AMILO Pro V3205 Edition
Your gateway to
light mobile working Pages 3
You are looking for an ultra-portable notebook with latest technology, convenient keyboard and an attractive price?
Then the AMILO Pro V3205 Edition is the right choice. The AMILO Pro V3205 Edition is a sensibly sized system. It is
small and light enough to be easily carried and stowed away, but large enough to preserve the ergonomics of an A4
portable. The combination of performance, connectivity and flexibility gives you the functionality and ease of use of a
full-sized desktop.
Latest Intel® Centrino® Duo Mobile Technology delivers high performance and long working away from the power
socket. It enables simple and wireless communication via WLAN and Bluetooth®.
Elegance
Designed for the most demanding mobile users.
AMILO Pro Series is the perfect synthesis of form,
function and style.
Slim and stylish design for every profile –
in and out of the office
Light and valuable 12.1-inch notebook with only 1.8 kg
Brilliant crystal view widescreen display
Ergonomics
Enjoy the viewing quality of brilliant
12.1-inch WXGA TFT-display
Ambient Light Sensor for automatically adjustment of
display brightness depending on ambient light
Excellent resolution and video quality with integrated
Intel 945GM chipset
Connectivity
Easy synchronization of your data between different
devices with integrated Bluetooth
Integrated Wireless LAN 802.11 a/b/g
Reliability
Highest quality design with magnesium lid
Mechanical and function stability through extensive
quality tests
German quality standards
RoHS compliant for environmental friendly working

Datasheet ⏐Issue: January 2007⏐AMILO Pro V3205 Edition Page 2 / 3
System AMILO Pro V3205 Edition
Processor
Intel® Core™ Duo Processor Up to T2250 (1.73 GHz)
Second level cache 2 MB
Front side bus (FSB) 533 MHz
Intel® Core2™ Duo Processor Up to T7200 (2.0 GHz)
Second level cache Up to 4 MB
Front side bus (FSB) 667 MHz
Chipset
Northbridge Intel 945GM
Southbridge ICH 7-M
Memory
DDR2-533 SDRAM, 533 MHz Up to 2 GB
DIMM slots 2
BIOS
BIOS Flash EPROM Phoenix First BIOS
Interfaces
Express card 34/54 1
4in1 flash card port (SD, MS, MMC, MSPRO) 1
USB 2.0 4
S-Video out (TV-out) 1
DVI-I port 1
Modem RJ-11 1
LAN RJ-45 1
Audio-in (line-in / microphone) 1
Audio-out (line-out / headphone) 1
DC-in 1
SPDIF 1 (via audio out)
IEEE1394 1
Kensington Lock 1
Modem on board
56K V.90 modem Connexant x
LAN on board
integrated 10/100 Mbps Intel Ekron x
Wireless Technologies (WLAN)
Import and usage according to country-specific regulations.
Dual band antenna
Intel PRO/Wireless 3945 a/b/g x
Bluetooth
Bluetooth V2.0 x
Audio
Stereo speakers x
Sound chip Conexant AMOM
Internal microphone Built-in array microphone
Keyboard and pointing device
Keyboard 87 keys
Touchpad with two mouse buttons
Launch keys x
Status LED x
Graphics
Intel GMA 950 with 256-bit graphics core with dynamic video
memory technology up to 128MB, 32-bit color depth x
Direct X9 x
DualView (Windows XP) x
Display
12.1-inch TFT WXGA (wide format) Crystal View technology
/1280 x 800 x with ambient light sensor
Max. resolution for external displays 1600 x 1200 / / true color / 85 Hz
Hard disk drives (internal) *
S.M.A.R.T. x
Up to 120 GB S-ATA 150 (5400 rpm) x
* 1 Gbyte equals one billion bytes, when referring to hard
disk drive capacity; accessible capacity may vary, also
depending on used software and tool.
Fixed drives
DVD+/- RW Dual layer (+R) Multiformat DVD writer with
double layer support x

Datasheet ⏐Issue: January 2007⏐AMILO Pro V3205 Edition Page 3 / 3
All rights, including rights created by patent grant or registration of a utility model or design as well
as rights of technical modifications are reserved. Delivery subject to availability. Designations may
be trademarks, the use of which by third parties for their own purposes may violate the rights of the
trademark owners.
Copyright ©Fujitsu Siemens Computers, 01/2007
Published by
Fujitsu Siemens Computers
http://www.fujitsu-siemens.com/
Company stamp
System AMILO Pro V3205 Edition
Manageability
Supported Standard x
PXE x
Security
Physical security
Kensington Lock support x
System Security
Norton Internet Security Symantec x
User Security
User and supervisor BIOS password x
Power supply
Li-Ion battery 6 cell 2200mAh (53Wh)
1st Li-Ion battery 6 cell 2400mAh (53.28 Wh) x
First battery * (Mobile Mark 2005) [up to] 3.5 h
AC adapter 20V/65W Adapter
Rated voltage (AC input) 100 - 240 V
Rated frequency 50 - 60 Hz
DC output 20 V, 3.25 A
x
* Battery life may vary depending on product model,
configuration, applications, power management settings and
features utilized. Battery recharge time depends on usage.
Operating temperatures
Relative humidity (non-condensing) 20% - 85% (running)
Ambient temperature 5° - 35° C
Dimensions / Weight
Dimensions (H x W x D) 23.9~32 x 299 x 220 mm
Weight* 1.8 kg
* Weight may vary depending on actual configuration
Certificates
CE Marking x
CE according to EU Directives 89/336/EEC (EMC)
73/23/EEC (Product safety) x
CE according to 99/5/EEC (R&TTE) x
CE! (Wireless) x
R&TTE x
CB Generic Report x
CB (Safety) x
RoHS x
WHQL x
TBR21 x
Operating System
Fujitsu Siemens Computers recommends
Microsoft® Windows® XP Professional
Microsoft Windows XP Professional x
MicrosoftWindows Vista™ capable 1)
(min. 512 MB RAM necessary) x
Microsoft Windows Vista™ Premium Ready
(min. 1GB RAM / DVD reader necessary) x
Software (compatibility / preinstalled)
Adobe Acrobat Reader x
Driver and Utility DVD x
Easy Guide on-line user documentation x
Nero x
Norton Internet Security (incl. Firewall) on Driver and Utility
CD x
Bluetooth Toshiba Stack x
Accessories (order number)
AC-adapter S26391-F321-L100
WinDVD 7 S26361-F2598-L20
Case Value case
S26391-F119-L50
Port Replicator S26391-F6007-L100
Battery S26391-F6125-L100 (6 cells)
Modem adapter set 1: D, UK
Modem adapter set 2: SW, NO, FI, DK
Modem adapter set 3: CH, A, B, NL, F, I, E, POR
S26361-F3145-L10
S26361-F3145-L20
S26361-F3145-L30
http://www.fujitsu-siemens.com/accessories/
1) Not all Windows Vista™ features are available for use on all Windows Vista Capable PCs. All Windows Vista Capable PCs will run the core experiences of Windows Vista, such as
innovations in organizing and finding information, security, and reliability. Some features available in premium editions of Windows Vista -- like the newWindows® Aero™ user interface --
require advanced or additional hardware. Check www.windowsvista.com/getready for details.
This Data Sheet describes the highest configurations. The product is offered in fixed configurations which vary from country to country and edition to edition.
