G-Force TM 9-N Technical specifications

USE AND INSTALLATION MANUAL
edition: 1/05.10.2020
Page 1of 10
TM 9-N
APAVE SUDEUROPE SAS - BP 193 - 13322 MARSEILLE
CEDEX 16 –FRANCE
Figure 1 –General view of device
TABLE OF CONTENTS:
1. GENERAL DESCRIPTION .......................................... 2
2. LOAD LIMIT AND STRENGTH.................................... 2
3. TRANSPORT AND WEIGHT....................................... 3
4. MAINTENANCE AND STORAGE................................ 3
5. GENERAL DIMENSIONS ............................................ 4
6. TIME OF USAGE......................................................... 5
7. PERIODIC INSPECTIONS .......................................... 5
8. MARKING OF DEVICE................................................ 5
9. INSTALLATION OF TRIPOD....................................... 6
10. INSTALLATION OF WORK ROPE OF DEVICE
INSTALLED ON TRIPOD LEG ............................................. 7
11. INSTALLATION OF PERSONAL PROTECTIVE
EQUIPMENT ............... 7
12. INSTALLATION OF UNIVERSAL HOLDER UTB
(AT017-300) ......................................................................... 7
13. INSTALLATION OF RESCUE DEVICES 7
14. ESSENTIAL PRINCIPLES FOR USE OF PERSONAL
FALL PROTECTION EQUIPMENT ....................... 8
15. WARRANTY ................................................................ 9
16. IDENTITY CARD ....................................................... 10
SAFETY TRIPOD
EN 795/B TS 16415/B
Notified body which supervises the production of the equipment

USE AND INSTALLATION MANUAL
edition: 1/05.10.2020
Page 2of 10
1. GENERAL DESCRIPTION
Safety tripod TM9-N is an anchor point compliant with
EN 795/B and document TS 16415/B and can be used as a
component of fall protection equipment.
Tripod TM9-N provides protection for up to 3 users at a
time.
Tripod TM9-N is composed of powder-coated aluminium
head, equipped with 3 polyamide rollers with bearings (for
work rope guidance in rescue devices CRW200 / RUP502-U /
RUP504 / RUP506). The head is fitted with 3 anchor points
located at its side walls. Each of these points can be used as
an anchor point for fall protection equipment. One point is
designed to be used by maximum one user at a time.
The above mentioned rescue devices can be mounted on
each of three aluminium telescopic legs by means of universal
holder UTB (AT017-300). Each telescopic leg is terminated
with a foot made of zinc-plated steel, equipped with rubber
pad. Each foot has teeth which penetrate through loose or
slippery ground (soil, sand, grit, ice, snow). Inner leg is locked
in outer leg using automatic pin with locking fins which are
released by button in pin holder.
Basic parameters of device:
x Maximum height “under head”: 2.10m
x Minimum height “under head”: 1.53m
x Range of diameters above which tripod can be
unfolded: 1.0...1.4m.
2. LOAD LIMIT AND STRENGTH
a) GENERAL INFORMATION
Minimum Breaking Strength (MBS): 15kN.
The device can be loaded vertically downwards within a
space limited by legs of the device.
The maximum load that could be transmitted in service
from the device to the static construction –10 kN.
If the device is used as a part of a fall arrest system, the
user must be equipped with an element limiting maximum
dynamic forces applied on user while arresting a fall to max.
6kN.
b) FOR MATERIAL TRIPODS installed on the tripod
head and/or leg using universal holder UTB (AT017-
300):
Working Load Limit (WLL): 500kg
Safety Factor (SF): 3:1.
c) FOR PERSONAL PROTECTIVE EQUIPMENT
(PPE) mounted to anchor points located on the head:
Maximum 3 users at the same time. Whereas one user is
connected to one anchor point.
According to the requirements of EN 795/B and
document TS 16415/B strength of the device is min. 14kN
d) FOR PERSONNEL RESCUE DEVICES installed on
tripod leg with use of universal holder UTB (AT017-
300):
Working Load Limit (WLL): 140kg
Safety Factor (SF): 10:1.
Work load of rescue device used cannot be
greater than 140kg.
Figure 2 –Permissible directions of loading of anchor
point within inner area determined by tripod legs

USE AND INSTALLATION MANUAL
edition: 1/05.10.2020
Page 3of 10
3. TRANSPORT AND WEIGHT
Weight of complete device: 15.45kg.
Personal fall protection equipment must be transported in
a package (e.g.: bag made of moisture-proof textile or foil bag
or cases made of steel or plastic) to protect it against damage
or moisture.
4. MAINTENANCE AND STORAGE
Personal protective equipment should be cleaned without
causing adverse effect on the materials used in the
manufacture of the equipment. For textile materials
(webbings, ropes) use agents suitable for delicate fabrics. Can
be washed in hands or in a washing machine. Rinse
thoroughly. Wash textile elements with water only.
- When the equipment becomes wet, either from being in use
or after cleaning, allow it to dry naturally, and keep it away
from sources of heat. In metallic products slightly lubricate
some mechanical parts (springs, hinges, pawls, etc.) on a
regular base to ensure their better operation.
Personal fall protection equipment should be stored
loosely packed in well-ventilated rooms, protected from light,
UV degradation, dust, sharp edges, extreme temperatures
and aggressive chemical substances.
Figure 3 –Transport dimensions

USE AND INSTALLATION MANUAL
edition: 1/05.10.2020
Page 4of 10
5. GENERAL DIMENSIONS
Figure 4 –General dimensions of device –front view
Figure 5 –General dimensions of device –bottom view

USE AND INSTALLATION MANUAL
edition: 1/05.10.2020
Page 5of 10
6. TIME OF USAGE
Maximum time of usage of correctly operating
devices is unlimited.
The device must be withdrawn from use immediately
and destroyed if it has been used to arrest a fall or there are
any doubts concerning its function.
NOTE: Maximum time of usage of the device depends on
intensity and environment of use. If the device is used in heavy
conditions, being exposed to frequent contact with water,
sharp edges, corrosive substances, extreme of temperatures,
it may be necessary to withdraw the device after only one use.
7. PERIODIC INSPECTIONS
At least once a year, after every 12 months of use, it
is necessary to carry out periodic detailed inspection of the
device.
Periodic inspection can be carried out by a properly
qualified and skilled person.
After 5 years of use, it is recommended that periodic
inspections are carried out by the manufacturer of the
equipment or an entity authorised by the manufacturer to carry
out such inspections.
8. MARKING OF DEVICE
Marking:
a) Name/ type of device.
b) Device model designation.
c) Reference number.
d) Number/year/class of European standard.
e) CE mark and number of notified body which
supervises the production of the equipment.
f) Month and year of manufacture.
g) Serial number of device.
h) Attention: read instruction manual.
i) Marking of manufacturer or distributor of the device.
j) Maximum number of simultaneous users.
Figure 6 –Identity label of device
Figure 7 –Location of marking of device
Figure 8 –“Next inspection”sticker
“Next inspection” sticker should be affixed near identity label
and it is necessary to mark month and year of the next periodic
inspection. Do not use the device after this date.
Attention: Before the first use, mark the date of next
inspection (date of first use + 12 months, e.g. first use 01.2013
– mark 01.2014). “Next inspection” sticker affixed near identity
label.

USE AND INSTALLATION MANUAL
edition: 1/05.10.2020
Page 6of 10
9. INSTALLATION OF TRIPOD
Tripod TM9-N can be installed by one person.
a) Place the tripod vertically in the lowest position on a
level, stable and hard surface. The legs should be
turned outside to their maximum.
Make sure that feet are placed on a hard surface
and can bear the load. The tripod should be placed
above opening so that work rope is approximately in
the middle of the opening.
b) Pull out tripod legs to a desired length and lock them
using locking split pins. Adjust length of legs so the
head is located horizontally. Legs must be of the
same length at all times.
c) Correct securing of the leg with split pin.

USE AND INSTALLATION MANUAL
edition: 1/05.10.2020
Page 7of 10
d) Secure tripod legs against accidental moving apart with
a chain. Chain ends must be connected with a
carabiner. The chain should be well tensioned between
tripod legs. If necessary remove any excess clearance.
Instead of chain, special strip (delivered with tripod)
can be used.
e) To fold the tripod, remove steps, pull out cotter bolts
and fold the legs.
10. INSTALLATION OF WORK ROPE OF DEVICE
INSTALLED ON TRIPOD LEG
a) Pull out adequate work rope length from the device
and mount the rope on the roller integrated with the
head. Check whether work rope is fitted correctly on
the roller.
b) Attach energy absorber SDW at the end of work rope
of rescue devices RUP502-U, RUP503-U, RUP504,
RUP506.
11. INSTALLATION OF PERSONAL
FALL PROTECTION EQUIPMENT
Personal fall protection equipment can be connected to
three anchor points located on side platens of the head.
E.g. CR / WR retractable type fall arresters.
12. INSTALLATION OF UNIVERSAL HOLDER
UTB (AT017-300)
See: UTB instruction manual.
13. INSTALLATION OF RESCUE DEVICES
See: UTB instruction manual.

USE AND INSTALLATION MANUAL
edition: 1/05.10.2020
Page 8of 10
14. ESSENTIAL PRINCIPLES FOR USE OF
PERSONAL FALL PROTECTION EQUIPMENT
xAnchor point AT150 must be used in accordance with
instruction manuals for personal fall protection equipment
and standards:
EN 361 - full body harnesses
EN 352-3; EN 355; EN 360 - fall restraint devices
EN 362 - connectors
EN 795 / TS16415 - anchor points
xpersonal fall protection equipment should be used only by
personnel trained in its use.
xpersonal fall protection equipment must not be used by a
person with medical condition that could affect safety of
the equipment user in normal and emergency use.
xprepare a rescue plan to be implemented whenever
necessary.
xit is forbidden to make any alterations or additions to the
equipment without prior written consent given by the
manufacturer.
xany repair shall only be carried out by manufacturer of the
equipment or his certified representative.
xpersonal fall protection equipment shall not be used for
any purpose other than intended.
xpersonal fall protection equipment provides individual
protection and shall be used by one person only.
xbefore each use make sure that all parts of fall protection
system cooperate correctly. Periodically examine
connections and fitting of components of the equipment
to prevent any accidental loosening or disconnection.
xit is forbidden to use a combination of the equipment
where function of any one item is affected by, or interferes
with the function of any other.
xbefore each use of personal fall protection equipment, a
pre-use check should be carried out to ensure that it is in
a serviceable condition and operates correctly.
xIn particular, inspect all accessible elements of the
equipment for any damages, excessive wear, corrosion,
abrasion, cutting or improper function. For individual
devices pay particular attention to:
9in full body harnesses and work positioning devices:
buckles, regulating elements, attachment points
(buckles), webbings, seams, belt loops;
9in energy absorbers: attachment loops, webbings,
seams, housing, connectors;
9in lanyards and textile guides: rope, loops, thimbles,
connectors, regulating parts, splices;
9in lanyards and steel guides: rope, wires, clamps,
loops, thimbles, connectors, regulating parts;
9in retractable type fall arresters: lanyard or webbing,
retractor and locking mechanism for proper
operation, housing, energy absorber, connectors;
9in guided type fall arresters: body, proper guiding,
locking mechanism for proper operation, rollers, bolts
and rivets, connectors, energy absorber;
9in connectors (snap hooks): load-bearing body,
rivets, main pawl, locking mechanism functionality.
xat least once a year, after each 12 months of use,
personal fall protection equipment must be
withdrawn from use to carry out periodic detailed
inspection. Periodic inspection can be carried out by
a person who is responsible for periodic inspections
in user’s organisation and properly trained in this
respect. Periodic inspections can be carried out also
by the manufacturer of the equipment or his
authorized representative, or an authorized
company. Inspect in detail all accessible elements of
the equipment paying attention to any damages,
excessive wear, corrosion, abrasion, cutting or
incorrect function (see the above item.) In some
cases, if fall protection equipment has a complex
design (e.g. fall arresters), periodic inspections can
be carried out by the manufacturer of the equipment,
or his authorized representative only. After the
periodic inspection, date of the next inspection
should be defined.
xregular periodic inspections are essential in respect
of the equipment condition and safety of users which
is dependent on functionality and durability of the
equipment.
xduring periodic inspection it is necessary to check the
legibility of all markings on the equipment (identity
label of the device).
xall information on fall protection equipment (name,
serial number, date of purchase and date of first use,
name of user, information on repairs and inspections
and withdrawal from use) must be provided in the
Identity card of the device. It is responsibility of user’s
organisation to provide the Identity card and to fill in
the required details. The Identity card should be filled
in by a person in charge of personal fall protection
equipment in user’s organisation. It is forbidden to
use personal fall protection equipment if the Identity
card is not filled in.
xif the equipment is re-sold outside the original
country of destination the reseller must provide
instructions for use, for maintenance, for periodic
inspection and for repair in language of the country
where the product is to be used.
xpersonal fall protection equipment must be
withdrawn from use immediately if any doubts arise
in regard of its condition, or proper operation. The
equipment must not be used until manufacturer of
the equipment carries out a detailed inspection and
gives his written consent to use the equipment again.
xpersonal fall protection equipment must be
withdrawn from use immediately and destroyed if it
has been used to arrest a fall.
xfull body harness is the only admissible device to be
used to support the user’s body in personal fall
protection equipment.

USE AND INSTALLATION MANUAL
edition: 1/05.10.2020
Page 9of 10
xin full body harness use only attachment points
(buckles, loops) marked with capital letter “A” to
attach a fall protection system.
15. WARRANTY
The manufacturer grants a warranty for 12 months
from the date of purchase of the device. If a defect is found in
any part, the warranty and guarantee period for this part is
extended by the time of repairs and effective removal of the
defect found.
The warranty covers:
xDefects in material,
xDefects in workmanship,
xAnti-corrosion coating defects
According to the requirements of EN 365 an anchor
point shall be subject to periodic inspections carried out at
least every 12 months. Periodic inspection shall be carried
out by service point authorized by the manufacturer
or person trained in inspections of such equipment.
A trained person is a person who, based on own
specialized education and adequate experience, has
sufficient knowledge in installed protective and rescue
equipment, and is familiarized with applicable OHS
regulations, guidelines and generally acknowledged technical
rules to such extent that is able to assess safety of use
and correct application of protection devices.
Before each use of the system check whether date of
the next inspection is not expired. Do not use the device after
this date. Before each use of the system visually check
the system for its integrity and technical condition and
whether steel cable is tensioned.
If any defect or lack of integrity is found, do not use the
point.
If any doubts arise as regards the use of the
equipment, please contact the manufacturer and never repair
the equipment on your own!
A system which has been used to arrest a fall must be
withdrawn from use immediately!
The system which has been used to arrest a fall can be
admitted for use again after a detailed inspection is carried out
by the manufacturer or an authorized service point.
When using the system, pay special attention to risks
affecting operation of the personal fall protection equipment or
the user’s safety, and in particular to kinks and rope movement
on sharp edges, oscillatory falls, electricity, influence of
extreme temperatures, equipment damage, adverse
environmental factors, chemical substances and
contamination.
Neither modify, repair components of the system nor
replace them with non-original spare parts.

USE AND INSTALLATION MANUAL
edition: 1/05.10.2020
Page 10 of 10
16. IDENTITY CARD
IDENTITY CARD………….. ( in accordance with EN365 )
Reference number of
device
TM 9
-N (ref. AT011
-N)
Serial number:
……………………….
Date of first use
( installation )
………………….
Date of manufacture:
………………………..
Place of installation
………………………………………………………………………………………………
………………………………………………………………………………………………
User name:
………………………………………………………………………………………………
………………………………………………………………………………………………
Inspection and repair record
No.
Date of
inspection
Type of
inspection / repair
Remarks
Date of
next
inspection
Name and signature of
service technician
1
2
3
4
5
6
7
8
9
10
Manufacturer:
PROTEKT - Starorudzka 9 - 93-403 Lodz - Poland
tel. [phone] - fax. [phone] - www.protekt.pl
6DIHW\/LIWLQ*HDUFRP
8QLW5'5RFNLQJKDP*DWH3RSODU:D\:HVW&DERW3DUN%ULVWRO%6<:7HO
)D[VDOHV#VDIHW\OLIWLQJHDUFRP
