Microwave Oven
Instructions
Model: P90J23AL-V1

1
PRECAUTIONS TO AVOID POSSIBLE
EXPOSURE TO EXCESSIVE
MICROWAVE ENERGY
1.Do not attempt to operate this oven with the door open since open-door operation can
result in harmful exposure to microwave energy. It is important not to defeat or tamper
with the safety interlocks.
2.Do not place any object between the oven front face and the door or allow soil or
cleaner residue to accumulate on sealing surfaces.
3.Do not operate the oven if it is damaged. It is very important that the oven door close
properly and that there is no damage to the
a) Door (including any bent),
b) Hinges and latches (broken or loosened),
c) Door seals and sealing surfaces.
4.The oven should not be adjusted or repaired by anyone except qualified service
personnel.
Content
PRECAUTIONS TO AVOID POSSIBLE EXPOSURE TO EXCESSIVE MICROWAVE ENERGY....................1
IMPORTANT SAFETY INSTRUCTIONS ..................................................................................................... 2
GROUNDING INSTRUCTIONS ..................................................................................................................4
Installation Guide ......................................................................................................................................... 4
Cooking Utensils Guide ................................................................................................................................ 5
Specifications...............................................................................................................................................6
Product Diagram .......................................................................................................................................... 6
Control Panel ............................................................................................................................................... 7
Operation Instructions................................................................................................................................... 8
Setting the clock ................................................................................................................................ 8
Express cooking................................................................................................................................. 8
+30 sec. function................................................................................................................................ 8
Setting the kitchen timer.................................................................................................................... 8
Microwave cooking........................................................................................................................... 8
Time defrost....................................................................................................................................... 9
Weight defrost.................................................................................................................................... 9
Multistage cooking ............................................................................................................................ 9
Child lock ........................................................................................................................................ 10
Pad closed protection....................................................................................................................... 10
Auto cook ........................................................................................................................................ 10
Cleaning and Care .......................................................................................................................................11

2
IMPORTANT SAFETY INSTRUCTIONS
WARNING!--To reduce the risk of burns, electric shock, fire, injury to persons or exposure
to excessive microwave energy:
1. Read all instructions before using the appliance.
2. Read and follow the specific "PRECAUTIONS TO AVOID POSSIBLE EXPOSURE TO
EXCESSIVE MICROWAVE ENERGY" on page 1.
3. This appliance must be grounded. Connect only to properly grounded outlet. See
"GROUNDING INSTRUCTIONS" on page 4.
4. Install or locate this appliance only in accordance with the provided installation
instructions.
5. Do not operate the oven when empty.
6. Some products such as whole eggs and sealed containers -for example, closed glass
jars- are able to explode and should not be heated in this oven.
7. Use this appliance only for its intended use as described in this manual. Do not use
corrosive chemicals or vapors in this appliance. This type of oven is specifically
designed to heat, cook, or dry food. It is not designed for industrial or laboratory use.
8. As with any appliance, close supervision is necessary when used by children.
9. To reduce the risk of fire in the oven cavity:
a) Do not overcook food. Carefully attend appliance when paper, plastic, or other
combustible materials are placed inside the oven to facilitate cooking.
b) Remove wire twist-ties from paper or plastic bags before placing bag in oven.
c) If materials inside the oven should ignite, keep oven door closed, turn oven off, and
disconnect the power cord or shut off power at the fuse or circuit breaker panel.
d) Do not use the cavity for storage purposes. Do not leave paper products, cooking
utensils or food in the cavity when not in use.
10. Liquids, such as water, coffee, or tea are able to be overheated beyond the boiling point
without appearing to be boiling due to surface tension of the liquid. Visible bubbling or
boiling when the container is removed from the microwave oven is not always present.
THEIS COULD RESULT IN VERY HOT LIQUIDS SUDDENLY BOILING OVER WHEN A
SPOON OR OTHER UTENSIL IS INSERTED INTO THE LIQUID. To reduce the risk of
injury to person:
a) Do not overheat the liquid.
b) Stir the liquid both before and halfway through heating it.
c) Do not use straight-sided containers with narrow necks.
d) After heating, allow the container to stand in the microwave oven for a short time
before removing the container.
e) Use extreme care when inserting a spoon or other utensil into the container.

3
11. Do not heat oil or fat for deep-frying. It is difficult to control the temperature of oil in
microwave oven.
12. Do not cover or block any openings on the appliance.
13. Do not store or use this appliance outdoors. Do not use this product near water, for
example, near a kitchen sink, in a wet basement, near a swimming pool, or similar
locations.
14. Do not operate this appliance if it has a damaged cord or a plug, if it is not working
properly or if it has been damaged or dropped.
15. Do not immerse cord or plug in water. Keep cord away from heated surface. Do not let
cord hang over edge of table or counter.
16. This appliance should be serviced only by qualified service personnel, contact nearest
authorized service facility for examination, repair, or adjustment.
17. When cleaning surfaces of door and oven that comes together on closing the door, use
only mild, nonabrasive soaps, or detergents applied with a sponge or soft cloth.
18. This equipment has been tested and found to comply with Part 18 of the FCC Rules.
Operation is subject to the following two conditions: (1) This device may not cause
harmful interference, and (2) this device must accept any interference received,
including interference that may cause undesired operation.
CAUTION: Changes or modifications not expressly approved by the party responsible
for compliance could void the user's authority to operate the product.
19. This equipment generates, uses and can radiate radio frequency energy and, if not
installed and used in accordance with the instructions, may cause harmful interference
to radio communications. However, there is no guarantee that interference will not occur
in a particular installation. If this equipment does cause harmful interference to radio or
television reception, which can be determined by turning the equipment off and on, the
user is encouraged to try to correct the interference by one or more of the following
measures:
Reorient or relocate the receiving antenna.
Increase the separation between the equipment and receiver.
Connect the equipment into an outlet on a circuit different from that to which the
receiver is connected.
Consult the dealer or an experienced radio/TV technician for help.
SAVE THESE INSTRUCTIONS

4
GROUNDING INSTRUCTIONS
This appliance must be grounded. In the event of an electrical short circuit, grounding
reduces risk of electric shock by providing an escape wire for the electric current. This
appliance is equipped with a cord having a grounding wire with a grounding plug. The plug
must be plugged into an outlet that is properly installed and grounded.
WARNING!-- Improper use of the grounding plug can result in a risk of electric shock.
Consult a qualified electrician or serviceman if the grounding instructions are not
completely understood, or if doubt exists as to whether the appliance is properly grounded,
and if it is necessary to use an extension cord, use only a 3-wire extension cord that has a
3-blade grounding plug and a 3-slot receptacle that will accept the plug on the appliance.
The marked rating of the extension cord shall be equal to or greater than the electrical
rating of the appliance.
Electrical Requirements
The electrical requirements are a 120 volt 60 Hz, AC only, 15 amp. It is recommended that
a separate circuit serving only the oven be provided. The oven is equipped with a 3-prong
grounding plug. It must be plugged into a wall outlet properly installed and grounded.
Power Cord
1. A short power supply cord is provided to reduce the risks resulting from becoming
entangled in or tripping over a longer cord.
2. Longer cord sets or extension cords are available and may be used if care is exercised
in their use.
3. If long cord or extension cord is used：
a) The marked electrical rating of the cord set or extension cord should be at least as
great as the electrical rating of the appliance.
b) The extension cord must be a grounding-type 3-wire cord, and The longer cord should
be arranged so that it will not drape over the counter top or table top where it can be
pulled on by children or tripped over unintentionally.
Installation Guide
1. Make sure that all the packing materials are removed from the inside of the door.
2. This microwave oven must be placed on a flat.
3. For correct operation, the oven must have sufficient air flow. Allow 20cm of space above the oven,
10cm at back and 5cm at both sides. Do not cover or block any openings on the appliance. Do not
remove feet on which oven stands.
4. Do not operate the oven without glass tray, roller support, and shaft in their proper positions.
5. Make sure that the power cord is undamaged and does not run under the oven or over any hot or
sharp surface.
6. The socket must be readily accessible so the microwave oven can be easily unplugged in an
emergency.

5
Cooking Utensils Guide
This section lists which utensils can be used in this microwave, which have limited use for short periods,
and which should not be used in this microwave.
RECOMMENDED
Microwave browning dish —Use to brown the exterior of small items such as steaks, chops, or
pancakes. Follow the directions provided with your browning dish.
Microwaveable plastic wrap —Use to retain steam. Leave a small opening for some steam to escape
and avoid placing it directly on the food.
Paper towels and napkins —Use for short-term heating and covering; these absorb excess moisture
and prevent spattering. Do not use recycled paper towels, which may contain metal and could ignite.
Glass and glass-ceramic bowls and dishes —Use for heating or cooking.
Paper plates and cups —Use for short-term heating at low temperatures. Do not use recycled paper,
which may contain metal and could ignite.
Wax paper —Use as a cover to prevent spattering.
Thermometers —Use only those labeled "Microwave Safe" and follow all directions. Check the food in
several places. Conventional thermometers may be used on microwave food once the food has been
removed from the oven.
LIMITED USE
Aluminum foil —Use narrow strips of foil to prevent overcooking of exposed areas. Using too much foil
can damage your oven, so be careful. You should keep distance of 1 inch (2.54cm) between aluminum
foil and cavity.
Ceramic, porcelain, and stoneware—Use these if they are labeled "Microwave Safe". If they are not
labeled, test them to make sure they can be used safely.
Plastic —Use only if labeled "Microwave Safe". Other plastics can melt.
NOT RECOMMENDED
Glass jars and bottles —Regular glass is too thin to be used in a microwave. It can shatter and cause
damage and injury.
Paper bags —These are a fire hazard, except for popcorn bags that are designed for microwave use.
Styrofoam plates and cups —These can melt and leave an unhealthy residue on food.
Plastic storage and food containers —Containers such as margarine tubs can melt in the microwave.
Metal utensils —These can damage your oven. Remove all metal before cooking.
Note:
Should you wish to check if a dish is safe for microwaving, place the empty dish in the oven and
microwave on HIGH for 30 seconds. A dish which becomes very hot should not be used.

6
Specifications
Power Consumption
120V/60Hz, 1400W(microwave)
Output
900W
Operation Frequency
2450MHz
Outside Dimensions(H x W x D)
10 7/8×19×13 3/8in.
Oven Capacity
0.9cu.ft.
Net Weight
Approx.20.4 lbs
Product Diagram
1. Door Safety Lock System
2. Oven Window
3. Shaft
4. Roller Ring
5. Control Panel
6. Wave Guide (Please do not remove the
mica plate covering the wave guide)
7. Glass Tray

7
Control Panel
⚫DISPLAY
Cooking time, power, indicators and clock time are
displayed.
⚫AUTO COOK MENUS
There are 6 kinds of auto cook menus. Use to set auto cook
program.
⚫CLOCK
Press to set clock time.
⚫TIME COOK
Press to set microwave cooking program.
⚫KITCHEN TIMER
Press to set the oven timer function.
⚫TIME DEFROST
Press to set defrost program based on time.
⚫WEIGHT DEFROST
Press to set defrost program based on weight.
⚫POWER LEVEL
Press to set microwave power level.
⚫NUMBER PADS (0-9)
Press to adjust power level, set time or food weight.
But use the number pads from 1 to 6 can set express
cooking program.
⚫STOP/CLEAR
Press to cancel setting or reset the oven before setting a
cooking program.
Press once to temporarily stop cooking, or twice to
cancel cooking altogether.
It is also used for setting child lock function.
⚫START/+30 SEC.
Press to start cooking program.
Simply press it a number of times to set cooking time and
cook immediately at full power level.

8
Operation Instructions
➢When the oven first plugged in, beep will sound and the display will show "1:01".
➢In the process of cooking setting, broke about 30 seconds the oven will return to standby mode.
➢During cooking, if press STOP/CLEAR pad once, the program will be paused, then press START/+30
SEC. pad once to resume, but if press STOP/CLEAR pad twice, the program will be canceled.
➢After cooking end, the screen will display End with sound every two minutes until user press
STOP/CLEAR pad or open the door.
➢In the process of operation, press a valid pad, the buzzer rings once, but if press a invalid pad, the
buzzer rings twice.
SETTING THE CLOCK
This is a 12 or 24 hour clock, and you can select it by pressing CLOCK pad.
1. In standby mode, press CLOCK pad once or twice to select 12 or 24 hour clock.
2. Use the number pads to enter correct time.
3. Press CLOCK pad again to confirm.
NOTE: During cooking, the current time of the clock can be seen by pressing CLOCK pad.
EXPRESS COOKING
Directly in standby mode, press the number pad once (1-6), the corresponding system direct start
cooking time respectively 1 minute, 2 minutes, 3 minutes, 4 minutes, 5 minutes and 6 minutes. The oven
will start to cook at full power level.
+30 SEC.FUNCTION
In standby mode, press START/+30 SEC. pad repeatedly to enter cooking time (each press to increase
30 seconds, and up to 99 minutes and 99 seconds). The oven will auto start cooking at full power level.
NOTE: During express cooking and microwave cooking program, you can add cooking time by pressing
START/+30 SEC. pad.
SETTING THE KITCHEN TIMER
1. In standby mode or during cooking, press KITCHEN TIMER pad once.
2. Press number pads to enter the amount of time. The longest time is 99 minutes and 99 seconds.
3. Press START/+30 SEC..
NOTE: When the countdown ends, the buzzer will beep to remind you. You can check the
countdown time by pressing KITCHEN TIMER pad, but if STOP/CLEAR pad is pressed when the
display shows the time, the function can be cancelled..
MICROWAVE COOKING
1. In standby mode, press TIME COOK pad once.
2. Press number pads to enter cooking time. The longest time is 99 minutes and 99 seconds.
3. Press POWER LEVEL pad once (default 100% power level), and then use the number pads to enter
other power level.
4. Press START/+30 SEC. pad.

9
Use single digit to set a cooking power level:
Number pad
Cooking power (Display)
Number pad
Cooking power (Display)
1,0
100% (P100)
4
40% (P-40)
9
90% (P-90)
3
30% (P-30)
8
80% (P-80)
2
20% (P-20)
7
70% (P-70)
1
10% (P-10)
6
60% (P-60)
0
0% (P-00)
5
50% (P-50)
NOTE: During cooking, the current cooking power level can be seen by pressing POWER LEVEL pad. If
you want to set 100% power level, you can omit the step 3 given above.
TIME DEFROST
1. In standby mode, press TIME DEFROST pad.
2. Press number pads to enter defrosting time. The longest time is 99 minutes and 99 seconds.
3. Press START/+30 SEC. pad.
NOTE: During defrosting program, the system will pause and sound beeps to remind user to turn food
over, and then press START/+30 SEC. pad to resume.
WEIGHT DEFROST
1. Press WEIGHT DEFROST pad once.
2. Press number pads to enter weight of food. The frozen food weight ranges from 100 g to 1800 g.
3. Press START/+30 SEC. pad.
NOTE:During defrosting program, the system will pause and sound to remind user to turn food over,
after that, press START/+30 SEC. to resume the defrosting.
MULTISTAGE COOKING
Your oven can be programmed up to 3 automatic cooking sequences. It can be composed of time defrost
with one or two microwave cooking program, or composed of two microwave cooking program.
A. Time defrost with one or two-stage microwave cooking
1. Open the door and place the food into the oven, close it.
2. Press TIME DEFROST pad once.
3. Enter desired defrosting time by pressing correct number pads.
4. Input the first microwave cooking program. Do not press START/+30 SEC. pad.
5. Input the second microwave cooking program.
6. Press START/+30 SEC. to start.
NOTE: Step 5 is not necessary if you have one microwave cooking program. Time defrost can only be set
in the first stage.
B. Two-stage microwave cooking
Some recipes require different stages of cooking at different temperatures.
1. Input the first microwave cooking program.
2. Input the second microwave cooking program.
3. Press START/+30 SEC. to start.

10
CHILD LOCK
The lock prevents unsupervised operation by children.
To set: In standby mode, press and hold the STOP/CLEAR pad for 3 seconds, a beep sounds and lock
indication appears on the display for 3 seconds, the oven will auto enter child lock mode. In the lock state,
all pads are disabled.
To cancel: Press and hold the STOP/CLEAR pad for 3 seconds to cancel the program and a beep
sounds.
PAD CLOSED PROTECTION
In any state, if any pad on the control panel is closed for 1 minute, the program stops working immediately,
the display shows "FAIL" and the system will sound beep. If the pad keep closing, beep will sound every
one minute. Any pad is invalid at this time. After troubleshooting, press the STOP/CLEAR pad to return
standby mode.
AUTO COOK
For the following food, it is not necessary to program the cooking time and power. It is sufficient to
indicate the type of food that you want to cook as well as the weight or servings of this food.
1. In standby mode, press the corresponding menu pad once or repeatedly to select the food weight or
servings.
2. Press START/+30 SEC. pad.
Auto cook menus:
Food
Note
Potato (230 g/serving, 1-3 servings)
The result of auto cook depends on factors
such as the shape and size of food, your
personal preference as to the doneness of
certain foods and even how well you happen
to place food in the oven. If you find the
result at any rate not quite satisfactory,
please adjust the cooking time a little bit
accordingly.
Popcorn (99 g)
Pizza (150-450 g)
Beverage (200 ml/cup, 1-3 cups)
Frozen Dinner (250-500 g)
Reheat (200-800 g)

11
Cleaning and Care
1. Turn off the oven and unplug the power cord from the wall when cleaning.
2. Keep the inside of the oven clean. When food splatters or spilled liquids adhere to oven walls, wipe
with a damp cloth. Mild detergents may be used if the oven gets very dirty. Avoid using spray or other
harsh cleaners. They may stain, streak or dull the door surface.
3. The outside of the oven should be cleaned with a damp cloth. To prevent damage to the operating
parts inside the oven, water should not be allowed to seep into the ventilation openings.
4. Wipe the door and window on both sides, the door seals and adjacent parts frequently with a damp
cloth to remove any spills or spatters. Do not use abrasive cleaner.
5. Do not allow the control panel to become wet. Clean with a soft, damp cloth. When cleaning the control
panel, leave oven door open to prevent oven from accidentally turning on.
6. If steam accumulates inside or around the outside of the oven door, wipe with a soft cloth. This may
occur when the microwave oven is operated under high humidity condition. And it is normal.
7. It is occasionally necessary to remove the glass tray for cleaning. Wash the tray in warm sudsy water
or in a dishwasher.
8. The roller ring and oven floor should be cleaned regularly to avoid excessive noise. Simply wipe the
bottom surface of the oven with mild detergent. The roller ring may be washed in mild, soapy water or
in a dishwasher. When removing the roller ring, be sure to replace it in the proper position.
9. Remove odors from your oven by combining a cup of water with the juice and skin of one lemon in a
microwaveable bowl. Microwave for 5 minutes. Wipe thoroughly and dry with a soft cloth.
10. If the light bulb burns out, please contact customer service to have it replaced.
11. The oven should be cleaned regularly and any food deposits should be removed. Failure to maintain
the oven in a clean condition could lead to deterioration of surface that could adversely affect the life of
the unit and could possibly result in a hazardous situation.
12. Please do not dispose of this appliance into the domestic rubbish bin; it should be disposed to the
particular disposal center provided by the municipalities.
