FUTUREROBOT E300 Series Reference manual

E300 Series Fanless Embedded Computer
1
Introduction
Copyright Statement
All documents, drawing, data and other contents in this User Manual are owned by Future Robot
Technology Co., Limited, all rights reserved.
All specifications and applications are subject to change without prior notice
Safety Instruction
1. Please read this safety instruction carefully
2. Please keep this User Manual for future reference
3. Please unplug power line before clearing with wet duster cloth. Do not use liquid or
decontamination sprays to clean equipment.
4. Please do not use the equipment in damp environment
5. Please ensure placing equipment on flat surface before installation, accidental drop may
cause damage to the equipment.
6. Before connecting the equipment with power supply, please confirm the voltage meets
requirement.
7. If you do not use equipment for a long time, please disconnect from power supply to avoid
excessive voltage fluctuations
8. Please avoid any liquid in case of fire or short circuit.
9. Please call for professional support with following situations:
Damage of power line or plug
Liquid inflow into the equipment
Exposure to excessive moisture working environment
Drop or damage of Equipment
10. Please do not place the equipment in the environment beyond recommended
temperature range, or it may cause damage to equipment.
11. The computer is equipped with a real-time clock circuit powered by the battery. If
the battery is not replaced correctly, there will be a risk of explosion. Therefore,
only the same or the same type of battery recommended by the manufacturer can
be replaced. Please follow the manufacturer's instructions to dispose of the used
battery.

2
12. Note: any unproven component may cause accidental damage to the equipment.
To ensure correct installation, only use the parts provided in the accessory box,
such as screws.
Warning and notice
Warning！
During operation, users shall pay special attention to the warning information in this
manual to avoid injury.
Notice！
The notes in this manual help users to avoid hardware damage or data loss, such as the
risk of exploding if the battery is not replaced correctly. Therefore, you can only replace it
with one or the same type of battery recommended by the manufacturer. Please follow the
manufacturer's instructions to dispose of old batteries.
Safety Precautions
Follow these simple precautions to protect yourself and your device from harm and
damage.
To avoid electric shock, please do not touch the main board and any parts before power
off.
Power supply must be disconnected before any parts is replaced, otherwise sensitive
components will be damaged due to excessive power when connecting jumpers or
installing other components.

E300 Series Fanless Embedded Computer
3
Table of Contents
Chapter 1 Overview ............................................4
1.1 Brief Introduction ..............................................................................................................................4
1.2 Specification ......................................................................................................................................5
1.3 Dimension..........................................................................................................................................6
1.4 LED Indicators...................................................................................................................................7
Chapter 2 I/O Interface .........................................8
I/O Instruction..........................................................................................................................................8
2.1 Power Button .........................................................................................................................9
2.2 Power Input Interface.............................................................................................................9
2.3 DisplayPort............................................................................................................................9
2.4 HDMI Port...........................................................................................................................10
2.5 USB Port..............................................................................................................................10
2.6 Ethernet (LAN)....................................................................................................................10
2.7 Audio....................................................................................................................................11
2.8 Serial Port (COM)................................................................................................................11
2.9 TF Card................................................................................................................................12
2.10 WiFi/4G Antenna (Optional)..............................................................................................12
2.11 Clear CMOS.......................................................................................................................12
2.12 Build-in 5V/12V Power Interface (5VCONN/12VCONN)...............................................13
2.13 Build-in Remote switch interface(CONN_EXT_BTN).....................................................13
Chapter 3 Operating Instruction .................................14
3.1 Unpacking Check.............................................................................................................................14
3.2 Operation Environment....................................................................................................................14
3.3 Getting Started.................................................................................................................................14
3.4 Installation .......................................................................................................................................14
Chapter 4 BIOS Setup Instruction................................16
4.1 BIOS Introduction............................................................................................................................16
4.1.1 CMOS Setup.....................................................................................................................16
4.1.2 Function Key and Instruction............................................................................................17
4.2 Main Menu.......................................................................................................................................18
4.3 Main (standard CMOS function setting)..........................................................................................19
4.4 Advanced (advanced BIOS function setting)...................................................................................19
4.5 Chipset(chipset function setting) .....................................................................................................21
4.6 Security (administrator/user and password).....................................................................................22
4.7 Boot..................................................................................................................................................23
4.8 Save&Exit........................................................................................................................................24

4
Chapter 1 Overview
1.1 Brief Introduction
E300 Series ultra-compact embedded computer are based on Intel Apollo Lake processor, with
optimum I/O design to fulfill multi connection requirements. Reinforced aluminum alloy enclosure
design is ideally suitable for steady performance in hash industrial environment.
E300 Series has unique expansion design to go through PCIe/USB/SPI/I2C/LPC connections to
expand and achieve rich and effective customization.
E300 Series intelligent and powerful embedded computer supports wide range of applications and
easy arrangement and deployment, it has excellent performance in Intelligent Transportation,
Facility Management, Industrial Automation and Internet of Things.

E300 Series Fanless Embedded Computer
5
1.2 Specification
P/N
E300 series
E310 series
CPU
Intel Apollo Lake N3350/N4200/J3455/E3900 Series processor
Memory
Onboard 2GB DDR3L upto 8GB
Display
1x DP, Max.4096 x 2304 @ 60Hz
1x HDMI, Max.4096 x 2304 @ 24Hz
HDMI+DP independent display
Audio
Realtek ALC662, High Definition Audio. Line-out, Mic-in
Ethernet
1x RTL8111H GbE, support Wake
On Lan
1x RTL8111H GbE, support Wake On Lan
2x Intel i211 GbE, support Wake On Lan
Serial Port
1 x RS232 (optional)
2 x RS232, 2 x RS485
USB
2 x USB3.0, 2 x USB2.0
2 x USB3.0,3 x USB2.0 ( 1x USB2.0
internal)
Mini-PCIe
-
1xFull Size for WLAN/WWAN module
SIM Card
-
1 x USIM for 3G/4G LTE communication
M.2 E Key
1 x M.2 E Key for WLAN
-
eMMC
8GB upto 256GB
TF-Card
1x TF slot
SATA3.0
-
1 x SATA3.0 for 2.5”HDD
Power Supply
24W AC-DC power adaptor
12~32V DC-input
OS
Windows 10 64 Bit, Linux
Enclosure
Aluminum Alloy
Mounting
Wall Mounting
Dimension
120 x 101 x 39.5mm (LxWxH)
120 x 101 x 51mm (LxWxH)
Weight
0.57kg
0.65kg
Operation
Temperature
-20°C~ 60°C, airflow 0.7m/s
Storage
Temperature
-40°C~80°C
Relative
Humidity
95% @ 40 (Non-Condensing)
ESD
Contact +/-4 KV, Air+/-8 KV
EMC
CE/FCC
Table 1-1: Specification

6
1.3 Dimension
Dimension for E300 series Fanless Embedded computer, all units are in millimeters (mm).
Figure 1-1: Top view
Figure 1-2: Side view

E300 Series Fanless Embedded Computer
7
Dimension for E310 series Modular Fanless Embedded computer, all units are in millimeters (mm).
Figure 1-3: Side view
1.4 LED Indicators
Icon
Color
Status
Description
Blue
Power
Power off: Off
Power on: On
Green
SATA HDD test
With HDD: light on
Operating: blink
No HDD: light off
Green
Standby Indicator
Standby: blink
Operating: light off
Table 1-2: LED Operation Indicators

8
Chapter 2 I/O Interface
I/O Instruction
I/O connectors on front, rear and side panel of E300 series. *mark is specific for E310 series.
Figure 2-1: Front Panel I/O
Figure 2-2: Rear Panel I/O
WiFi/4G(optional)
Figure 2-3: Side Panel I/O

E300 Series Fanless Embedded Computer
9
2.1 Power Button
The power button is a non-latched push button with a blue LED indicator. System is turned on when
button is pressed, and the power LED lit. If the system hangs, depressing the button for 5 seconds
powers down the system.
Figure 2-4: Power Button
2.2 Power Input Interface
E300 series DC jack 12V Power input, E310 series 12~32V 3pin phoenix.
Figure 2-5: 12V DC input jack
Figure 2-5: Phoenix DC input
2.3 DisplayPort Connector
One DisplayPort connector on the rear panel supports for resolutions Max. 4096 x 2304 @ 60Hz.

10
Figure 2-7: DisplayPort Connector
2.4 HDMI Port
One HDMI port on the rear panel supports for resolutions Max. 4096 x 2304 @ 24Hz.
Figure 2-8: HDMI Port
2.5 USB Port
2xUSB2.0, 2xUSB3.0 supporting plug and play which allow users connect or disconnect any time,
no need to shut off the computer.
Figure 2-9: USB port
2.6 Ethernet (LAN)
One Ethernet port on the rear panel support with Intel i210 GbE controller for E300.
Three Ethernet ports on front and rear panel with one RTL8111H GbE and two Intel i210 GbE
controllers for E310.
RJ-45 standard socket
LED indicator on front panel indicates Transmission/Connected status.
USB2.0
USB3.0

E300 Series Fanless Embedded Computer
11
Figure 2-10: Ethernet
2.7Audio
Two 3.5 stereo Audio ports support Mic-in and Line-out.
Audio controller Realtek ALC662
Figure 2-11: Mic-in and Line-out
2.8 Serial Port (COM)
Onboard 9-pin RS232 connector for E300
Four D-sub 9-pin Serial Ports supports 2 x RS232 (COM1, COM2) and 2 x RS485 (COM3, COM4)
for E310.
Reminder: recognizing with the first pin and noticing the triangle next to the serial socket.
Figure 2-12: Serial Ports
Pin
RS232(D-sub)
RS485(D-sub)
RS232(Onboard)
1
DCD
DATA-
DCD
2
RXD
DATA+
DSR
3
TXD
NC
RXD
4
DTR
NC
RTS
5
GND
GND
TXD
6
DSR
NC
CTS
7
RTS
NC
DTR
8
CTS
NC
RI

12
9
RI
NC
GND
Table 2-1: Pin definition of Serial Port
Note: NC stands for No Connection
2.9 TF Card
1 x TF Card slot, Max 256GB
Figure 2-13: TF Card
2.10 Wi-Fi/4GAntenna (optional)
1 x M.2 E Key for WLAN, Wi-Fi communication –E300 series
1 x Full Size Mini-PCIe for WLAN or WWAN module, 1 x USIM for 3G/4G LTE communication –
E310 series
Figure 2-14: Wi-Fi/4G Antenna
2.11 Clear CMOS
Clear CMOS Jumper as Figure 2-15.
CMOS is powered by button cell on motherboard. To clear CMOS will result in permanent
elimination of system settings and will be restored to factory default settings.
Steps:
(1) Turn off computer and disconnect power supply
(2) Press Clear CMOS for 3-5 seconds with a slender needle and release
(3) Star computer and press Del entering into BIOS setting to reload optimum default value
(4) Save and exit
Figure 2-15: Clear CMOS
Do not clear CMOS when computer is power on to avoid any damage of the
device.

E300 Series Fanless Embedded Computer
13
2.12 Build-in 5V/12V Power Interface
Build-in 2-pin 5V/12V power interface, user can supply power to the device according to their
needs.
Figure 2-16: 5V/12V Power Interface
Pin
5V
12V
1
5V+
12V+
2
GND
GND
Table 2-2: Pin Definition
2.13 Build-in Remote Switch Interface (CONN_EXT_BTN)
User can choose relevant signal according to their needs with 4-pin build-in remote switch interface
on E300 motherboard.
Figure 2-17: Remote Switch Interface
Pin
Remote Switch
1
PWR
2
GND
3
GND
4
3.3V+
Table 2-3: Pin Definition of Remote Switch

14
Chapter 3 Operating Instruction
3.1 Unpacking check
Before unpacking, check the packing list about part number and details. After unpacking, check the
device inside. If there’s any damage or inconformity of product details, inform your dealer
immediately.
To avoid static electricity from damaging the device, please touch a metal object
which effectively grounded before touching the device circuit to release the static
charge carried by body and please wear anti-static gloves.
3.2 Operation Environment
Keep device away from high-power and strong electromagnetic commercial appliances and
environment.
3.3 Getting Started
Be prepared with following before installation:
(1) E300 Unit
(2) DisplayPort/HDMI display
(3) Cables
(4) Keyboard and mouse
3.4 Installation
3.4.1 Step1: hardware connection
(1) Get computer and display ready
(2) Connect computer to network interface with cables
(3) Connect computer to display with DP/HDMI
(4) Start up

E300 Series Fanless Embedded Computer
15
Figure 3-1: E310 connections
3.4.2 Step 2: Software installation
(1) Install operation system
(2) Install relevant drivers

16
Chapter 4 BIOS Setup Instruction
4.1 BIOS Introduction
BIOS is a basic input/output control program stored in Flash Memory. The program is a bridge
between the motherboard and the operating system and is responsible for managing the parameter
Settings between the motherboard and the expansion card. When the computer is activated, it is
controlled by a BIOS program, which first performs a self-test called POST and detects all
hardware devices and confirms synchronization hardware parameters. It does not transfer control of
the system to the operating system (OS) until all checks are completed.
Because BIOS is the only channel that hardware and software contact, how to properly set the BIOS
parameters will determine whether your computer is running stable and whether it’s in the best state,
so correct BIOS setting is the key factor of system stability, and to ensure the system performance
to achieve the best state.
CMOS Setup will store the set data in the built-in CMOS SRAM on the main board. When power is
turned off, the lithium battery on the motherboard continues to power the CMOS SRAM. The BIOS
Settings utility allows you to configure:
1) Hard drives and peripherals
2) Video display type and options
3) Password protection
4) Power management characteristics
Since BIOS version of the motherboard is constantly being updated, the BIOS
description in this manual is for reference only. We do not guarantee that the
content of this manual is consistent with the information you have obtained.
4.1.1 CMOS Setup
When the computer is started, BIOS enters the boot self-check (Post) program, which is a series of
diagnostic programs fixed in the BIOS. When the self-check program is completed and no error,
you can press DEL or ESC to enter the BIOS interface. If this message disappears before you could
respond, you can turn it off and restart your computer, or you can restart your computer by
simultaneously pressing <Ctrl> +< Alt>+<Delete>.

E300 Series Fanless Embedded Computer
17
4.1.2 Function Key and Instruction
↑
Move to previous item
↓
Move to next item
←
Move to left
→
Move to right
ESC
Exit current screen
Enter
Confirm
+
Change settings or increase value
－
Change settings or DEcrease value
F1
Help
F2
Load last value
F3
Load optimum value
F4
Save settings and exit CMOS SETUP
Main screen Instruction
As you move the options on the Setup home screen, the main Settings for the corresponding options
are shown below. If you want to leave the help window, just press ESC.

18
4.2 Main Menu
When you enter the CMOS setup menu, the main menu as shown in Figure 4.1 can be seen on the
top of the screen. In the main menu, you can select different setting options and press left and right
direction keys to select. After selecting the submenu, detailed setting options will be displayed at
the bottom.
Figure 4-1: Main Menu
1) Main (Standard CMOS setting)
Set time and date
2) Advanced (Advanced BIOS setting)
Set CPU, USB, PCI, LAN
3) Chipset
Set North Bridge, South Bridge
4) Security (Administrator/User & P/W)
5) Boot (Startup configuration feature)
6) Save&Exit

E300 Series Fanless Embedded Computer
19
4.3 Main( Standard CMOS setting)
Figure 4-2: Main Menu
1) System Time(hh:mm:ss)
2) System Date(mm:dd:yy)
4.4 Advanced( Advanced BIOS settings)
Figure 4-3: Advanced Menu

20
1) Trusted Computing
2) ACPI Settings
3) SMART Setting
4) Serial Port Console Redirection
5) CPU Configuration
6) AMI Graphic Output Protocol Policy
7) SIO Configuration
8) PCI Subsystem settings
9) Network Stack Configuration
10) CSM Configuration
11) NVMe Configuration
12) USB Configuration
13) Platform Trust Technology
14) Security Configuration
15) Thermal
16) System Component
17) Debug Configuration
18) RC ACPI Settings
19) RTD3 Setting
