Fujitsu lifebook t726 User manual

System
Operating Manual
FUJITSU LIFEBOOK T726

Contact address in North America
FUJITSU AMERICA INC.
1250 East Arques Avenue, Sunnyvale,
CA 94085-3470, U.S.A.
Telephone: [phone] or 408 746 6000
"http://solutions.us.fujitsu.com"
"http://solutions.us.fujitsu.com/contact"
Have a question? Email us at: "AskFujits[email protected]jitsu.com"
Copyright
©2016F
ujitsu America, Inc. All rights reserved
B5FK-6481-01ENZ0-00

FUJITSU LIFEBOOK T726
Operating Manual
Declarations of conformity 9
Fujitsu Contact Information 10
Ports and controls 12
Important notes 15
First-time setup of your device 20
Working with the notebook 23
Security functions 67
Connecting external devices 75
Removing and installing components
during servicing 81
Settings in BIOS Setup Utility 89
Troubleshooting and tips 92
Technical data 101
Manufacturer’s notes 106
Declarations of conformity 109
FCC Regulatory Information 110
Canada, Industry Canada (IC) 113
Appendix 115
Index 133

Copyright and Trademark Information
Fujitsu America, Incorporated has made every effort to ensure the accuracy and completeness
of this document; however, as ongoing development efforts are continually improving the
capabilities of our products, we cannot guarantee the accuracy of the contents of this
document. We disclaim liability for errors, omissions, or future changes.
Fujitsu, the Fujitsu logo and LIFEBOOK are registered trademarks of Fujitsu Limited
or its subsidiaries in the United States and other countries.
Intel and Intel Core are trademarks or registered trademarks of Intel Corporation or
its subsidiaries in the United States and other countries.
Microsoft and Windows are either registered trademarks or trademarks of Microsoft
Corporation in the United States and/or other countries.
Bluetooth is a trademark of Bluetooth SIG, Inc., USA.
OmniPass is a trademark of Softex, Inc.
Roxio is a trademark of Roxio, a division of Sonic Solutions.
YouCam is a trademark of CyberLink Corp.
Adobe, Acrobat, and Adobe Reader are either a registered trademarks or trademarks of
Adobe Systems Incorporated in the United States and/or other countries.
The DVD player found in some models of the LIFEBOOK notebook incorporates copyright
protection technology that is protected by method claims of certain U.S. patents and other
intellectual property rights owned by Macrovision Corporation and other rights users. Use
of this copyright protection technology must be authorized by Macrovision Corporation, and
is intended for home and other limited viewing uses only unless authorized by Macrovision
Corporation. Reverse engineering or disassembly is prohibited.
All other trademarks specified here are the property of their respective owners.

Contents
Contents
Declarationsofconformity ............................................................. 9
Fujitsu Contact Information ............................................................ 10
Notational conventions .................................................................. 11
Portsandcontrols ..................................................................... 12
Importantnotes ........................................................................ 15
Safetyinstructions ...................................................................... 15
Additional safety notes for devices with radio components . . . . . ............................. 16
Energysaving .......................................................................... 16
Energy saving under Windows ....................................................... 16
Traveling with your notebook . . ........................................................... 17
Beforeyoutravel ................................................................... 17
Transporting the notebook ........................................................... 18
Storing the notebook .................................................................... 18
Cleaning the notebook .................................................................. 19
Further informationoncleaningthenotebook .......................................... 19
First-timesetupofyourdevice ......................................................... 20
Unpacking and checking the device . . . ................................................... 20
Choose a location . ...................................................................... 21
Connecting the AC adapter . . . ........................................................... 21
Switching on the device for the firsttime .................................................. 22
Installing Bonus Apps . . . . . ........................................................... 22
Working with thenotebook ............................................................ 23
Status indicators ........................................................................ 23
Opening the notebook ................................................................... 25
Switching the notebook on . . . . ........................................................... 26
ProgrammingtheON/OFFbutton ..................................................... 26
Different ways to use your notebook . . . ................................................... 27
From notebooktoTabletPC .......................................................... 27
Select displayorientation(portraitorlandscapeformat) ................................. 29
From TabletPCtonotebook .......................................................... 30
Switching off the notebook . . . . ........................................................... 31
Closing the notebook . . .................................................................. 32
Handwriting recognition .................................................................. 32
LCD screen ............................................................................ 33
Ambientlightsensor ................................................................. 33
Using thedeviceasaTabletPC .......................................................... 33
Using fingers ....................................................................... 33
Using thestylus(onlydeviceswithDualDigitizer) ...................................... 34
Using thedeviceasanotebook .......................................................... 38
Touch padandtouchpadbuttons ...................................................... 38
Keyboard ............................................................................... 39
Virtualnumberkeys ................................................................. 42
Countryandkeyboardsettings ....................................................... 42
Key combinations ................................................................... 43
Tabletbuttons .......................................................................... 45
Webcam ............................................................................... 46
Rechargeablebattery ................................................................... 47
Fujitsu 3

Contents
Charging,caringforandmaintainingthebattery ....................................... 47
Removingandinstallingthebattery ................................................... 47
Batterychargingstatusindicator ...................................................... 50
Modules ............................................................................... 51
Removing a modular bay device . . . . . ................................................. 51
Installing a modular bay device . . . . . . ................................................. 52
Opticaldrive ............................................................................ 52
Handling optical disks . . . ............................................................ 52
CD/DVDindicator ................................................................... 53
Insertingorremovinganopticaldisk .................................................. 53
Manual removal (emergency removal) . . . ............................................. 54
Usingtheenergysavingfunctions ........................................................ 55
Memorycards .......................................................................... 56
Supportedformat .................................................................... 56
Insertingthememorycard ........................................................... 56
Removingthememorycard .......................................................... 56
Speaker and microphone ................................................................ 57
SIMcard ............................................................................... 58
InsertingaSIMcard ................................................................. 58
RemovingaSIMcard ............................................................... 59
Optional wireless LAN/Bluetooth/4G radio components . . . .................................. 59
Switching the wireless components on and off ......................................... 59
ConfiguringWLANaccess ........................................................... 60
FurtherinformationonWLANandBluetooth ........................................... 60
AccessviaWirelessWAN ............................................................ 60
Accessvia4G ...................................................................... 60
UMTS/LTEantenna ................................................................. 61
EthernetandLAN ....................................................................... 62
Your port replicator (optional) ............................................................ 63
Portsontheportreplicator ........................................................... 63
Connecting the notebook to the port replicator . . . . . . .................................. 64
Connecting the AC adapter to the port replicator . . . . .................................. 65
Switching on the notebook via the port replicator . . . . . .................................. 65
Disconnecting the notebook from the port replicator . .................................. 66
Securityfunctions ..................................................................... 67
Briefoverviewofthesecurityfunctions .................................................... 68
Configuring the fingerprint sensor ........................................................ 69
UsingtheSecurityLock ................................................................. 70
Configuringpasswordprotectionin BIOSSetupUtility ...................................... 70
Protecting BIOS Setup Utility (supervisor password and user password) . . ............... 71
Password protection for booting the operating system .................................. 72
Passwordprotectionfortheharddisk ................................................. 72
Smart Card reader . . . . . . ................................................................ 73
InsertingtheSmartCard ............................................................. 73
Trusted Platform Module - TPM (device dependent) . . . . . . .................................. 74
EnablingTPM ....................................................................... 74
DisablingTPM ...................................................................... 74
Connectingexternaldevices ........................................................... 75
Connecting an external monitor . . ........................................................ 76
HDMIport .......................................................................... 77
Connecting USB devices ................................................................ 77
USBportwithchargingfunction(AnytimeUSBcharge) ................................. 78
4Fujitsu

Contents
Connecting an external SATA hard drive (eSATA) (port replicator only) . . . . . .............. 79
SaferemovalofeSATAandUSBdevices ............................................. 79
Connecting external audio devices ....................................................... 80
Microphone port/Line In . . . ........................................................... 80
Headphones port . . .................................................................. 80
Removing and installing components during servicing .. . . ............................. 81
Notesoninstallingandremovingboardsandcomponents .................................. 81
Preparing to remove components . ....................................................... 82
Removing and installing memory expansion . . . ............................................ 82
Removethecover ................................................................... 83
Removingamemorymodule ......................................................... 83
Installingamemorymodule .......................................................... 84
Attachingthecover .................................................................. 84
Removingandinstallingtheharddisk .................................................... 85
Removethecover ................................................................... 85
Removingtheharddisk .............................................................. 86
Installingaharddisk ................................................................. 87
Attachingthecover .................................................................. 88
Finishing component removal . ........................................................... 88
Settings in BIOS Setup Utility . . . ....................................................... 89
StartingtheBIOSSetupUtility ........................................................... 89
BIOSSetup Utilityoperation ............................................................. 90
ExitingBIOSSetupUtility ................................................................ 91
Exit Saving Changes - save changes and exit BIOS Setup Utility . . ..................... 91
Exit Discarding Changes - Reject changes and exit BIOS Setup Utility . . . . . .............. 91
Load Setup Defaults – load default values . ............................................ 91
Discard Changes - Discard Changes without exiting BIOS Setup Utility . . . . .............. 91
Save Changes - save changes without exiting the BIOS Setup Utility . . . . . . .............. 91
Savechangesandpoweroff ........................................................ 91
Troubleshootingandtips .............................................................. 92
Helpifproblemsoccur ................................................................... 92
RecoveringyourFactoryImage .......................................................... 92
The notebook’s date or time is incorrect ................................................... 93
Battery indicator does not illuminate . . . ................................................... 93
Whencertaincharactersareenteredonthekeyboard,onlynumeralsarewritten ............. 93
The notebook’s LCD screen remains blank . . . . ............................................ 93
The LCD screen of the notebook is difficulttoread ......................................... 93
Theexternalmonitorremainsblank ...................................................... 94
Theexternalmonitorisblankortheimageisunstable ..................................... 94
The cursor does not correctly follow the stylus movements . . . . ............................. 95
Stylusinputnotworking ................................................................. 95
The notebook does not start after switching it on . . . ........................................ 95
The notebook stops working . . ........................................................... 96
The printer does not print . . . . . ........................................................... 96
The wireless connection to a network does not work . . . .................................... 96
Thebatterydischargestooquickly ........................................................ 97
Smart Card reader is not recognized . . . ................................................... 97
SmartCardPINforgotten ................................................................ 97
SmartCardlost ......................................................................... 97
User and/or supervisor Smart Card lost . . . . . . ............................................ 98
Acousticwarning ........................................................................ 98
Fujitsu 5

Contents
Error messages on the screen . . . ........................................................ 99
Technicaldata ......................................................................... 101
Notebook . . . . ........................................................................... 101
WLAN specifications .................................................................... 102
Portreplicator(optional) ................................................................. 104
Rechargeable battery . . . ................................................................ 104
AC adapter for use with notebook and port replicator . . . . . .................................. 105
Manufacturer’snotes .................................................................. 106
Disposalandrecycling .................................................................. 106
Recyclingyourbattery ............................................................... 106
DOC (Industry CANADA) Notices ........................................................ 106
ULNotice ........................................................................... 107
ENERGYSTARCompliance ............................................................. 108
Declarationsofconformity ............................................................. 109
FCCRegulatoryInformation ........................................................... 110
RegulatoryNotesandStatements ........................................................ 110
WirelessLAN,HealthandAuthorizationforuse ........................................ 110
Regulatory Information/Disclaimers . . ................................................. 111
Federal Communications Commission and Industry Canada statement: . . . ............... 111
FCCInterferenceStatement ......................................................... 111
FCC Radio Frequency Exposure statement . . . ......................................... 112
Exportrestrictions ................................................................... 112
Restrictions concernant l’exportation . ................................................. 112
Canada,IndustryCanada(IC) .......................................................... 113
Canadian Notice . ....................................................................... 113
Avis pour le Canada . . . . . ................................................................ 114
Appendix .............................................................................. 115
Before Using the Optional Wireless LAN . ................................................. 115
WirelessLANDevicesCoveredbythisDocument ...................................... 115
CharacteristicsoftheWLANDevice .................................................. 115
Wireless LAN Modes Using this Device . . ............................................. 116
Deactivating/DisconnectingtheWLANDevice ......................................... 118
ConfiguringtheWirelessLAN ............................................................ 119
Configuring the WLAN Using Windows . . . ............................................. 119
Connection to the network . . . ........................................................ 119
TroubleshootingtheWLAN ........................................................... 120
UsingtheBluetoothDevice .............................................................. 122
Image Backup and Recovery Procedures ................................................. 123
Windows® 7 Procedures ................................................................ 123
Creating a Backup of Bootable Disc and Recovery Image for Windows 7 . ............... 123
Creating a backup of the System-SpecificSoftwareDrivers ............................. 124
WINDOWS 7 RECOVER YOUR SYSTEM WHEN THE HARD DRIVE IS STILL
ACCESSIBLE ....................................................................... 124
RECOVER YOUR SYSTEM WHEN THE HARD DRIVE IS NOT BOOTABLE FOR
WINDOWS7 ....................................................................... 126
Recovering Your Recovery Image Using Recovery and Utility (for new hard drive or
non-bootableharddrive) ............................................................. 127
InstallingtheSoftwareaftertheRecoveryImageisRestored ............................ 128
Windows® 10 Procedures . . . ............................................................ 129
6Fujitsu

Contents
Creatingarecoverydrive ............................................................ 129
Recovery options in Windows 10 . . ................................................... 129
Downloading driver updates . . ........................................................... 132
Index .................................................................................. 133
Fujitsu 7

Contents
8Fujitsu

Declarations of conformity
Declarations of conformity
DECLARATION OF CONFORMITY
according to FCC Part 15
Responsible Party Name: Fujitsu America, Inc.
Address: 1250 E. Arques Avenue
Sunnyvale, CA 94085
Telephone: [phone]
Declares that product: Base Model Configuration: LIFEBOOK T726 Notebook
Complies with Part 15 of the FCC Rules.
This device complies with Part 15 of the FCC rules. Operations are subject to the
following two conditions: (1) This device may not cause harmful interference. (2) This
device must accept any interference received, including interference that may cause
undesired operation.
Fujitsu 9

Fujitsu Contact Information
Fujitsu Contact Information
Service and Support
You can contact Fujitsu Service and Support in the following ways:
• Toll free phone: 1-800-8Fujitsu (1-800-838-5487)
• Website: "http://solutions.us.fujitsu.com/www/content/support/contact/index.php"
Before you place the call, have the following information ready so that the customer
support representative can provide you with the fastest possible solution:
• Product name
• Product configuration number
• Product serial number
• Purchase date
• Conditions under which the problem occurred
• Any error messages that have occurred
• Type of device connected, if any
Fujitsu Shopping Online
Please go to "http://www.shopfujitsu.com/store/ ".
Maintaining Latest Configuration
To ensure that you always have the most current driver updates related to your system, you should
occasionally access the Fujitsu Software Download Manager (FSDM) utility. The FSDM utility is
available from the Fujitsu Support site. FSDM will allow you to view a list of the most current
drivers, utilities and applications to determine whether you have the latest versions. If you have a
Windows 7 or Windows 10 operating system, you will need to go to the Support Site to download
the FSDM Utility: "http://support.fujitsupc.com/CS/Portal/support.do?srch=DOWNLOADS".
Limited Warranty
Your LIFEBOOK notebook is backed by a Fujitsu International Limited Warranty. Check the service
kit that came with your notebook for the Limited Warranty period and terms and conditions.
10 Fujitsu

Fujitsu Contact Information
Notational conventions
Pay particular attention to text marked with this symbol. Failure to observe
this warning will endanger your life, will damage the device or lead to loss
of data. The warranty will be invalidated if the device becomes defective
through failure to observe these warnings.
Indicates important information which is required to use the device properly.
►indicates an activity that must be performed
indicates a result
This style indicates data entered using the keyboard in a program dialogue or at
the command line, e.g. your password (Name123)oracommandusedto
start a program (start.exe)
This style indicates information that is displayed on the screen by a program, e.g.:
Installation is complete.
This style indicates
• terms and texts used in a software interface, e.g.: Click on Save.
• names of programs or files, e.g. Windows or setup.exe.
"This style" indicates
• Cross-references to another section, e.g. "Safety information"
• cross-references to an external source, e.g. a web address: For more
information, go to "http://solutions.us.fujitsu.com/"
• names of CDs, DVDs and titles or designations of other materials, e.g.:
"CD/DVD Drivers & Utilities" or "Safety/Regulations" manual
Key indicates a key on the keyboard, e.g: F10
This style indicates terms and text that are emphasized or highlighted, e.g.: Do not
switch off the device
Fujitsu 11

Ports and controls
Ports and controls
This chapter presents the individual hardware components of your device. It gives an
overview of the indicators and connections of the device. Please familiarize yourself
with these items before you start to work with the device.
Notebook open
4
123
1
6
57
78
9
14
11
12
13
15
16
10 10
1 = Microphone
2 = Webcam
3 = Webcam LED
4 = UMTS/LTE antenna
5 = Fingerprint sensor (device-dependent)
6 = Ambient light sensor
7 = Speaker
8 = Windows button
9 = ON/OFF switch
10 = Status indicators
11 = Keyboard
12 = Touchpad
13 = Touchpad buttons
14 = Removal button for stylus
15 = Tether eyelet for stylus tether
16 = Memory card slot
12 Fujitsu

Ports and controls
Left-hand side
1 2 3 5 76
4
1 = DC jack (DC IN)
2 = External monitor port (VGA)
3 = HDMI port
4 = SmartCard reader (device-dependent)
5 = USB port 3.0 with charging function
(Anytime USB charge)
6 = Microphone port
7 = Headphones port
Rear
1 2 3
1=US
Bport3.0
2 = LAN port
3=Vo
lume-Down button, Volume-Up button
Fujitsu 13

Ports and controls
Right-hand side
1 2 3 4
1 = Stylus slot
2 = Modular bay with optical drive
3=USBport3.0
4 = Security Lock device
Bottom
12
3
4
5
6
7
8
9
1 = Hard disk service compartment
2 = Memory upgrade compartment
3 = Modular bay with optical drive
4 = Modular bay release button
5 = Battery lock slider
6 = Battery with SIM card slot under the battery
7 = Battery charging status indicator
8 = Port for port replicator
9 = Battery lock slider
14 Fujitsu

Important notes
Important notes
ImportantnotesNotes
This chapter contains essential safety information which must be followed
when working with your notebook. Other notes also provide useful information
which will help you with your notebook.
Safety instructions
SafetyinformationInform ation,
Please observe the following safety information.
Please pay special attention to the sections in the manual marked
with the symbol on the left.
When connecting and disconnecting cables, observe the relevant
notes in this operating manual.
Read the information on the ambient conditions in the "Technical data", Page 101
chapter and the "First-time setup of your device", Page 20 chapter before preparing
your notebook for use and switching it on for the first time.
When cleaning the device, please observe the relevant notes in the
section "Cleaning the notebook", Page 19.
Pay attention to the additional safety notes for devices with radio components
provided in the "Safety/Regulations" manual.
Please refer to the notes in the chapter "Removing and installing
components during servicing", Page 81.
When handling this device, you will come into contact with lead, a chemical which in
California is held to be a possible cause of birth defects and other damage to fertility.
Wash your hands after using the device.
This notebook complies with the relevant safety regulations for data processing equipment.
If you have any questions about setting up your notebook in the intended environment,
please contact your sales outlet or our Hotline/Service Desk.
Fujitsu 15

Important notes
Additional safety notes for devices with
radio components
Radiocomponent sWirelessLANBluetooth,Safetynotes
If a radio component (Wireless LAN, Bluetooth, UMTS, 4G) is incorporated in your notebook,
you must be sure to observe the following safety notes when using your notebook:
• Switch off the radio components when you are in an aircraft or driving in a car.
• Switch off the radio components when you are in a hospital, an operating room or near a medical
electronics system. The transmitted radio waves can impair the operation of medical devices.
• Switch off the radio components, when you let the device get near flammable gases
or into hazardous environments (e.g. gas station, paintshops), as the transmitted
radio waves can cause an explosion or a fire.
For further information on how to switch the radio components on and off, refer
to chapter "Switching the wireless components on and off", Page 59.
Energy saving
NotesEnergyPowersaving
Switch the notebook off when it is not in use. Switch off any connected external devices when
they are not in use. If you use the energy saving functions, the notebook uses less power. You
will then be able to work for longer before having to recharge the battery.
The energy efficiency is increased and environmental pollution is reduced.
You save money and help protect the environment.
Energy saving under Windows
►Make use of the available energy saving functions as described in chapter
"Using the energy saving functions", Page 55.
16 Fujitsu

Important notes
Traveling with your notebook
MobileoperationNotesTrans portNotebook
Please observe the points listed below when traveling with your notebook.
Before you travel
►Back up important data stored on your hard disk.
NotebookTraveling,notebook
►Switch off the radio component for data security reasons. With data traffic via a wireless
connection, it is also possible for unauthorized third parties to receive data.
Information on activating data encryption is provided in the documentation
for your radio component.
►If you wish to use your notebook during a flight, check with the flight attendants if its use is safe.
When traveling in other countries
►If you are traveling abroad, check that the AC adapter can be operated with the local AC
voltage. If this is not the case, obtain the appropriate AC adapter for your notebook.
Do not use any other converter!
►Check whether the local AC voltage and the AC cable are compatible. If this is not
the case, buy an AC cable that suits the local conditions.
►Enquire with the corresponding government office of the country you will be traveling to,
whether you may use your notebook with its integrated radio component there.
►Take the necessary travel adapters with you when traveling abroad. Check the following
table to see which travel adapters you will need, or ask your travel organizer.
Power connection Travel destination
United States, Canada, Mexico, parts of Latin
America, Japan, Korea, Philippines, Taiwan
Russia and the Commonwealth of Independent
States (CIS), much of Europe, parts of Latin
America, the Middle East, parts of Africa, Hong
Kong, India, much of south-east Asia
United Kingdom, Ireland, Malaya, Singapore,
parts of Africa
China, Australia, New Zealand
Fujitsu 17

Important notes
Transporting the notebook
Protect the notebook from severe shocks and extreme temperatures
(e.g. direct sunlight in a car).
►If your device has an optical drive, remove all optical disks from the drives (e.g. CD, DVD).
TransportNotebook
►Switch the notebook off.
►Unplug the AC plug of the AC adapter and all external devices from the power outlets.
►Disconnect the AC adapter cable and the data cables for all external devices.
►Close the LCD screen.
►To protect against damaging jolts and bumps, use a notebook carrying
case to transport your notebook.
Storing the notebook
• If storing your notebook for a month or longer, turn it off, fully charge the battery, then
remove and store all the Lithium Polymer batteries in a suitable location.
• Store your notebook in a cool dry location. Temperatures should remain
between 13 ºF / -25 ºC and 140 ºF / 60 ºC.
• Store your notebook and batteries separately. If you store your notebook with a
battery installed, the battery will discharge, and battery life will be reduced. In
addition, a faulty battery might damage your notebook.
• Always power off the notebook before transporting and/or packaging it.
After shutting down the notebook, wait until the status LED panel indicates
the power-off condition (i.e., no lights are illuminated).
• It is possible that the notebook may not automatically go to power-off or sleep mode
when you close the lid. This situation may occur due to pre-operating system boot
password security settings or some other application running on the notebook.
• Attempting to transport the notebook while power is on may damage
the notebook due to shock or overheating.
18 Fujitsu
