Fusion CS-FR4020 User manual

FULL RANGE SPEAKERS
 CS-FR4020 CS-FR5020 CS-FR6020 CS-FR6930
PeakPower(Watts) 160 190 210 310
RatedPower(Watts) 30 35 40 55
FrequencyResponse 44Hz-24kHz 41Hz-24kHz 35Hz-24kHz 28Hz-25kHz
Impedance 4Ohms 4Ohms 4Ohms 4Ohms
Sensitivity 83dB 84dB 85dB 87dB
ConeMaterial Polypropylene Polypropylene Polypropylene Polypropylene
Tweeter PEI PEI PEI PEI
MountingDepth 45mm(1-3/4”) 43mm(1-11/16”) 41.5mm(1-11/16”) 71.5mm(2-14/16”)
MountingDiameter 103mm 118mm 126mm 222x156mm
 (4-1/16”) (4-21/32”) (5”) (8-24/32x6-3/16”)
CS-FR4020 CS-FR5020 CS-FR6020 CS-FR6930
WARNING:Donotdrillmountingholeswithspeakerinplaceasthiscouldallowdrillshavingstodamagethe
voicecoilandvoidyourwarranty.
SPEAKER PARAMETERS
INSTALLATION GUIDELINES
Ensuretheaudiosystemisturnedoffbeforemakinganyconnectionstothe
amplier,speakersorsourceunit.Failuretodosocouldresultinpermanent
damagetotheaudiosystem.
Whenwiringthespeakersensurethatthewireisprotectedfromsharp
objectsandalwaysuserubbergrommetswhenwiringthroughmetalpanels.
Ensureallterminalsandconnectionsareprotectedfromthevehiclechassis
andfromeachotherasfailuretodosocouldresultinpermanentdamageto
theaudiosystem.
Whenconnectingthesourceunitandspeakersensureyouconnectthe
positiveandnegativeoutputwirefromthesourceunittothecorresponding
speakerterminals.Thiswillensuretheaudiosystemwillbeinphase.
1) Ensurethereisadequateclearanceanddepthforthespeakertobe
 mounted.
2) Usethesuppliedtemplatetomarkout&cutthecorrectdiameterhole.
3) Drillfourholesforthemountingscrews.
4) Seperatethegrillefromtheframe.
5) Insertthespeakerandgrilleframeandafxwiththescrewsprovided.
6) Completeinstallationbyreplacingthegrilleintothegrilleframe.
www.fusionelectronics.com

PUBLISHED BY FUSION ELECTRONICS LIMITED: © Copyright 2010 by FUSION Electronics Limited. All rights reserved. Specications and design are subject to change without notice.
YOU CAN HELP PROTECT THE ENVIRONMENT! Please remember to respect the local regulations: Hand in the non-working electrical equipment to an appropriate waste disposal center.
RECORD YOUR PURCHASE DETAILS HERE:
SERIAL NUMBER
DATE OF PURCHASE
AFFIX RECEIPT HERE
WARNING: Audio Systems can produce sound levels over 135dB. Continuous exposure to sound pressure levels over 100dB may cause permanent
hearing loss! Please watch for emergency vehicles as warning signals may not be heard. USE COMMON SENSE!
