EL Series Installation Instructions
Important Safety Information
WARNING
Failure to follow these warnings and cautions could result in
personal injury, damage to the vehicle or vessel, or poor product
performance.
This device must be installed according to these instructions.
Disconnect the vehicle's or vessel's power supply before
beginning to install this product.
CAUTION
Continuous exposure to sound pressure levels over 100 dBA
may cause permanent hearing loss. The volume is typically too
loud if you cannot hear people speaking around you. Limit the
amount of time you listen at high volume. If you experience
ringing in your ears or muffled speech, stop listening and have
your hearing checked.
Always wear safety goggles, ear protection, and a dust mask
when drilling, cutting, or sanding.
NOTICE
When drilling or cutting, always check what is on the opposite
side of the surface.
It is strongly recommended that you have your audio system
installed by a professional installer to ensure optimum
performance.
You must read all installation instructions before beginning the
installation. If you experience difficulty during the installation, go
to www.fusionentertainment.com for product support.
Tools Needed
• Electric drill
• Drill bit (size varies based on surface material)
• Phillips screwdriver
• Wire strippers
• Crimping tool
• Electrical tape
• Appropriate saw or utility knife to cut surface material
• Marine sealant (optional)
NOTE: For customized installations, additional tools and
materials may be needed.
Mounting Considerations
Selecting the correct mounting location is critical to optimize the
performance of each speaker. FUSION® speakers are designed
to perform in the widest possible range of mounting locations,
but the more you plan the installation, the better the speakers'
sound will be.
• For the best performance, you should mount the speakers
higher in the boat. Sound travels in the direction in which the
speakers are facing, so if you mount them in a lower location,
the sound quality and volume may not be not ideal.
• If you intend to mount the speakers outside the boat, you
must mount them in a location well above the waterline,
where they are not submerged or damaged by docks, pilings,
or other pieces of equipment. When mounted correctly, these
speakers are rated IP65 for protection from the front of the
speaker. Water exposure and damage to the rear of the
speaker voids the warranty. This includes situations when the
speakers are mounted in a sealed enclosure, especially if
they are exposed to wash down. On supported models, using
an enclosure with a port or vent exposed to the outside
environment may allow water to collect and damage the
speaker.
• You should select mounting locations that enable you to hear
sound from both speakers at the same time to achieve a
sound stage effect. To achieve this effect, you should not
mount the speakers side-by-side.
• When possible, you should select mounting locations where
the area behind each speaker is enclosed.
• You must select mounting locations that provide sufficient
clearance for the mounting depth of the speakers as
specified in the product specifications.
• For better bass performance, you should select a mounting
locations that provide the appropriate space behind the
speaker according to the optimum enclosure design
requirements in the specifications section. Too small an area
restricts bass, and too large an area compromises bass
performance. Also, mounting a speaker close to an open
area (where sound from the back of the speaker has a very
short path to compete with sound from the front of the
speaker) produces the least bass.
• On supported models, when a speaker is not exposed to the
outside environment, you can achieve a better bass
performance using an enclosure with a ported design. For
supported models, the optimum enclosure design
recommendations in the specifications section include
dimensions for the optimum port size and length.
• You should select a flat mounting surface for the best seal.
• You should protect the speaker wires from sharp objects and
always use rubber grommets when wiring through panels.
• You should select mounting locations that avoid potential
obstacles, such as fuel and hydraulic lines and wiring.
• You should protect all terminals and connections from
grounding and from each other. Failure to do so could result
in permanent damage to the audio system and void the
product warranty.
• To avoid interference with a magnetic compass, you should
not mount the speakers closer to a compass than the
compass-safe distance value listed in the product
specifications.
• You must turn off the audio system before making any
connections to the source unit, amplifier, or speakers. Failure
to do so could result in permanent damage to the audio
system.
Mounting the Speakers
Before mounting the speakers, you must choose a location
following the guidelines above.
Before cutting the mounting surface you should verify that there
is enough clearance for the speaker behind the surface. Refer to
the specifications for clearance information.
NOTICE
Do not apply grease or lubricant to the screws when fastening
the speakers to the mounting surface. Grease or other lubricants
can cause damage to the speaker.
1Route the wires from the source to the speaker location,
away from sources of electrical interference.
GUID-FF67D738-0427-418B-829A-44F0C22D890C v2August 2020

2Trim the template and make sure it fits in the selected
location.
3Orient the template so that the FUSION logo is right-side up
on the template.
4Secure the template to the selected location.
5Using a rotary tool or jigsaw, cut the mounting surface along
the inside of the line on the template.
6Place the speaker in the cutout to test the fit.
7If necessary, use a file and sandpaper to refine the size of
the cutout.
8After the speaker fits correctly in the cutout, ensure the
mounting holes on the speaker line up with the pilot holes on
the template.
9If the mounting holes on the speaker do not line up, mark the
new hole locations.
10Using an appropriately sized drill bit for the mounting surface
and screw type, drill the holes.
11Remove the template from the mounting surface.
12Connect the speaker wires while observing polarity.
13If necessary, connect the LED wires (LED Wiring, page 2).
14Place the speaker in the cutout.
15Secure the speaker to the mounting surface using the
included screws .
NOTE: Do not over tighten the screws, especially if the
mounting surface is not flat.
16With the speakers mounted, hold the grille with the FUSION
logo at the bottom, or at the 6 o'clock position.
17Turn the grille counter-clockwise about 30 degrees, so the
FUSION logo is at the 5 o'clock position.
18Place the grille on the speaker, and twist it clockwise to
secure it.
NOTE: Instead of twisting to install the grille, you can line it
up so the FUSION logo is at the 6 o'clock position and press
to snap it into place.
LED Wiring
Connecting the LED Wires
Before you connect the LED wires, you should determine which
speaker LED color you want to use, and identify the
corresponding speaker wire colors.
Speaker LED Color Speaker Wire Color
Red Red
Green Green
Blue Blue
Yellow Red and green
Magenta Red and blue
Cyan Blue and green
White Red, green, and blue
NOTE: This feature is available only on the sports model
speakers.
You can control the color of the speaker LEDs through the
polarity of the LED wires. You can splice the ground wire to
multiple wires on the LED cable to customize the LED color.
The black wire on the LED cable is terminated with a 4 mm
female bullet connector, and the color wires are terminated with
4 mm male bullet connectors. You can connect these to 4 mm
bullet connectors on your wires (not included), or remove the
bullet connectors to connect to the bare wires instead.
1Connect a positive wire to the black wire on the LED cable.
2Connect a ground wire to the wire on the LED cable
according to the preferred speaker LED color.
3Route the positive and negative wires, and connect them to a
power source (Connecting the Sports Model Speakers LED
Wires to Power, page 2).
Connecting the Sports Model Speakers LED Wires to Power
NOTE: This feature is available on only the Sports model
speakers.
You must connect all 12 Vdc wiring to the LEDs to a 3 A fuse at
the power-source end of the cable. You should connect the
positive (+) power wire to a 12 Vdc power source through an
isolator switch or circuit breaker to turn the speaker LEDs on
and off. You can use the same isolator or circuit breaker
controlling the power supply to your stereo, which allows you to
turn the LEDs and the stereo on and off at the same time.
You should use 20 AWG (0.5 mm2) or thicker wire to connect
the LEDs to the battery.
1Route the positive power (+) and negative ground (-) wires
from the speaker to the battery.
2Connect the negative wire to the negative (-) battery terminal.
3Connect the positive wire to the positive (+) terminal through
a 3 A fuse and isolator switch or circuit breaker.
Attaching the Grille
1With the speakers mounted, hold the grille with the FUSION
logo at the bottom, or at the 6 o'clock position.
2Turn the grille counter-clockwise about 10 degrees, so the
FUSION logo is at the 5 o'clock position.
3Place the grille on the speaker, and twist it clockwise to
secure it.
NOTE: You can press on the grille to snap it into place
instead of twisting it.
Speaker Information
Registering Your EL Series
Help us better support you by completing our online registration
today.
• Go to www.fusionentertainment.com.
• Keep the original sales receipt, or a photocopy, in a safe
place.
2 EL Series Installation Instructions

Dimension Drawings
Side View
40 mm (1 37/64 in.)
127 mm (5 in.)
A Sports model speaker is shown, but the dimensions are the
same for the Classic model.
Front View
176 mm (6 15/16 in.)
A Sports model speaker is shown, but the dimensions are the
same for the Classic model.
Back View
176 mm (6 15/16 in.)
156 mm (6 1/8 in.)
Cleaning the Speakers
NOTE: When mounted correctly, these speakers are rated IP65
for protection in the harsh marine environment from the front of
the speaker. They are not designed to withstand high pressure
water spray, which may occur when you wash down your
vessel. Failure to carefully spray-clean the vessel may damage
the product and void the warranty.
NOTICE
Do not use harsh or solvent-based cleaners on the speakers.
Using such cleaners may damage the product and void the
warranty.
1Clean all salt water and salt residue from the speaker grille
with a damp cloth soaked in fresh water.
2Use a mild detergent to remove a heavy buildup of salt or
stains.
Troubleshooting
Before you contact your FUSION dealer or service center, you
should perform a few simple troubleshooting steps to help
diagnose the problem.
If the FUSION speaker has been installed by a professional
installation company, you should contact the company so the
technicians can assess the problem and advise you about
possible solutions.
There is no sound coming from the speakers
• Verify that all connections from the source device and/or the
amplifier are connected correctly to the speaker terminals.
The system lacks bass or high frequencies
• Verify that the correct wire polarity is observed between the
source and speakers.
The wires should be connected positive to positive and
negative to negative.
• Verify that the speakers are attached firmly to the mounting
surface.
The audio is distorted
• Verify that the source volume is not too loud for the speaker,
and reduce the volume if necessary.
• Verify that the panels surrounding the speaker on the vessel
are not rattling.
• Verify that the source device and/or the amplifier are
connected to the speaker terminals correctly.
• If the speaker is connected to an amplifier, verify that the
input level of the amplifier is matched to the output level of
the stereo. For more information, see the manual for the
amplifier.
The LED lights will not turn on
• Verify that all wiring connections are correct and tight.
Specifications
Max. power (Watts) 80 W
RMS power (Watts) 20 W
Efficiency (1 W/1 m) 88 dB
Frequency response (+ 3 dB) 45 Hz to 16 kHz
Min. mounting depth (clearance) 43 mm (1 11/16 in.)
Mounting diameter (clearance) 130 mm (5 1/8 in.)
Impedance 4 ohm
Amplifier power-rating
recommendation
From 20 to 40 W RMS, playing
music
EL Series Installation Instructions 3

LED supply voltage (sports model
speakers only)
From 10.8 to 16 Vdc
LED load current at 16 Vdc (sports
model speakers only)
150 mA per color
Optimum enclosure volume
recommendation1
8 L (0.3 ft.3)
Operating temperature range From 0 to 50°C (from 32 to
122°F)
Storage temperature range From -20 to 70°C (from -4 to
158°F)
Cone material Polypropylene
Water and dust rating IEC 60529 IP65
NOTE: This speaker is not intended to be installed in a vented
or ported enclosure.
Compass-Safe Distances
All speakers contain magnets which may cause interference
with instruments on your boat. The size of the magnet used in
the speaker affects how much interference the speaker may
cause.
Interference can cause deviations and variations in the readings
of sensitive navigational equipment, such as magnetic
compasses. These deviations can cause inaccuracies or offsets
in the readings, but will not harm the equipment. To alleviate the
deviations, adjust the compass for the deviation following the
manufacturer's instructions or move the speaker away from the
navigational equipment. After moving a source of interference,
you may need to recalibrate the compass.
If you are navigating solely by a magnetic compass, use
extreme caution to place the speaker far enough away from the
compass to avoid causing deviations in the readings.
To avoid deviations to navigational equipment, position the
speakers so they are separated from the navigational equipment
by at least the distance listed in the table below.
171 cm (5 ft. 8 in.)
171 cm (5 ft. 8 in.)
254 cm (8 ft 4 in.)
171 cm (5 ft. 8 in.)
171 cm (5 ft. 8 in.)
254 cm (8 ft 4 in.)
© 2018 Garmin Ltd. or its subsidiaries
Garmin®, the Garmin logo, FUSION®, the Fusion logo, and True-Marine™ are trademarks
of Garmin Ltd. or its subsidiaries, registered in the USA and other countries. These
trademarks may not be used without the express permission of Garmin.
1 Sealed enclosure, fully filled with absorption material.
© 2018 Garmin Ltd. or its subsidiaries www.fusionentertainment.com
