Gah Itd 130 User manual

Technical and Installation manualechnical and Installation manual

echnical and Installation manualechnical and Installation manual

echnical and Installation manual

All Models

For owners, installers and service engineers

heating products

Important Health and Safety Information for Installers and Service Engineers

Health and Safety at Work Act 1974

Consumer Protection Act 1987

COSHH Regulations 1988

The following information is given as a requirement of the

above legislation.

Great care is taken by GAH (HEATING PRODUCTS) LIMITED to

ensure that Dualstream systems are designed and

manufactured to meet general safety requirements when

properly used and installed as recommended in this manual.

It is the responsibility of Users and Engineers to ensure that

adequate protective clothing and glasses are worn when

working with the Dualstream system.

SEALS AND INSULATIONSEALS AND INSULATION

SEALS AND INSULATION

Insulation and sealing materials are used in the construction of

the Dualstream cylinders. Units are sealed and when used in

the manner for which they are intended the insulating and

sealing materials do not present any known hazard. However

always observe the following recommendations:-

1. Avoid inhalation of fibres or dust, wear face mask.

2. Avoid eye contamination by fibres or dust - wear eye

protection.

3. As far as possible avoid any skin contact with Fibreglass

Insulation, Glass Rope, Mineral Wool, Insulation Pads and

Ceramic Fibre.

GAH (HEATING PRODUCTS) LIMITED will not accept

responsibility for any damage or personal injury caused

by not giving due consideration to the above safety

recommendations.

OTHER MATERIALSOTHER MATERIALS

OTHER MATERIALS

SEALANTS, ADHESIVES AND PAINTS

Sealants, Adhesives and Paints are used in the construction of

the Dualstream components. When used in the manner for

which they are intended they do not present any known hazard.

ELECTRICELECTRIC

ELECTRIC

All cylinders have electrical supply of 240V (enough to

endanger life) connected to the Immersion Heater.

Always isolate before adjustment, servicing and repair.

All electrical installation and maintenance of the Dualstream

must be carried out by a competent qualified installer.

All electrical work must be installed to the requirements of

these ‘User and Installation Instructions’.

Patents GB 2349908atents GB 2349908

atents GB 2349908atents GB 2349908

atents GB 2349908

©©

2012 GAH (HEATING PRODUCTS) L2012 GAH (HEATING PRODUCTS) L

2012 GAH (HEATING PRODUCTS) LTD.TD.

TD.TD.

TD.

DualstrDualstr

Dualstream is a Team is a T

eam is a Team is a T

eam is a Trademark of GAH (HEATING PRODUCTS) Lrademark of GAH (HEATING PRODUCTS) L

rademark of GAH (HEATING PRODUCTS) Lrademark of GAH (HEATING PRODUCTS) L

rademark of GAH (HEATING PRODUCTS) LTD.TD.

TD.TD.

TD.

Manual by Harber Technical Services Tel/Fax 01263 515444

E-mail:[email protected] www.harbertech.co.uk

GAH (Heating PrGAH (Heating Pr

GAH (Heating Products) Ltd.oducts) Ltd.

oducts) Ltd.oducts) Ltd.

oducts) Ltd.

Building 846

Bentwaters Parks

Rendlesham

Woodbridge

Suffolk IP12 2TW

Tel:el:

el:el:

el: 01394 42116001394 421160

01394 42116001394 421160

01394 421160

Fax:Fax:

Fax: 01394 42117001394 421170

01394 42117001394 421170

01394 421170

email: [email protected]

www.gah.co.uk

In pursuance of a policy of constant development, GAH (HEATING PRODUCTS) LIMITED

reserve the right to change any boiler part or design without notice, therefore certain

details included in this manual may not be correct at the time of printing. Any

modification and improvements detailed in this manual does not commit GAH to update

any system previously supplied.

Front cover shows typical components.

Manual Part No. ...................015-15011

Manual Ref ..........................CS10

Issue ...................................7a

Date ....................................25/02/2013

HTS REF GAH Dualstream 250213 (Aquabravo cylinders)

CONTENTSCONTENTS

CONTENTS

1 INTRODUCTION1 INTRODUCTION

1 INTRODUCTION

2 OPERA2 OPERA

2 OPERATOR CONTROLSTOR CONTROLS

TOR CONTROLSTOR CONTROLS

TOR CONTROLS

3 TECHNICAL INFORMA3 TECHNICAL INFORMA

3 TECHNICAL INFORMATIONTION

TIONTION

TION

5 COMMISSIONING5 COMMISSIONING

5 COMMISSIONING

7 F7 F

7 FAULAUL

AULAUL

AULT FINDINGT FINDING

T FINDINGT FINDING

T FINDING

CONTENTSCONTENTS

CONTENTS

Section 1 IntrSection 1 Intr

Section 1 Introductionoduction

oductionoduction

oduction

1-1 Introduction ---------------------------------------------- 2

1-2 System Layout ------------------------------------------- 3

1-3 System Requirements ------------------------------------ 4

Section 2 Operator ContrSection 2 Operator Contr

Section 2 Operator Controlsols

olsols

ols

2-1 Hot Water Temperature - Heating System ---------------- 7

2-2 Hot Water Temperature - Immersion Heater--------------- 7

2-3 Hot Water Overheating ----------------------------------- 8

2-4 Shut Off Valves ------------------------------------------ 10

2-5 Expansion Relief----------------------------------------- 11

2-6 Servicing ------------------------------------------------ 11

2-7 Protech Anti-corrosion System -------------------------- 11

Section 3 TSection 3 T

Section 3 Technical Informationechnical Information

echnical Informationechnical Information

echnical Information

3-1 Specifications ------------------------------------------- 12

3-2 Dimensions --------------------------------------------- 13

3-3 Wiring --------------------------------------------------- 16

Section 4 InstallationSection 4 Installation

Section 4 Installation

4-1 Building Control ----------------------------------------- 18

4-2 Installation ---------------------------------------------- 18

4-3 Expansion Discharge ------------------------------------ 21

4-4 Larger Systems ------------------------------------------ 23

4-5 System Pressure ---------------------------------------- 24

4-6 Parts Supplied - ----------------------------------------- 25

Section 5 CommissioningSection 5 Commissioning

Section 5 Commissioning

5-1 Commissioning Checks --------------------------------- 28

5-2 Handing Over ------------------------------------------- 29

Section 6 ServicingSection 6 Servicing

Section 6 Servicing

6-1 Routine Service ----------------------------------------- 30

Section 7 Fault FindingSection 7 Fault Finding

Section 7 Fault Finding

7-1 Fault Finding -------------------------------------------- 31

6 SERVICING6 SERVICING

6 SERVICING

4 INST4 INST

4 INSTALLAALLA

ALLAALLA

ALLATIONTION

TIONTION

TION

IMPORTANT

BEFORE STARTING THE INSTALLATION OF THE DUALSTREAM CHECK ALL COMPONENTS HAVE

BEEN DELIVERED AND ARE IN SATISFACTORY CONDITION.

1-1 Introduction

INTRODUCTION 1INTRODUCTION 1

INTRODUCTION 1

1-1.1 The Dualstream System

The Dualstream systems by GAH Heating Products have been developed as an advanced

solution for domestic hot and cold water installations. A Dualstream system will increase

the water volume and maintain the mains pressure to both the hot and cold supplies

when more than one outlet is in use at the same time.

Dualstream has been designed to function on the minimum standard for domestic water

supply as provided by local water authorities - which is 1 Bar at 9 litres per minute.

GAH offer full technical assistance and design service to enable the optimum Dualstream

system to be configured to overcome situations where poor mains supply and pressure

are considered a problem.

1-1.2 How the Dualstream system works

The system mainly comprises:- an unvented direct or indirect cylinder, an accumulator

(cold water storage vessel), a combination valve and an expansion relief valve.

The accumulator has an internal controlled butyl diaphragm, incoming cold water is

stored within this diaphragm at mains pressure. The air space between the diaphragm

and the accumulator case is pressurised, this balances the supply and maintains

pressure to the unvented hot water cylinder and cold outlets. When hot and cold water

outlets are turned on the stored water from the accumulator supplements water from the

incoming main, this results in consistent pressure and flow to all taps, showers and baths

when outlets are used simultaneously. Pressure will be sustained for as long as the

accumulator is holding sufficient volume of water.

1-1.3 System Comprises

1. An unvented hot water cylinder pre-plumbed with all valves and controls with easy

access pipe connections for quick, trouble-free installation.

2. Cylinder Thermostat and Thermal Cut-Out Thermostat.

3. An accumulator (cold water storage) and associated fittings which can be

positioned anywhere in the dwelling, outhouse or garage, refer to 4-2.6.

4. A Motorised Valve for connection to the heating systems flow to cylinder.

1-1.4 Dualstream System Features

1. All taps and showers are at maximum ‘System Pressure’.

2. Provide increased water flow rate to both hot and cold water outlets.

3. Suitable for properties with very low mains flow rates (9 litres per minute).

4. Balanced Hot and Cold water supply pressures.

5. Minimum pressure drop when more than one tap is in use.

6. More than 25% less pipework than traditional systems.

7. No loft storage tank - no risk of water stagnation.

8. Completely sealed system - wholesome water to all cold taps.

9. No tank filling noise.

10. Dualstream utilises GREEN TECHNOLOGY.

Note

For components supplied with system refer

to page 25.

Note

It is recommended to obtain the nominal

mains pressure and flow rate before

installing a Dualstream system, this will

enable the optimum system to be

configured to suit conditions.

Note

Direct cylinder heated by immersion

heater. Indirect cylinder heated by boiler

(also has immersion heater).
