Fulbat FLTX20HL User manual

FULBAT - www.fulbat.com
Release 2020-03
EN 2-5
DE 18-21 FR 6-9
NL 14-17
IT 10-13 ES 22-25
LITHIUM ION STARTER BATTERY

FULBAT - www.fulbat.com 2
EN PRODUCT INSTRUCTION SHEET
FEATURES
• Ultrahigh rate Lithium Iron Phosphate battery technology.
• Ultra light weight- 1/3 of normal lead-acid battery.
• Low self-discharge,it can be used in a vehicle after one year’s storage.
• Excellent Cycle life-over 1000 cycles under 1C standard(lead acid battery only
100-200cycles).
• Highly Safety-Lithium Iron Phosphate material and soft pack process ensure the
safety performance.
• Signicant Energy Efciency-high and stable voltage stage improve rapidly the action
efciency of spark plug which reach fuel-efcient.
• Can be installed in any direactions, no need to worry about the leakage.
WARNINGS
• Please strictly follow the instructions, Do not make the battery short circuit, otherwise
the battery may smoke, re and even endanger personal safety!
• Do not use the battery in combination with primary batteries(such as dry cell
batteries) or batteries of different capacity, type, or brand.
• Do not try to take apart the battery! Do not touch the battery directly if the electrolyte leaks.
The electrolyte may harm skin&eyes. If skin contact occurs, wash skin immediately with soap
and water. If eye contact occurs, ush immediately with water and get prompt medial help.
CHARGING
• The new battery can be used directly if the voltage is above 13V. If you want fully
charge the battery before using, a conventional lead-acid battery 12V charger(with
out pulse charging fuction) or a specially designed LiFePO4 battery charger can be
used for charging.
• Both vehicle and battery charger need to limit voltage between 14.0-14.8 volts when
charging. The battery can not be full charged if charging voltage is less than 14.0
volts, and the battery would be damaged if the charging voltage is over 14.8 volts.
• Always remove the battery from the vehicle before charging separately.
• Charge the battery with a lower current than the MAX Charging Current.
• After charging, leave the battery for 1 to 2 hours before checking the voltage. If the

FULBAT - www.fulbat.com 3
voltage is less than 13.0 volts, additional charging is necessary.
• If the battery becomes hot to the touch, stop charging. Allow battery to cool before
resuming.
INSTALLATION
• Please check the battery voltage before installing; if the voltage is lower than 13V,
charge the battery see charging section
• Make sure the charging system of your motorcycle is normal.
• Remove the original battery from your motorcycle.
• Compare the original battery with the new one; if
the new battery is smaller in any directions(len-
gth,width,height),use the self-adhesive foam to adjust
the battery size, so that the new battery ts the vehicle’s
battery box (reference Figs).
• In order to save the materials, please cut the self-ad-
hesive foam into small pieces, and then stick it to the
battery, that makes the battery achieve better heat
dissipation effect.
• Connect correctly the positive and negative leads.
USAGE
• Verify that the correct size LifePO4 Lithium Iron battery has been chosen.
• Do not engage your starter for longer than 5 seconds per try. Allow adequate time
between starting intervals (at least 5 seconds). Also make sure that your vehicle
is in a proper state of tune, as this will drastically shorten the starting time draw
on the battery.
• Try to avoid keeping the vehicle light on for any extended period of time while the
engine is not running.This will help prevent over discharging.
• If the vehicle is going to be stored for an extend period (more than 7 days), we suggest
removing the battery to lower the discharge rate. Vehicles installed with anti-theft
device will discharge the battery faster.
• The performance of the battery may be inuenced by the low temperature environ-
ment. For instance, When used under 0°C, it should be preheated for 1~2minutes
by turning on the headlamp, and then the vehicle can be started. In this way, a
better starting performance can be achieved and a longer battery service life
will be maintained.
Self-adhesive
Foam for sizing

FULBAT - www.fulbat.com 4
• The vehicle which used LifePO4 battery should avoid using or storing in hot tempe-
rature environment for a long time, especially do not expose the vehicle in the sun
too long (over a few hours), otherwise the battery’s service life will be shortened.
The battery needs no special maintenance if the vehicle with good power supply
system that is working properly.
STORAGE
• The battery should be stored with 70% charge state(approx).
• The battery will be damaged at high temperture or humid environment for long time
storage. It should be stored in dry and ventilated environment, and the storage
temperaure should be lower than 25°C(77),the suitable warehouse temperature is
0°C~25°C; this can help to maixmize the battery’s storage life.
• If the ambient temperature for long-term storage(>30days) is higher than 40°C, it
may certainly shorten the battery storage life; if higher than 55°C,the battery may
be damaged and will not be covered under warranty.
• The battery should be charged completely once every 180 days when in storage.
TRANSPORTATION
• The battery should be packed with insulation and shockproof material to avoid damage
from sudden jolts a collision.
• The battery should be handled with care when loading and unloading during trans-
portation. Do not throw the batteries and avoid collision.
• Do not transport the batteries together with ammable, explosive objects,or sharp
metal goods.
MAINTENANCE
• Disconnect the battery cable is always the best choice if the vehicle is in storage or
used infrequently. Or use a standard maintainer or charger to maintain the battery.
Or regular charging the battery.
• If the battery stands by any period of time, check the voltage in case lower12.8 volts,
charge the battery(see charging section).
• Keep the connecting poles clean and securely fastened.
• The battery is factory sealed and requires no topping up of any uid. Never attempt
to open the battery.

FULBAT - www.fulbat.com 5
CAUTIONS
• Do not make the battery terminal short circuit or reverse connected!
• Do not connect the battery with a power socket directly.
• Do not put the battery into a re or apply direct heat to it.
• Do not use more than one battery in parallel or in series.
• Do not press on indicator button longer than three seconds.
• Do not use the battery if it gives off an odor, generates heat,becomes discolored or
deformed,or appears abnormal in any way. If the battery is in use or being recharged,
remove it from the deivce or charger immediately and discontinue use.
• Please x the battery terminal with original screws and nuts securely. Battery and
even vehicle may be damaged by the sparks because of the loose connect.
• Do not open or damage the battery case.
• Do not drop the battery into water or moisten the battery.
• Avoid impacting,throwing,twisting the battery.
• Keep the battery away from chirdren and pets.
• Do not allow discharge below 12.8V(resting voltage).
• Do not allow charge voltage in excess of 14.8V.
OTHERS
• FULBAT shall not be liable for any unforeseen events arising out of the operation of
the foregoing instructions.
