Fujitsu FTR-G1 Series User guide

1
FTR-K1 SERIES
FEATURES
Compact for high density packaging
High contact capacity with proven contact material (min.
100,000 operations, 14V, 25A)
Coil power savings (640mW nominal achived with state-of-
the-art magnetic analysis/design)
Ease of PCB layout (all terminals on perimeter, coil and
contact terminals separated)
Lower noise (57dB average at 5cm)
RoHS compliant
Please see page 5 for more information
Actual marking does not carry the type name: "FTR"
E.g.: Ordering code: FTR-G1CN010W1 Actual marking: G1CN010W1
FTR-G1 Series
COMPACT POWER RELAY
1 POLE - 25A (For Automotive Applications)
PARTNUMBER INFORMATION
FTR-G1 C N 010 W1
[Example] (a) (b) (c) (d) (e)
APPLICATIONS
Power window Power seat
Door lock Wiper/IWW
Tilt steering Retractable antenna
Sunroof
(a) Relay type FTR-G1: FTR-G1 Series
(b) Contact configuration C : 1 form C
(c) Contact gap N : 0.25mm
(d) Coil rated voltage 010 : 9....12VDC
Coil rating table at page 3
(e) Contact material W1 : Silver-tin oxide indium

2
FTR-K1 SERIES
* 1 Need to consider the heat to PCB when max. current is more than 10A
* 2 Minimum switching loads mentioned above are reference values. Please perform the confirmation test with actual
load before production since reference values may vary according to switching frequencies, environmental conditions
and expected reliability levels.
FTR-G1 SERIES
SPECIFICATION
Item FTR-G1
Contact
Data
Configuration 1 form C
Material Silver-tin oxide indium (AgSnO2)
Contact voltage drop Max. 100mV at 1A, 6VDC (after stabilization)
Contact rating 25A at 14VDC (locked motor load)
Max. carrying current *125A/1 hour (25 °C, 100% rated coil voltage)
Max. switching voltage 16VDC (reference)
Max. switching current 35A (reference)
Min. switching load * 21A, 6VDC
Life Mechanical Min. 1 x 106operations
Electrical
* Min. 100 x 103operations,
14VDC, 25A inrush power window motor
(1 operation: 1 forward and 1 reverse)
* Min. 100 x 103operations
14VDC, 20A inrush door locked motor
Coil Data Rated power 640mW
Operate power 237mW
Operating temperature range -40 °C to +85 °C (no frost)
Timing Data Operate (at nominal voltage) Max. 10 ms (without bounce)
Release (at nominal voltage) Max. 5 ms (without bounce, no diode)
Insulation Resistance (initial) Min. 100MΩat 500VDC
Dielectric withstanding
voltage
Open contacts 500VAC , 1 min.
Between coil
and contacts 500VAC, 1 min.
Other Vibration resistance Misoperation 10 to 55Hz double amplitude 1.5mm
Shock Misoperation 100m/s² minimum (10G)
Endurance 1,000m/s² minimum (100G)
Weight Approximately 3.5 g
Sealing Plastic sealed cat III

3
FTR-K1 SERIES
FTR-G1 SERIES
REFERENCE DATA
COIL RATING
Coil
Code
Rated Coil
Voltage (VDC)
Coil Resistance
+/- 10% (Ohm)
Must Operate Voltage
(VDC) *
Must Release Voltage
(VDC) *
Coil Power at
Nominal Voltage
(W)
009 9 126 5.4 0.75
0.64
6.8 (at 85 °C)
010 10 160 6.5 0.8
8.2 (at 85 °C)
012 12 225 7.3 1
9.2 (at 85 °C)
Note: All values in the table are valid for 20°C and zero contact current, unless otherwise indicated.
* Specified operate values are valid for pulse wave voltage.

4
FTR-K1 SERIES
FTR-G1 SERIES
DIMENSIONS
SchematicsMounting hole layout
(bottom view)
Marking (example)
Tube
Unit: mm

5
FTR-K1 SERIES
FTR-G1 SERIES
1. General Information
All automotive relays produced by Fujitsu Components are compliant with RoHS directive 2002/95EC
including amendments.
Cadmium as used in electrical contacts is exempted from the RoHS directives on October 21st, 2005.
(Amendment to Directive 2002/95/EC)
All our automotive relays are lead-free.
Lead free solder plating on relay terminals is Sn-3.0Ag-0.5Cu, unless otherwise specified.
This material has been verified to be compatible with PbSn assembly process.
2. Recommended Lead Free Solder Profile
Recommended solder Sn-3.0Ag-0.5Cu.
RoHS Compliance and Lead Free Information
3. Moisture Sensitivity
Moisture Sensitivity Level standard is not applicable to through hole mounted electromechanical relays, unless
otherwise indicated.
4. Tin Whiskers
Dipped SnAgCu solder is known as presenting a low risk to tin whisker development. No considerable length
whisker was found by our in house test.
We highly recommend that you confirm your actual solder conditions
Flow Solder condition:
Pre-heating: maximum 120˚C
Soldering: dip within 5 sec. at
260˚C solder bath
Solder by Soldering Iron:
Soldering Iron
Temperature: maximum 360˚C
Duration: maximum 3 sec.

6
