Fulgor Milano F4DWT24DS1 User manual
EN
USER 0$18$/
F4DWT24DS1
F4DWS24SS1
',6+:$6+(5
4.1. General Appearance...................................................................................................... 9
USA-CAN - 4
• The cup racks are designed to support cups, glasses and kitchen
utensils. When the cup racks are in the dishwasher do not lean on
or use the cup racks to support your body weight.
• This appliance must be grounded. In the event of a malfunction or
breakdown, grounding will reduce the risk of electric shock by
providing a path of least resistance for electric current. This
appliance is equipped with a cord having an equipment grounding
conductor and a grounding plug. The plug must be plugged into an
appropriate outlet that is installed and grounded in accordance with
all local codes and ordinances.
WARNING:
Improper connection of the equipment grounding conductor can
result in a risk of electric shock. Check with a qualied electrician or
service representative if you are in doubt whether the appliance is
properly grounded. Do not modify the plug provided with the
appliance, if it will not t the outlet, have a proper outlet installed by
a qualied electrician.
• Some dishwasher detergents are strongly alkaline. They can be
extremely dangerous if swallowed. Avoid contact with the skin and
eyes and keep children and inrm persons away from the
dishwasher when the door is open.
Consult a doctor immediately if detergent has been swallowed or
inhaled.
• Do not remove the dishes from the appliance until the program is
complete. Some detergent may remain on the dishes.
• Check that the detergent dispenser is empty after the completion
of each wash program.
appliance.
SAVE THESE INSTRUCTIONS
USA-CAN - 8
3. INSTALLATION
WARNING: When installing the dishwasher, follow basic
precautions, including the following:
Please check the standards and local codes for placement of
machine.
• Installation, maintenance and repair should be performed by a
qualied installer. Work by unqualied persons could be dangerous
and may void the warranty.
• Do not operate the appliance if damaged, malfunctioning, partially
disassembled or if it has missing or broken parts.
• Before installation or service, disconnect the power supply to the
work area by unplugging the unit, “tripping” the circuit breaker or
removing the fuse.
• Only connect the dishwasher to the power supply when all
installation and plumbing work is complete.
• Never connect the ground wire to gas lines, or hot water pipes,
plumbing lines.
• Do not install or store the dishwasher where it can be exposed to
below freezing temperatures or exposed to weather.
• Dishwasher must be secured to adjacent cabinetry using the
brackets provided. Failure to do this may cause damage to property
or bodily injury.
• Connect to a properly rated, protected and sized power supply
circuit to avoid electrical overload. The dishwasher is designed for
an electrical supply of 120 V (volts), 60 Hz (hertz),
AC, connected to a dishwasher dedicated, properly grounded
electrical circuit with a fuse or breakers rated for 15 amperes.
Electrical supply conductors shall be a minimum of # 16 AWG
copper wire rated at 75 °C (167 °F) or higher. These requirements
must be met to prevent injury and machine damage. Consult a
qualied electrician if in doubt.
• Do not use any extension cord or portable outlet device to connect
the dishwasher to a power supply.
WARNING: Danger of suocation! Ensure that any plastic
wrappings, bags, small pieces etc. are disposed of safely and kept
out of the reach of children.
1
2
4
5
3
8
6
7
9
1
2
3
4
5
6
1
1
1
1
2
3
4
5
6
3 4
1 2
cleaning.
•
1
2
3
4
5
USA-CAN - 17
6.1 Upper Rack
Load the upper rack with dessert plates,
cups, glasses etc.
Top rack load pattern for 10 place settings.
Additional Loading Pattern 12 place settings
6.2. Lower Rack
You can load into the lower basket such
round and deep items as pots with long
handles, pot lids, plates, salad plates,
cutlery sets. The lower rack should not be
used for small items such as cups, wine
glasses.
Bottom rack load patterns for 10 place
settings.
