Fusion FUS-SW104 User manual

FUS-SW104 FUS-SW124
Peak Power (Watts) 800 1000
Rated Power (Watts) 200 250
Frequency Response 28Hz - 2kHz 26Hz - 1.5kHz
Impedance 4 Ohm 4 Ohm
Sensitivity 88dB 90dB
Cone Material Pressed Paper Pressed Paper
Voice Coil Type Round Wound Copper Round Wound Copper
Mounting Depth 126mm (4-15/16”) 138mm (5-7/16”)
Mounting Diameter 230mm (9-1/16”) 279mm (11”)
FUS-SW104 Ported Sealed
Volume 40.0L (1.53 cu.ft.) 15.0L (0.53 cu.ft.)
Fb (Hz) Tuned frequency 33.5 49.1
Port Diameter 76.2mm (3”) -
Port Length 114mm (4-1/2”) -
FUS-SW124 Ported Sealed
Volume 60L (2.12 cuft) 28L (0.989cuft)
Fb (Hz) Tuned frequency 33.3 49.2
Port Diameter 76.2mm (3”) -
Port Length 42mm (1.62”) -

INSLLATIN GUIDELINES









 
 
 
 

FUS-SW104 FUS-SW124
Fs (Hz) 36.60 34.40
Qms 9.23 9.23
Vas (liters) 33.72 60.66
Vas (Cu ft) 1.19 2 .12
Mms (gms) 101. 0 0 140.91
Mms (oz) 3.56 4.97
Rms (kg/s) 2.51 3 .12
Rms (lb/s) 5.53 6.89
Cms (um/N) 188.00 152.00
Xmax (mm) 6.00 6.00
Xmax (inches) 0.24 0.24
Xmech (mm) 9.00 9.00
Xmech (inches) 0.35 0.35
Dv (mm) 212.70 259.80
Dv (inches) 8.37 10.23
Sd (sq cm) 356.33 530.93
Sd (sq inches) 55.23 82.29
Vd (liters) 0.21 0.32
Vd (cu.ft.) 0.0075 0.0112
Qes 0.89 1. 2 2
Re (Ohms) 3.63 3.71
Le (mH) 1. 37 1.50
BL 9.73 9.63
Qts 0.81 1.08
no (%) 0 .18 0.20
