Fuzzrocious pedals lunaReclipse User manual

lunaReclipse
ABOUT
lunaReclipse is the first effect of its kind. A 12-position rotary provides 12 ways to clip (distort/provide overdrive) your instrument or re-
clip any effect that comes before the lunaReclipse. If placed near the front of your signal line, lunaReclipse can drive other effects in
new, exciting, vibrant ways.
If you want a more vintage distortion/overdrive sound out of your modern, high gain distortion, turn the lunaReclipse rotary to 2:00 and
allow a pair of germanium diodes to re-clip the circuit and provide a more vintage feel. Turn it to 10:00 to use asymmetrical
germanium-germanium/LED clipping to provide a sound that feels both modern and vintage.
With a simple volume control and 12 rotary positions to choose from, dialing and sculpting a new, exciting sound of your instrument
and other effects pedals opens up a world of possibilities.
CONTROLS
VOLUME – makes the output of the circuit louder or quieter.
ROTARY – selects a different diode combination. The rotary starts at 1:00 and ends at 12:00.
1:00 – 1n914/1n914
2:00 – germanium / germanium
3:00 – 1n4001/1n4001
4:00 – LED/LED
5:00 – 1n914-1n914/1n914
6:00 – germanium - germanium / germanium
7:00 – 1n4001-1n4001/1n4001
8:00 – LED - LED /LED
9:00 – 1n914-1n914/germanium
10:00 – germanium - germanium /LED
11:00 – 1n4001-1n4001/LED
12:00 – clean boost
POWER
Fuzzrocious Pedals’ products do not support batteries due to risk of damage to the unit and for ecological concerns related to the use
and disposal of batteries. It is the customer’s responsibility to power the pedal with a 9V DC 2.1mm center negative tip adaptor that will
not be provided by Fuzzrocious Pedals, LLC.
PAINT
All handpainted pedals, unless otherwise specified are painted with enamel or acrylic paint by Shannon Ratajski. Some pedals are
painted by the Ratajski children. Powdercoating and screenprinting for pedals sold through dealers are done locally by Juxtaprints.
http://fuzzrociouspedals.com ||| [email protected]
For information about warranties, please visit http://fuzzrociouspedals.com/termsandconditions.

LAYOUT
Black knob – Volume
Red knob – 12-position rotary (moves clockwise from 1:00-12:00)
Side jacks
Top-mounted power
Created by Ryan Ratajski, July 2017
