Furrion Trekker 300 Installation instructions

1
lippert.com 432-LIPPERT (432-547-7378) Rev: 11.11.22
Trekker™300W
Portable Power Station
Installation and Owner’s Manual
(For Aftermarket Applications)
CCD-0006492
Table of Contents
Introduction ............................................ 2
Safety ................................................... 2
Product Specications ................................. 2
Product Features ....................................... 3
LCD Display Screen .................................... 4
Operation ............................................... 5
Charging Modes ....................................... 5
Product Usage Tips .................................... 6
Recycling ............................................... 6
Maintenance ............................................ 6
Notes .................................................... 6
Trekker™300W
Portable Power
Station
Installation and
Owner’s Manual
(For Aftermarket Applications)
Part #Part # DescriptionDescription
2022111762 Furrion Trekker 300

2
lippert.com 432-LIPPERT (432-547-7378) Rev: 11.11.22
Trekker™300W
Portable Power Station
Installation and Owner’s Manual
(For Aftermarket Applications)
CCD-0006492
Introduction
This Furrion Trekker 300W Portable Power Station has a
built-in high-quality lithium battery that supports DC, USB
output, AC output.
Additional information about this product can be obtained
from Lippert.com/support or by using the LippertNOW app.
Replacement kits can be ordered from https://store.lci1.
com/ or by using the LippertNOW app.
The LippertNOW app is available for free on Apple App
Store®for iPhone®and iPad®and also on Google Play™for
Android™users.
App Store®and iPad®are registered trademarks of
Apple Inc.
Google Play™and Android™are trademarks of Google Inc.
Safety
Read and fully understand all instructions before installing
or operating this product.
Adhere to all safety labels.
Product Specifications
THE TREKKER 300 MAY GENERATE HEAT WHEN
CHARGED. THIS IS NORMAL. BE CAREFUL WHEN
HANDLING.
DO NOT COVER THE TREKKER 300 WITH TOWELS,
CLOTHES, OR OTHER OBJECTS WHEN USING.
KEEP THE TREKKER 300 OUT OF REACH OF
CHILDREN.
Description Information
Size (L*W*H) 8-21/32” x 5-1/8” x 7-7/8”
Battery Capacity 90000mAh
Weight 6.6lbs
Built-in Battery Technology 100% original quality
lithium battery
DC Input DC15V/3.0A
MPPT Yes
Fully Charged Time About 9hrs
USB Output
USB 1 & 2 (QC3.0): 5V/3A
9V/2A 12V/1.5A
USB-C PD 60W: 5V/3A
9V/3A 12V/3A
15V/3A 20V/3A (In/Out)
USB-C PD 18W: 5V/3A
9V/2A 12V/1.5A
DC Output DC*1+Cig Port*1. 12V/15A (Max)
AC Output AC 120V/60Hz
AC Power Continuous Power: 300W
LED Lighting Power 2W
LED Lighting Three stage: Bright, Strobe, SOS
Battery Indicator Symbol of battery cell, one cell
represents 25% of power
Ambient Temperature
Charging: 0 - 104°F
Discharging: -50 - 104° F
Storage: 0 - 95°F
Cycle Life 500+ Times

3
lippert.com 432-LIPPERT (432-547-7378) Rev: 11.11.22
Trekker™300W
Portable Power Station
Installation and Owner’s Manual
(For Aftermarket Applications)
CCD-0006492
Product Features
1. DC Input Indicator
2. DC Input Port
3. DC Output
4. DC Power Button
5. DC12V Car Cigarette Lighter
6. AC Power Button
7. AC Output
8. USB Power Button
9. USB-C PD60W Port
10. USB1 QC3.0 Port
11. USB2 QC3.0 Port
12. USB-C PD18W Port
13. LCD Display Screen
14. LED Power Panel
15. LED Button
16. Cooling Fan
11
2
1
97
5 6
10
13
14 15
16
12
8
4
3
Left/Right View
Back View
Front View

4
lippert.com 432-LIPPERT (432-547-7378) Rev: 11.11.22
Trekker™300W
Portable Power Station
Installation and Owner’s Manual
(For Aftermarket Applications)
CCD-0006492
A. - Battery Life Indicator
The battery indicator when full will show four cells within,
with each cell representing 25%. When charging, the cells
will flash to represent the current state of the charging
process. Once complete the screen will display “FUL”.
B. - AC Output Symbol
Long-press the button located by the AC output section of
the unit to activate the outputs. The display will show the
“AC” symbol when activated. To turn off, long-press the AC
button again.
NOTE: It is important to turn off the AC outputs when not
in use to avoid battery drain. These outputs are supported
during the charging process.
C. - USB Output Symbol
Short-press the button located by the USB section of the
unit to activate the ports.
The display will show either the “USB” symbol or the “USB
TPYE-C” symbol dependent on the device plugged into the
respective port.
To turn off, short-press the button.
D. - High Temperature Alarm Symbol
This icon will be displayed if the operating temperature of
the unit is too high during use.
E. -Type-C Output Symbol
Short-press the button located by the USB section of the
unit to activate the ports. The display will show either the
“USB” symbol or the “USB TYPE-C” symbol dependent
on the device plugged into the respective port. To turn off,
short-press the button.
When charging the unit utilizing the PD 60W port the
display will show the “USB TYPE-C” symbol.
F. - DC Output Symbol
Short-press the button located by the DC outputs to
activate the ports. The “DC” symbol will be displayed when
device is plugged into either of the ports.
To turn off, short-press the button.
G. OVERLOAD - Overload Alarm Symbol
When the product is overloaded, the overload alarm
symbol will be on, the corresponding port symbol will flash,
the automatic protection will be turned on and the output
will be closed. After the load is removed, the symbol will
be closed, AC will be automatically recovered, and other
buttons can be pressed for recovery.
H. - Real Time Power Display Symbol
Whether the unit is being charged or discharged (powering
devices), the display will represent the amount of power
being used or delivered at the current time. This number
will fluctuate in real time with the plugged in
devices demand.
I. - Real Time Use of Time Symbols
When the unit is being charged, this display will provide
the amount of time estimated until full charge is achieved.
When the unit is being used to power a device, the display
will show the amount of time estimated until charge
is required.
LCD Display Screen
A
B C D E F
I
G H

5
lippert.com 432-LIPPERT (432-547-7378) Rev: 11.11.22
Trekker™300W
Portable Power Station
Installation and Owner’s Manual
(For Aftermarket Applications)
CCD-0006492
Charging Modes
Plug the Power Adapter (Fig. 1A) into the wall outlet (Fig. 1B).
Next plug the Trekker 300 adapter’s round plug into the DC
input (Fig. 1C). The Trekker 300W is fully charged in about 9
hours. The Battery Life indicator will show full when this is
achieved (Fig.1D).
To charge the Trekker 300W with the USB-C PD 60W
input (Fig.2A) (charger not supplied) plug charger into the
PD 60W input to begin the charging process. The Trekker
300W is fully charged in about 7 hours. The Battery Life
indicator will show full when this is achieved (Fig. 2D).
Plug the car charger (Fig. 3A) into the car charging unit in
the vehicle (Fig. 3B). Then plug the power adapters round
plug into the DC input (Fig. 3C). The Trekker 300W is fully
charged in about 13 hours. The Battery Life Indicator will
show full when this is achieved (Fig.3D).
When utilizing solar panels (sold separately) to charge
the Trekker 300W it is important panel wattage does not
exceed 100W (Fig.4A). Plug the solar panel into the DC
Input (Fig.4B). The Trekker 300W is fully charged in about
10-15 hours. The Battery Life Indicator will show full when
this is achieved (Fig.4D).
Fig.1
Fig.2
Fig.3
Fig.4
A B C
D
A
B C
D
A B C D
A B C
Operation
PLEASE STAY AWAY FROM TV, RADIO AND
OTHER EQUIPMENT TO AVOID INTERFERENCE
DURING CHARGING.
NOTE: When storing the Trekker 300W for extended
periods of time, be sure to disconnect all cables prior to
storage.
NOTE: To maintain the battery health of the Trekker 300W,
it is recommended to charge the unit every 3 months or at
least once in a 6-month period.

6
lippert.com 432-LIPPERT (432-547-7378) Rev: 11.11.22
Trekker™300W
Portable Power Station
Installation and Owner’s Manual
(For Aftermarket Applications)
CCD-0006492
Product Usage Tips
• Please observe ambient temperature range of 50-68 F
for optimal performance/charging.
• Be aware of electronic inference which can potentially
disrupt the unit during the charging process.
• When Storing the Trekker 300W for extended periods of
time, be sure to disconnect all cables prior to storage.
• To maintain the battery health of the Trekker 300W, it is
recommended to charge the unit every 3 months or at
least once in a 6-month period.
Recycling
Follow proper recycling guidelines for disposal of this
product.
Maintenance
AVOID STORING THIS DEVICE WITH COINS,
BRACELETS, KEYS AND OTHER METAL OBJECTS.
STORING WITH THESE ITEMS CAN CAUSE A SHORT
CI RCUIT.
• Do not expose the unit to excessive heat, fire, liquids or
long periods of direct exposure to the sun.
• Avoid excessive exposure to areas with high humidity.
• Do not dismantle the unit.
• Impacts, drops or mishandling of the unit will potentially
result in damage.
• Follow proper recycling guidelines for disposal of this
product.

7
lippert.com 432-LIPPERT (432-547-7378) Rev: 11.11.22
Trekker™300W
Portable Power Station
Installation and Owner’s Manual
(For Aftermarket Applications)
CCD-0006492
Notes

8
lippert.com 432-LIPPERT (432-547-7378) Rev: 11.11.22
Trekker™300W
Portable Power Station
Installation and Owner’s Manual
(For Aftermarket Applications)
CCD-0006492
Manual information may be distributed as a complete
document only, unless Lippert provides explicit consent
to distribute individual parts.
All manual information is subject to change without
notice. Revised editions will be available for free
download at lippert.com. Manual information is
considered factual until made obsolete by a revised
version.
Please recycle all obsolete materials and contact
Lippert with concerns or questions.
