Fujitsu Lifebook N6470 User manual

BENEFITS
Desktop Performance in a Notebook
The LifeBook N6470 notebook rivals the performance
of most desktop computers with its fast Intel®Core™
2 Duo Processor, providing a noticeable performance
boost on multithreading and multi-tasking operations.
Dazzling imagery that seamlessly moves and responds
is made possible with up to 4 GB of dual channel
DDR2 memory and 512 MB of HyperMemory™3on
the ATI Radeon®HD 2600 graphics processor. The
large, 17” Colour-Enhanced Crystal View WXGA+
TFTLCD display exploits your DVD player’s potential
for saturated colors and razor-sharp detail. Notebook
storage capacity can sometimes present a challenge—
not so with the LifeBook N6470 notebook. It can be
confi gured with dual hard drives for up to 600 GB of
storage, challenging the most ambitious data pack-
rats to fi ll that much capacity. From power-hungry
3D games to video editing, with the LifeBook N6470
notebook, you won’t sacrifi ce power for portability.
Sight and Sound
The vivid image quality you see on the large,
glossy, Crystal View display is 40% brighter than
the standard TFT screen. The display features deep
blacks and vibrant whites with a contrast ratio of
up to 600:1 (double the standard contrast ratio),
delivering an extremely rich visual experience. The
Visual Optimizer is a new feature which allows you
to greatly enhance your video viewing experience.
It provides rich image quality by employing cutting
edge technologies such as a 3D colour management
system, auto contrast correction, black and white
stretch, and edge enhancement. By pressing the Visual
Optimizer button while watching a DVD, there will be
a noticeable improvement in the colour and richness of
your display. The integrated HDMI port let’s you watch
your notebook contents and movies on a large-screen
HDTV. Fujitsu engineering has brought a new level of
refi nement to the LifeBook N6470 notebook’s internal
speakers. By applying innovative sound technology to
the notebook computer chassis, rich tone quality and
excellent base response has been attained. You have to
hear it to believe it.
Advanced Media Options
You can expand your creativity and enjoy the best
in home entertainment in an easy, complete, and
connected way with Genuine Windows Vista®Home
Premium. You will be able to store, share, and enjoy all
of your photos, music, home videos, and even watch,
record, or pause live TV (TV tuner option required) in
one sleek and easy-to-use system. The standard remote
control adds even more convenience by giving you the
ability to control your Media Center notebook from
across a room. With the many built-in media ports on
the LifeBook N6470 notebook, you can quickly and
easily download home movies and photos from your
digital camera and burn them onto a CD or DVD.
You can also save your favorite music and data to a
CD, synchronize your PDA, or connect to practically
any peripheral on the market. With the addition of a
media control panel (located above the keyboard)
playing your digital media is just a button push away.
With easy-to-access, one-touch controls, playing your
DVDs or CDs has never been easier.
The integrated biometric fi ngerprint reader is now
standard on the LifeBook N6470 notebook. One
advantage to fi ngerprint readers is that it associates
your fi ngerprint to passwords so now there are no
passwords to forget or cards to lose. The sensor also
functions as a scroll button so the enhanced security
comes at no cost to functionality.
Ultimate in Flexible Connectivity
With both modem and high-speed Gigabit Ethernet
built in, it is a very simple procedure to connect to your
offi ce network or the Internet for the ultimate mobile
experience. The Intel®Wireless WiFi Link 4965AGN
product operates in both the 2.4 GHz and 5.0 GHz
spectrum, delivering high throughput and a host of
features that enhance your mobile lifestyle.
Quality and Reliability
The close interaction between Fujitsu design,
manufacturing, and service engineers creates some of
the highest quality products offered in the PC market.
In a time when most PCs are assembled by third-party
vendors, Fujitsu takes pride in its own world-class
design and manufacturing capabilities.
The LifeBook®N6470 notebook fuses the convenience of a notebook with the power of a
desktop. With Genuine Windows Vista®Home Premium, your notebook can transform into an
uncompromising Media Center PC. The high-speed mobile Intel®Core™ 2 Duo Processor coupled
with high speed ATI Mobility™ Radeon®HD 2600 graphics, deliver the level of performance
gamers and technology enthusiasts crave. With its unique high contrast 17” Colour-Enhanced
Crystal View display, video enhancement Visual Optimizer circuitry and built-in stereo sound
system (which includes a subwoofer), the LifeBook N6470 notebook takes portability to a whole
new level. You won’t believe the power and features packed into this mobile computer.
OVERVIEW
17” wide-aspect Colour Enhanced Crystal View
Display—unique high contrast display that
delivers brighter images and richer colours
High speed Intel®Core™ 2 Duo Processor
High-end graphics processing with ATI Radeon®
HD 2600 graphics and 512MB HyperMemory™
(256 MB dedicated and 256 MB shared)
Integrated HDMI Port
Very large 500 GB storage capacity with dual
hard drive option
Great sound with stereo speakers and a sub-
woofer
Integrated fingerprint sensor for security and
password management. Also works as a scroll
button
High speed Gigabit Ethernet and Intel
802.11N wireless for fast network and wireless
connection
•
•
•
•
•
•
•
•
LifeBook®N6470 Notebook

Software
Operating Systems Genuine Windows Vista®Home Premium
Software Adobe®Reader®, Microsoft®Internet Explorer, Norton Internet Security®20081, Fujitsu HotKey and
Fujitsu Driver Update Utility, CyberLink®PowerDVD, PowerProducer™, PowerDirector™, Roxio Easy
Media Creator®, Google Desktop, Google Toolbar, Softex OmniPass finger print authentication and
password management software.
Optional Software Depending upon your system’s configuration, you may also receive:
CyberLink®MakeDisc software
Key Specifi cations
Processor Intel®Core™ Duo 2 Processor T8100 (2.1 GHz, 3 MB L2 cache, 800 MHz FSB)
or Intel®Core™ Duo 2 Processor T8300 (2.4 GHz, 3 MB L2 cache, 800 MHz FSB).
Chipset Mobile Intel®PM965 Express Chipset.
Memory Two DIMM slots; max 4 GB2(2 GB x 2); DDR2 667 MHz PC2-5300, dual-channel.
Display LCD 17" Colour-Enhanced Crystal View WXGA+ TFT display.
(Brightness 370 nits; Contrast Ratio 600:1)
Video Controller ATI Mobility™ Radeon®HD 2600 with 512 MB HyperMemory™3.
Maximum Resolution Internal display: 1440 x 900, 16M colours.
External monitor: 1600 x 1200, 16M colours.
Simultaneous display: 1024 x 768, 16M colours.
Hard Drive2Dual HDD 320 GB (160 GB x2; SATA, 5400 rpm)
Configuration or 500 GB (250 GB x2; SATA, 4200 rpm)
Optical Drive Dual-Layer Multi-Format DVD Writer
(24x CD-R, 10x CD-RW, 8x DVD±R, 4x DVD±RW, 2x DVD-R DL, 2.4x DVD+R DL, 5x DVD-RAM)
Audio Realtek ALC262.
Headphone/line-out/optical digital (SPDIF) jack and Microphone/line-in jack.
2 internal stereo speaker and subwoofer.
Communications Multinational456K5V.90 modem.
Gigabit (10/100/1000) Ethernet LAN.
Wireless Communications Intel®Wireless WiFi Link 4965AGN (802.11 a/b/g and Draft N).
Wi-Fi®, CCX and WPA certified.
User Interfaces Integrated touchpad with fingerprint sensor which can also be used for scroll function.
103-key full-size keyboard with a separate 10-key keypad; 19 mm key pitch and 3 mm key stroke.
Ports 5 USB 2.0, IEEE 1394 (4-pin), External CRT, HDMI, S-Video out, Modem (RJ-11), LAN (RJ-45)
Card Slots One Type I/II PCMCIA slot.
One ExpressCard™ slot. (54 mm / 34 mm)
One shared slot for MemoryStick®, MemoryStick PRO™, Secure Digital (SD) card, xD Picture card.
Security Security lock slot.
Integrated biometric fingerprint sensor.
Battery6Lithium-ion (6-cell, 10.8V, 3200 mAh). Up to 1 hour battery life.
AC Adapter Auto-sensing 100-240V AC, 100 W; supplying 19V DC, 5.27A
Dimensions/Weight 404 mm x 295 mm x 46 - 51 mm (15.9” x 11.6” x 1.8 - 2.02”).
Approximately 4.8 kg (10.58 lbs) with single hard drive.
Operating Temperature 5°C to 35°C (41°F to 95°F), ambient temperature.
20% to 85% relative humidity, non-condensing.
Non-operating Temperature -15°C to 60°C (5°F to 140°F).
8% to 85% relative humidity, non-condensing.
Key Accessories For a list of accessories, visit www.fujitsu.ca or call 1-800-FUJITSU.
Optional External TV Tuner S-Video in Y signal: 1 Vp-p, 75 ohm
C signal: 0.286 Vp-p, 75 ohm
Video in Signal: 1 Vp-p, 75 ohm
Audio in Audio level: 0.7 Vrms, typical
Input impedance: 10k ohm above
Resolution Up to 720 x 480
Channel support RF frequency range:
55.25-127.25 MHz (VHF low band, USA)
133.25-361.25 (VHF high band, USA)
367.25-801.25 MHz (UHF band, USA)
Receives both ATSC and NTSC signals
Encorder Video compression method: MPEG2
Compliance and Service Information
Compliance FCC Part 15B Class B and FCC Part 15C
IC ICES-003 Class B and RSS-210
UL-cUL Listed
FCC Part 68
IC CS-03
ExpressCard™ ID EC100064
Warranty7One year International Limited Warranty.
24/7 technical support.
Fujitsu extended service plans available.
1) Preinstalled with a free 90-day trial version of Symantec
Norton Internet Security 2007. The 90-day trial version is
activated upon user’s acceptance of software license.
2) One gigabyte (GB) = one billion bytes; accessible capacity
will be less and actual capacity depends on the operating
environment and formatting.
3) 512 MB HyperMemory™ is a total of 256 MB dedicated
video and 256 MB shared system memory.
4) The internal modems on all Fujitsu notebooks from Fujitsu
Canada, Inc. are only qualified for use with telephone systems
in select countries, including the United States and Canada.
For a list of certified countries, please check http://www.
computers.us.fujitsu.com/modems.
5) Actual speeds over North American telephone lines vary,
and are less than 56Kbps due to the current FCC regulations
and line conditions.
6) Battery life estimates reflect the results of clocked
observation of operating time performed upon systems
with user-configurable battery life settings at maximum
energy savings. Actual battery life will vary based on screen
brightness, applications used, features selected, power
management settings, battery conditioning, and other
customer preferences. DVD/CD-RW, DVD Writer, LAN,
wireless LAN or hard drive usage may also have a significant
impact on battery life.
7) Service and warranty turnaround time may vary by country
and product. The International warranty is only valid for
products purchased in North, Central, and South America.
Fujitsu, the Fujitsu logo, and LifeBook are registered
trademarks of Fujitsu Limited. Centrino, Intel, Intel Core, the
Centrino logo and the Intel logo are trademarks or registered
trademarks of Intel Corporation or its subsidiaries in the
United States and other countries. Microsoft, Windows and
Windows Vista are registered trademarks or trademarks
of Microsoft Corporation in the United States and/or other
countries. Adobe Reader is a registered trademark of Adobe
Systems, Inc. Wi-Fi is a trademark of the Wireless Ethernet
Compatibility Alliance (WECA). Memory Stick and Memory
Stick PRO are registered trademarks or trademarks of Sony
Corporation and/or its affiliates. Blu-ray Disc™ and the Blu-
ray Disc logo are trademarks of the Blu-ray Disc Association.
Norton Internet Security is a registered trademark of
Symantec Corporation. Quicken is a registered trademark of
Intuit, Inc. The ExpressCard word mark and logo are owned by
the PCMCIA and any use of such marks by Fujitsu Computer
Systems Corporation is under license. All other trademarks
mentioned herein are the property of their respective owners.
Product description data represents Fujitsu design objectives
and is provided for comparative purposes; actual results may
vary based on a variety of factors. Specifications are subject
to change without notice.
©2008 Fujitsu Canada, Inc. All rights reserved.
FCI-02.24.2008-E
Fujitsu Canada, Inc.
6975 Creditview Road, Unit 1
Mississauga, Ontario L5N 8E9
Tel: [phone]
Fax: [phone]
Toll Free: 1-800-263-8716
URL: http://www.fujitsu.ca
Eastern Canada
1000 Sherbrooke Street, Suite 1500
Montreal, Quebec H3A 3G4
Tel: [phone]
Fax: [phone]
Toll Free: 1-800-663-0756
URL: http://www.fujitsu.ca/fr/
LifeBook®N6470 Notebook
