1 General information
This manual contains important instructions for the safe operation of the unit. Read and follow
the safety instructions and all other instructions. Keep the manual for future reference. Make
sure that it is available to all those using the device. If you sell the unit please make sure that
the buyer also receives this manual.
Our products are subject to a process of continuous development. Thus, they are subject to
change.
General information
4Colour Burst
LED flower effect

1.1 Further information
On our website (www.thomann.de) you will find lots of further information and details on the
following points:
Download This manual is also available as PDF file for you to download.
Keyword search Use the search function in the electronic version to find the topics of
interest for you quickly.
Online guides Our online guides provide detailed information on technical basics
and terms.
Personal consultation For personal consultation please contact our technical hotline.
Service If you have any problems with the device the customer service will
gladly assist you.
General information
Colour Burst 5
LED flower effect

1.2 Notational conventions
This manual uses the following notational conventions:
The letterings for connectors and controls are marked by square brackets and italics.
Examples: [VOLUME] control, [Mono] button.
1.3 Symbols and signal words
In this section you will find an overview of the meaning of symbols and signal words that are
used in this manual.
Letterings
General information
6Colour Burst
LED flower effect

Signal word Meaning
DANGER! This combination of symbol and signal word indicates an
immediate dangerous situation that will result in death or
serious injury if it is not avoided.
WARNING! This combination of symbol and signal word indicates a pos-
sible dangerous situation that can result in death or serious
injury if it is not avoided.
NOTICE! This combination of symbol and signal word indicates a pos-
sible dangerous situation that can result in material and
environmental damage if it is not avoided.
Warning signs Type of danger
Warning – high-voltage.
Warning – suspended load.
General information
Colour Burst 7
LED flower effect

Warning signs Type of danger
Warning – danger zone.
General information
8Colour Burst
LED flower effect

2 Safety instructions
This device is intended to be used as an electronic illumination effect using LED technics. The
device is designed for professional use and is not suitable for use in households. Use the
device only as described in this user manual. Any other use or use under other operating con-
ditions is considered to be improper and may result in personal injury or property damage. No
liability will be assumed for damages resulting from improper use.
This device may be used only by persons with sufficient physical, sensorial, and intellectual
abilities and having corresponding knowledge and experience. Other persons may use this
device only if they are supervised or instructed by a person who is responsible for their safety.
Intended use
Safety instructions
Colour Burst 9
LED flower effect

DANGER!
Danger for children
Ensure that plastic bags, packaging, etc. are disposed of properly and are not
within reach of babies and young children. Choking hazard!
Ensure that children do not detach any small parts (e.g. knobs or the like) from
the unit. They could swallow the pieces and choke!
Never let children unattended use electrical devices.
DANGER!
Electric shock caused by high voltages inside
Within the device there are areas where high voltages may be present. Never
remove any covers.
There are no user-serviceable parts inside.
Do not use the device if covers, protectors or optical components are missing or
damaged.
Safety
Safety instructions
10 Colour Burst
LED flower effect

WARNING!
Eye damage caused by high light intensity
Never look directly into the light source.
WARNING!
Risk of epileptic shock
Strobe lighting can trigger seizures in photosensitive epilepsy. Sensitive persons
should avoid looking at strobe lights.
NOTICE!
Risk of fire
Do not block areas of ventilation. Do not install the device near any direct heat
source. Keep the device away from naked flames.
Safety instructions
Colour Burst 11
LED flower effect

NOTICE!
Operating conditions
This device has been designed for indoor use only. To prevent damage, never
expose the device to any liquid or moisture. Avoid direct sunlight, heavy dirt, and
strong vibrations.
NOTICE!
External power supply
The device is powered by an external power supply. Before connecting the
external power supply, ensure that the input voltage (AC outlet) matches the
voltage rating of the device and that the AC outlet is protected by a residual cur-
rent circuit breaker. Failure to do so could result in damage to the device and pos-
sibly the user.
Unplug the external power supply before electrical storms occur and when the
device is unused for long periods of time to reduce the risk of electric shock or
fire.
Safety instructions
12 Colour Burst
LED flower effect

3 Features
Compact effect spotlight for large-area RGB dot rotation effects.
n3 × 3 W LEDs (RGB)
nControl via supplied remote control
nPreprogrammed automatic shows
nSound control
n12 V power supply included
Features
Colour Burst 13
LED flower effect

4 Installation
Unpack and carefully check that there is no transportation damage before using the unit. Keep
the equipment packaging. To fully protect the device against vibration, dust and moisture
during transportation or storage use the original packaging or your own packaging material
suitable for transport or storage, respectively.
WARNING!
Risk of injury caused by falling objects
Make sure that the installation complies with the standards and rules that apply
in your country. Always secure the device with a secondary safety attachment,
such as a safety cable or a safety chain.
Installation
14 Colour Burst
LED flower effect

NOTICE!
Risk of overheating
Always ensure sufficient ventilation.
The ambient temperature must always be below 40 °C (104 °F).
NOTICE!
Use of stands
When mounting the device onto a stand, ensure that the stand is in a safe and
stable position and that the weight of the device does not exceed the maximum
permissible load capacity of the stand.
Installation
Colour Burst 15
LED flower effect

NOTICE!
Possible data transmission errors
For error-free operation make use of dedicated DMX cables and do not use ordi-
nary microphone cables.
Never connect the DMX input or output to audio devices such as mixers or ampli-
fiers.
You can install the device in either the hanging or standing position. During use, the device
must always be attached to a solid surface or to an approved support. Use the openings pro-
vided on the bracket for attaching.
Always work from a stable platform whenever installing, moving or servicing the unit. In doing
so, the area underneath the device must be cordoned off.
The safety-rope must be attached to the bracket.
Options
Installation
16 Colour Burst
LED flower effect

Please note that this device must not be connected to a dimmer.
Installation
Colour Burst 17
LED flower effect

5 Connections and operating elements
Connections and operating elements
18 Colour Burst
LED flower effect

1 Mounting bracket.
2 Locking screws for the mounting bracket.
3 Sensor for the signals from the included remote control.
4[MIC]
Built-in microphone for sound-controlled operation.
5[MICROPHONE SENSITIVITY]
Control to adjust the sensitivity of the built-in microphone.
6[12 V =]
Connection socket for the supplied 12 V power adapter.
Connections and operating elements
Colour Burst 19
LED flower effect

6 Operating
The unit functions are only controlled by the included remote control. The unit is ready for use
as soon as the supplied 12 V power supply is plugged into the unit and connected to a
grounded mains socket.
To use the remote control, point its infrared diode at the infrared sensor on the unit and press
the desired buttons.
Operating
20 Colour Burst
LED flower effect
