Fujitsu Siemens AMILO Pa Series Product information sheet

Notebook
EasyGuide
English
AMILO Pa Series

Are there ...
... any technical problems or other questions that you need help with?
Please contact:
●our Hotline/Help Desk
(refer to the enclosed Help Desk list or find us on the Internet: www.fujitsu-siemens.com/helpdesk)
●your sales partner
●your sales office
Additional information is contained in the Help Desk list and the "Warranty" manual.
The "Warranty" manual can be found on your notebook under Start – Manuals or on the
"Drivers & Utilities" CD/DVD.
Latest information on our products, tips, updates etc. can be found on our website at:
www.fujitsu-siemens.com

This manual was produced by
Xerox Global Services
Published by
Fujitsu Siemens Computers GmbH
Printed in the Federal Republic of Germany
AG 08/06
Edition 1
Order No.: 10600718731
Order No.: 440 N30742

AMILO Pa Series
Operating Manual
Introduction
Technical data
Ports and operating
elements
Manufacturer’s notes
Important notes
Index
Preparing the notebook
for use
Working with the
notebook
Security functions
Connecting
external devices
Memory: expansion
Settings in
BIOS Setup Utility
Troubleshooting
and tips
August 2006 edition

Microsoft, MS, MS-DOS, Windows, and Windows Vista are registered trademarks of
Microsoft Corporation.
Acrobat Reader is a trademark of Adobe Systems Incorporated.
Macrovision is a trademark of Macrovision Corporation, USA.
MultiMediaCard is a registered trademark of Infineon Technologies AG
Sony and Memory Stick are registered trademarks of Sony Electronics, Inc.
All other trademarks referenced are trademarks or registered trademarks of their respective
owners, whose protected rights are acknowledged.
Copyright © Fujitsu Siemens Computers GmbH 2006
All rights, including rights of translation, reproduction by printing, copying or similar methods,
in part or in whole, are reserved.
Offenders will be liable for damages.
All rights reserved, particularly for rights created by patent grant or registration of a utility
model or design.
Delivery subject to availability. Right of technical modification reserved.

Contents
Innovative technology... ..................................................................................................................... 1
Do you need more information? ........................................................................................................... 1
Notational conventions ......................................................................................................................... 2
Ports and operating elements ........................................................................................................... 3
Important notes .................................................................................................................................. 5
Safety notes.......................................................................................................................................... 5
Energy saving....................................................................................................................................... 5
Information sources.............................................................................................................................. 6
Travelling with your notebook............................................................................................................... 7
Before you travel .......................................................................................................................... 7
Transporting the notebook ........................................................................................................... 7
Cleaning the notebook.......................................................................................................................... 8
Preparing your notebook for use...................................................................................................... 9
Unpacking and checking your notebook............................................................................................... 9
Selecting the location ......................................................................................................................... 10
Connecting the mains adapter............................................................................................................ 10
Switching the notebook on for the first time........................................................................................ 11
Working with the notebook ............................................................................................................. 13
Switching on the notebook ................................................................................................................. 13
Switching off the notebook ................................................................................................................. 14
Status indicators................................................................................................................................. 15
Keyboard ............................................................................................................................................ 17
Virtual numeric keypad............................................................................................................... 19
Key combinations ....................................................................................................................... 19
Country and keyboard settings...................................................................................................21
Easy Launch keys .............................................................................................................................. 22
Touchpad and touchpad buttons........................................................................................................ 23
LCD screen......................................................................................................................................... 24
Information on the LCD screen .................................................................................................. 24
Monitor settings .......................................................................................................................... 25
Battery ................................................................................................................................................ 26
Charging, caring for and maintaining the battery........................................................................ 26
Monitoring the battery charge level ............................................................................................ 26
Removing and installing the battery ........................................................................................... 27
Using the energy saving functions...................................................................................................... 28
ExpressCards ..................................................................................................................................... 29
Inserting the ExpressCard.......................................................................................................... 29
Removing the ExpressCard ....................................................................................................... 30
Memory cards..................................................................................................................................... 31
Inserting the memory card.......................................................................................................... 31
Removing the memory card ....................................................................................................... 31
Hard disk ............................................................................................................................................ 32
CD/DVD data storage media and CD/DVD drive (device-dependent) ............................................... 32
CD/DVD data storage media...................................................................................................... 32
CD/DVD drives (device-dependent) ........................................................................................... 33
Handling CD/DVDs..................................................................................................................... 34
Inserting or removing a CD/DVD................................................................................................ 35
Regional codes for DVD films and DVD players ........................................................................ 36
Adjusting AutoPlay function of your CD/DVD drive .................................................................... 36
10600718731, edition 1

Contents
Microphone and loudspeakers............................................................................................................37
Adjusting the volume...................................................................................................................37
Integrated 56k modem ........................................................................................................................38
Connecting notebook modem to telephone wall socket..............................................................38
Radio components: Wireless LAN/ Bluetooth .....................................................................................39
Switching the wireless LAN/ Bluetooth module on and off..........................................................39
Ethernet and LAN................................................................................................................................39
Remote control for Windows XP Media Center Edition (optional).......................................................40
Security functions.............................................................................................................................41
Brief overview of security functions.....................................................................................................41
Using the Kensington Lock .................................................................................................................41
Configuring the password protection in the BIOS Setup Utility...........................................................42
Protecting BIOS Setup Utility (supervisor and user password)...................................................42
Password protection of operating system...................................................................................43
Connecting external devices............................................................................................................45
Ports....................................................................................................................................................46
Connecting an external monitor ..........................................................................................................47
USB devices: connecting ....................................................................................................................48
Connecting external audio devices .....................................................................................................48
Connecting an external device to S-Video Out ...................................................................................50
Connecting FireWire devices ..............................................................................................................51
Removing and installing components during servicing................................................................53
Notes on installing and removing boards and components ................................................................53
Removing and installing the battery....................................................................................................54
Removing and installing the hard disk ................................................................................................54
Removing the hard disk ..............................................................................................................54
Installing the hard disk ................................................................................................................55
Memory upgrades ...............................................................................................................................56
Installing and removing the memory upgrade.............................................................................56
Settings in BIOS Setup Utility ..........................................................................................................59
Starting the BIOS Setup Utility............................................................................................................59
Using the BIOS Setup Utility ...............................................................................................................60
Exiting the BIOS Setup Utility..............................................................................................................60
Troubleshooting and tips .................................................................................................................61
Restoring installed software................................................................................................................61
Restoring the operating system, drivers, manuals and special software....................................62
The notebook's date or time is incorrect .............................................................................................62
The notebook’s LCD screen remains blank ........................................................................................62
The LCD screen is difficult to read......................................................................................................62
The external monitor remains blank....................................................................................................63
The external monitor is blank or the image is unstable.......................................................................63
The notebook cannot be started .........................................................................................................64
The notebook stops working ...............................................................................................................64
DVD film playback stops .....................................................................................................................65
The printer does not print....................................................................................................................66
The radio connection to a network does not work...............................................................................66
A beep sounds at a rate of one per second ........................................................................................66
Technical data ...................................................................................................................................67
Notebook.............................................................................................................................................68
Battery.................................................................................................................................................68
Mains adapter 90 W............................................................................................................................68
10600718731, edition 1

Contents
Manufacturer’s notes ....................................................................................................................... 69
Disposal and recycling........................................................................................................................ 69
Declarations of Conformity ................................................................................................................. 69
Copyright-protected technology.......................................................................................................... 69
CE marking......................................................................................................................................... 70
Index .................................................................................................................................................. 71
10600718731, edition 1

Contents
10600718731, edition 1

Innovative technology...
and ergonomic design make your AMILO a reliable, convenient notebook.
Your notebook is available in several different versions. Most of the sections in this manual apply to
all models - any differences are pointed out separately. Some of the illustrations and features in this
manual may differ from your model and are for guidance only.
Your operating system (Microsoft Windows XP or Windows Vista) has already been preinstalled and
optimally configured so that you can be up and running from the moment you switch on your AMILO
for the first time.
Your notebook features the very latest technology so that you get the best performance from your
computing experience. Depending on which model you own, you have access to:
●up to 2 or 4 GB of main memory (RAM). Please contact our Technical Support for information
on approved memory modules.
●a multi-format DVD drive with double layer support or, depending on the device, a multi-format-
DVD drive with double layer support and Label Flash for playing back DVD films or writing
CDs/DVDs
●an S-Video Out socket for connecting your notebook to your television
●a FireWire port for connecting high speed devices such as digital camcorders
●several USB ports which provide easy expansion with webcams, game pads, printers and more
●an internal modem, LAN or wireless LAN for Internet access
●an ExpressCard slot for operating an ExpressCard/34 or ExpressCard/54
●a memory card slot for transferring digital photos, music and videos quickly onto your notebook.
●an onboard audio controller and two stereo loudspeakers for your audio enjoyment
●You can even connect a microphone and external loudspeakers to obtain an even better output
level.
With the user-friendly BIOS Setup Utility you can control your notebook’s hardware and protect your
system better against unauthorised access by using the powerful password protection properties.
Among other things, this operating manual tells you how to prepare your AMILO for use, and how to
operate it in daily use.
Do you need more information?
An overview with further information about your notebook can be found in "Information sources".
10600718731, edition 1 1

Innovative technology...
Notational conventions
The following notational conventions are used in this manual:
Indicates information which is important for your health, the operability of
your notebook or the safety of your data. Faults on the notebook caused by
your failure to follow the instructions will invalidate your warranty.
!
Indicates important information which is required to use the system properly.
i
►Texts which follow this symbol describe activities that must be performed.
This font indicates screen outputs.
This font indicates programme names, commands, or menu items.
"Quotation marks" indicate names of chapters, hard disks, CDs, DVDs, and terms that are
being emphasised.
210600718731, edition 1

Ports and operating elements
This chapter presents the individual hardware components of your notebook. It provides an overview
of the notebook’s displays and ports. Please familiarise yourself with these components before you
start to work with your notebook.
23
22
1213
17
18
10
11
9
19
20
21
11
24
25
26
4
6
5
7
8
1615
14
321
16
15 = Memory card slot
1 = DC IN jack
16 = Built-in microphone
2 = Monitor port DVI-I
17 = Headphones/SPDIF port
(loudspeaker port / line out)
3 = S-Video out socket
4 = USB ports
18 = Microphone port/ line In
5 = FireWire port
19 = CD/DVD drive
6 = LAN port
20 = Modem port
7 = USB ports
21 = Kensington Lock
8 = ExpressCard slot
22 = Service compartment (hard disk)
9 = Easy Launch keys
23 = Service compartment (memory)
10 = ON/OFF switch of the Notebook
24 = Battery release
11 = Built-in loudspeakers
25 = Battery
12 = Touchpad
26 = Battery release
13 = Touchpad buttons
14 = Status indicators
10600718731, edition 1 3

Ports and operating elements
410600718731, edition 1

Important notes
Here you will find essential safety information regarding your notebook. The other notes provide
helpful information on your notebook.
Safety notes
!
Pay attention to the information provided in the "Safety" manual and in the following safety
notes.
Observe the sections in the manual marked with the symbol on the left.
●When connecting and disconnecting cables, observe the relevant notes in this operating
manual.
●Read the information on the ambient conditions in "Technical data" and "Technical data" before
preparing your notebook for use and switching it on for the first time.
●When cleaning the device, please observe the relevant notes in "Cleaning the notebook".
●If you have a notebook with a wireless component, you must also observe the additional safety
precautions for devices with wireless components in the "Safety" manual.
This notebook complies with the relevant safety regulations for data processing equipment. If you
have questions about using your notebook in a particular area, please contact your sales outlet or
our Hotline/Help Desk.
Energy saving
Switch the notebook off when it is not in use.
Make use of the available energy saving functions (see "Working with the notebook"). The notebook
uses less energy when the available energy saving functions are used. You will then be able to work
for longer before having to recharge the battery.
Energy saving under Windows
If a monitor with energy saving features is connected to your notebook, you can use the Screen Saver
tab to activate the energy saving features of the monitor. Select a screen saver via Start – Control
Panel – Appearance and Themes – Display – Screen Saver.
You may set further energy saving functions in the menu Start – Control Panel – Performance and
Maintenance – Power Options.
10600718731, edition 1 5

Important notes
Information sources
Detailed instructions and technical information for your notebook are contained in this "EasyGuide"
manual. The manuals are only available as PDF files. If you connect a printer to your notebook, you
can print out the manuals.
Information Source Type of Information Where?
Quick Start Guide
(printed)
Poster with information about
getting started
Accessories kit
"Safety" manual (printed
and/or PDF file)
Safety notes Accessories kit and/or on your
notebook
"EasyGuide" manual
(PDF file)
Detailed instructions for startup,
operation and technical
information
"Wireless LAN" manual
(PDF file)
Detailed instructions on using
wireless LAN and technical
information
"Warranty" manual (PDF
file)
General warranty conditions
Information files (e.g.
*.TXT,T*.DOC, *.CHM,
*.HLP)
Information on utilities and
programmes
The manuals are located on your
notebook under
Start – Manuals
or, in some cases, updated
versions can be found on the
Internet at:
www.fujitsu-siemens.com/support/
"Recovery Process"
manual (PDF file)
Information on restoring the
operating system, drivers,
manuals and special software
Information files (e.g.
*.TXT,
Information about Bluetooth In the software for these
applications
T*.DOC, *.CHM,
*.HLP)
610600718731, edition 1

Important notes
Travelling with your notebook
Please observe the points listed below when travelling with your notebook.
Before you travel
●Back up important data stored on your hard disk.
●Switch off the radio component for data security reasons. With data traffic via a wireless
connection, it is also possible for unauthorised third parties to receive data.
i
Information on activating data encryption is provided in the documentation for your radio
component.
●If you wish to use your notebook during a flight, first check with the flight attendants if it is OK to
do so.
When travelling in other countries
●If you are travelling abroad, check that the mains adapter can be operated with the local mains
voltage. If this is not the case, obtain the appropriate mains adapter for your notebook.
Do not use any other voltage converter!
●Check whether the local power supply and the specifications of the power cable are
compatible. If this is not the case, buy a power cable that matches the local conditions. Do not
use a connection adapter for electrical devices to connect the notebook.
●Enquire with the corresponding government office of the country you will be travelling in as to
whether you may operate the radio component integrated in your notebook there (also see "CE
marking").
●If you use a modem, incompatibilities with the local telephone system may arise. This may
result in poor performance, or the modem may not work at all.
You may require a country-specific telephone adapter (available as an accessory).
Transporting the notebook
●Remove all data carriers (e.g. CD, DVD) from the drives.
●Switch the notebook off.
●Unplug the mains adapter and all external devices from the power socket.
●Disconnect the mains adapter cable and the data cables for all external devices.
●Close the LCD screen so that it locks into place.
●To protect against damaging jolts and bumps, use a notebook carrying case to transport your
notebook.
●Protect the notebook from severe shocks and extreme temperatures (e.g. direct sunlight in a
car).
10600718731, edition 1 7

Important notes
Cleaning the notebook
►Switch the notebook off.
►Unplug the mains plug of the mains adapter from the mains socket.
►Remove the battery (see "Removing the battery").
Do not clean any interior parts yourself; leave this job to a service technician.
Only use cleaning products designed for computers. Normal household cleaners and
polishes can damage the markings on the keyboard and the device, the paintwork or the
notebook itself.
Ensure that no liquid enters the notebook.
!
The Crystal View display is very sensitive to scratching! Only clean the display surface with
a very soft, slightly damp cloth.
Wipe the casing with a dry cloth.
If particularly dirty, use a cloth which has been moistened in mild domestic detergent and then
carefully wrung out.
To clean the keyboard and the touchpad, you can use disinfectant wipes.
810600718731, edition 1

Preparing your notebook for use
!Please read "Important notes".
Before you can use your notebook for the first time you need to charge the battery and install the
supplied software. The Windows operating system and drivers required are already pre-installed.
Upon delivery, the battery can be found in the battery compartment. The battery must be charged if
you want to operate your notebook with the battery.
When not plugged into a mains outlet, the notebook runs on its built-in battery. You can increase the
battery's life by enabling the system's energy saving functions.
If you use the notebook in at home or in an office, we recommend you use the mains adapter instead
of the battery.
Please refer to "Connecting external devices" for instructions on how to connect devices such as a
mouse and a printer to the notebook.
Unpacking and checking your notebook
►Unpack all the individual parts.
►Check your notebook for damage incurred during transportation.
Should you discover any damage incurred during transportation, notify your local sales
outlet immediately!
!
We recommend that you keep the original packaging material.
i
You may need the packaging in the future if you need to return your device.
10600718731, edition 1 9

Preparing your notebook for use
Selecting the location
Select a suitable location for the notebook before setting it up. Consider the following
points when selecting a location:
!●Never place the notebook on a soft surface (e.g. carpeting, upholstered furniture,
bed). This can block the air vents and cause overheating and damage.
●Do not place the notebook on your legs for a long period of time. The underside of
the notebook heats up during normal operation. Prolonged contact with the skin can
become unpleasant or may even cause burns.
●Place the notebook on a stable, flat, nonslippery surface. Please note that the rubber
feet may mark certain types of surfaces.
●Keep other objects 100 mm away from the notebook and its mains adapter to ensure
adequate ventilation.
●Never cover the ventilation slots of the notebook or the mains adapter.
●Do not expose the notebook to extreme environmental conditions.
Protect the notebook against dust, humidity and heat.
Connecting the mains adapter
Please note the information in "Safety notes".
!The power cable supplied conforms to the requirements of the country in which you
purchased your notebook. Make sure that the power cable is approved for use in the
country in which you intend to use it.
The mains adapter's power cable should only be connected to a mains socket if the
notebook is connected to the mains adapter.
Make sure that the rated current of the mains adapter is not higher than that of the power
system to which you connect it (see technical data for the mains adapter).
►Connect the mains adapter cable (1) to the
DC jack (DC IN) on the notebook.
1
2
3
►Plug the power cable (2) into the mains
adapter.
►Plug the power cable (3) into a mains
outlet.
10 10600718731, edition 1
