AMILO PI 3560
An elegant home cinema
DATASHEET
Issue: December 2009
The Notebook AMILO Pi 3560 combines an exciting external design with excellent inner qualities. The
high-performance NVIDIA®GeForce®GT 240M graphics card with real-life image quality, whether you
are enjoying your favourite game or watching your favourite series in HD quality with friends - that’s no
problem thanks to the optional Blu-ray drive. The BrilliantView display in 16:9 format provides fantastically
clear images and brilliant colours. Entertainment whenever and wherever you want.
PROCESSOR TECHNOLOGY
Intel®mobile processor technology with Intel®Core™2 Duo processor
RELIABILITY AND SECURITY FOR YOUR NOTEBOOK
Spillproof keyboard to protect your notebook against accidentally spilt liquids
DISPLAY
39.6 or 40.6 cm (15.6 or 16-inch) TFT HD display with BrilliantView technology and a 16:9 widescreen
format
Energy-saving LED display technology - perfect for outdoor use
MULTIMEDIA AND COMMUNICATION
High-performance NVIDIA®GeForce®GT 240M with 1 GB dedicated VRAM and HDMI interface
Integrated 1.3 megapixel webcam and built-in digital array microphone are perfect for video
conferencing and Internet telephony (VoIP)
Surf the internet and check your e-mails when and wherever you want thanks to the integrated WLAN
Integrated Blu-ray Disc™ drive to enjoy your favorite movies in HD quality (optional)
BEST CONNECTIVITY
Integrated Bluetooth to synchronize the calendars of your notebook and mobile phone
5-in-1 card reader for easy access to pictures, movies and more
2x USB 2.0 ports for 3G/UMTS sticks or any other kind of accessories and peripherals
eSATA for superfast data transfer

HARD DISK DRIVES (INTERNAL) 640 GB, 5400 rpm, SATA, 2.5-inch, HDD cache: , S.M.A.R.T.
500 GB, 5400 rpm, SATA, 2.5-inch, HDD cache: 8 MB, S.M.A.R.T.
320 GB, 5400 rpm, SATA, 2.5-inch, HDD cache: 8 MB, S.M.A.R.T.
Hard disk notes Hard disk capacity depends on exact conguration. Please check at your local retailer.
One Gigabyte equals one billion bytes, when referring to hard disk drive capacity.
OPTICAL DRIVES
Optical drive technology Blu-ray Disc™ drive incl. SuperMulti-format DVD
burner with double layer (DL) support
SuperMulti-format DVD burner with double layer (DL)
support
Interface type SATA SATA
Optical drive read speed BD 2x, CD-ROM 24x, DVD-ROM 8x CD-ROM 24x, DVD-ROM 8x
Optical drive write speed CD-R 16x, CD-RW 10x, DVD+R 8x, DVD-R 8x,
DVD+RW 4x, DVD-RW 4x, DVD+R DL (8.5 GB) 4x,
DVD-R DL (8.5 GB) 4x, DVD-RAM 5x
CD-R 24x, CD-RW 16x, DVD+R 8x, DVD-R 8x,
DVD+RW 8x, DVD-RW 6x, DVD+R DL (8.5 GB) 6x,
DVD-R DL (8.5 GB) 6x, DVD-RAM 5x
Optical drive notes Optical disc drive depends on exact conguration. Please check at your local retailer.
DISPLAY
Base unit name AMILO Pi 3560 (40.6 cm / 16-inch) AMILO Pi 3560 (39.6 cm / 15.6-inch)
Display 40.6 cm (16-inch); LED backlight, BrilliantView TFT;
(HD); glossy display
39.6 cm (15.6-inch); LED backlight, BrilliantView TFT;
(HD); glossy display
Aspect ratio 16:9
Display Resolution type HD
Resolution (native) 1366 x 768 pixel
Response time typical 8 ms 10 ms
Brightness - typical 220 NIT
Contrast - typical 400 : 1 600 : 1
BATTERY
Battery voltage 11.1 V
Battery runtime (idle mode) Up to 3:00 hours
Battery runtime (DVD playback) Up to 2:00 hours (depending on usage)
Battery charging time (idle mode) Up to 1:30 hours
Battery charging time (maximum
active mode)
Up to 2:00 hours (depending on usage)
Battery charging time (off mode) Up to 1:30 hour
COMPONENTS
PROCESSOR Intel®Pentium®processor T4400 (2.2 GHz, 1 MB, 800 MHz)
Intel®Pentium®processor T4300 (2.1 GHz, 1 MB, 800 MHz)
Intel®Core™2 Duo processor T6600 (2.2 GHz, 2 MB, 800 MHz)
Intel®Core™2 Duo processor P7450 (2.13 GHz, 3 MB, 1066 MHz)
Processor notes Processor depends on exact conguration. Please check at your local retailer.
MEMORY OPTIONS
3 GB (2 module(s) with 1 GB and 2 GB, DDR2), 800 MHz
4 GB (2 module(s) with 2 GB, DDR2), 800 MHz
6 GB (2 module(s) with 2 and 4 GB, DDR2), 800 MHz
8 GB (2 module(s) with 4 GB, DDR2), 800 MHz
Supported capacity RAM (min.) 3 GB
Supported capacity RAM (max.) 8 GB
Memory slots total 2
Memory slot type SO DIMM (DDR2, 800 MHz)
Memory notes Memory size depends on exact conguration. Please check at your local retailer.

Battery notes Battery life may vary depending on product model, conguration, applications, power management settings and
features utilized. Battery recharge time varies depending on usage. The recharge capacity may decrease after
some months so that the battery lifetime as well as operating time can not be assured for the whole lifetime of
the notebook.
Battery runtime tested with MobileMark 2007 at 50% LCD brightness.
AMILO PI 3560
OPERATING SYSTEM
Operating system compatible Genuine Microsoft®Windows®7 Home Premium 64-bit
Genuine Microsoft®Windows Vista®Home Premium 64-bit
Recovery application Recovery media is inlcuded. Drivers and Utility on CD or DVD is included optionally.
Drivers Updates are downloadable at http://ts.fujitsu.com/support
PRODUCT DESIGN
Color Glossy black cover and silver palmrest with design pattern
GENERAL SYSTEM INFORMATION
System architecture Intel®Mobile Processor Technology
Chipset Intel®PM45, ICH 9-M
GRAPHICS
Graphics brand name NVIDIA®GeForce®GT 240M
Dedicated video memory 1 GB (DDR3 VRAM, 800 MHz)
Shared video memory up to 4606 MB
3D Benchmark points Up to 6300 (3D Mark 2006, depending on conguration); up to 2550 (3D Vantage)
Max. resolution external display 1080p (HDMI); 2048 x 1536 pixels (QXGA) for a 4:3 display (VGA)
Graphics features NVIDIA® PhysX™ delivers the most advanced gaming physics, to dene a totally new level of dynamic motion
and interaction
NVIDIA®Cuda™ technology lets your graphics card take over complex computations so that you obtain extreme
performance boost for high-res 3D applications within a fraction of the time required on a CPU
NVIDIA®PureVideo®HD technology
- Ultra-smooth video playback
- Superb picture clarity and
- Precise, vivid colors on any display
DirectX®10.1 support - for stunning 3D graphics and shading effects
Graphics notes Shared video memory size may vary depending on conguration and the version of the operating system. The
video memory size that is displayed in the system information software, as well as the actually used video
memory size depends on Microsoft®Windows Vista®memory management. The following values might serve as
orientation.
- 3072 MB system memory enables up to 2301 MB static and shared memory
- 4096 MB system memory enables up to 2798 MB static and shared memory
- 6144 MB system memory enables up to 3822 MB static and shared memory
- 8192 MB system memory enables up to 4606 MB static and shared memory
INTERFACES
DC-in 1
Audio: line-in 1
Audio: line-out / headphones / SPDIF 1
Audio: microphone 1
Internal microphones 2
USB 2.0 total 2
eSATA & USB combo 1
VGA 1
HDMI 1 (version 1.3a, incl. HDCP support)
Ethernet (RJ-45) 1
Memory card slots 1x 5-in-1 (supported formats: SD, MS, MS PRO, MMC, XD picture card with SDHC support)
Express card slots 1 (34 / 54 mm)
Kensington Lock support 1
COMMUNICATION
Bluetooth Integrated v2.1 + EDR (Enhanced Data Rate)
LAN type Gigabit Ethernet (10/100/1000 Mbit/s)
WLAN Built-in WLAN (Wireless Local Area Network)

WLAN (OPTIONAL)
WLAN name pre-n WLAN (IEEE 802.11b/g/pre-n)
WLAN max. data rate up to 300 Mbit/s
WLAN encryption WEP, WPA, WPA2
WLAN notes For use in: BE, CH, DK, DE, EE, FI, FR, EL, IE, IS, IT, LI, LV, LT, LU, MT, NL, NO, PL, AT, PT, SE, SK, ES, CZ, HU, UK,
CY
AUDIO
Audio type On board
Audio codec Realtek ALC272
Audio features Support of high-denition audio for S/PDIF output with up to 5.1 channels
2x built-in stereo speakers (1 W each)
Built-in digital array microphone
Sound volume control via function key (down: Fn+F4; up: Fn+F5)
CAMERA
Camera 1.3 megapixel webcam
Frame rate 30 per second (depending on the resolution)
Camera features Automatic brightness adjustment with status LED (blue: on, red: streaming / application on)
Camera notes Webcam frame rate can vary signicantly depending on the used software application.
INPUT DEVICES / CONTROL BUTTONS
Power Button Located left of the keyboard, back-lighted
Keyboard Spill-resistant keyboard
Number of keyboard keys 85
Keyboard notes In the event of an accidental spill, Fujitsu recommends that users keep the system power off and consult Fujitsu
Service & Support or an Authorized Service Provider.
Input device(s) Hidden touchpad, with left and right mouse button, touchpad disable function via function key combination
(Fn+F6)
HOT KEYS
Hot key Fn+F1 WLAN / Bluetooth on / off
Hot key Fn+F3 Mute on / off
Hot key Fn+F4 Volume down
Hot key Fn+F5 Volume up
Hot key Fn+F6 Touchpad on / off
Hot key Fn+F7 Camera on / off
Hot key Fn+F8 Brightness down
Hot key Fn+F9 Brightness up
Hot key Fn+F10 Display switch
Hot key Fn+F11 Silent mode
Hot key Fn+F12 Suspend
STATUS INDICATORS
Status indicators The notebook has 3 status LEDs
Power status (& suspend)
Blue (always on): on
Blue blinking: stand by
None: off
Battery status
Blue (always on): full
Blue blinking: charging
Red constant: < 20 % capacity
Red blinking: < 10 % capacity
WLAN / Bluetooth
Blue: on
None: off
POWER SUPPLY
AC adapter 20 V / 90 W (4.5 A)
Rated voltage range 100 - 240 V (AC Input)
Rated frequency range 50 - 60 Hz

POWER SUPPLY
Battery features ACPI 3.0 supported
ENERGY CONSUMPTION
S0 (idle mode) Up to 18 W
S0 (max. active mode) Up to 90 W
S3 (stand by / energy saving mode) Up to 1.3 W
S4 (hibernate) Up to 0.8 W
S5 (off mode) Up to 0.8 W
ACPI functions ACPI 3.0 compliant for Vista requirement
Power on stand by (S1 LCD off)
Stand by / energy saving mode (S3 save to RAM)
Hibernate mode (S4 save to disk)
Off mode (S5 soft off)
Energy consumption notes Energy consumption of AMILO Pi 3560 is EuP compliant.
NOISE EMISSION
Idle mode 28 dB(A) (silent mode off)
Maximum active mode 35 dB(A) (silent mode off, no ODD activity)
Noise emission Tested according to ISO 7779 and ISO 9296
DIMENSIONS / WEIGHT / ENVIRONMENTAL
Dimensions (W x D x H) 380 x 245 x 24.8 - 37.4 mm
Weight Approx. 2.75 kg (with 6-cell battery and HDD)
Weight notes Actual weight may vary depending on conguration
Operating ambient temperature 5 - 35°C
Operating relative humidity 10 - 90 % (relative humidity, non-condensing)
COMPLIANCE
Europe CE Marking
R&TTE (WLAN, Bluetooth®)
Global RoHS (Restriction of hazardous substances)
ISO9241-307 (Pixel fault class II)
Russia GOST
Compliance link https://sp.ts.fujitsu.com/sites/certicates/default.aspx
APPLICATION SOFTWARE
Ofce software Microsoft® Ofce Ready (60-day trial version for Microsoft® Ofce Professional software package, only with
Windows®7 operating system)
Adobe Acrobat Reader
Windows Mail (only within Windows Vista®operating system)
Windows Calendar (only within Windows Vista®operating system)
Multimedia software Nero Essentials S (burning software)
Vista DVD Playback Pack (DVD playback software, only within Windows Vista®operating system)
Windows Media Player (playback of music CDs and Video DVDs)
Windows Media Center edition
- Share and stream media easily in your home network
- Organize media (videos, music, pictures)
- Watch and record TV shows
(For certain aspects of Windows Media Center functionality, a TV tuner and
additional hardware may be required. To watch Internet TV, Internet access is
required. Free Internet TV content varies by geography.
Some content may require additional fees.)
CyberLink YouCam
Internet software Microsoft®Internet Explorer
Country specic Internet provider
Security software Symantec Norton Internet Security (90-day trial version)
Additional software (optional) CyberLink PowerDVD BD (playback software for Blu-ray Disc™, only with Blu-ray Disc™ drive)
SECURITY
Physical security Kensington Lock support
Lid switch (hidden)
User security User and supervisor password

WARRANTY
Standard Warranty 1 year / 2 years (depending on country)
Service level Collect & Return Service / Bring in (depending on county specic requirements)
MAINTENANCE AND SUPPORT SERVICES - THE PERFECT EXTENSION
Recommended Service 3 years, Collect & Return Service
Spare Parts availability 3 years
Service Weblink http://ts.fujitsu.com/Supportservice
ACCESSORIES
Accessories included Manuals (manual on hard disk, quick start guide, safety guide, warranty guide, recovery guide)
AC adapter 90 W
First Battery 6 cells
Accessories link http://ts.fujitsu.com/accessories
Information about environmental care, policies, programs and our Environmental Guideline FSC 03230:
http://ts.fujitsu.com/aboutus
Take back and Recycling information:
http://ts.fujitsu.com/recycling
All rights reserved, including intellectual property rights. Changes to technical data reserved.
Delivery subject to availability. Any liability that the data and illustrations are complete, actual or
correct is excluded.
Designations may be trademarks and/or copyrights of the respective manufacturer, the use of
which by third parties for their own purposes may infringe the rights of such owner.
For further information see http://ts.fujitsu.com/terms_of_use.html
Copyright © Fujitsu Technology Solutions December 2009
Published by
Fujitsu Technology Solutions
http://ts.fujitsu.com
