Funktion-one Resolution 1 User manual

Resolution 1
Resolution 1Resolution 1
Resolution 1
User Manual
User Manual User Manual
User Manual EN1.0.0.1
EN1.0.0.1EN1.0.0.1
EN1.0.0.1

i
Symbol Description
Publishing Information
Resolution 1 User Manual Version EN1.0.0.1, October 2008.
© Funktion One Research Limited; all rights reserved.
Keep this document with its relevant product or in a safe accessible
place. When selling or reselling this product please draw the new
owner(s) attention to this manual.
Please note:
Every effort has been made to insure up to date accuracy of this
manual, in the unlikely event that there is outdated or incorrect
information Funktion One Research Limited will not be held responsible
for any resulting errors or incidents.
Funktion One Research Limited.
Hoyle, Horsham Road, Beare Green, Dorking, Surrey. RH5 4PS.
England.
Telephone [phone], Fax [phone],
Email: [email protected]m Website: www.funktion-one.com
DANGER! Electrical Hazard
WARNING! Important information.

ii
WARNING
Long term exposure to high Sound Pressure Levels (SPL) will result in
permanent hearing damage. Funktion One produces high efficacy
loudspeakers that can exceed the daily exposure limits set in the
Control of Noise at Work Act 2005 in the United Kingdom.
Only use Funktion One produced or recommended accessories and
replacement parts. Other parts may cause damage to the system and
may pose as a health and safety risk.
When deploying any Funktion One system please refer to weights and
dimensions to determine suitable placement and rigging.
Inspect equipment for excessive wear and tear that might cause a
health and safety risk, if in doubt contact the manufacture for advice and
support.
The loudspeaker contains large powerful magnets that can damage any
electromagnetically sensitive equipment, such as floppy disks, hard-
drives and electronic measuring tools. Please bear this in mind when
deploying or transporting.
Contents
Symbol Description ....................................................................................................... i
Publishing Information...................................................................................................i
WARNING.................................................................................................................... ii
Contents....................................................................................................................... ii
Introduction to the Resolution One ...............................................................................3
Options and Accessories..............................................................................................4
Wiring and Connections ...............................................................................................7
Technical Specifications ...............................................................................................8

3
Introduction to the Resolution One
The Resolution 1 is a radical 2-way
loudspeaker enclosure resulting from Tony
Andrews’ 30 years pioneering research and
development of high efficiency cone mid-
range. This has resulted in a completely new
5 inch loudspeaker which eliminates the need
for compression drivers with their inherent
harshness and distortion. This device, when
used in conjunction with a miniaturised,
dedicated Axhead-loaded waveguide,
smoothly reproduces both the vital mid range
and high frequencies with exceptional
coherency and detail. Further, instead of stretching the response of a
compromised compression driver to (almost) meet an equally stretched
and indistinct 12" or 15" low frequency driver at 1 to 2 kHz as in
traditional 2-way systems, Funktion One’s new 5" device smoothly
connects with the (outstanding) 12" ported bass driver at 520Hz. The
resulting bass is lively and very well defined.
The high efficiency, projection and imaging of the R1 make it hard to
imagine that it comes in such a compact and lightweight package. The
enclosure shape has a rear recess that can either be used to flush fit a
separate passive crossover module or an amplifier module in a future
self powered version. The waveguide can be rotated for use in either
vertical or horizontal formats.
Notes:

4
Options and Accessories
The Resolution 1 has a rotational wave guide to allow flexibility in the
way it is deployed, horizontally or vertically. See the Resolution One
Technical drawing page at the rear of this document for further
illustration.
Note: It is not recommend excessively changing the angle of the wave
guide, as this may cause the fixing to weaken. If in doubt, contact
Funktion One for advice and help.
Finishing and Grills
Standard cabinet finishes are violet or silver. There are two grill options -
a half height punched metal grill which protects the 12" loudspeaker and
covers the ports whilst leaving the also produce a full height black foam
covered metal grill waveguide fully visible. For those preferring a more
discrete appearance (particularly for theatre and AV applications)
Funktion One.
Connections
The Resolution 1 comes with NL4 as standard.
A Passive crossover module is available. The module is inserted in-
between a high power full range signal and the Input connection. The
module is mounted to the outer rear of the enclosure.
Notes:

5
Mountings
The resolution 1 has a verity of mounting options for pole mounts, flying
and wall fixing. Below is the information of types available at the time of
printing:
Product
Code Description Notes
WM1-55 Wall Bracket for R1 (short arm – 55mm)
WM1-160 Wall Bracket for R1 (short arm – 160mm)
SB1-K1 Squaring Bracket (pair) inc Bolts
SB1-K2
Squaring Bracket (pair) inc Bolts and Hand
Wheels
YS1 Simple Yoke (top suspension) Needs a SB1 kit
YT1 Universal ‘Theatre’ Yoke, allows full rotation Needs a SB1 kit
YH1-K1 Yoke kit for Horizontal Mounting
TB1 T-Bar to Fly Two Resolution 1s. Needs a JP1 kit
JP1-K1 Back Joiner for Pair of R1s inc Bolts
JP1-K2 Back Joiner for Pair of R1s inc Bolts an
d Hand
Wheels
Also see the rear of this document for the relevant Technical Drawings.
More up to date information and technical drawings can be found at
www.funktion-one.com.
WARNING: Only use Funktion One approved mounting equipment that is
specifically designed to be used with the Resolution 1. If in doubt, contact
Funktion One for help and Getting Connected
The Following information is recommendations made for sonic quality
through over thirty years of experience.
Notes:

6
Power
There is no substitute for a good clean amplifier, Funktion One has
extensively searched for good quality high power amplifiers and strongly
recommend Funktion Ones OEM E series Amplifiers, developed from
the specialists at MC
2
.
For two or three pairs of Resolution 1 we recommend using a E25 to
drive the 12” while the 5” are driven by an E15. For passively crossed
Resolution 1 an E25 can drive up to 2 pairs.
System Management
For non passive modules we recommend the use of Funktion Ones
Crossover, designed to maintain signal quality during this sensitive
period. We recommend the output settings to be:
Driver
Delay
(mS) Polarity
Cross
Over Point
(HP)
Cross
Over Type
(HP)
Cross
Over Point
(LP)
Cross
Over Type
(LP)
Relative
Gain
Settings (dB)
12” 1.521 Positive 30Hz 24dB LR 520Hz 24dB LR +3
5” 0 Positive 520Hz 24dB LR 22kHz 24dB LR -6
LR= Linkwitz Riley HP= High Pass LP= Low Pass
When paired with a suitable bass it is recommended to raise the 12”
High Pass cross over point to 70-100Hz, see Pairing with Bass for more
information.
Note: These settings are made under the assumption that the
amplifiers of identical input sensitivity and through gain.
GAINS ARE GIVEN AS A STARTING POINT AND NOT AN ABSOLUTE.
Pairing with Bass
Recommended bass loudspeakers
are Funktion One’s Minibass 212,
F118 and the F218. With the High
Pass cross over point between 70-
100Hz depending on the
application.
Notes:

7
Wiring and Connections
The Resolution 1 Loudspeaker utilizes two
Speakon NL4 Connections; an Input and a
Link. The Resolution 1 follows the
standard wiring configuration as shown in
left hand-side diagram.
When using the Passive Module the connection configuration should be
done accordingly to the diagram show below. In this configuration the
full range signal is connected via channel 1 on the NL4 to the Module,
while channel 2 is not connected.
WARNING: The passive module is only designed to drive an
individual Resolution One and thus the Link port MUST NOT BE
USED. When not using the passive module insure it is completely
isolated from the signal path.

8
Technical Specifications
Frequency Response ± 4dB: 65Hz – 15 kHz
Weight: 19 Kg [42 lbs]
Nominal Dispersion: 50°Horizontal
25°Vertical
Connectors: 2 x Speakon 4 Pole [NL4]
Driver Freq. Band
Sensitivity
[1W at 1M]
Power
[RMS]
Nominal
Impedance
12” 65-520 Hz 102dB 350W 8Ω
5” 520-15kHz 112dB 75W 12Ω
Notes:

9
Horizontal Polar Response

10
Vertical Polar Response

36mm
[1 7/16"]
Accessories for:
Copyright Funktion-One Research Ltd
All dimensions in mm and inches
Phone: [phone]
Fax: [phone]
Hoyle, Horsham Road, Beare Green, Dorking, Surrey, RH5 4PS, England
[email protected]
www.funktion-one.com
Resolution 1
DM1 - Double pole mount to array two R1s

Centre Of Gravity
JP1 Joiner Kit
JP1 Joiner Kit
Tilt holes are at 10° increments
Accessories for:
Copyright Funktion-One Research Ltd
All dimensions in mm and inches
Phone: [phone]
Fax: [phone]
Hoyle, Horsham Road, Beare Green, Dorking, Surrey, RH5 4PS, England
[email protected]
www.funktion-one.com
Resolution 1
TB1 - T-Bar to fly two R1s (bar only) - needs JP1 joiner kit
JP1-K1 - Back joiner for pair of R1s, including eyebolt and bolts to attach
to R1
JP1-K2 - Back joiner for pair of R1s, including eyebolt and handwheel bolts
to attach to R1

WM1-160
WM1-55
WM1-55 allows the cabinet to be rotated horizontally until the
cabinet's side is parallel with the mounting wall
WM1-160 allows a greater tilt angle
Tilt
Pan
Accessories for:
Copyright Funktion-One Research Ltd
All dimensions in mm and inches
Phone: [phone]
Fax: [phone]
Hoyle, Horsham Road, Beare Green, Dorking, Surrey, RH5 4PS, England
[email protected]
www.funktion-one.com
Resolution 1
WM1-55 - Wall Bracket for R1 (short arm - 55mm) - allows pan and tilt
WM1-160 - Wall Bracket for R1 (short arm - 160mm) - allows pan and tilt

SB1-K2
SB1-K1
Accessories for:
Copyright Funktion-One Research Ltd
All dimensions in mm and inches
Phone: [phone]
Fax: [phone]
Hoyle, Horsham Road, Beare Green, Dorking, Surrey, RH5 4PS, England
[email protected]
www.funktion-one.com
Resolution 1
SB1-K1 - Squaring Bracket (pair), including bolts to attach to R1 and yoke
SB1-K2 - Squaring Bracket (pair), including bolts to attach to R1 and
handwheels for yoke

413mm
[1'-4 1/4"]
780mm
[2'-6 11/16"]
612,2mm
[2'-0 1/8"]
360° rotation
Handwheels included in
SB1-K2 kit
Squaring Brackets
(SB1) YT1 Yoke
YS1 Yoke
Accessories for:
Copyright Funktion-One Research Ltd
All dimensions in mm and inches
Phone: [phone]
Fax: [phone]
Hoyle, Horsham Road, Beare Green, Dorking, Surrey, RH5 4PS, England
[email protected]
www.funktion-one.com
Resolution 1
YS1 - Simple yoke for R1 (top suspension), needs SB1 kit
YT1 - Universal 'Theatre' yoke for allowing full cabinet rotation, needs SB1 kit

776mm
[2'-6 9/16"]
457,07mm
[1'-6"]
Ø13mm
[Ø1/2"]
250° rotation
Accessories for:
Copyright Funktion-One Research Ltd
All dimensions in mm and inches
Phone: [phone]
Fax: [phone]
Hoyle, Horsham Road, Beare Green, Dorking, Surrey, RH5 4PS, England
[email protected]
www.funktion-one.com
Resolution 1
YH1-K1 - Yoke kit for mounting Horizontal R1, includes two pivot plates
and bolts to attach to R1
