g-lites Beam200W Titanium PRO User manual

INSTALLATION
Installing / replacing the lamp
DANGER TO LIFE
Only install the lamp with the device switched off! Unplug from mains before!
For the installation, you need one 189W fast fit lamp
Protection gloves, helmet with sight, leather apron.
CAUTION!
The lamp has to be replaced when it is damage or deformed due to the heat!
● The lamp life given by the manufacturer must never be exceeded, this is why you need to take
note on the operational time of the lamp and replace the lamp in time.
● Keep exchanged lamp in a protective container and remove accordingly.
● During the operation, the lamp reaches temperatures of up to 600°C
● Before replacing the lamp unplug mains lead and let the lamp cool down (appr 10 min)
● During the installation do not touch the glass- bulbs bare-handed! Please follow the lamp
manufacturer’s notes!
● Do not install lamps with a higher wattage! Higher wattage lamp generate temperatures, the
device was not designed for. Damages caused by non-observance are not subject to warranty.
Procedure:
Step 1: unscrew the fixation screws of the lamp cover and remove it.
Step 2: unscrew the knurled-head screws of the lamp holder and remove it.
Step 3: if replacing the lamp, remove the old lamp from the lamp holder.
Step 4: insert the lamp into the lamp holder.
Step 5: replace the lamp holder and tighten the knurled-head screws.
Step 6: adjust the lamp as described under lamp adjustment.
Step 7: replace the lamp cover and tighten the fixation screws.
Do not operate the device with opened cover!
Lamp adjustment
● The lamp holder is aligned at the factory, due to differences between lamps, fine adjustment
may improve light performance.
● Strike the lamp, open the shutter and the iris, set the dimmer intensity onto 100% and focus the
light on flat surface(wall), center the hot-spot(the brightest part of the beam) using the 3
adjustment screw turn one screw at a time to drag the hot spot, adjust the lamp until the light is
even.
● To reduce a hot-spot, pull the lamp in by turning all three screws, clockwise 1/4 turn, at a time
until the light is evenly distributed.
● If the light is brighter around the edge than it is in the center, or if light output is low, the lamp is
too far back in the reflector, push the lamp out by turning the screw counter clockwise 1/4 turn
at a time the light is bright and evenly distributed.

Rigging
DANGER TO LIFE!
Please consider the respective national norms during the installation!
The installation must only be carried out by an authorized dealer!
● The installation of the projector has to be built and constructed in a way that it can hold 10
times the weight for 1 hour without any harming deformation.
● The installation must always be secured with a secondary safety attachment, this secondary
safety attachment must be constructed in a way that no part of the installation can fall down if
the main attachment fails.
● When rigging servicing the fixture staying in the area below the area below the installation
place. On bridges, under high working places and other endangered areas is forbidden.
● The operator has to make sure that safety-relating and machine-technical installations are
approved by an expert before taking into operation for the first time and after changes before
taking into operation another time.
● The operator has make sure that safety-relating and machine-technical installations are
approved by expert after four year in the course of an acceptance test.
● The operator has make sure that safety-relating and machine-technical installations are
approved by a skilled person once a year.
Procedure:
● The projector should be installed outside areas where persons may walk by or be seated.
● Important! Overhead rigging requires extensive experience. Including (but not limited to)
calculating working load limited, installation material being used, and periodic safety inspection
of all installation material and the projector. If you lack these qualifications, do not attempt the
installation yourself, but instead use a professional structural rigger. Improper installation can
result in bodily injury and or damage the property.
● The projector has to be installed out of the reach of people.
If the projector shall be lower from the ceiling or high joists, professional trussing systems have
to be used, the projector must never be fixed swinging freely in the room.
Caution: Projectors may cause severe injuries when crashing down!
● If you have doubts concerning the safety of a possible installation, do not install the projector!
● Before rigging make sure that the installation area can hold a minimum point load of 10 times
the projector’s weight.
DANGER TO LIFE!
When installing the device, make sure there is no highly-inflammable material (decoration articles,
etc,) within a distance of min 0.5m.
CAUTION!
Use 2 appropriate clamps to rig the fixture on the truss.
Follow the instructions mentioned at the bottom of the base.
Make sure that the device is fixed properly! Ensure that the structure (truss) to which you are
attaching is secure.
● The moving head can be placed directly on the stage floor or rigged in any orientation on a truss
without altering its operation characteristics.

● For overhead use, always install a safety rope that can hold at least 12 times the weight of the
fixture, you must only use safety ropes with screw on cardinal. Pull the safety rope through the
hole on the bottom of the base and over the trussing system etc. insert the end on the cardinal
and tighten the fixation screws.
● Use the safety rope exclusively as a closed ring. Never use by only securing at each end. The
maximum drop distance must never exceed 20cm
● A safety rope which already hold the strain of a crash or which is defective must not be used
again.
1. Omega-holders
2. Clamp
3. safety-rope
4. Quick-lock fastener
● Screw one clamp each via a M12 screw and nut onto the Omega-holders.
● Insert the quick-lock fasteners of the first Omega-holder into the respective holes on the bottom
of the device. Tighten the quick-lock fasteners fully clock-wise; install the second Omega-holder.
DANGER TO LIFE
Before taking into operation for the first time, the installation has to be approved by expert!
DMX-512 connection / connection between fixtures.
The wires must not come into contact with each other; otherwise the fixtures will not work at
all, or will not work properly.
● Only use a stereo shielded cable and 3-pan XLR-plugs and connectors in order to connector the
controller with the fixture or one fixture with another.
● If you are using controllers with occupation. You can connect the DMX-output of the controller
directly with the DMX-input of the first fixture in the DMX-chain.
● If you wish to connect DMX-controllers with other XLR-outputs, you need to use adapter-cables.
Building a serial DMX-chain.
● Connect the DMX-output of the first fixture in the DMX-chain with the DMX-input of the next
fixture , always connect one output with the input of the next fixture until all fixtures are
connected.
● Caution: At the last fixture, the DMX-cable has to be terminated with a terminator. Older a 120
resister between signal (-) and signal (+) into a 3-pin XLR-plug it in the DMX-output of the last
fixture.
Connection with mains
● Connect the device to the mains with the enclosed power supply cable.
The occupation of the connection-cables is as follows:
CABLE
PIN
INTERNATIONAL
Brown
Live
L
blue
Neutral
N
Yellow/green
Earth
Ground
The earth has to be connected!
Lighting effects must not be connected to dimming-packs.

OPERATION
● After you connected the effect to the mains, this moving-head light starts running. During the
reset, the motors are trimmed and the device is ready for use afterwards.
● You can control the projectors individually via you DMX-controller, Every DMX-channel has a
different occupation with different features, in order to all up the different features. You first
have to open the shutter.
● Turn the focus-screw next to the objective-lens for adjusting the focus in order to obtain a sharp
projection.
Connection:
● After finished all mentioned process, confirm fixed the right lamp, turn on the switch and check
if everything is correct, connect the light with power supply, after some seconds will start.
Reposition, at the same time, if everything is ok, LCD screen will display DMX start ADD No (run
node: DMX512- DMX001.
DIMMER:
● Turn on the lamp controller and use cross screw-driver adjust the three screw which located at
the back of light, adjust the three screw, and turn to best brightness.

Maintenance
1. To reduce the risk of electrical shock of fire, do not expose this unit to rain or moisture.
2. Do not spill water or other liquids into or on to your unit.
3. During long periods of non-use, disconnect the unit’s main power.
4. It should be installed in a well-ventilatedplaceatadistanceof50centimeterormorewiththe
walls, at the same time, please check if the fan and ventilation holes are unobstructed.
Stagement
The product has perfect performance and integrity packing. All users should be strictly complying
with the warning and operating instructions as stated, or we aren’t in charge of any result by
misusing. Any neglecting the manual is also not in the charge of dealers.
Note: all information is subject to change without prior notice.
Safety precautions
1. In order to guarantee the product’s life, please don’t put in the damp places or even the
environment over 60 degrees.
2. Always mount this unit in safe and stable matter. The qualified professionals are allowed to
carry out the lamp installation, operation and maintenance, but they much guarantee to operate
in strict accordance with the instructions referred to.
3. Using lamp, the change rate of power voltage should be within 10%, if the voltage is too high, it
will shorten the light’s life, if it’s not enough, the lamp will be dark.
4. Please restart if after turning off light for 20 minutes until full-cooling. Frequent switching will
reduce the life span of lamps and bulbs; intermittent using will improve the life for bulbs and
lamps.
5. In order to make sure the product is used well, please read the manual carefully.
Products instruction
Power supplies: 110V-240V, 50Hz/60Hz, for electronics ballast.
Lamp source: Discharge lamp with a short arc burner in a reflector system.
•Type: Philips MSD Platinum 5R Lamp
•Output lamp power: 189W
•Color temperature: 8500K
•Average life: 2000 hours
Optics
3-lens optical group combination
Focus: electronic
Light output at 20 meters (65 feet): 59760 lux
Color system
Interchangeable color wheel with 14 colors + open.
