration ..................................................................11
6-2. Air conditioner registration .............................................................................................11
7. Accessories.................................................................................................12

WIRELESS LAN ADAPTER
MODEL NAME:
UTY-TFSXZ1
UTY-TFSXZ2
UTY-TFSXZ4
