FUNAI DBVR-5700 User manual

EN
Printed in China
DVD/CD PLAYER & VIDEO
CASSETTE RECORDER
DBVR-5700
Owner’s Manual
Table of Contents
Precautions ...........................................................................2
LASER SAFETY ..................................................................2
IMPORTANT........................................................................2
POWER SUPPLY ................................................................2
DEW WARNING ..................................................................2
CAUTION.............................................................................2
Positioning ...........................................................................2
Connection to Power............................................................3
A Note about Recycling .......................................................3
Playable Discs .....................................................................4
Unplayable Discs .................................................................4
Important Copyright Information ..........................................4
Symbols Used in this Manual...............................................4
Functional Overview ............................................................5
Front Panel ..........................................................................5
Display .................................................................................5
Remote Control....................................................................6
Loading Batteries.................................................................6
VCR/DVD Switching ............................................................6
Rear View ............................................................................7
Setting up Your DVD/VCR....................................................7
Before Connecting ...............................................................7
Connecting to a TV ..............................................................7
For Better Sound (for DVD Features) ..................................8
External Input Mode (for VCR Features) .............................9
Video Cassette Tape ...........................................................9
TV Colour System................................................................9
Video Channel Setting .........................................................9
Setting the Clock................................................................10
Channel Presetting ............................................................10
Automatic Channel Preset .................................................10
Manual Channel Preset .....................................................11
To Skip a Preset Channel..................................................11
Channel Reprogramming...................................................11
VCR Operation ....................................................................12
VCR Features ....................................................................12
Playback ............................................................................12
Recording...........................................................................13
Hi-Fi Stereo Sound System ...............................................13
OTR (One Touch Recording).............................................14
Auto Repeat Playback .......................................................14
Picture Select.....................................................................14
Automatic Operations ........................................................14
Real Time Tape Counter....................................................15
Supplied Accessories
• Remote control
• Two R6 (AA) batteries
•RFcable
• Scart cable
•Owner’sManual
Timer Recording................................................................ 15
Auto Return ....................................................................... 16
Quick-Find......................................................................... 16
Index Search ..................................................................... 16
Time Search...................................................................... 16
Recording from DVD to VCR ............................................ 16
Copying a Video Tape....................................................... 17
Status Display ................................................................... 17
DVD Operation ................................................................... 18
Basic Playback.................................................................. 18
Disc Menus ....................................................................... 18
Title Menu ......................................................................... 18
Calling up a Menu Screen During Playback...................... 18
About the PBC Function of Video CD ............................... 18
MP3 Playback .................................................................. 18
Resume............................................................................. 19
Pause ................................................................................ 19
Step by Step Playback ...................................................... 19
Fast Forward / Reverse Search ........................................ 19
Slow Forward / Reverse.................................................... 19
Zoom ................................................................................. 19
Audio Language ................................................................ 19
Subtitle Language ............................................................. 20
Camera Angle ................................................................... 20
Stereo Sound Mode .......................................................... 20
Virtual Surround ................................................................ 20
Track Search..................................................................... 20
Title / Chapter Search ....................................................... 20
Time Search...................................................................... 21
Marker Setup..................................................................... 21
Repeat............................................................................... 21
Programmed Playback...................................................... 22
Random Playback ............................................................. 22
On-Screen Information...................................................... 22
DVD Setup .......................................................................... 23
Language Setting .............................................................. 23
Audio Setting..................................................................... 23
Display Setting .................................................................. 23
Parental Control ................................................................ 24
To Reset All the Settings of the SET UP screen............... 24
Troubleshooting Guide ..................................................... 26
Specifications .................................................................... 27
Maintenance ....................................................................... 27
Declaration of Conformity................................. Back Cover
Model/Serial Number
This appliance has a serial number located on the rear panel.
Please note down the serial number and retain the information
for your records.
Model number: DBVR-5700
Serial number:
PAL
FUN_H9701BD(EN).fm Page 1 Tuesday, July 27, 2004 5:57 PM

2EN
Precautions
.
LASER SAFETY
This unit employs a laser. Only a qualified service person
should remove the cover or attempt to service this device, due
to possible eye injury.
CAUTION: USE OF CONTROLS OR
ADJUSTMENTS OR
PERFORMANCE OF PROCEDURES
OTHER THAN THOSE SPECIFIED
HEREIN MAY RESULT IN
HAZARDOUS RADIATION
EXPOSURE.
CAUTION: VISIBLE LASER RADIATION WHEN
OPEN AND INTERLOCK
DEFEATED. AVOID EXPOSURE TO
BEAM.
LOCATION:
• PRINTED ON THE BACK
IMPORTANT
• Use only discs marked DVD or disc with this DVD.
• Use only cassettes with the VHS mark with this VCR.
POWER SUPPLY
The main power supply is engaged when the main plug is
plugged in a 220-240V, 50Hz AC outlet. To operate the unit,
press FUNCTION to turn on the unit.
WARNING:LIVE PARTS INSIDE.
DO NOT REMOVE ANY SCREWS.
DEW WARNING
Moisture condensation may occur inside the unit when it is
moved from a cold place to a warm place, or after heating a
cold room or under conditions of high humidity. Do not use
the DVD/VCR at least for 2 hours until its inside is dry.
CAUTION
1) Do not attempt to open the cabinet. There are no parts
you can service inside. Refer all servicing to qualified
service personnel.
2) Slots and openings in the cabinet and the sides or bottom
are provided for ventilation. To ensure reliable operation
and to protect the unit from overheating, these openings
must not be blocked or covered.
Avoid installation in enclosed spaces such as bookcases
unless proper ventilation is provided.
3) Keep the unit away from radiators and other heat sources.
4) Avoid use near strong magnetic fields.
5) Do not push objects of any kind into the DVD/VCR
through the cabinet slots or openings as they could touch
electrically live parts or short circuit parts resulting in a
fire or electric shock.
6) Never spill liquid on this unit. If liquid is spilled and
penetrates into the unit, consult qualified service
personnel.
7) Use this unit in a horizontal (flat) position only.
8) Before attempting to operate the unit, make sure that the
timer recording mode is “OFF”.
9) This product is in Stand-by mode when it turns off while
the power cord is connected.
10)Do not place any combustible objects on the device
(candles, etc.).
Positioning
• Do not place the DVD/VCR directly on top of, or
underneath, your TV set. Ensure that there is at least 20 cm
between the DVD/VCR and the TV set, and that air can
circulate freely through the ventilation openings of the
DVD/VCR.
WARNING:TO REDUCE THE RISK OF FIRE OR
ELECTRIC SHOCK, DO NOT
EXPOSE THIS APPLIANCE TO
RAIN OR MOISTURE.
CAUTION: TO REDUCE THE RISK OF
ELECTRIC SHOCK, DO NOT
REMOVE COVER (OR BACK). NO
USER SERVICEABLE PARTS
INSIDE. REFER SERVICING TO
QUALIFIED SERVICE
PERSONNEL.
The lightning flash with arrowhead symbol,
within an equilateral triangle, is intended to
alert the user to the presence of uninsulated
“dangerous voltage” within the product’s
enclosure that may be of sufficient magnitude
to constitute a risk of electric shock to
persons.
The exclamation point within an equilateral
triangle is intended to alert the user to the
presence of important operating and
maintenance (servicing) instructions in the
literature accompanying the appliance.
CAUTION
RISK OF ELECTRIC SHOCK
DO NOT OPEN
CLASS 1 LASER PRODUCT
KLASSE 1 LASER PRODUKT
KLASS 1 LASER APPARAT
CLASSE 1 PRODUIT LASER
FUN_H9701BD(EN).fm Page 2 Tuesday, July 27, 2004 5:57 PM

3EN
Connection to Power
Before Switching on make sure that the voltage of your
electricity supply is the same as that indicated on the rating
plate.
Mains Cord
This appliance may be fitted with a non-rewireable plug. If it
is necessary to change the fuse in a non-rewireable plug the fuse
cover must be refitted. If the fuse cover is lost or damaged, the
plug must not be used until a replacement available from the
appliance manufacturer is obtained.
It is important that the colour of the replacement fuse cover
corresponds with the rating marking on the base of the plug.
If the plug has to be changed because it is not suitable for your
socket, or becomes damaged, it should be cut off and an
appropriate plug fitted following the wiring instructions
below. The plug removed must be disposed of safely as
insertion into a 13A socket is likely to cause an electrical
hazard. For your own safety read the following instructions
carefully before attempting to connect this unit to mains.
The wires in this mains lead are coloured in accordance with
the following code:
BLUE=NEUTRAL, BROWN=LIVE
Important
As the colours of the wires in the mains lead of this appliance
may not correspond with the coloured markings identifying
the terminals in your plug, proceed as follows:-
The wire which is coloured blue must be connected to the
terminal which is marked with the letter N or coloured black.
The wire which is coloured brown must be connected to the
terminal which is marked with the letter L or coloured red.
No connection is to be made to the earth terminal of the plug.
If a 13 Amp (BS 1363) Plug is used, a 3 Amp Fuse must be
fitted, or if any other type of Plug is used a 3 or 5 Amp Fuse
must be fitted, either in the Plug or Adaptor, or on the
Distribution Board.
Mains Supply:220 - 240 V ~ 50 Hz - AC only
Do not make any connection to the larger pin marked with the
letter “E” or by the symbol or coloured green or green and
yellow.
A Note about Recycling
This product’s packaging materials are recyclable and can be
reused. Please dispose of any materials in accordance with your
local recycling regulations.
Batteries should never be thrown away or incinerated but
disposed of in accordance with your local regulations
concerning chemical wastes.
FUSE
BLUE
(Neutral)
BROWN
(Live)
CORD GRIP
OUTER SHEATH OF THE WIRE
FUN_H9701BD(EN).fm Page 3 Tuesday, July 27, 2004 5:57 PM

4EN
Playable Discs
The following discs can be played back on this unit.
• DVD video with region code 2 or ALL (*1, 2, 5, 7)
• DVD+R/RW (*1, 3, 4, 5, 6, 7)
• DVD-R/RW (*1, 3, 4, 5, 6, 7)
• Audio CD (*5, 7)
• CD-R/RW with MP3 files (*5, 6, 7)
• Video CD (*1, 5, 7)
• DTS-CD (*5, 7)
Note:
*1: This unit conforms to the PAL colour system. Also you can
play discs recorded with the NTSC system via a PAL
system TV set.
*2: The region code 2 or ALL are marked on DVDs as follows.
*3: Certain DVD-Video discs do not operate as described in
this manual due to the intentions of the disc's producers.
*4: Only the discs recorded in the video format and finalized
can be played back.
Depending on the recording status of a disc, the disc may
not be played back at all or normally (the picture or sound
may not be smooth, etc.).
*5: Scratched or stained discs may not be played back.
*6: Some discs cannot be played back because of incompatible
recording conditions, characteristics of the recorder or
special properties of discs.
*7: You can play back discs which bear marks above. If you use
nonstandardized discs, this unit may not play them back.
Even if they are played back, the sound or video quality
will be compromised.
Unplayable Discs
•On the following discs, only the sound can
be heard (picture cannot be viewed).
CDV
CD-G
•NEVER play back the following discs.
Otherwise, malfunction may result!
DVD-RAM
CD-I
Photo CD
DVD with region codes other than 2 or ALL
DVD-ROM for personal computers
CD-ROM for personal computers
•On the following disc, the sound MAY NOT
be heard.
Super Audio CD
Note: Only the sound recorded on the normal CD layer can
be delivered.
The sound recorded on the high density Super Audio
CD layer cannot be delivered.
• Any other discs without compatibility indications.
Important Copyright Information
DVD:
Unauthorized copying, broadcasting, public performance and
lending of discs are prohibited.
This product incorporates copyright protection technology
that is protected by method claims of certain U.S. patents and
other intellectual property rights owned by Macrovision
Corporation and other rights owners. Use of this copyright
protection technology must be authorized by Macrovision
Corporation, and is intended for home and other limited
viewing uses only unless otherwise authorized by Macrovision
Corporation. Reverse engineering or disassembly is
prohibited.
VCR:
Unauthorised recording or use of broadcast television
programming, video tape, film or other copyrighted material
may violate applicable copyright laws. We do not take
responsibility for the unauthorised duplication, use, or other
acts which infringe upon the rights of copyright owners.
Symbols Used in this Manual
The following symbols appear below in some headings and
notes in this manual, with the following meanings!
: Description refers to playback of DVD video discs.
: Description refers to playback of audio CDs.
: Description refers to playback of MP3 discs.
: Description refers to playback of video CDs.
: Description refers to the items to be set in the QUICK
mode.
2DVD-V
CD
MP3
VCD
QUICK
FUN_H9701BD(EN).fm Page 4 Tuesday, July 27, 2004 5:57 PM

5EN
Functional Overview
Front Panel
1. FUNCTION indicator
The indicator is on when this unit is turned on.
2. FUNCTION
To turn the unit ON or OFF.
3. Cassette Compartment
4. OPEN/CLOSE (DVD)
To open or close the disc tray.
5. Disc tray
6. PLAY (DVD)
To begin disc playback.
7. STOP (DVD)
To stop playback.
8. DVD OUTPUT indicator (Green)
The indicator is on when this unit is in the DVD mode.
Make sure that this indicator is on before using the DVD
player.
9. OUTPUT
To select the DVD mode or VCR mode.
10. VCR OUTPUT indicator (Green)
The indicator is on when this unit is in the VCR mode.
Make sure that this indicator is on before VCR
operation.
11. CHANNEL (VCR)
To change TV channels.
To adjust the tracking manually during playback.
12. Display
13. Remote Sensor
14. REC/OTR (VCR)
Press once to start recording or repeatedly to start One-
To u c h R e c o rd i n g .
15. PLAY (VCR)
To begin tape playback.
16. STOP/EJECT (VCR)
To stop playback.
To eject the tape in the Stop mode.
17. F.FWD (VCR)
To fast forward the tape.
18. REW (VCR)
To rewind the tape.
19. AUDIO in jacks
Connect audio cables coming from the audio out jacks of
a camcorder, another VCR, or an audio source here.
20. VIDEO in jack
Connect a cable coming from the video out jack of a
camcorder, another VCR, or an audio-visual source (laser
disc player, video disc player, etc.) here.
Display
OPEN/CLOSE
CHANNEL
VCR DVD
STOP PLAY
OUTPUT
FUNCTION
REW F.FWD PLAY REC/OTRSTOP/EJECT
VIDEO
L -AUDIO- R
12131415161718 9876101120 19
1 2 3 54
DVD-V
DVD
VCD
Lights up when the inserted
disc is being played back.
Displays a type of
disc on the tray.
• DVD : DVD disc
• CD : Audio CD, MP3
• VCD : Video CD
Lights up when the
inserted disc comes
to a pause.
Lights up when
the A-B repeat
function is on.
Lights up when
the playback is
in slow mode.
Lights up when
the repeat function is on.
Displays how long
the current title or
track has been
played back. When
a chapter or track is
switched, the number
of a new title, chapter
or track is displayed.
Lights up when
the ALL repeat
function is on.
No disc inserted or
displaying DVD menu
Playback control
function of a video
CD is activated
Opening the tray
Closing the tray
Loading the disc or
turning this unit on
VCR
Lights up when the inserted
cassette is being played
back.
Lights up when
the playback is
in still or slow mode.
Lights up during
playback when
the repeat function
is on.
Works as a tape counter(hour,minute,second).
Also displays a channel number,
tape speed, remaining time for OTR or
current time.
REC
Lights up
when a tape is
in the DVD/VCR.
Lights up during a recording.
Flashes when a recording
is paused.
Lights up when
the timer recording or an
OTR recording has been set.
FUN_H9701BD(EN).fm Page 5 Tuesday, July 27, 2004 5:57 PM

6EN
Remote Control
1. SPEED/SYSTEM (VCR)
To c h an ge th e rec ord in g s pe ed .
(Only the function of SPEED is available for this unit.)
2. FUNCTION
To turn the unit ON or OFF.
3. 0-9 number buttons
To select numbered items on the menu screen. /
To select chapters, titles or tracks directly. (DVD)
To select a channel. (VCR)
+10 (DVD)
To enter 10 and over.
4. DISPLAY
To display the current playback mode. (DVD)
To display the current time, tape counter and channel number.
(VCR)
5. VCR
Press this button before using the remote control for VCR
features.
6. h
To search backward through the disc. (DVD)
To rewind the tape. (VCR)
7. STOP
To stop playback. (DVD)
To stop playback or recording. (VCR)
8. REC/OTR (VCR)
Press once to start recording or repeatedly to start One-Touch
Recording.
9. MENU
To call up the main menu on a DVD. /
To call up the MP3 menu. (DVD)
To call up the VCR menu. (VCR)
10. TOP MENU (DVD)
To call up the title menu on a DVD.
11. SETUP (DVD)
To access or remove the DVD setup menu.
12. ZOOM (DVD)
To magnify the part of picture.
13. MODE (DVD)
To set up programmed or random playback for Audio CDs and
MP3 files.
To set the Virtual Surround ON or OFF.
14. SUBTITLE (DVD)
To change subtitles on a DVD.
T-SET (VCR)
To put the VCR into Standby mode for a timer recording.
15. ANGLE (DVD)
To change camera angles on a DVD.
16. REPEAT (DVD)
To play the selected chapter, title, track, group or a whole disc
repeatedly.
17. A-B (DVD)
To repeat between your chosen point A and B.
18. SEARCH MODE
To search chapters, titles, tracks, markers or time. (DVD)
To call up the index or time search menu. (VCR)
19. QUICK-FIND (VCR)
To skip to the beginning of next programme.
20. RETURN (DVD)
To return to the previous menu.
21. Arrow (s/ B/ K/ L)
To mov e the c urs or.
22. ENTER (DVD)
To confirm your menu selections.
23. g
To search forward through the disc. (DVD)
To fast forward the tape. (VCR)
24. PLAY
To begin playback.
25. DVD
Press this button before using the remote control for DVD
features.
26. PAUSE
To pa u s e p l a y b a c k . /
To advance playback one frame at a time. (DVD)
To pause playback or recording. / To advance playback one
frame at a time. (VCR)
27. SLOW (VCR)
To view the tape in slow motion.
28. CLEAR (DVD)
To clear the markers. / To clear the incorrect input.
C.RESET (VCR)
To reset the tape counter.
29. SKIP H G(DVD)
To skip chapters or tracks.
CH. K/L(VCR)
To change TV channels. / To adjust the tracking manually
during playback.
30. OPEN/CLOSE (DVD)
To open or close the disc tray.
EJECT (VCR)
To eject the tape from the VCR.
31. AUDIO
To change audio languages on a DVD. / To change sound
modes of a CD. (DVD)
To change sound modes. (VCR)
Loading Batteries
1) Open the battery compartment cover.
2) Insert two R6 (AA) batteries, with each one
oriented correctly.
3) Close the cover.
Note: • Do not mix alkaline and manganese
batteries.
•Do not mix old and new batteries.
VCR/DVD Switching
Note: Since this product comprises VCR and DVD players, it
is necessary to select the correct output mode.
SWITCHING TO VCR MODE
Press VCR on the remote control or OUTPUT on the front
panel. (Make sure that the VCR OUTPUT indicator is lit.)
SWITCHING TO DVD MODE
Press DVD on the remote control or OUTPUT on the front
panel. (Make sure that the DVD OUTPUT indicator is lit.)
Note: Pressing only OUTPUT on the front panel does not
switch the mode of the remote control. To change the
mode of the remote control, press VCR or DVD on the
remote control.
STANDBY-ON
AUDIO
PAUSE
SETUP
TOP MENU
ENTER
MENU
MODE
ZOOM
QUICK - FIND
REPEAT
ANGLE
RETURN
SLOW
VCR DVD
SPEED/
SYSTEM
OPEN/CLOSE
/EJECT
DISPLAY
1 2 3
4 5 6
7 8 9
0+10
PLAY
STOP
REC/OTR
A-B
SEARCH
MODE
SUBTITLE
T - SET
CLEAR/
C.RESET
SKIP/CH.
2
1
3
4
5
6
7
8
910
12
13
15
14
11
30
26
27
28
25
29
24
23
21
20
22
17
18
19
16
31
FUN_H9701BD(EN).fm Page 6 Tuesday, July 27, 2004 5:57 PM

7EN
Rear View
1. Power Cord
Connect to a standard AC outlet
2. DIGITAL AUDIO OUT (OPTICAL, COAXIAL ) jacks (DVD
only)
Connect to an amplifier with digital input jacks such as
Dolby Digital decoder, DTS decoder, etc.. Use a
commercially available optical or coaxial cable.
3. ANALOG AUDIO OUT jacks (DVD only)
Connect to the audio input jacks of your TV or stereo
system. Use commercially available audio cables.
4. S-VIDEO OUT jack (DVD only)
Connect to the S-VIDEO input jack on your TV. Use a
commercially available S-VIDEO cable.
5. AV1(TV) jack
Connect to the scart jack on your TV. Use the supplied
scart cable.
6. AV2(DECODER) jack (VCR only)
Connect a scart cable from another VCR, camcoder, or
an audio/video source.
7. AERIAL jack
Connect to an antenna or cable.
8. RF OUT jack
Connect to the antenna in jack of your TV, cable box or
direct broadcast system. Use the supplied RF cable.
CAUTION: Do not touch the inner pins of the
jacks on the rear panel.
Electrostatic discharge may cause
permanent damage to the unit.
Setting up Your DVD/VCR
Before Connecting
• Please refer to the instruction books of your TV, DVD/
VCR, Stereo System or other devices as necessary to make
the best connections.
• Make one of the following connections, depending on the
capabilities of your existing equipment.
The following guidelines are options for the best picture and
sound quality available on your DVD/VCR.
1) Use SCART Output (DVD/VCR(AV1 TV)) for best
picture quality (for DVD and VCR features).
2) Use S-Video Output for the better picture quality (for
DVD features only).
3) If your TV only has a RF-style (Antenna IN or 75 ohm)
input, use the RF OUT for connection and set your TV
to channel 22 ~ 69 with the same channel for DVD/VCR
is set (for DVD and VCR features).
Note: • When your TV conforms to RGB input signal, the
Euro AV (scart) connection ensures you the best
picture and audio quality. However if your TV does
not conform to RGB input signal, the S-VIDEO
OUT and analog AUDIO OUT connection is better.
(for DVD features only)
Sound
1) Use SCART Output (DVD/VCR(AV1 TV)) for best
sound quality (for DVD and VCR features).
2) Digital audio connections provide the clearest sound.
Connect the DVD/VCR’s DIGITAL AUDIO OUT
(either COAXIAL or OPTICAL) to your amplifier or
receiver (for DVD features only).
3) If digital connections are not possible, connect the DVD/
VCR’s ANALOG AUDIO OUT(Left and Right) to your
amplifier, receiver, stereo or TV (for DVD features only).
WARNING!
• Never make or change connections with the power
switched on.
• Connect the DVD/VCR directly to your TV, instead of eg.
a VCR, to avoid distortion because DVD video discs are
copy protected.
• Do not connect the ANALOG AUDIO OUT of DVD/
VCR to PHONO IN of your amplifier or receiver.
• If you use the Euro audio/video cable, it is not necessary to
connect the analog audio cables.
Connecting to a TV
1) Disconnect the antenna or cable from your TV.
2) Connect that antenna or cable to the AERIAL jack of this
unit.
3) Connect the RF OUT jack of this unit to the antenna in
jack of your TV. Use the supplied RF cable.
4) Connect the AV1 (TV) scart jack of this unit to the scart
input jack of your TV. Use the supplied scart cable.
5) Plug in the TV and this unit.
Note: • The TV must be connected to this unit through AV1
(TV) jack. A connection to AV2 (DECODER) jack
will not function correctly.
RF OUT
AERIAL
VCR
AV2 (DECODER)
DVD/VCR AV1 (TV)
L
R
DVD
OPTICAL COAXIAL
DIGITAL
AUDIO OUT ANALOG AUDIO OUT S-VIDEO OUT
123456 78
RF OUT
AERIAL
VCR
AV2 (DECODER)
DVD/VCR AV1 (TV)
L
R
DVD
OPTICAL COAXIAL
DIGITAL
AUDIO OUT ANALOG AUDIO OUT S-VIDEO OUT
VHF/UHF
MIXER
UHF VHF
to aerial socket
RF cable
(supplied)
scart cable
(supplied)
(TV)
to 21-pin
scart jack
FUN_H9701BD(EN).fm Page 7 Tuesday, July 27, 2004 5:57 PM

8EN
If your TV has no scart input jack but has an
S-VIDEO input jack,
1) Follow the steps 1) to 3) above.
2) Connect the S-VIDEO OUT jack on this unit to the
S-VIDEO input jack on your TV.
3) Connect the analog AUDIO OUT jacks of this unit to
the analog audio input jacks of your TV.
4) Plug in the TV and this unit.
Note: The S-VIDEO connection only supplies video (picture)
in the DVD mode. Therefore, video channel setting is
necessary for watching videotapes. For more details,
refer to page 9.
If your TV has no VIDEO input jacks,
1) Follow the steps 1) to 3) and 5) right under “Connecting
to a TV.”
2) Video channel setting is necessary. Refer to page 9.
For Better Sound (for DVD Features)
These 2 connections are optional for better sound.
1) For clear digital sound quality, use the DIGITAL AUDIO
OUT (either OPTICAL or COAXIAL) jack for the
connection to your digital audio system.
•If the audio format of the digital output does not match
the capabilities of your receiver, the receiver will produce
a strong, distorted sound or no sound at all.
Hints for connecting to a Dolby Digital
decoder, DTS decoder or MPEG decoder
• By connecting this unit to a Multi-channel Dolby Digital
decoder, you can enjoy high-quality 5.1ch Dolby Digital
surround sound as heard in the movie theaters.
• When this unit is connected to a DTS decoder, you can
enjoy 5.1 channel surround system which reproduces the
original sound as truthfully as possible. 5.1 channel
surround system is developed by the Digital Theater
System, Inc.
• A digital component with a built-in MPEG 2, Dolby
DigitalTM or DTS decoder allows you to enjoy the surround
sound while producing the effecting of being in a movie
theater or a concert hall.
• If output is Dolby Digital encoded audio, connect to a
Dolby Digital decoder, and set “DOLBY DIGITAL” to
“ON” in the AUDIO menu. (Refer to page 23.)
• If output is DTS encoded audio, connect to a DTS
decoder, and set “DTS” to “ON” in the AUDIO menu.
(Refer to page 23.)
• If output is MPEG encoded audio, connect to a MPEG
decoder, and set “MPEG” to “ON” in the AUDIO menu.
(Refer to page 23.)
Hints for connecting to an MD deck or DAT
deck
• The audio source on a disc in a Dolby Digital 5.1 channel
surround format cannot be recorded as digital sound by an
MD or DAT deck.
• Unless connected to a Dolby Digital decoder, set “DOLBY
DIGITAL” to “OFF” in the AUDIO menu. Playing a
DVD using incorrect settings may generate noise
distortion, and damage the speakers. (Refer to page 23.)
• Set “DOLBY DIGITAL”, “DTS”, and “MPEG” to
“OFF” in the AUDIO menu for connecting to an MD
deck or DAT deck. (Refer to page 23.)
2) For dynamic sound effects, use the ANALOG AUDIO
OUT jacks for the connection to your audio system.
VCR AV2 (DECODER)
DVD/VCR AV1 (TV)
L
R
DVD
OPTICAL COAXIAL
DIGITAL
AUDIO OUT ANALOG AUDIO OUT S-VIDEO OUT
L
R
S-VIDEO
IN
AUDIO
IN
TV
DVD / VCR
S-Video cable
(not supplied)
(Back of the unit)
COAXIAL
OPTICAL
or
Digital Audio
Input jacks
Optical
cable
(not supplied)
Coaxial
cable
(not supplied)
DVD / VCR
Dolby Digital decoder,
DTS decoder or
MPEG decoder etc.
OPTICALCOAXIAL
DIGITAL
AUDIO OUT
“DTS” and “DTS Digital Out” are trademarks of
Digital Theater Systems, Inc.
Manufactured under license from Dolby
Laboratories. “Dolby” and the double-D symbol
are trademarks of Dolby Laboratories.
RL
AUDIO SYSTEM
DVD/VCR
Audio
L
R
ANALOG
AUDIO OUT
Audio cables
(not supplied)
FUN_H9701BD(EN).fm Page 8 Tuesday, July 27, 2004 5:57 PM

9EN
External Input Mode (for VCR Features)
Connect an external device (a decoder, a camcorder, etc.) to
the AV2 (DECODER) jack. Press 0,0,2, with the number
buttons, so that “AV2” appears on the TV screen.
If you use the front AUDIO/VIDEO input jacks, press 0,0,3,
with the number buttons, so that “AV3” appears on the TV
screen.
If you use the AV1 (TV) jack for connecting a device, press 0,
0,1 with the number buttons, so that “AV1” appears on the
TV screen.
Video Cassette Tape
This DVD/VCR will operate with any cassette that bears the
VHS mark. For best results, we recommend the use of high-
quality tapes. Do not use poor quality or damaged tapes.
• You can prevent accidental erasing of a recording by
breaking off the erase-prevention tab on the back edge of
the cassette.
• If you decide to record on the tape again, cover the hole
with plastic tape.
TV Colour System
Different countries use different television colour systems.
Tapes recorded in the PAL or NTSC system can be played
back on this unit. Usually, the picture on the TV screen will
be in black and white when you play back a tape that is
recorded in a different colour system.
Tapes recorded in the NTSC system can be played back on
this unit and a PAL system TV set. This feature is only
available in the SP mode. When playing back such tapes, the
picture may roll up or down, shrink vertically and black bars
may appear both at the top and bottom of the screen. Adjust
the vertical hold control on your TV, if the TV features this
control.
Video Channel Setting
Video channel setting will be necessary, if your DVD/VCR is
connected to the TV via the coaxial cable.
• Use the remote control for this procedure.
1) Press VCR.
2) Insert a pre-recorded tape into the DVD/VCR.
The DVD/VCR will start playback automatically.
If playback does not start, press PLAY.
3) Select and adjust your TV to channel 35.
•If the playback picture appears on the TV screen,
continue with step 9).
•If channel 35 is set for broadcasting, or interference lines
appear on the picture, the RF converter must be set to a
different channel between CH22 and CH69. Continue
with step 4).
4) Press MENU.
5) Press Kor Lrepeatedly to select to “INITIAL”. Then,
press B.
6) Press Kor Lrepeatedly to select to “RF OUT”. Then,
press B. The RF OUT CH menu will appear.
7) Press Kor Lto select a channel which is not used for
broadcasted between channel 22 and channel 69 in your
area, then press B.
8) Press MENU to exit.
Set the TV channel to the RF OUT CHANNEL which
was selected on the DVD/VCR. A picture from the DVD/
VCR will appear on the TV screen. If a picture does not
appear, repeat steps 4) to 8) using a different channel
which is not used for broadcasting.
9) Press STOP to stop the tape.
Note: • You may also access the RF OUT CH menu by
pressing and holding MENU on the remote control for
3 seconds during power off until the RF OUT CH
menu appears.
•If this unit and your TV are connected using a scart
cable, the RF converter may be switched off to avoid
any possibility of interference. To switch off the RF
converter, follow steps 1) and 4) to 6) above and press
Lrepeatedly until “- -” appears next to “RF OUT
CH.” Press B, then MENU to exit.
Ta b
MENU
TIMER
SET UP
INITIAL
RF OUT CH 35
INITIAL
CH TUNING
CLOCK
RF OUT
FUN_H9701BD(EN).fm Page 9 Tuesday, July 27, 2004 5:57 PM

10 EN
Setting the Clock
This unit incorporates a 24-hour clock. The clock must be set
for the Timer Recording function to operate correctly.
• Use the remote control for this procedure.
1) Press VCR, then MENU.
2) Press Kor Lto select “INITIAL”, then press B.
3) Press Kor Lto select “CLOCK”, then press B.
4) Press Kor Luntil the relevant year appears, then press B.
5) Press Kor Luntil the relevant month appears, then press
B.
6) Press Kor Luntil the relevant day appears, then press B.
7) Press Kor Luntil the relevant hour appears, then press B.
8) Press Kor Luntil the relevant minute appears.
9) Press MENU to start the clock.
Note:
•Presssto go one step back from the current step during
steps 5) to 8).
• Although seconds are not displayed, they begin counting
from 00 when you exit by pressing MENU. Use this feature
to synchronize the clock with the correct time.
• If this unit is unplugged or if there is a power failure for
more than 30 seconds, you may have to reset the clock.
Channel Presetting
Tuning of broadcast channels not already preset in the DVD/
VCR can be performed in two ways.
Automatic Channel Preset
• By “AUTOMATICALLY” tuning channels and placing
them in sequential order in the DVD/VCR’s memory i.e.
the first channel found will be memorized into the DVD/
VCR’s channel position 1, the second channel found will
be memorized into the DVD/VCR’s channel position 2
and so on.
• Execution of the “Automatic” channel presetting cancels all
the preset channels. DO NOT use this feature if you intend
to use some of the pre-tuned channels. Use the “Manual”
channel presetting function to tune in the additional
channels you require.
Manual Channel Preset
• Each channel is tuned manually and individually. Follow
the steps laid out in the “Manual Channel Preset”.
Before you preset Channel...
• It is necessary to set the video channel if this unit is
connected to the TV via the coaxial cable, and TV channel
35 is set for broadcasting, or interference lines appear on
the picture. Please refer to “Video Channel Setting”.
Automatic Channel Preset
You can programme the tuner to scan only the channels that
you can receive in your area.
• Use the remote control for this procedure.
1) Turn on the TV and select the TV channel to the video
channel on the TV.
2) Press VCR, then MENU.
3) Press Kor Lto select “INITIAL”, then press B.
4) Press Kor Lto select “CH TUNING”, then press B.
5) Press Kor Lto select “AUTO”, then press B.
• The tuner scans and memorizes all the active channels in
your area. After scanning, the tuner stops on the lowest
memorized channel.
To Select a Desired Channel
You can select a desired channel by using CH. (K/L), or
directly pressing the number buttons on the remote control.
• Enter a channel numbers as a two-digit number for the
quickest results. For example, to select channel 6, press 0
and 6. If you only press 6, channel 6 will be selected after a
brief delay.
• You can only select channels 1–99.
MENU
TIMER
SET UP
INITIAL
INITIAL
CH TUNING
CLOCK
RF OUT
CLOCK
YEAR 2 0 0 4
MONTH 0 1
DAY 0 7 WE
HOUR _ _
MINUTE _ _
INITIAL
CH TUNING
CLOCK
RF OUT
CH TUNING
AUTO
MANUAL
MOVE
scanning
MENU
TIMER
SET UP
INITIAL
FUN_H9701BD(EN).fm Page 10 Tuesday, July 27, 2004 5:57 PM

11 EN
Manual Channel Preset
• Use the remote control for this procedure.
1) Press VCR, then MENU.
2) Press Kor Lto select “INITIAL”, then press B.
3) Press Kor Lto select “CH TUNING”, then press B.
4) Press Kor Lto select “MANUAL”, then press B.
5) Press Kor Lto select “POSITION”, then press B.
•When a weak signal is received in Manual Tuning mode,
you can change the background to solid blue or the
static screen by pressing C.RESET.
6) Press the number buttons, K, or Lto select your desired
position number, then press B.
•You can select position number 01-99.
•If [ON] appears on the right side of “SKIP”, press Kor
Lto point to “SKIP”. Then, press Bto select [OFF].
•If you want to remove scrambled signals, press Kor L
repeatedly to point to “DECODER”. Then, press Bto
select [ON].
7) Press Kor Lto select “CHANNEL”, then press B.
Press Kor L. The DVD/VCR tuner will begin to search
up or down automatically. When a channel is found, the
DVD/VCR will stop searching and the picture will appear
on the TV Screen.
•You can select desired channel number by using
the number buttons. You must refer to the following
Channel Plan table and press three digits to select the
channel number.
(To select channel 24, press “0” button first and then
press “2” and “4”.)
•If this is the channel you want, press B.
8) Press MENU to exit.
Note: To confirm that a channel has been added, press
CH. (K/L).
To Skip a Preset Channel
The channels you can no longer receive or seldom watch can
be set to be skipped when you access channels by pressing
CH. (K/L).
• Use the remote control for this procedure.
1) Press VCR, then MENU.
2) Press Kor Lto select “INITIAL”, then press B.
3) Press Kor Lto select “CH TUNING”, then press B.
4) Press Kor Lto select “MANUAL”, then press B.
5) Press Kor Lto select “POSITION”, then press B.
6) Press the number buttons, K, or Lto select relevant
position number, then press B.
7) Press Kor Lto select “SKIP”, then press Bto select
[ON].
•To memorize the channel again, press B. “ON” will
change to “OFF”.
8) Press MENU to exit.
Note: To confirm that a channel has been deleted, press
CH. (K/L).
Channel Reprogramming
You can replace two channels.
• Use the remote control for this procedure.
1) Press VCR, then MENU.
2) Press Kor Lto select “INITIAL”, then press B.
3) Press Kor Lto select “CH TUNING”, then press B.
4) Press Kor Lrepeatedly to select “MOVE”, then press B.
5) Press Kor Lrepeatedly to select the position number you
want to change the channel, then press B.
•You cannot select a position number where “- - -”
appears next to the number. This is because SKIP is set
to [ON] for this position number.
•When a weak signal is received in Channel
Reprogramming mode, you can change the background
to solid blue by pressing C.RESET.
If you press the button again, the background will return
to the static screen.
6) Press Kor Lrepeatedly until the channel move to another
position number, then press B.
Channel Plan
CH Indication TV Channel
01 – 10 IRA – IRJ, GAP
21 – 69 E21 – E69
74 – 78 X, Y, Z, Z+1, Z+2
80 – 99, 100 S1 – S20, GAP
121 – 141 S21 – S41
INITIAL
CH TUNING
CLOCK
RF OUT
CH TUNING
AUTO
MANUAL
MOVE
MANUAL
POSITION
CHANNEL
DECODER
SKIP
P08
008
[OFF]
[OFF]
MENU
TIMER
SET UP
INITIAL
INITIAL
CH TUNING
CLOCK
RF OUT
MANUAL
POSITION
CHANNEL
DECODER
SKIP
P08
008
[OFF]
[ON]
CH TUNING
AUTO
MANUAL
MOVE
MENU
TIMER
SET UP
INITIAL
FUN_H9701BD(EN).fm Page 11 Tuesday, July 27, 2004 5:57 PM

12 EN
7) Press MENU.
VCR Operation
VCR Features
Ensure that all VCR setting begins in VCR mode by pressing
VCR.
(Make sure that the VCR OUTPUT indicator is lit.)
Playback
Tracking Adjustment
• Tracking adjustment will be activated automatically
(Digital Tracking function) when you start playback.
• When playing pre-recorded tapes or tapes recorded on units
other than your own, noise lines (black and white streaks)
may appear on the playback picture. If this occurs, you can
adjust the tracking control manually by pressing
CH. (K/L) until the streaks disappear. To return to the
DTR function, stop the tape once and start playback again.
• You can reduce the noise lines by pressing CH. (K/L) in
Slow mode, too. Slow tracking adjustment is not set
automatically.
• In the Still mode, press SLOW, and press CH. (K/L) until
the streaks disappear. To return to the Still mode, press
PAUSE again.
1) Turn on the TV and select the video channel on the TV.
2) Insert a prerecorded tape.
The DVD/VCR will turn on automatically. If the erase-
protection tab has been removed, the DVD/VCR will
start playback automatically.
•If the DVD/VCR power was already on, press VCR to
switch to VCR mode.
3) If playback does not start automatically, press VCR, then
press PLAY.
•Tracking adjustment will be activated automatically
(Digital Tracking function) when you start playback. To
adjust the tracking manually, press CH. (K/L).
<If a tape is already in the DVD/VCR...>
•Using the buttons on the DVD/VCR
Just press PLAY on the DVD/VCR. Power will
automatically turn on and playback will start. (Direct
Button Operation)
•Using the buttons on the remote control
Press FUNCTION to turn on, and then press PLAY.
4) Press STOP to stop playback.
Speed Search
1) Press gor hduring playback to view a videotape at a
high speed in either a forward or reverse direction. In this
mode, the sound will be muted.
2) Press the button again, the DVD/VCR will now search in
super high speed. (This function will not operate for a
NTSC tape.)
3) Press PLAY to return to normal playback.
Still Picture
Press PAUSE during playback to view a still picture on the TV
screen.
• When the picture begins to vibrate vertically, stabilize the
picture by pressing CH. (K/L) in the Still mode.
• After the DVD/VCR has been in Still mode for 5 minutes,
it will stop automatically to protect the tape and the video
head.
<Note for “Speed Search” and “Still Picture”>
• Usually there will be video “noise” lines (black and white
streaks or dots) on the screen. This is normal.
The still picture will, in addition to containing the “noise”
lines, be black and white.
This is not a fault of the machine but merely a by-product
of the technology involved in producing a DVD/VCR with
LP mode.
INITIAL
CH TUNING
CLOCK
RF OUT
CH TUNING
AUTO
MANUAL
MOVE
MOVE
P01:
P02:
P03:
P04:
P05:
01
02
03
04
05
P06:
P07:
P08:
P09:
P10:
06
07
08
09
10
Position
Number Channel
Number
[ ]
MOVE
P01:
P02:
P03:
P04:
P05:
01
02
10
04
05
P06:
P07:
P08:
P09:
P10:
06
07
08
09
03
[ ]
MENU
TIMER
SET UP
INITIAL
MOVE
P01:
P02:
P03:
P04:
P05:
01
02
10
04
05
P06:
P07:
P08:
P09:
P10:
06
07
08
09
03
FUN_H9701BD(EN).fm Page 12 Tuesday, July 27, 2004 5:57 PM

13 EN
Slow Motion
•PressSLOW to reduce the playback speed. The DVD/VCR
mutes the sound during slow motion. You can control the
speed by pressing g(faster) or h(slower). Press PLAY
to return to normal playback.
• If it is left in the Slow mode for more than five minutes, the
DVD/VCR will automatically switch to the Stop mode.
Recording
Viewing and Recording the Same Programme
1) Insert a cassette tape with its erase-prevention tab in place.
(If necessary, rewind or fast forward the tape to the point
at which you want to begin recording.) Press VCR.
2) Press the number buttons or CH. (K/L) to select the
channel to be recorded.
3) Press SPEED/SYSTEM to select the tape speed (SP/LP).
4) Press REC/OTR to begin recording.
•The REC indicator on the display comes on.
5) Press STOP when recording is completed.
Two Different Tape Speeds
Before recording, select the tape speed : SP mode (Standard
Play) or LP mode (Long Play). The table below shows the
maximum recording/playback time using E-60, E-120, E-180
or E-240 tapes in each mode.
Skipping Unwanted Programme Material During
Recording
1) Press PAUSE when you want to temporarily halt
recording.
You can check the remaining pause time with
C marks on
the TV screen. Each
C mark represents 1 minute. After 5
minutes, the DVD/VCR will automatically switch to the
Stop mode to prevent tape damage.
2) Press PAUSE or REC/OTR to resume recording.
Recording One Programme While Viewing Another
You can record one programme while viewing another. To
start recording, follow steps 1) to 4) under “Viewing and
Recording the Same Programme”. Then, set the TV to the
channel you want to watch.
To Monitor the Progress of Your Recording
Select the video channel on the TV.
Assemble Function
• You can record in continuation from previous programme
on a pre-recorded tape.
1) Insert a pre-recorded tape. Press PLAY to start playback.
2) Press PAUSE at the desired point on the tape.
3) Press REC/OTR. The DVD/VCR will be in the Recording
Pause mode.
4) Press CH. (K/L) to select the channel to be recorded.
5) Press REC/OTR or PAUSE. The recording will begin.
6) Press STOP when recording is completed.
Hi-Fi Stereo Sound System
This DVD/VCR will record and playback Hi-Fi stereo sound.
In addition it has a NICAM stereo sound decoder.
This equipment will receive stereo and bilingual broadcasts
and it is possible the several ways of recording and playing back
the sound.
Selecting the Sound Mode
You can select each mode by pressing AUDIO on the remote
control. Each mode is indicated on the TV screen as following.
• During playback of the recorded tape in Hi-Fi mode:
• Reception of stereo broadcasts:
• During reception of bilingual broadcasts:
Note: • If you play non-Hi-Fi tapes, the DVD/VCR will play
automatically in monaural even if you select any
mode.
•If the stereo signal becomes weak, the broadcast is
automatically recorded in monaural.
Tape Type Recording/Playback Time
Tape Speed SP Mode LP Mode
E-60 1 hour 2 hours
E-120 2 hours 4 hours
E-180 3 hours 6 hours
E-240 4 hours 8 hours
Mode AUDIO OUTPUT Display on
the TV screen
Stereo L Hi Fi L Audio STEREO
R Hi Fi R Audio
LL Hi Fi L Audio LEFT
R Hi Fi L Audio
RL Hi Fi R Audio RIGHT
R Hi Fi R Audio
Normal L Normal Audio -None-
R Normal Audio
Mode AUDIO OUTPUT Display on
the TV screen
Stereo L L Audio STEREO
RRAudio
LL L Audio LEFT
R L Audio
RLRAudio RIGHT
RRAudio
Monaural LL+RAudio -None-
RL+RAudio
Mode AUDIO OUTPUT Display on
the TV screen
MAIN L Main Audio MAIN
R Main Audio
SUB L Sub Audio SUB
R Sub Audio
MAIN L Main Audio MAIN
SUB R Sub Audio SUB
FUN_H9701BD(EN).fm Page 13 Tuesday, July 27, 2004 5:57 PM

14 EN
OTR (One Touch Recording)
This function enables you to set the duration of a recording
simply by pressing REC/OTR.
1) Follow steps 1) to 3) in “Viewing and Recording the Same
Programme”.
2) Press REC/OTR repeatedly until the desired recording
length appears in the upper left corner of the TV screen.
Recording stops when 0:00 is reached.
• To check time remaining during an OTR
Press DISPLAY.
• To change the recording length during an OTR
Press REC/OTR repeatedly until the desired length appears.
• To stop an OTR before recording is finished
Press STOP.
• To cancel the OTR but continue recording
Press REC/OTR repeatedly until “I” appears without the
recording length.
• If there is no timer recording set after an OTR, this unit
switches to DVD mode and indicator flashes because
the VCR is still on standby for timer recordings. Press
T-SET on the remote control or STOP/EJECT on the front
panel to cancel timer standby, then press VCR to use the
VCR again.
If there is a timer recording set after an OTR, this unit
switches to DVD mode and indicator lights up,
indicating that this unit is on timer standby. Press
T-SET on the remote control or STOP/EJECT on the front
panel to cancel timer standby, then press VCR to use the
VCR again.
Auto Repeat Playback
The DVD/VCR has an auto repeat function that allows you to
repeat a tape indefinitely without touching PLAY.
• Use the remote control for this procedure.
• Insert a pre-recorded tape.
1) Press VCR, then MENU.
2) Press Kor Lto select “SET UP”, then press B.
3) Press Kor Lto select “AUTO REPEAT”.
4) Press Bso that “ON” appears next to “AUTO REPEAT”
on the TV screen.
When in Stop mode, Auto Repeat mode will start
automatically.
If the on-screen menu still remains, press MENU to exit,
then press PLAY.
Note: Once you select the Auto Repeat mode, it stays in effect
even after you turn off the DVD/VCR.
To Stop Playback
Press STOP.
To Exit the Auto Repeat Mode
Repeat steps 1) to 3). Then, press B.
“OFF” will appear next to “AUTO REPEAT” on the TV
screen. Press MENU to exit.
Picture Select
This function enables you to select the picture quality of a
tape.
• Use the remote control for this procedure.
1) Press VCR, then MENU.
2) Press Kor Lto select “SET UP”, then press B.
3) Press Kor Lto select “PICTURE”.
4) Press Buntil the desired mode (NORMAL, SOFT, or
SHARP) is indicated on the TV screen.
5) Press MENU to exit.
Note: Once you select the Picture Select mode, it stays in
effect even after you turn off the DVD/VCR.
Automatic Operations
Automatic Rewind, Eject
When the end of a tape is reached during recording, playback,
or fast-forward, the tape will automatically rewind to the
beginning. After that, the DVD/VCR will eject the tape.
• The tape will not auto-rewind during timer recording or
One Touch Recording.
Tape Eject
A tape can be ejected with the DVD/VCR power on or off
(but the DVD/VCR must be plugged in).
• If a timer recording is set, press STOP/EJECT twice to eject
a tape.
II[0:30] I[1:00]... I[7:30] I[8:00]
(Normal (OTR:
recording) 30 minutes)
MENU
TIMER
SET UP
INITIAL
SET UP
AUTO REPEAT [ON]
PICTURE [NORMAL]
AUTO RETURN [ON]
MENU
TIMER
SET UP
INITIAL
MENU
TIMER
SET UP
INITIAL
MENU
TIMER
SET UP
INITIAL
SET UP
AUTO REPEAT [ON]
PICTURE [NORMAL]
AUTO RETURN [ON]
FUN_H9701BD(EN).fm Page 14 Tuesday, July 27, 2004 5:57 PM

15 EN
Real Time Tape Counter
• This shows the elapsed recording or playback time in
hours, minutes, and seconds on screen. (Nothing is shown
in the case of blank portion.)
• Display on the front panel shows elapsed time in hours and
minutes.
• The “ – ” indication will appear when the tape is rewound
further than the tape counter position “0:00:00”.
Timer Recording
You may programme the DVD/VCR to start and end a
recording while you are away. You can set 8 programmes to
record on specific days, daily or weekly within a 1-year period.
• Use the remote control for this procedure.
• Insert a cassette tape with its erase-prevention tab in place.
(If necessary, rewind or fast forward the tape to the point at
which you want to begin recording.)
1) Press VCR, then MENU.
2) Press Kor Lto select “TIMER”, then press B.
Note: If you have not set the clock yet, “CLOCK” setting
menu appears. If so, follow the steps outlined in the
“Setting the Clock”. Then, set the timer.
•WhenyoupressBafter pressing Kor Lduring steps 3) to
9), the input mode will move to the next step.
• If you do not press Bwithin 5 seconds of setting an item,
the input mode will move to the next step.
•Press
sto go back one step from the current setting during
steps 4) to 9). If sis pressed when the TIMER NUMBER
is flashing, the entire programme contents will be erased.
3) Programme number flashes. Press Kor Lrepeatedly until
the desired programme number appears. Then, press B.
4) For once-only recording : Press Kor Lrepeatedly until
the relevant month appears.
For daily recording : To record a TV programme at the
same time on the same channel from Monday through
Friday. While the month digit is flashing, press Kor L
repeatedly to select “MO-FR”.
For everyday recording : To record a TV programme at
the same time on the same channel everyday. While the
month digit is flashing, press Kor Lrepeatedly to select
“MO-SU”.
For weekly recording : To record a TV programme at the
same time on the same channel every week. While the
month digit is flashing, press Kor Lrepeatedly to select
“W-MO” (Example: every monday).
5) For once-only recording only : Press Kor Lrepeatedly
until your desired day appears.
6) Press Kor Lrepeatedly until the relevant start hour
appears. Next, enter the minute digit.
7) Press Kor Lrepeatedly until the relevant end hour
appears. Next, enter the minute digit.
8) Press Kor Lrepeatedly until the relevant channel number
appears.
9) Press Kor Lrepeatedly until the desired tape speed
appears.
10)Press B. Programme 1 is now completed.
•To set another timer programme, repeat steps 3) to 10).
11)Press MENU to exit.
12)Press T-SET to activate a timer recording.
The VCR goes into timer-standby mode.
To Stop a Timer Programme Which Has Already
Started
Press STOP/EJECT on the DVD/VCR.
Note: STOP on the remote control will not function in the
Timer Recording mode.
To Correct Timer Programmes
If the unit is already in timer standby mode, press
STOP/EJECT on the unit or T-SET to exit from the standby
mode.
1) Repeat steps 1) to 3) in the “Timer Recording”.
2) Select the setting you want to change using Bor s.
3) Enter the correct numbers using Kor L, then press B.
4) Press MENU to exit.
5) Press T-SET to return to timer standby mode.
To Cancel or Check the Start/End Time
If the unit is already in timer standby mode, press
STOP/EJECT on the unit or T-SET to exit from the standby
mode.
1) Repeat steps 1) to 2) in the “Timer Recording”.
2) Select a programme number you want to check using Kor
L. The details of selected programme appears on the TV
screen. You may cancel the entire programme by pressing
s.
3) Press MENU to exit.
Avoid Overlap of TIMER Programmes...
A timer programme does not work while another programme
is under execution.
Hint for Timer Recording
• If either there is a power failure or this unit is unplugged for
more than 30 seconds, clock and all timer settings are lost.
• If a tape runs out before a timer recording is finished, the
unit ejects the tape and switches into DVD mode
automatically. Press T-SET to activate VCR function.
• Once the unit goes into Timer- standby mode, no VCR
functions are available until T-SET is pressed. (OUTPUT on
the front panel and VCR on the remote control will not
function.)
•PressT-SET to activate VCR functions after your timer
recording is finished.
• DVD functions are available during Timer-standby mode
and Timer recording. You don’t have to stop your timer
recording.
MENU
TIMER
SET UP
INITIAL
TIMER NUMBER 1
START
END
DATE
CHANNEL
SPEED
--/--
--:--
--:--
--
--
9:00 10:00 11:00
Programme 1
Programme 2
Programme 3
FUN_H9701BD(EN).fm Page 15 Tuesday, July 27, 2004 5:57 PM

16 EN
Auto Return
If there are any remaining programmes including Daily,
Everyday, & Weekly, AUTO RETURN will not operate.
1) Press VCR, then MENU.
2) Press Kor Lrepeatedly to point to “SET UP”, then press
B.
3) Press Kor Lto point to “AUTO RETURN”, then press
B.
[ON] will appear next to “AUTO RETURN”.
4) Press MENU.
Watch the Recorded Timer Programme
Press T-SET to turn on the DVD/VCR, then press PLAY.
Quick-Find
This function enables you to search and confirm the contents
of the recorded programme(s) using the index mark.
• Use the remote control for this procedure.
• The tape must be fully rewound.
1) Press VCR, then QUICK-FIND.
To Skip to the Beginning of Next Programme
1) Press QUICK-FIND.
To View at Normal Speed
1) Press PLAY. The Quick-Find is cancelled.
Note: • This function will not operate in the Recording mode.
•When you want to cancel the Quick-Find while in
progress, press STOP.
•When the end of a tape is reached during the Quick-
Find, the tape will automatically rewind to the
beginning. After rewinding finishes, the DVD/VCR
will eject the tape.
Index Search
• The index mark will be made automatically when
REC/OTR is pressed. It will also be marked at the starting
point of Timer recording and OTR.
• The index mark is not recorded if PAUSE is pressed and
released during recording.
• The time gap between index marks on the tape should be
greater than 1 minute for SP recording and 2 minutes for
LP recording.
• Use the remote control for this procedure.
1) Press VCR, then SEARCH MODE.
2) Press K, Lrepeatedly until the number of programmes
that you want to skip appears.
3) Press sor B.
The DVD/VCR begins rewinding or fast forwarding to
the beginning of desired programme.
When the preset programme is reached, the DVD/VCR will
start playback automatically.
Note: • Index Search can be set up to 20.
•This function will not operate in the Recording mode.
•Operations must be followed up within 30 seconds,
from steps 2) to 3). Otherwise the Index Search mode
will be cancelled.
•To exit the Index Search mode, press MENU in step 2).
Or press STOP after step 3).
Time Search
If a tape includes both programmes recorded in the PAL
system and ones recorded in the NTSC system, this function
may not be operated correctly.
• Use the remote control for this procedure.
1) Press VCR, then SEARCH MODE twice.
2) Press K, Lrepeatedly until the desired time appears.
3) Press sor B.
The DVD/VCR begins rewinding or fast forwarding to
the specified point.
When 0:00 is reached, the DVD/VCR will start playback
automatically.
Note: • Time Search can be set up to 9 hours 59 minutes
(9:59).
•This function will not operate in the Recording mode.
•Operations must be followed up within 30 seconds,
from steps 2) to 3). Otherwise the Time Search mode
will be cancelled.
•To exit the Time Search mode, press MENU in step 2).
Or press STOP after step 3).
Recording from DVD to VCR
1) To activate DVD function, press DVD.
2) Insert a non-copyright-protection DVD, then press
PAUSE at the point where you want to start recording.
3) Press VCR, then insert a tape with its erase-prevention tab
in place. Make sure the VCR is in Stop mode after you
find your recording point.
4) Press SPEED/SYSTEM to choose your recording speed.
“SP” or “LP” appears on the front panel display.
5) Press 0, 0, 4, with number buttons, then “disc” briefly
appears on the front panel display.
6) Press REC/OTR.
7) Press DVD, then press PLAY.
8) To s t o p r e c o rd i n g , p r e s s VCR, then STOP.
FUN_H9701BD(EN).fm Page 16 Tuesday, July 27, 2004 5:57 PM

17 EN
Copying a Video Tape
Connect the recording DVD/VCR (this unit), playing VCR
(another VCR) and your TV as outline in the following
diagrams.
1) Insert a pre-recorded videocassette into the playing VCR.
2) Insert video cassette tape with its erase prevention tab in
place into the cassette compartment of the recording
DVD/VCR.
3) Press SPEED/SYSTEM to select the desired recording
speed (SP/LP).
4) Select “AV2” or “AV3” position on the recording DVD/
VCR.
See “External Input Mode (for VCR features)” (Refer to
page 9).
5) Press REC/OTR on the recording DVD/VCR.
6) Begin playback of the tape in the playing VCR.
7) To s t o p r e c o rd i n g , p r e s s STOP/EJECT on the recording
DVD/VCR, then stop playback of the tape in the playing
VCR.
Note: • For best results during dubbing, use the DVD/VCR’s
front panel controls whenever possible. The remote
control might affect the playing VCR's operation.
•If video or colour fades in and out, you may be
copying a copy guarded video tape.
•Unauthorised recording of copyrighted materials may
infringe on the rights of copyright owners, violate
copyright laws and may not record clearly.
Status Display
To check the Counter, or Clock & Channel number, press
DISPLAY. Each time you press DISPLAY, TV screen will
change as illustrated:
When you select the channel using the number buttons, select
the desired channel (position number).
Note: If the on screen display or indicators on the front panel
show an abnormal reading or no reading, unplug this
unit for 30 seconds, then replug it again.
Please note that clock and timer settings will be cleared
after disconnection.
RF OUT
AERIAL
VCR AV2 (DECODER)
DVD/VCR AV1 (TV)
L
R
DVD
OPTICAL COAXIAL
DIGITAL
AUDIO OUT ANALOG AUDIO OUT S-VIDEO OUT
to 21-Pin Scart jack
to 21-Pin Scart jack
Playing VCR
(TV)
Recording DVD/VCR
(this unit)
OPEN/CLOSE
CHANNEL
VCR DVD
STOP PLAY
OUTPUT
STANDBY-ON
REW F.FWD PLAY REC/OTRSTOP/EJECT
VIDEO
L-AUDIO-R
Playing VCR
to the audio output jack
to 21-Pin Scart jack
(TV)
to the video output jack
Recording DVD/VCR (this unit)
to AV1 (TV)
Scart jack on
the back of the
DVD/VCR
Using scart jacks
Using AV front terminals
■
SP
0:12:34
■
SP 17:40
P02
<CLOCK and CHANNEL
NUMBER mode>
<COUNTER mode>
Press once. Press once.
Press once.
<OFF mode>
FUN_H9701BD(EN).fm Page 17 Tuesday, July 27, 2004 5:57 PM

18 EN
DVD Operation
Basic Playback
Getting started
• Turn on the power of the TV, amplifier and any other
components which are connected to this unit.
• Make sure the TV and audio receiver (commercially
available) are set to the correct channel.
• Make sure that the DVD OUTPUT indicator is lit. If not,
press DVD to switch to DVD mode.
• Unless stated, all operations described are based on remote
control use. Some operations can be carried out on main
unit.
1) Press FUNCTION.
•Make sure that the DVD OUTPUT indicator is lit. If
not, press DVD to switch to DVD mode.
2) Press OPEN/CLOSE to open disc loading tray.
3) Place the chosen disc on the tray, with the label facing up.
4) Press PLAY.
•The tray will close automatically, and playback will then
start from the first chapter or track of the disc.
•When you play back a DVD with a title menu
recorded, it may appear on the screen. In this case, refer
to “Title Menu”.
5) Press STOP to stop playback.
Note: • A “prohibited icon” may appear at the
top-right on the TV screen during
operation, warning that a prohibited
operation has been encountered by this
unit or the disc.
•Some DVDs may be played from title 2 or 3 due to
specific programs.
•During the playback of two layered disc, pictures may
stop for a moment. This happens while the 1st layer is
being switched to the 2nd layer. This is not a
malfunction.
•DVDs recorded with the NTSC system can be viewed
on PAL, NTSC or Multi system TV. (Refer to page
24.)
•Depending on the TV, when playing back a NTSC
DVD on a PAL TV, the picture may roll up or down,
shrink vertically and black bars may appear at the both
top and bottom of the screen.
•It may take a time to deliver the picture or the sound.
This is not a malfunction.
Disc Menus
1) Press MENU.
•The DVD main menu will appear.
2) If the feature is not available, symbol may appear on
the TV screen.
3) If disc menu is available on the disc, audio languages,
subtitle options, chapters for the title and other options
will appear for selection.
4) Press Arrow ( s/ B / K/ L) to select an item, and
ENTER to confirm selection.
Title Menu
1) Press TOP MENU.
•The title menu will appear.
2) If the feature is not available, symbol may appear on
the TV screen.
3) Press Arrow ( s/ B / K/ L) to select an item, and
ENTER to confirm selection.
•Playback will begin at the selected Title.
1) The title menu will appear.
2) Press the number buttons to select an item.
Playback will start.
Calling up a Menu Screen During Playback
•Press
MENU to call up the DVD main menu.
•Press
TOP MENU to call up the title menu.
Note: Menu operations may vary depending on the disc. Refer
to the manual included in the disc for details.
About the PBC Function of Video CD
• This unit conforms to Video CD ver. 1.1 (standard) and
ver. 2.0 (with PBC function).
• “PBC” stands for Play Back Control.
• Video CD with PBC function has its original menu. Menu
operation may vary depending on the disc. Refer to the
manual included in the disc for details.
• “PBC” appears on the front panel display when a Video
CD with PBC function is loaded.
Cancelling and Calling Back PBC Function
When playing Video CDs with PBC function, some
operations (e.g. select and repeat tracks, resume) cannot be
performed unless the PBC function is cancelled temporarily.
1) Insert a Video CD.
•Title menu will appear on the display.
•Playback will start automatically.
2) Press STOP.
3) Press the number buttons to enter the desired Track
number.
•PBC function is now cancelled and the playback of the
Video CD will start.
4) To call back PBC function, press STOP twice, and then
press PLAY.
MP3 Playback
Insert an MP3-format disc, then press MENU to call up the
MP3 menu on the TV screen, and the number of tracks is
displayed on the front panel.
DVD-V CD MP3 VCD
DVD-V
DVD-V
VCD
DVD-V
VCD
MP3
FUN_H9701BD(EN).fm Page 18 Tuesday, July 27, 2004 5:57 PM

19 EN
1) Press Kor Lto select the desired group or track.
•If a group is selected, press Bor ENTER to go on to the
track selection screen. Press Kor Lto choose a track,
then press PLAY or ENTER.
•If a track is selected, press PLAY or ENTER to start
playing the track, and the subsequent tracks will be
played.
•Press sto go back to the previous hierarchy.
•Press TOP MENU to return to the first item.
2) Press STOP to stop playback.
Note: • Folders are known as Groups, and files are known as
Tracks.
•MP3 files are accompanied by icon.
•Folders are accompanied by icon.
•A maximum of 255 folders can be recognized.
•A maximum of 512 files can be recognized.
•Up to 8 hierarchies can be created.
•The name of group and track can be displayed in up to
25 characters.
Unrecogrizable characters will be replaced with
asterisks.
•Unplayable groups or tracks may be displayed
depending on the recording conditions.
This unit recommends the files recorded under the following
circumstances:
• Sampling frequency: 44.1kHz or 48kHz
• Constant bit rate: 112kbps ~ 320kbps
Resume
1) During playback, press STOP.
•Resume message will appear on the TV screen.
2) Press PLAY. Playback will resume from the point at which
playback was stopped.
•To cancel resume, press STOP twice.
Note: • For MP3 files, playback will resume from the
beginning of the track at which playback was stopped.
•The resume information stays on even when the
power is turned off.
Pause
1) During playback, press PAUSE.
•Playback will be paused and sound will be muted.
2) To continue playback, press PLAY.
Note: On DVDs, set “STILL MODE” to “FIELD” in the
DISPLAY menu if pictures in the pause mode are
blurred. (Refer to page 24.)
Step by Step Playback
1) During playback, press PAUSE.
•Playback will be paused and sound will be muted.
2) The disc advances by one frame each time PAUSE is
pressed.
3) To exit step by step playback, press PLAY.
Note: On DVDs, set “STILL MODE” to “FIELD” in the
DISPLAY menu if pictures during step by step playback
are blurred. (Refer to page 24.)
Fast Forward / Reverse Search
1) During playback, press gor hrepeatedly to select the
required forward or reverse speed.
•For DVDs and Video CDs, fast forward or reverse
search speed is different depending on the disc.
•For DVDs, approximate speed is 1(x2), 2(x8), 3(x50),
and 4(x100).
•For Video CDs, approximate speed is 1(x2), 2(x8), and
3(x30).
•For Audio CDs, approximate speed is x16.
•For MP3, approximate speed is x8.
2) To return to normal playback, press PLAY.
Note: On DVDs, set “STILL MODE” to “FIELD” in the
DISPLAY menu if pictures during fast forward and
reverse search are blurred. (Refer to page 24.)
Slow Forward / Reverse
1) During playback, press PAUSE.
2) Press gor h.
•Slow motion playback will begin and sound will be
muted.
3) Press gor hrepeatedly to select the required speed.
Slow forward or reverse speed varies with the disc.
Approximate speed is 1(1/16), 2(1/8), and 3(1/2).
4) To return to normal playback, press PLAY.
Note: • Slow Reverse is not available on video CDs.
•On DVDs, set “STILL MODE” to “FIELD” in the
DISPLAY menu if pictures in the slow motion
playback mode are blurred. (Refer to page 24.)
Zoom
The Zoom function allows you to enlarge the video image and
to pan through the enlarged image.
1) Press ZOOM during playback.
•Playback will continue.
2) Press ZOOM repeatedly to select the required zoom factor:
x2, x4 or OFF.
3) Use Arrow ( s/ B / K/ L) to slide the zoomed picture
across the screen.
4) To exit Zoom mode, press ZOOM to set to OFF.
Note: • If you press ENTER, the zoom position window
appears at the bottom-right on the TV screen. If you
press it again, that (the zoom position) window
disappears.
•Zooming function does not work while the disc menu
is showing up.
•x4 zoom is not available on some discs.
•Only x2 zoom is available on video CDs.
Audio Language
This unit allows you to change audio languages during DVD
disc (if multi language available) playback.
1) Press AUDIO during playback.
2) Press AUDIO repeatedly to select your desired language.
DVD-V CD MP3 VCD
DVD-V CD MP3 VCD
DVD-V VCD
folder name 4
folder name 1
folder name 3
folder name 2
folder name 1
DISC NAME
FILE LIST
FOLDER
MP3
ENTER
PLAY
file name 3
file name 2
file name 1
1/2
3
DVD-V CD MP3 VCD
DVD-V VCD
DVD-V VCD
DVD-V
FUN_H9701BD(EN).fm Page 19 Tuesday, July 27, 2004 5:57 PM

20 EN
Note: • If your language is not shown after pressing AUDIO
several times, the disc may not have that language.
However, some discs allow you to change audio
language setting in the disc menu. (Operation varies
with the disc, so refer to the manual included in the
disc.)
•If you choose a Language that has a 3-letter
abbreviation, the abbreviation will be displayed every
time you change the Audio language setting. If you
choose any other languages, ‘---’ will be displayed
instead. (Refer to page 25.)
Subtitle Language
This unit allows you to change languages for subtitle during
DVD disc (if available) playback.
1) Press SUBTITLE during playback.
2) Press SUBTITLE repeatedly to select your desired subtitle
language.
•The selected language will be displayed on the display
bar at the top of the screen.
3) To turn off subtitles, press SUBTITLE repeatedly until
“OFF” appears.
Note: • If your language is not shown after pressing SUBTITLE
several times, the disc may not have that language.
However, some discs allow you to change subtitle
language setting in the disc menu. (Opetation varies
with the disc, so refer to the manual included in the
disc.)
•When “NOT AVAILABLE” appears on the TV
screen, it means no subtitle is recorded on the scene.
•If you choose a Language that has a 3-letter
abbreviation, the abbreviation will be displayed every
time you change the Subtitle language setting. If you
choose any other languages, ‘---’ will be displayed
instead. (Refer to page 25.)
Camera Angle
Some DVD discs contain scenes which have been shot
simultaneously from various angles. You can change the
camera angle when the ( ) icon appears on the screen.
1) Press ANGLE during playback.
•The selected angle will be displayed on the display bar at
the top of the screen.
2) Press ANGLE repeatedly to select your desired angle.
Note: If the ANGLE ICON setting is “OFF” in the DISPLAY
menu, the ( ) icon will not appear.
Stereo Sound Mode
1) Press AUDIO repeatedly during playback to select one
among “STEREO”, “L-CH” and “R-CH”.
STEREO - both right and left channels are active (stereo)
L-CH - only left channel is active
R-CH - only right channel is active
Note: If the Virtual Surround setting is “ON” or during a
DTS CD is being played back, the sound mode is fixed
to “STEREO”, and can not be changed.
Virtual Surround
You can enjoy stereophonic virtual surround effects on your
existing stereo system.
1) Press MODE during playback.
2) Press ENTER to change a value to “1”(Natural effect),
“2”(Emphasized effect) or “OFF”(original sound).
3) Press MODE or RETURN to exit.
Note :
• Virtual Surround will not be effective if the sound mode is
set to something other than “STEREO” (for audio CDs
and video CDs only).
• Turn down the level or turn it “OFF” if the sound is
distorted.
Track Search
There are three ways to begin the playback of a specific track.
Using the number buttons
1) Press the number buttons to enter the desired Track
number.
•Playback will start at the selected track.
•For single digit tracks (1-9), press a single number (e.g.
to play track 3, press 3).
•To play track 26, press +10, 2, 6.
Using SEARCH MODE
1) Press SEARCH MODE.
•The Track Search display appears.
2) Within 30 seconds, select a desired track number using
the number buttons. For single digit track number, press 0
first when there are 10 or more tracks in the disc.
•Playback will start at the selected track.
Using SKIP H ,G
During playback, press SKIP Gto move to the next track.
Press it repeatedly to skip subsequent tracks.
Press SKIP Hto go back to the beginning of the current
track. Press it repeatedly to go back to the previous tracks.
•Track number will appear briefly on the front panel
display.
•If SKIP H,Gare pressed while the playback is paused,
the playback will be paused again after skipping to the
next track.
Note: SKIP H,Gare not available when playback is
stopped.
Title / Chapter Search
Using SEARCH MODE
1) During playback, press SEARCH MODE once for the
“Chapter Search”, twice for the “Title Search”.
2) Enter the desired chapter/title number using the number
buttons.
DVD-V
DVD-V
CD VCD
DVD-V CD MP3 VCD
CD MP3 VCD
DVD-V
OFF
/2
FUN_H9701BD(EN).fm Page 20 Tuesday, July 27, 2004 5:57 PM
