S5 Electric Scooter
User’s Manual
WARNING
Please read the user manual carefully before using your new scooter.
This version is for private use only and should not be distributed.

Contents
1 Package Contents---------------------------------------------------------------------- 02
2 Diagram -------------------------------------------------------------------------------- 03
3 Assembly ------------------------------------------------------------------------------- 06
4 Charge ---------------------------------------------------------------------------------- 07
5 How To Ride ---------------------------------------------------------------------------- 07
6 Safety Instructions ---------------------------------------------------------------------- 09
7 Folding and Carrying ------------------------------------------------------------------- 14
8 Daily Care and Maintenance------------------------------------------------------------ 14
9 Specifications -------------------------------------------------------------------------- 16
10 Limited Guarantee Period -------------------------------------------------------------- 17

Welcome to use
Thank you for purchasing S5 Electric Scooter (Abbreviated as scooter) !
This scooter is an easy-to-carry short-distance transportation product. It is a sports and
recreational vehicle with style.
47—78in
16—60 years
All pictures in this user manual are for reference only, please refer to the actual product.
When riding a scooter, please
wear helmets, knee pads, wrist
pads and other protect ive gear
to reduce the risk of injury
01

1. Package Contents
Assembled Electric Scooter
User Manual
Accessories
Accessories Box : Screw × 5 Tool Kits × 1 Inner Tube × 1 Valve Core Wrench × 1
Carefully check package contents, if anything is missing or damaged,please contact the customer service in time.
Battery Charger
Accessories Box
02
S5 Electric Scooter
User Manual

2. Diagram
Electronic Throttle
Control Panel
Hook
Stem
Charge Prot
Taillight
Rear Fender
Buckle
Hub Motor
Kickstand
Brake Lever
Headlight
Folding Latch
Front Wheel
Bell
03

Speed & Error
Odograph
Battery Level
Power Button
Speed Level
Light
Mode Button
Push Assistance
km/h
MPH
ln
njmf
Trip
ODO
04
Battery Level Display
The power level is indicated by five segments on the control panel.Each segment represents about 20 % of
the power.
Power Button
Hold “ ”button for 3s to turn on or off the scooter. When the scooter is on, press “ ”button to turn on or
off the headlight and taillight.(If your scooter is not used for more than 10 minutes, the power will be
automatically turned off.)
Mode Button
Keep holding“ M ”button to enter push assistance mode.
Press“ M ”button to switch riding mode.
Mode Display
Mode “1”: ECO mode. (Lower power)
Mode “2”: Normal mode. (Normal power)
Mode “3”: Sport mode. (Higher power)
Mode “Cruise”: When the driving speed remains unchanged for 7s, the cruise control will be automatically
activated, and then the “warning light” is flashing on the control panel. The scooter will maintain that speed
even if the throttle is not pressed. Cruise control can be deactivated by pulling the brakes or pressing the
throttle again.
Warning Light
[1]
[1]： / Different control panels may display
different indicator ICONS, please refer to the
actual display

05
Error Code
01
02
03
04
05
06
Definition
Controller failure
Communication failure
Hall element failure
Throttle failure
Brake failure
Motor failure
Odograph Display
The Odograph position is displayed as ODO （Total mileage）3 seconds after the instrument is started, and
then it is switched to trip 3 seconds later.
Error Code Display
If the speed area of the display shows or flashes «OX», it indicates a malfunction of the scooter. Error code
meanings can be found below.
SystemSettings
In the power-on state, when the display shows the speed of 0
1.Hold “ ”button and“ M ”button at the same for 3s to enter the setting interface.
2.Press“ M ”button to select P1-Speed Limit Setting or P2-Unit Setting.
3.Press“ ”button to enter the parameter modification state.
4.Press“ M ”button for parameter selection.
5.Hold “ ”button for 3s to save the parameter and return to the first setting interface.
6.Hold “ ”button for 3s to exit the setting interface.
P1: Speed Limit Setting
By modifying this value, you can set the maximum riding speed of your scooter. The selectable range of the
maximum speed setting value is 25km/h-32km/h(15MPH-20MPH).
P2: Speed Unit Setting
By modifying this value, you can set the unit of your scooter. 00 represents the metric system, and 01
represents the imperial system.

3. Assembly
1. Put the kickstand down to support the
scooter, then unfold the handlebar stem
and fix it by folding mechanism.
2. Firmly connect the wires inside the
handle and the stem. Slide the handle
onto the stem. Be aware of the correct
orientation.
3. Install four screws (two on each side)
with the included hex wrench.
4. Ensure that your scooter can be powered
on and off.
06

4. Charge
Charging condition description:
The scooter is fully charged when the LED on the charger changes from red (charging) to green(trickle charge).
Charging Port
Open the charge
port cover.
Insert the
charge plug.
Close the charge
port cover when
charging finished.
5. How To Ride
Warning: Wear a helmet,
elbow pads and knee pads.
Please read the instruction
carefully before using. Do not
touch the power system. Refer
to the instruction for more
information
1. Long press to power on the
scooter.
07

2. Step on the deck with one foot, and slowly
kicks off the other on the ground.
3. When the scooter starts to coast, put both feet on
the deck and press the accelerator (the accelerator
initiates once the coasting speed exceeds 2.4 MPH).
When the scooter is at a full stop, the accelerator automatically turns off.
To restart the scooter, it is necessary to repeat step 2.
4. Release the accelerator and the kinetic energy
recovery system (KERS) initiates automatically
to brake slowly; And squeeze the brake lever
for a sudden brake
5. Tilt your body to the steering direction as you turn, and
slowl y turn the handlebar
08

6. Safety Instructions
Do not ride in the rain
Watch out for safety risks
Look out for doors, elevators and other
overhead obstacles
Always steer clear of obstacles
Keep both feet on the deck all time.
09

Do not accelerate when you go downhill
Do not press the accelerator when you’re
walking alongside the scooter
To prevent inappropriate use of the scooter, the rear wheel of the machine must be locked with a padlock when parked.
Do not hang bags or other heavy
stuff on the handlebar
Please slow down and pass slowly
when you ride through speed bumps
10

Do not try following dangerous actions
Do not ride in traffic lanes or residential
areas where vehicles and pedestrians
are both allowed
Do not turn the handlebar violently during
high-speed riding
Do not ride through puddles or any
other (water) obstacle. In such a case
please lower your speed and bypass
the obstacle.
Do not ride with anyone else, including
children
11

Do not keep your hands away from handlebar Do not try riding up or down stairs, and
jumping over obstacles
Stay alert and do not perform any other activities
while riding.
Do not park the scooter outdoors or in the
open air for a long time
12

Safety Reminder
13
• The scooter is intended for riders older than 16 years. Riders with a lack of experience or knowledge should drive carefully.
Children should not play with the scooter or parts of it nor should cleaning or maintenance be done by children. The use of
the machine results in the transmission of vibrations throughout the driver's body.
• This electric scooter is a leisure device. But once they're in a public area, they'll be seen as vehicles, subjecting to any risks faced
by vehicles. For your safety, please follow instructions in the manual and traffic laws and regulations set forth by government
and regulator y agencies.
• At the same time, you should understand that risks cannot be entirely avoided as others may violate traffic regulations and
drive incautiously, and you're exposed to road accidents just as when you're walking or biking. The faster the scooter is, the
longer it takes to stop. On a smooth sur face, the scooter may slip, lose balance, and even resul t in a fall. Thus it is crucial that
you use caution, keep proper speed and distance, especially so when you're unfamiliar with the place.
• Respect pedestrian's right of way. Try not to startle them while driving, especially children. When you ride from behind
pedestrians, ring your bell to give them a heads-up and slow your scooter to pass from their left (applicable to countries
where vehicles drive on the right). When you ride across pedestrians, keep to the right at a low speed. When you drive across
pedestrains, keep the lowest speed or getting off the vehicle.
• Closely follow the safety instructions in the manual especially in china and countries that lack relevant laws and regulations
regarding electric scooters. G-Force shall not be liable for any financial losses, physical injuries, accidents, legal disputes and
other interest conflicts resulted from actions that violate user instructions.
• Riding with high speed or a speed that is not appropriate or adequate for the situation (bad weather conditions, bad surface
conditions, or the like) may lead into a potential loss of stability or loss of control. To reduce any risk, you must follow all
instructions in this user manual. Be careful when mounting and dismantling the product, it may fall and cause injury.
• Do not lend your scooter to whoever knows not the operations. And when you do lend it to your friends,please take the
responsibility to ensure he/she knows the operation and wears the safety gear.
• Check the scooter before every use. When you note loosen parts, low bat tery aler ts, flat tires, excessive wear, strange sounds,
malfunctions and other abnormal conditions, stop riding immediately and call for professional support.
• When riding a scooter, you need to hold the handle with both hands to avoid shaking and falling down.
• Always place the scooter on its stand on a flat and stable surface. The scooter must be placed with the stand against the
slope to prevent it from tipping over. Never place the scooter with the front facing down the slope, as the stand may close and
tip the machine. Once the scooter is on its stand, check its stability to avoid any risk of falling (by slip, wind or slight jolt). Do not
park the scooter in a busy area, but rather along a wall. If possible, always choose to park your scooter on flat ground.
• Do not touch the brake system, it could cause safety injuries.
• To avoid inappropriate use, it is necessary to start coasting the scooter to activate the motor and the accelerator. When the
scooter is stopped, the accelerator does not work.

8. Daily Care and Maintenance
Put the kickstand down to support the scooter, the scooter needs to be turned off before folding. Hold the
handlebar stem, toggle upward the safety hook of the folding mechanism, in this state, open the quick release
lever. Fold the vertical bar over the pedals, while connecting the handlebar hook to the buckle. Hold the
handlebar stem with either one hand or both hands to carry.
7. Folding and Carrying
Storage
Notes: do not clean the scooter with alcohol, gasoline, kerosene or other corrosive and volatile chemical
solvents to prevent dire damage. Do not wash the scooter with a high-pressure water spray. During cleaning,
make sure that the scooter’s turned off, the charging cable is unplugged, and the rubber flap is closed as
water leakage may result in electric shock or other major problems.When the scooter’s not in use, keep it
indoors where it is dry and cool. Do not put it outdoors for long time. Excessive sunlight, overheating and
overcooling accelerate tire aging and compromise the scooter and the battery pack’s lifespan.
14
• Wear a helmet, elbow pads and knee pads to avoid injury. Poor driving can lead to falls or serious accidents. Store the electric
scooter indoors when not in use. Read the instruction manual and drive the electric scooter carefully. You should only operate
the electric scooter after you have understood and applied all the safety rules. The scooter operator will be responsible for
any damage or injury caused by failure to follow the instructions in the owner's manual. For a better driving experience, it is
recommended to conduct a regular maintenance of the product. Refer to the user manual for more information. Please read
the user manual before charging the bat tery. Do Not drive in rain or puddles. Required age of driver: 14 to 50 years. Not
allowed for children.

15
Maintenance and removal of the battery
Do not remove the battery. Removing the battery is complicated and can alter the operation of the scooter:
You can contact us if the product is still under warranty.Spare tires supplied with the product are to be mounted
on the wheel by a professional repairer. Removing the wheels is complicated and incorrect assembly can lead
to instability and malfunctions:
1. Use original battery packs, use other models or brands may cause safety issue;
2. Do not touch the contacts. Do not dismantle or puncture the casing. Keep the contacts away from metal
objects to prevent short circuit which may result in battery damage or even injuries and deaths;
3. Use original power adapter to avoid potential damage or fire;
4. Mishandling of used batteries may do tremendous harm to the environment. To protect natural environment,
please follow local regulations to properly dispose used batteries.
5. After every use, fully charge the battery to prolong its lifespan.Do not place the battery in an environment
where the ambient temperature is higher than 50°C or lower than -20°C (e.g., do not leave the scooter or the
battery pack in a car under direct sunlight for an extended time). Do not throw the battery pack into fire as it
may lead to battery failure, battery overheating, and even another fire. If the scooter is expected to be left
idle for more than 30 days, please fully charge the battery and place it in a dry and cool place. Keep in mind
to recharge it every 60 days to protect the battery from potential damage which is beyond limited warranty.
Scooter shall be only be used with original batteries and charging of the scooter shall only be done by the
original charging adapter supplied with the scooter (or any battery model or charging adapter model
approved by the manufacturer as compatible).Always charge before exhausting the battery to prolong the
battery’s lifespan. The battery pack performs better at normal temperature, and poor when it is below 0°C.
For instance, when it is below -20°C, the riding range is only half or less at normal state. When the
temperature rises, the riding range restores. For detailed information The external flexible cable of this
transformer can not be replaced; if the cord is damaged,the transformer must be discarded and replaced
by a new one.
Note: The damage caused by prolonged no charge is irreversible and is beyond limited warranty. Once the
damage is done, the battery can not be recharged (non-professionals are forbidden to dismantle the battery
pack, as it may cause electric shock, short circuit or even major safety accidents).
In case of accident or breakdown: please contact an authorized repairer if the product is still under guarantee.
Contact us
E - mail : [e-mail]

Items Specifications
Unfold: Length x Width x Height
Fold: Length x Width x Height
Net
Payload
Recommended Age
Required Height
Max. Speed
Typical Range
Max. Slope
Operating Temperature
Storage Temperature
IP Rating
Duration of Charging
Nominal Voltage
Max. Charging Voltage
Charging Temperature
Nominal Capacity
Number o f Batteries
Nominal Power
Max. Power
Output Power
Input Voltage
Output Voltage
Output Current
LED Rear Light
Riding Modes
Tire
Approx. 45 × 18 × 55 Inches
Approx. 45 × 18 × 23 Inches
Approx. 45 Pounds
220 Pounds
16+ years
47 — 78 Inches
Approx. 20 mph
30 miles
Approx. 15%
asphalt/flat pavement
obstacles <0.3 Inches; gaps < 1.1 Inches
-4 — 104℉
14 — 122℉
IPX5
6 - 7 hours
48V
54V
32 — 104℉
12Ah
1
250W
500W
100W
100 — 240V ～ 50/60Hz
54V
2A
Taillight
Mode1, Mode2, Mode3
10 Inches
Traversable Terrain
Battery Management System
Performance index
Dimensions
Weight
Rider
Machine Parameters
Battery
Motor
Charger
Features
BMS
Tire
9.Specifications
16

10.Limited Guarantee Period
This Limited Guarantee covers all defects in material and workmanship of the Product arising or occurring as
a result of your normal and ordinary use of the Product. In the event a defect covered by this Limited Guarantee
occurs, G-Force will repair or replace your Product in accordance with the terms of this Limited Guarantee. （This
Limited Guarantee only applicable to product problems caused by non-human or force majeure factors）The
original purchase date of the Product, Applies to the Product in the following ways:
Vehicle Body -------------------------------------------------------------------------------------------1 year
• Controler
• Hub Motor
• Frame Assembly
• Handle
Batteries and Charger --------------------------------------------------------------------------------- 180 days
• Batteries
• Charger
Components Subject to Wear--------------------------------------------------------------------------90 days
• Tire
• Inner Tube
• deck
• Taillight & Headlight
Note : The damage caused by man-made is not covered by the warran（The battery capacity decay is subject
to the test capacity of the machine,not the decay of the riding kilometers）
Service E-mail: [e-mail]
User Name
Address
Telephone
Purchase Site
Order Number
Store Name
Commodity Name
Serial Number
SexAge
Zip
Specifications
Note : If you need repair or replacement, please provide the information required in the table above
17
(except artificial)

E - mail : [e-mail]
Please scan the QR code for latest user manual.
