Fusion Active Wedge CS-AW1120 User manual

ACTIVE WEDGE
SPECIFICATIONS
 CS-AW1120 CS-AW2120
PeakPower(Watts) 450 750
RatedPower(Watts) 150 250
FrequencyResponse 34Hz-250Hz 34Hz-250Hz
LowPassFilter(Variable) 40Hz-250Hz 40Hz-250Hz
Tuning BassReex BassReex
WooferSize 12” Dual12”
Fuse 25A 25A
Dimensions(mm) 550(l)x408(w)x368(h) 820(l)x408(w)x368(h)
 21-21/32x16-1/32x14-15/32” 32-9/32x16-1/32x14-15/32”
CS-AW1120, CS-AW2120
www.fusionelectronics.com
CONTROL DESCRIPTIONS
LEVEL
Thisallowstheadjustmentoftheamplierlevelofthesubwoofer.
Turnclockwisetoincreasethelevel.Ifthesoundbecomesdistorted
reducethelevel.
LOW PASS FILTER (LPF)
This allows the adjustment of the highest frequency the Active
Wedgewillproduce.Thisshouldbeadjustedtoblendwithyourmain
speakers.Typically,thiswillbesettoaround100Hz(approximately
thecentralpositionofthecontrolknob).
REMOTE LEVEL CONTROLLER
Whenconnected,thisallowsfurthercontroloverthelevelfroma
remotelocation,usingthesuppliedlead.
INSTALLATION
MakesuretheActiveWedgeisrmlyxedinyourvehicle.Check
beforedrillingorcuttingholes.DONOTworkneargastanks,fuel
lines,hydrauliclinesorelectricalwiring.
DO NOT mount the Active Wedge in such a way as to pinch or
damagethewires.
Make sure everything is rmly connected, before attaching the
+12Vwire.Ensurethe+12Vwireisfusedascloseaspossibletothe
battery.Alwaysuseafusewiththerecommendedrating.
DISCLAIMER
AlwaysensuretheActiveWedgeissecurelyattached,toavoidmovement.FUSIONacceptsnoresponsibilityfordamageorinjuryinrelation
toinappropriatesecuringofthisproduct.
WIRING
• Connectthegroundwiretothevehiclerst(cleandirtandpaint
 tobaremetal).
• Connecttheremoteon(bluewire).
• ConnecttheRCAcablesifapplicable,OR
• Connectthespeakerlevelwirebysplicingintotheheadunits 
 speakerwires.SeeNote1onreverse.
• Connecttheremotelevelcontrollerwiththesuppliedlead.
• Connectthe12volt(redwire)tothepositivebatteryterminal. 
• Checkallconnections.
PUBLISHEDBYFUSIONELECTRONICSLIMITED:©Copyright2010byFUSIONElectronicsLimited.Allrightsreserved.Specicationsanddesignaresubjecttochangewithoutnotice.
YOUCANHELPPROTECTTHEENVIRONMENT!Pleaseremembertorespectthelocalregulations:Handinthenon-workingelectricalequipmenttoanappropriatewastedisposalcenter.
RECORD YOUR PURCHASE DETAILS HERE:
SERIALNUMBER
DATEOFPURCHASE
AFFIXRECEIPTHERE
WARNING:AudioSystemscanproducesoundlevelsover135dB.Continuousexposuretosoundpressurelevelsover100dBmaycausepermanent
hearingloss!Pleasewatchforemergencyvehiclesaswarningsignalsmaynotbeheard.USECOMMONSENSE!
Forfurtherproductandinstallationinformation,pleasevisitwww.fusionelectronics.com
Pourplusd’informationssurlesproduitsetl’installation,rendez-voussurwww.fusionelectronics.com
Paraobtenermásinformaciónacercadelosproductosydesuinstalación,visiteelsitiowebwww.fusionelectronics.com
Bezoekwww.fusionelectronics.comvoormeerproduct-eninstallatie-informatie.
WeitereProdukt-undInstallationsinformationenndenSieunterwww.fusionelectronics.com
Perulterioriinformazionisuiprodottielaloroinstallazione,potetevisitarewww.fusionelectronics.com
Для получения дополнительной информации о продуктах и установке зайдите, пожалуйста, на: www.fusionelectronics.com
Note 1
Takecaretomakesurethewires
aresplicedinthecorrectphase.
Positivetopositive,negativeto
negative.Failuretodothiscorrectly
couldresultinlossofbass.
SeeNote1
Spliceintosource
unit’sspeakerwires
(R+)Grey/White
(R-)Grey
(L+)Green/White
(L-)Green
Connecttheremote
levelcontrollerleadto
theamplier
Connectredwire
topositive(+12V)
batteryterminal
Connectbluewiretosourceunit’s
accessoryleadorswitched12volt
source(REM)
Connectblackwire
tochassisground
ofvehicle(Ground)
SpeakerLevel
InputPlug
RemoteLevelController
VehicleBattery
