G-cluster DSM-232 User manual

1. Package Contents
DSM-232 G-cluster
Media Adapter
G-cluster Holder
USB Cable
HDMI Cable
5V/1A Power Adapter
- No USB port on the TV
- Need to use gamepad for
gaming
Warranty Card
GPL (General Public
License)
QIG (Quick Installation
Guide)
2. Hardware Overview
WPS/Reset
Button
Micro-USB
USB
HDMI
Network information
15~20 sec, Reset to default setting
Connect the supplied USB cable here and the other end into the
USB port on the TV or power adapter
Connect the game pad here
Connect an HDMI cable here and the other end into your TV or
home theater receiver

1. Please connect the HDMI cable and USB cable to the G-
cluster media adapter
2. Please connect the HDMI cable and USB cable to the TV
Please use the supplied power adapter when there is no USB port
on the TV
3. Depending on the model of the TV, when using game pad, it
may need to use the power adapter, not the USB terminal of the
TV
4. After installation to a position that doesn’t block the ventilation
holes of the TV back, please make sure the lighting of the LED
lamp
5. Please switch to the HDMI input to which you have connected
the G-cluster by using the remote control of the TV
6. Please set according to the simple setup guide that will make
the initial configuration of the G-cluster
