FuzzDog SimpleTestRig User manual

Simple Test Rig
Make sure your builds are sweet
before you box ‘em up
Contents of this document are ©2016 Pedal Parts Ltd.
No reproduction permitted without the express written
permission of Pedal Parts Ltd. All rights reserved.

IMPORTANT STUFF
Go no further until you’ve read this page.
TESTING +GND CIRCUITS
The circuit is designed for use with standard negative-ground builds.
To test positive ground circuits you’ll have to either use a tip-positive supply or
connect your battery up in reverse.
The LED won’t function when doing this.
That’s about it. Carry on...

Schematic If you think it’ll help...
The tags of your footswitch
or toggle switch should be
oriented horizontally as
shown in red >>>>
If you want to wire up an off-
board DC socket, the and
GND pads are marked >>>>

R1 can be your prefered
value for the LED current
limiting resistor - we supply
2K2 with the kits. The short
leg (-) of the LED goes into
the square pad.
You don’t have to connect a
battery snap to pads B+ and
B- unless you intend to use
one. If you do, the battery
will only be connected when
a jack is inserted into the
input socket.
2-way screw
terminal
connector,
5mm pitc
1/4” jack socket,
PCB-mount Stereo
(output jack can be mono)
2.1mm DC socket,
PCB-mount* 3PDT Footswitc or
3PDT Toggle Switc
SIL sockets
4 or 6 way
TESTING YOUR CIRCUIT...
Direct Connect
Simply insert your 4- or 6-way ribbon connector into the sockets. More often than not it’ll be 4-way - this
should be inserted into the middle four sockets, ignoring the outer two.
Ensure you have the connections the right way around, i.e. IN to IN, to , etc. With all FuzzDog kits the
pots will be upover if aligned correctly, just like they would be on a boxed-up circuit.
Wired
Simply connect your four power and signal wires to the appropriate terminal.
