POWERPLANT
COMPONENT SPEAKERS
PP-CM525, PP-CM650
Speaker Parameters
Crossover Specifications
2-way, passive Butterworth crossover network
12db/octave slope rates
Adjustable 3-point tweeter level
High pass 3.5kHz
Low pass 4.0kHz
Installation Guidelines
Before any wiring and installation is performed, FUSION recommends you first plan the complete installation process.
Look at the wiring routing, speaker location, and fitment. Make sure you recheck the installation at completion.
A correct front stage and stereo image can be achieved by proper speaker placement. Ideally, speakers need to be posi-
tioned where the sound produced is directed at the occupants of the vehicle. The adjustable tweeter supplied with FUSION
PowerPlant Component Speakers is designed to make this easier.
Fusion speakers have been designed to fit in many stock or factory positions in the vehicle FUSION recommends a location
with sufficient air volume behind the speaker, for it to work within its frequency range.
Installation Warning
1. Ensure the vehicle 12 volt lead is removed from the battery before any equipment is connected.
2. Investigate the vehicle gas tanks, brake lines, and electrical wiring locations before you begin installation.
3. Attach the product securely to the vehicle to prevent damage in the event of an accident.
4. Ensure all wiring is protected to avoid damage or pinching of the cables.
Installation Guidelines:
Bass/mid speaker installation
1. Ensure there is adequate clearance and depth for the speaker to be mounted
2. Use the supplied template to mark out the correct diameter hole
3. Drill four holes for the mounting screws
4. Correctly connect the crossover to the speaker. Observe polarity. The striped wire is the positive.
5. Carefully study the mounting diagram before attempting to mount the speaker. Insert the speaker and grille frame
and affix with the screws provided. Your PowerPlant speaker is provided with two choices of grille frame. The cus-
tom grille is screwed directly into the frame of the speaker (see diagram A on reverse side). For the mesh grille,
first remove the mesh, then fit the speaker and the grille. The mesh is fitted last by simply pushing the tabs on the
mesh into the self-locking slots in the grille frame. (see diagram B on reverse side).
PP-CM5250 PP-CM650
Max Power Rating 210 Watts 280 Watts
RMS Power Rating 95 Watts 120 Watts
Frequency Response 50Hz - 22kHz 40Hz - 22kHz
Impedance 4 Ohms 4 Ohms
Sensitivity 90 dB 91 dB
Mounting Depth 60mm 65mm
Mounting Diameter 125mm 140mm
WARNING: Do not drill mounting holes with speaker in place, as this could allow drill shavings to damage the voice coil.
Always ensure the audio system is turned off before making any connections to the amplifier, speakers, crossover or
source unit. Failure to do so could result in permanent damage to the audio system.
When wiring the speakers, ensure that the wire is protected from sharp metal objects, and always use rubber grommets
when wire through metal panels. Ensure all terminals and connections are protected from the vehicle chassis and from
each other.
When connecting the source unit/amplifier crossover and speakers, you connect the positive and negative output wire
from the source unit/amplifier or crossover, to the corresponding speaker terminals. This will ensure the audio system
will be in correct phase.
RECORD YOUR PURCHASE DETAILS HERE:
MODEL NUMBER __________________________ DATE OF PURCHASE__________________________
AFFIX RECEIPT HERE
WARNING! Audio Systems can produce sound levels over 135dB. Continuous exposure to sound pressure levels over 100dB may
cause permanent hearing loss! Please watch for emergency vehicles as warning signals may not be heard. USE COMMON SENSE!
V 2.0
