Fujitsu FPCM11752 User manual

System
Operating manual
LIFEBOOK T900

Congratulations! You have decided to buy an
innovative Fujitsu product.
The latest information about our products, useful tips, updates etc. is available
from our website: "http://ts.fujitsu.com"
For automatic driver updates, please go to: "http://support.de.ts.fujitsu.com/de/support/index.html"
Should you have any technical questions, please contact:
• our Hotline/Service Desk (see Service Desk list or visit:
"http://ts.fujitsu.com/support/servicedesk.html")
• Your sales partner
• Your sales office
We hope you really enjoy using your new Fujitsu system.

Copyright
Fujitsu Technology Solutions 2009 12/09
Published by
Fujitsu Technology Solutions
Mies-van-der-Rohe-Straße 8
80807 Munich, Germany
Contact
http://ts.fujitsu.com/support
All rights reserved, including the rights to intellectual property. We reserve the right to amend technical data; ability to deliver
depends on availability. We do not guarantee that the data and the illustrations are complete, up-to-date or accurate and
any liability therefor is excluded. Brand names can be protected trademarks of the respective manufacturer and/or are
protected by copyright. Use of these brand names by third parties for their own purposes can constitute an infringement
of the rights of the owner. You will find further information at "http://ts.fujitsu.com/terms_of_use.html"
Order No. Fujitsu Technology Solutions GmbH: A26391-K313-Z200-1-7619, edition 1

LIFEBOOK T900
Operating manual
Innovative technology 7
Ports and controls 9
Important notes 13
First-time setup of your device 17
Working with the notebook 20
Security functions 75
Connecting external devices 98
Removing and installing components
during servicing 104
Settings in BIOS Setup Utility 109
Troubleshooting and tips 111
Technical data 120
Manufacturer’s notes 123
Index 130

Microsoft, MS, Windows XP, Windows Vista and Windows 7 are registered
trademarks of the Microsoft Corporation.
Adobe Reader is a trademark of Adobe Systems Incorporated.
MultiMediaCard is a registered trademark of Infineon Technologies AG
Sony and Memory Stick are registered trademarks of Sony Electronics, Inc.
All other trademarks referenced are trademarks or registered trademarks of their
respective owners, whose protected rights are acknowledged.
Copyright © Fujitsu Technology Solutions GmbH 2009
All rights reserved, including rights of translation, reproduction by printing, copying
or similar methods, in part or in whole.
In the event of violations, perpetrators will be liable to prosecution for damages.
All rights reserved, including rights created by patent grant or registration of a utility model or design.
Subject to availability and technical modifications.

Contents
Contents
Innovativetechnology ................................................................. 7
Furtherinformation ...................................................................... 7
Notational conventions .................................................................. 8
Portsandcontrols ..................................................................... 9
Importantnotes ........................................................................ 13
Safetynotes ............................................................................ 13
Additional safety notes for devices with radio components . . . . . ............................. 14
Energy saving .......................................................................... 14
Energy saving under Windows ....................................................... 14
Travelling withyournotebook ............................................................ 15
Before youtravel ................................................................... 15
Notebook:transporting ............................................................... 15
Cleaning the notebook .................................................................. 16
First-time setup ofyourdevice ......................................................... 17
Unpacking and checking the device ...................................................... 17
Selectingalocat
ion ..................................................................... 18
Mains adapter connecting ............................................................... 18
Switchingonthedevice for the first time .................................................. 19
Workingwiththenotebook ............................................................ 20
Statusindicators ........................................................................ 20
Opening thenotebook ................................................................... 22
Switching on the notebook . . . . ........................................................... 22
ProgrammingtheON/OFFswitch ..................................................... 23
Different ways to use your notebook . . . ................................................... 24
From notebook to Tablet PC . . ....................................................... 24
Select display orientation(portraitorlandscapeorientation) ............................. 27
FromTabletPCto notebook .......................................................... 28
Switching off the notebook . . . . ........................................................... 30
Closing the notebook . . .................................................................. 31
Language selection (Windows XP only) ................................................... 31
Selecting the language for menu texts . . . . ............................................ 31
Selecting the language for handwriting recognition and keyboard . . . ..................... 32
Handwriting recognition under Windows Vista . ........................................ 32
Handwriting recognition under Windows 7 . ............................................ 32
LCD screen ............................................................................ 33
Ambient lightsensor ................................................................. 33
UsingadeviceasatabletPC ............................................................ 34
Using fingers ....................................................................... 34
Usingthestylus pen ................................................................. 36
Usingthedeviceasanotebook .......................................................... 40
Touchpadandtouchpadbuttons ...................................................... 40
Keyboard ............................................................................... 42
Virtualnumerickeypad .............................................................. 44
Country and keyboard settings ....................................................... 44
Keycombinations ................................................................... 45
Tablet buttons .......................................................................... 47
Keycombinations ................................................................... 51
Programmingthetabletbuttons ...................................................... 52
Fujitsu Technology Solutions 3

Contents
Webcam ............................................................................... 52
Rechargeable battery . . . ................................................................ 53
Charging,caring forandmaintaining the battery ....................................... 53
Removing andinstallingthe battery ................................................... 54
Batteries with a capacity of 5800 mAh . . . ............................................. 56
Module ................................................................................. 57
Removing a module . ................................................................ 57
Installing a module . . ................................................................ 58
Opticaldrive ............................................................................ 58
Handling data carriers . . . ............................................................ 58
CD/DVDindicator ................................................................... 59
Insertingorremoving adatacarrier ................................................... 59
Manual removal (emergency removal) . . . ............................................. 60
Removing andreplacing thecasingcover(ventilationslotcover) togetridofdust ............ 61
Using the power-management features . . ................................................. 62
Memorycards .......................................................................... 63
Supportedformats .................................................................. 63
Insertingthememorycard ........................................................... 63
Removing thememorycard .......................................................... 64
ExpressCards .......................................................................... 65
Insertingthecard ................................................................... 65
Removing thecard .................................................................. 66
Loudspeakers and microphones . . ........................................................ 66
SIMcard ............................................................................... 67
InsertingtheSIM card ............................................................... 67
Removing aSIM card ............................................................... 68
Optional wireless components Wireless LAN / BlueTooth / UMTS . .......................... 69
Switching the wireless components on and off ......................................... 69
SettingupWLANaccess ............................................................ 70
AccessviaUMTS ................................................................... 70
Ethernetand LAN ....................................................................... 70
Portreplicator .......................................................................... 71
Settinguptheportreplicator ......................................................... 71
Connect the notebook to the port replicator . . . ......................................... 72
Switching on the notebook via the port replicator . . . . . .................................. 73
SwitchingoffnotebookviaPortReplicator ............................................. 73
Disconnecting the notebook from the port replicator . . .................................. 74
Securityfunctions ..................................................................... 75
Briefoverviewofsecurityfunctions ....................................................... 76
Configuring the fingerprint sensor ........................................................ 77
UseKensingtonLock .................................................................... 77
ConfiguringpasswordprotectioninBIOSSetupUtility ...................................... 78
Protecting BIOS Setup Utility (supervisor and user password) . .......................... 78
Password protection for booting of the operating system . .............................. 79
Passwordprotectionforthehard disk ................................................. 80
SmartCard reader ....................................................................... 81
InsertingtheSmartCard ............................................................. 81
SmartCard as software protection (SmartCase™Logon+) .............................. 82
SmartCardSystemLock(optional) ........................................................ 83
AccessrightsofSmartCards ......................................................... 84
SmartCard user groups . . ............................................................ 85
Installing SystemLock ............................................................... 86
4 Fujitsu Technology Solutions

Contents
Setting up the first system in a user group or a stand-alone system for use with SystemLock
..................................................................................... 86
Addingasystemto auser group ..................................................... 89
Carryingoutadministratorfunctions ................................................... 91
Remote Access Enabling – F4 ...................................................... 93
Switch onthedeviceusing SystemLock ............................................... 94
Start BIOS Setup F2 ............................................................... 94
Changing PIN . ...................................................................... 94
UninstallSystemLock ................................................................ 94
Errormessages ..................................................................... 95
Usingthesecurityfunctionofthetabletkeys .............................................. 95
Setting the Supervisor password . . ................................................... 95
SettingtheUser password ........................................................... 95
Enteringpasswordsusingthetablet buttons ........................................... 96
Trusted Platform Module (TPM) (device-dependent) . . . .................................... 96
Enabling TPM . ...................................................................... 97
DisablingTPM ...................................................................... 97
Connectingexternaldevices ........................................................... 98
Connecting an external monitor . . . ....................................................... 99
HDMI port .............................................................................. 100
Connecting USB devices . . . . . ........................................................... 101
Howto remove USBdevicescorrectly ................................................ 101
Connecting FireWire devices . . ........................................................... 102
Connecting external audio devices ....................................................... 102
Microphone port / Line In . ........................................................... 102
Headphone port . . . .................................................................. 103
Removing and installing components during servicing . . . . ............................. 104
Noteson installingandremovingboardsandcomponents .................................. 104
Preparing to remove components . ....................................................... 105
Installing and removing memory expansion . . . . ............................................ 106
Removing acover ................................................................... 106
Removing memorymodules .......................................................... 107
Installing amemorymodule .......................................................... 107
Attachingthecover .................................................................. 108
Finishing component removal . ........................................................... 108
Settings in BIOS Setup Utility . . . ....................................................... 109
StartingtheBIOS SetupUtility ........................................................... 109
OperatingBIOS SetupUtility ............................................................. 109
Exiting BIOS Setup Utility ................................................................ 110
Exit Saving Changes - save changes and exit BIOS Setup Utility . . ..................... 110
Exit Discarding Changes – Discard changes and exit BIOS Setup Utility . . . .............. 110
Load Setup Defaults – Copy Standard Entries . ........................................ 110
Discard Changes – Discard changes without exiting the BIOS Setup Utility . .............. 110
Save Changes - save changes without exiting the BIOS Setup Utility . . . . . . .............. 110
Save Changes and Power Off ....................................................... 110
Troubleshootingandtips .............................................................. 111
Helpifproblemsoccur ................................................................... 112
The notebook’s date or time is incorrect ................................................... 112
Battery indicator does not illuminate . . . ................................................... 112
When certaincharactersare enteredonthekeyboard,only numeralsarewritten ............. 113
Fujitsu Technology Solutions 5

Contents
The notebook’sLCDscreen remainsblank ................................................ 113
The LCD screen is difficultto read ........................................................ 113
The externalmonitorremainsblank ...................................................... 113
The externalmonitorisblankortheimage isunstable ..................................... 114
The cursordoesnotcorrectlyfollowthe penmovements ................................... 114
Pen input not working . . . ................................................................ 115
The notebook cannot be started . . ........................................................ 115
The notebookstops working ............................................................. 115
The printer does not print ................................................................ 116
The radio connection to a network does not work . ......................................... 116
The batterydischargestoo quickly ........................................................ 116
SmartCard reader is not recognised. . . . . . ................................................. 117
SmartCardPIN forgotten ................................................................ 117
SmartCardlost ......................................................................... 117
User and/or supervisor SmartCard lost . . ................................................. 117
Acousticwarnings ....................................................................... 118
Error messages on the screen . . . ........................................................ 118
Technicaldata ......................................................................... 120
Notebook . . . . ........................................................................... 120
PortReplicator (optional) ................................................................ 121
Rechargeable battery . . . ................................................................ 122
Mains adapter . . . ....................................................................... 122
Manufacturer’snotes .................................................................. 123
EnergyStar ............................................................................ 123
Disposaland recycling .................................................................. 123
DeclarationsofConformity ............................................................... 123
Tested safety (TS, depending on the device) . ............................................. 123
CE marking ............................................................................ 124
Regulatory notices ...................................................................... 124
Regulatory information for notebooks without radio device .............................. 124
DOC (Industry CANADA) notices . . . . ................................................. 126
FCC Regulatory information for notebooks with radio device . . .......................... 128
Index .................................................................................. 130
6 Fujitsu Technology Solutions

Innovative technology
Innovative technology
... and ergonomic design make your device a reliable and convenient companion.
The device boots very quickly, is ready for immediate use and offers a particularly
long operating time because of its high capacity battery.
With the user-friendly "BIOS Setup Utility" you can control your notebook’s hardware and better
protect your system against unauthorised access by using the powerful password properties.
Information on the connections and user components of your notebook
canbefoundin"Ports and controls", Page 9.
Further information
The Windows drivers for your device can be found on our Internet site.
The factory installation of your device does not support any other operating
system. Fujitsu Technology Solutions accepts no liability whatsoever
if any other operating system is used.
Software oriented components of these instructions refer to Microsoft products,
if they come within the scope of the delivery.
If you install other software products, pay attention to the operating
instructions of the manufacturer.
Fujitsu Technology Solutions 7

Innovative technology
Notational conventions
Pay particular attention to text marked with this symbol. Failure to observe
these warnings could pose a risk to health, damage the device or lead
to loss of data. The warranty will be invalidated if the device becomes
defective through failure to observe these warnings.
Indicates important information for the proper use of the device.
►Indicates an activity that must be performed
Indicates a result
This font indicates data entered using the keyboard in a program dialogue or at
the command line, e.g. your password (Name123) or a command used to
start a program (start.exe)
This font indicates information that is displayed on the screen by a program, e.g.:
Installation is complete.
This font indicates
• terms and texts used in a software interface, e.g.: Click on Save
• names of programs or files, e.g. Windows or setup.exe.
"This font" indicates
• cross-references to another section, e.g. "Safety information"
• cross-references to an external source, e.g. a web address: For more
information, go to "http://ts.fujitsu.com"
• Names of CDs, DVDs and titles or designations of other materials, e.g.:
"CD/DVD Drivers & Utilities" or "Safety" Manual
Key indicates a key on the keyboard, e.g: F10
This font indicates terms and texts that are emphasised or highlighted, e.g.: Do
not switch off the device
8 Fujitsu Technology Solutions

Ports and controls
Ports and controls
This chapter presents the individual hardware components of your device. It gives you
an overview of the device’s indicators and connections. Please familiarise yourself with
these components before you start to work with the device.
Notebook open
1
2*
3
4
5
7
5
10
11
13
9
12
6
6
8
8
14
1 = LCD screen
2 = WebCam 2 mega pixel (* optional)
3 = Tablet buttons
4 = ON/OFF switch
5 = Status indicators
6 = Loudspeakers
7 = Keyboard
8 = Microphone
9 = ON/OFF switch for wireless components
10 = Touchpad
11 = Touchpad buttons
12 = Ambient light sensor
13 = Fingerprint sensor
14 = Scroll sensor
Fujitsu Technology Solutions 9

Ports and controls
Left panel
1234 5678910
2
1 = DC input connector (DC IN)
2 = Attachment eye for the pen cord
3 = Microphone jack
4 = Headphone port
5 = USB port
6 = FireWire port
7 = ExpressCard slot
8 = Memory card slot
9 = SmartCard reader
10 = Pen slot
10 Fujitsu Technology Solutions

Ports and controls
Rear
1
2
3
4
5
6
1 = Kensington Lock device
2 = SIM card slot or modem connection
(depending on the device)
3=USBport
4 = VGA monitor port
5 = LAN port
6 = USB port
The SIM card slot, LAN port and VGA monitor port are protected with covers.
Right-hand side
12
1 = Kensington Lock device 2 = Module bay with optical drive
Fujitsu Technology Solutions 11

Ports and controls
Underside
34
5
21
1 = Ventilation slot cover
2 = Memory service compartment
3 = Port for port replicator
4 = Eject lever for module in module bay
5 = Rechargeable battery
12 Fujitsu Technology Solutions

Important notes
Important notes
ImportantnotesNotes
This chapter contains essential safety information which must be followed
when working with your notebook. Other notes also provide useful information
which will help you with your notebook.
Safety notes
SafetynotesNotes
Please note the information provided in the "Safety" manual and
in the following safety notes.
Please pay special attention to the sections in the manual marked
with the symbol on the left.
When connecting and disconnecting cables, observe the relevant
notes in this operating manual.
Read the information on the ambient conditions in the "Technical data",
Page 120 and "First-time setup of your device", Page 17 before preparing your
notebook for use and switching it on for the first time.
When cleaning the device, please observe the relevant notes in the
section "Cleaning the notebook", Page 16.
Pay attention to the additional safety notes for devices with wireless
components provided in the "Safety" manual.
Please refer to the notes in the chapter "Removing and installing
components during servicing", Page 104.
This notebook complies with the relevant safety regulations for data processing
equipment. If you have questions about using your notebook in a particular area,
please contact your sales outlet or our Hotline/Service Desk.
Fujitsu Technology Solutions 13

Important notes
Additional safety notes for devices with
radio components
Radiocom ponent:WirelessLAN:Bluetooth,safetynotes
If a radio component (Wireless LAN, Bluetooth, UMTS) is integrated in your notebook, you
must be sure to observe the following safety notes when using your notebook:
• Switch off the radio components when you are in an aircraft or driving in a car.
• Switch off the radio components when you are in a hospital, an operating room or near a medical
electronics system. The transmitted radio waves can impair the operation of medical devices.
• Switch off the radio components when you let the device get near flammable
gases or into hazardous environments (e.g. petrol station, paintshops), as the
transmitted radio waves can cause an explosion or a fire.
For information on how to switch radio components on and off, see chapter
"Switching the wireless components on and off", Page 69.
Energy saving
NotesEnergyEnergysaving
Switch the notebook off when it is not in use. Switch off external, connected devices if you
are not using them. If you use the energy saving functions, the notebook uses less energy.
You will then be able to work for longer before having to recharge the battery.
Energy efficiency is increased and the environmental impact is reduced.
You save money while protecting the environment.
Energy saving under Windows
►Make use of the power management features (see ""Using the power-management features",
Page 62").
14 Fujitsu Technology Solutions

Important notes
Travelling with your notebook
Mobileope rationNotesTrans porta tionNotebook
Please observe the points listed below when travelling with your notebook.
Before you travel
►Back up important data stored on your hard disk.
NotebookTravel,noteboo k
►Switch off the radio component for data security reasons. With data traffic via a wireless
connection, it is also possible for unauthorised third parties to receive data.
Information on activating data encryption is provided in the documentation
for your radio component.
►If you wish to use your notebook during a flight, first check with the flight
attendants if it is OK to do so.
When travelling in other countries
►If you are travelling abroad, check that the mains adapter can be operated with the
local mains voltage. If this is not the case, obtain the appropriate mains adapter for
your notebook. Do not use any other voltage converter!
►Check whether the local mains voltage and the power cable are compatible. If this is
not the case, buy a power cable that matches the local conditions.
►Enquire with the corresponding government office of the country you will be
travelling in as to whether you may operate the radio component integrated in your
notebook there (see also "CE marking", Page 124).
Notebook: transporting
Protect the notebook from severe shocks and extreme temperatures
(e.g. direct sunlight in a car).
►If your device has an optical drive, remove all data media (e.g. CD, DVD) from the drives.
Transportatio nNotebook
►Switch the notebook off.
►Unplug the mains adapter and all external devices from the power socket.
►Disconnect the mains adapter cable and the data cables for all external devices.
►Close the LCD screen.
►To protect against damaging jolts and bumps, use a notebook carrying
case to transport your notebook.
Fujitsu Technology Solutions 15

Important notes
Cleaning the notebook
Do not clean any interior parts yourself; leave this job to a service technician.
Only use cleaning products designed for computers. Normal household
cleaners and polishes can damage the markings on the keyboard and the
device, the paintwork or the notebook itself.
Ensure that no liquid enters the notebook.
The LCD screen very sensitive to scratches. Only clean the display
surface with a very soft, slightly damp cloth.
►Switch the notebook off.
CleaningNotesNotebo okKeyboardTouchpadLCDs creenCrystal Viewdisplay
►In order to prevent accidentially switching the device on, remove the power cable from the mains
adaptor and remove the battery (see "Removing and installing the battery", Page 54).
The surface can be cleaned with a dry cloth. If particularly dirty, use a cloth which has
been moistened in mild domestic detergent and then carefully wrung out.
To clean the keyboard and the touchpad, if available, you can use disinfectant wipes.
Ensure that no liquid enters the device.
16 Fujitsu Technology Solutions
