LifeBook P1610
Fingerprint Sensor Replacement
ESD Precautions are required when working on this LifeBook computer.
Make sure the LifeBook is turned off before beginning this procedure.
1. Turn the LifeBook over and
remove the battery
3. Extract 8 screws from the front of
the display.
2. Remove 8 screw covers from the
front of the display.
4. Using the plastic pry tool pry
around the perimeter of the display
to release the front cover from the
rear.

5. Gently slide the pry tool between
the screen and the front cover to
release the tape.
7. Extract 2 screws from the
Fingerprint Sensor board.
9. Connect the cable to the new
Fingerprint Sensor board and place it
into the rear cover.
11. Press the front cover into place
and secure it with 8 screws.
6. Lift the front cover off.
8. Disconnect the cable from the
board and lift it out.
10. Secure it with 2 screws.
12. Place 8 screw covers over these
screws.

13. Lift the display up and turn it
around.
15. Replace the battery.
14. Lay it back down and turn the
LifeBook over.
