Galaxy IPTV-DMG Guide

Digital Media Gatewa
y
IPTV-DMG
V1.0
User Manual
& Installation Guide

Table of Contents
CHAPTER 1 - INTRODUCTION - 1 -
THE IPTV-DMG - 1-
PACKAGE CONTENTS -1-
OPTIONAL KIT -1-
SYSTEM REQUIREMENTS -1-
PC REQUIREMENTS -1-
TV REQUIREMENTS -1-
INTERFACE INFORMATION -2-
REMOTE CONTROL -3-
[CLEAR] - 3-
[SELECT] - 3-
[TV MODE] - 3-
[SETUP] - 3-
[VOLUME] - 3-
[RETURN] - 3-
[SUBTITLE] - 4-
[AUDIO] - 4-
CHAPTER 2 - SYSTEM SETUP - 5 -
SETUP MENU -6-
OPTIONS -6-
[SCREENSAVER] - 6-
[LANGUAGE] - 6-
[SLIDESHOW] - 6-
[INTERNET] - 6-
[VIDEO] - 6-
[AUDIO] - 6-
[BROWSER OPTION] - 6-
[SOUND OPTION] - 6-
IP CONFIG -7-
[MACADDRESS] - 7-
[IPADDRESS] - 7-
[SUBNET MASK] - 7-
[PRIMARY DNS] - 7-
[SECONDARY DNS] - 7-
[DEFAULT GATEWAY] - 7-
[AOL] - 7-
WIRELESS SETUP -8-
[PREFERRED] - 8-
[AVAILABLE NETWORK] - 8-
[SSID] - 8-
[CONNECTION] - 8-
[SECURITY] - 8-
[KEY] - 8-
TIME SETUP -9-
UPDATE ROM - 9-
CHAPTER 3 – USB HOST - 10 -
CHAPTER 4 – NETWORK MODE - 11 -
UPNPDEVICES -11 -
MEDIA SERVER -11 -
ONLINE PREMIUM CONTENT -12 -
[VTUNER] - 12 -
[AOL] - 12 -
[INTERNET TV] - 12 -
[MUSIC] - 12 -
[PHOTO] - 12 -
[NEWS] - 12 -
[ENTERTAINMENT] - 12 -
[TECHNOLOGY] - 12 -
[SEARCH] - 12 -
[EDIT] - 12 -
CHAPTER 5 - APPENDIX - 13 -
SPECIFICATIONS -13 -
FAQ - 14 -
REMOTE CONTROL KEY FUNCTIONS -15 -
ABOUT THIS MANUAL -16 -

Chapter 1 - Introduction
The IPTV-DMG
The 'IPTV-DMG' Digital Media Gateway is the perfect gateway for your living room, linking
up your PC, TV, stereo, digital camera and much more. Great design coupled with
playback support for all kinds of standard media formats and simple installation makes it
the perfect all-in-one multimedia solution.
Product Dimensions: 16.5cm x 16.5 cm x 3.2 cm
6.50” x 6.50” x 1.26”
Package Contents
•IPTV-DMG
•External Power Adapter;
Input 100-240V, Output +12V/1A
•Composite and Component video cable
•SPDIF optical audio cable
•Ethernet cable, SCART adapter
•Infrared remote control
•Manual, CD with MyHome application and user guide
Note: Package content may vary, depending on vendor & version.
Optional Kit
•Antenna and mini-PCI card for wireless function
System Requirements
PC Requirements
•Minimum Intel Processor II 350MHz, 64MB RAM
•Operating System; Win98SE, WinME, Win2000, WinXP
•10 Mbps, 100 Mbps or 10/100Mbps Fast Ethernet card, or a USB-to-Ethernet converter
equipped PC with CD-ROM
TV Requirements
•Video/Audio input, standard Composite RCA input
•Optional Component input and amplifier for digital audio
Note: To make use of all features the IPTV-DMG offers, an Ethernet connection with
access to the local network and internet is required. Additionally, a computer running the
MyHome media server is recommended.
- 1 -

Interface Information
Following images are for reference only and show the IPTV-DMG without the optional
802.11 b/g antenna.
Green:
Power ON/OFF
Infrared Receiver
Yellow:
LAN connection
USB host
connectors
Power
switch Power
receptacle
A/V multi interface
connecto SPDIF
audio out Ethernet
r
p
ut
p
ort
- 2 -

Remote Control
Power ON/OFF
No Function
Input for time, search, login, URL and other text.
Input Selector
Clear (Backspace)
[CLEAR] Delete a letter or number when entering text.
[SELECT] Toggle text input between upper case, lower case and numbers.
TV Mode
Setup
No Function
Volume Adjustment
Mute Sound
Navigation Keys
Menu
Return
[TV MODE] Each time this button is pressed, the video output will change. Use this when
you only see a blank screen but go to setup and save your settings once you have a signal.
[SETUP] Press this key to enter the setup menu and change the settings and other
configuration options for your IPTV-DMG.
[VOLUME] When browsing web pages, these keys can be used to scroll up and down,
otherwise they are used to adjust the volume for music and video files.
[MENU] Tab between the different menu options.
[RETURN] Go one step back and return to the previous menu.
- 3 -

A: N/A
B: Return to Menu Playback Functions
Audio output
A: N/A
B: Return to Home
A: File Info
B: Go to Setup
A: Time Search
B: URL input
A: Repeat
B: Refresh
Subtitle encoding/OFF
Zoom Function
No function
Rotate Images
No function
[A-B] Return to the menu or the main screen depending on the present mode.
[REPEAT] Return to the main screen.
[INFO] Go to the setup menu or show file info during playback.
[EDIT/PROGRAMM] Go to URL or time search during playback.
[SHUFFLE] Refresh screen or change repeat mode during playback.
[SUBTITLE] Toggle between different encodings for the subtitles or turn them OFF.
[AUDIO] Change between stereo and mono output.
[ZOOM] Zoom mode for photos (press Enter in zoom mode to pan) and toggle between
full screen, actual size and original size for movies.
Note: See Appendix for detailed functions of each key.
- 4 -

Chapter 2 - System Setup
Find a suitable place for your IPTV-DMG, within a distance of 1.2m or less of your TV
screen. Connect the power supply and the power outlet.
Included with your IPTV-DMG is a standard AV cable and a YPbPr
cable. Connect it to the A/V connector on the IPTV-DMG and plug it
into your TV. For the video, use either S-Video (better quality) or if
not available, the yellow RCA connector. For analogue audio, use
the white and red RCA connectors. If your TV supports it, we
recommend using the component cable (YPbPr) for optimum video
quality (up to 720p or 1080i) instead of the standard AV composite
cable.
For Dolby 5.1 surround and digital audio output, we recommend
using the SPDIF optical audio cable. Connect this to your amplifier
or sound system and change the settings for audio output on your
IPTV-DMG to RAW format and 5.1 surround output.
For content streaming from your computer and the internet,
connect the LAN cable to an Ethernet switch or router. If you have
the optional wireless kit, content streaming is possible wirelessly
using 802.11b or g.
However, for optimum performance and high definition content with
high bitrates, we recommend using the wired LAN connection
option instead of the wireless setup.
Having connected all cables, you are now ready to turn on the power and use the remote
control to turn on the device. Simultaneously, turn on your television set, and set up the
A/V channel. Wait a few seconds for the system to boot and you should see the IPTV-
DMG welcome screen.
Note: If everything is setup correctly but you can not see the welcome screen, press the
TV Mode button until you find the right video signal.
- 5 -

Setup Menu
Once booted, press the SETUP key on your IPTV-DMG remote control to access the
configuration screen and its settings.
Options
[Screensaver] Set a time from 1-60 minutes before the screensaver turns on.
[Language] Select your preferred language for the on-screen menu, file browser encoding
and subtitles. You can also turn off the subtitles for your movies here. The default
language is English.
[Slideshow] Set the transition time and repeat mode for the slideshow presentation.
[Internet] Options for internet security used to browse the web. By default this is set to
SSL2, which will work fine for most purposes of the IPTV-DMG.
[Video] Select your video output and the preferred zoom level for watching movies. If you
accidentally saved the wrong video output and only see a blank screen, press the TV
Mode button until you see the screen again.
[Audio] By default, the audio is set to analogue stereo audio. If you use digital audio or
would like to change the default settings, change it here and save the new settings.
[Browser Option] Enables HD mode for a more compact and smaller browser.
[Sound Option] Turns the system alert or typing sound ON or OFF.
- 6 -

IP Config
By default, you can leave these settings and the IPTV-DMG will automatically request the
IP and other information over the network. If the internet connection does not work or you
would like to change it, switch to manual mode.
Input an IP address from your local network which is not in use yet. Enter an IP for the
subnet mask and the default gateway. For the DNS server, we recommend using two
different IP’s, preferable from a local and reliable provider.
[MAC Address] Displays hardware address to identify each unit
[IP Address] Choose an IP address that is different from other computers, printers and
various devices on your network but is part of the local network.
[Subnet Mask] The most common setting for home networks is 255.255.255.0.
[Primary DNS] The IP address of your Domain Name Server (DNS).
[Secondary DNS] The IP address of your backup Domain Name Server (DNS).
[Default Gateway] The IP address of the gateway or router on your local network.
[AOL] Server and URL setup for AOL subscriber services.
Note: To use direct internet access for IPTV, webradio, podcasts and other content, make
sure to enter a valid DNS server. Numbers seen in the image above are for reference only
and will be different to your settings.
- 7 -

Wireless Setup
To configure and use the wireless function, the optional antenna and mini-PCI card have
to be installed first. Set your preferred network to wireless and save the settings. You will
be prompted to reboot. After restarting the system, go back to WIFI Setup, select your
wireless network, configure the connection type and security key if required and then save
the setting.
[Preferred] Set to Wired if you use the Ethernet cable or set to Wireless if you use the
802.11b/g wireless antenna to connect to the network.
[Available Network] To use the wireless function, first set your preferred network to
wireless, save the settings and reboot. After restart, it will automatically display the
available access points (AP) and you can select your home network. To scan again for
available AP’s, select WIFI setup and click Enter.
[SSID] This field will be populated automatically once an available network has been
selected. If the SSID is hidden, enter the name of your SSID manually.
[Connection] Select your connection type. By default and for standard connections, this
will be set to Infrastructure (AP) but if required, you also set it toAd-Hoc (peer-to-peer).
[Security] IPTV-DMG supports WEP 64-bit or 128-bit encryption for additional security.
Select the WEP encryption used in your home network and enter the key or set it to OFF.
[Key] If you are using WEP encryption for your wireless network, enter the WEP key here,
otherwise leave this field empty. When 64-bit WEP is used, the WEP key should be 10
hexadecimal characters. If 128-bit WEP is used, the WEP key should be 26 hexadecimal
characters. A valid value for a hexadecimal character is 0 to 9 and A to F.
Remark: If upgrading your device with a wireless mini-PCI adapter, we strongly
recommend only using the GMG wireless kit.
- 8 -

Time Setup
Setup for clock time with time zone and NTP server. If the NTP server is set and an
internet connection exists, the IPTV-DMG can synchronise the time automatically.
The default value for the NTP server should work fine, so you only have to choose your
time zone, turn on daylight saving if required and save the settings.
Update ROM
Displays current firmware version and can be used to check for new releases and
upgrades for the IPTV-DMG.
If your IPTV-DMG is not connected to the internet, you can download the latest firmware
from your vendor’s website and save it on a USB disk. Connect it to the USB port on your
IPTV-DMG and browse for the update file, then manually update the firmware.
- 9 -

Chapter 3 – USB Host
The IPTV-DMG has two USB connectors for external USB devices. You can connect up to
two USB mass storage devices with digital media content to display on your TV. For IPTV-
DMG to recognise the external USB device it has to be mass storage class, and the file
format must be FAT12, FAT16 or FAT32. As an example, you may use a USB disk, an
USB card reader or a USB memory stick.
Simply plug in your USB device, turn on the power and you will be able to access the
device from the main screen. Browse the content, select the files you like to see and press
ENTER or PLAY to display them.
Note: USB hubs are not supported.
If there are more than 10 files in one folder, use the Volume +/- buttons to scroll up and
down the list quickly. To scroll up and down file by file, use the UP and DOWN buttons
instead. Press ENTER to play a single file or press PLAY to playback all the files in that
particular folder.
- 10 -

Chapter 4 – Network Mode
There are 3 different kinds of network modes:
•UPnP devices on local network
•Media server on PC
•Online premium content with direct internet access
UPnP devices
To access a Universal Plug and Play (UPnP) device, all you need to do is connect it to the
same local network as your IPTV-DMG. Turn on the UPnP enabled NAS or Windows
Media Connect as an example, then turn on the IPTV-DMG. On boot up, it will
automatically connect to the network and list any compatible devices. Once mounted, you
can access it from the main screen.
For UPnP servers such as Windows Media Connect or other applications, make sure your
firewall is setup properly; otherwise IPTV-DMG will not recognise the device.
Media Server
To use this mode, you need to install the included “MyHome” application or Windows
Media Connect on your computer. Connect the computer to the same network as your
IPTV-DMG, start the application and you will be able to access your shared files from the
computer directly on your IPTV-DMG.
To connect the IPTV-DMG to your computer without a local network, use a cross over
Ethernet cable.
To setup a new media server, go to the main screen. It should automatically detect new
servers but if not, click on the add button. You will have to enter the name of your MyHome
server and the IP address of that computer. Once it is setup, you can access the server
from the main screen.
For more details regarding the “MyHome” application and Windows Media Connect,
please refer to the PDF manual on the included CD.
- 11 -

Online Premium Content
In this mode, you can access content on the internet directly from your IPTV-DMG, without
the need to turn on any computer. To use this function, make sure your gateway and DNS
server are setup properly and that you have access to the internet.
[VTuner] Access to online radio broadcast and web radio with advanced search features.
Bookmark your favourite channels and listen to music from all over the world right from
your living room.
[AOL] Access to AOL subscriber services.
[Internet TV] View internet TV from all over the world. Sorted by countries, you can
browse the available TV channels and select the one you like for broadcast. For optimum
quality, high-speed internet access with good connection between TV server and your
home is required.
[Music] Listen to music news, web radio and podcast shows online.
[Photo] Access web based photo services like Flickr and view your photos.
[News] Read or listen to world news from ABC, BBC, CNN, Yahoo, MSNBC and others.
[Entertainment] Watch video clips and podcast shows related to entertainment.
[Technology] Watch podcast shows featuring the latest technology, gadgets, reviews and
other news.
[Search] Search the web by movies, podcasts, photos and other content using the Yahoo
search engine.
[Edit] Add your own bookmarks to your personal service portal or any other website.
- 12 -

Chapter 5 - Appendix
For RMA and other questions, please contact your vendor or check out their online support
area!
Specifications
Internal Memory N/A (data is accessed via USB or Ethernet)
Playback Formats Video:
•MPEG-1 up to 1.15Mbps CBR (MPG, MPE, MPEG, DAT,
M1V)
•MPEG-2 up to 15Mbps and 1080i (MPG, MPE, MPEG,
M2V, VOB)
•MPEG-4 up to 720p XviD, RMP4 (AVI, MOV, MP4)
•WMV9 up to 720p (ASF, WMV) (online key authorisation
not supported)
•MOV: 3ivX + MP3, 3ivX + PCM
(3ivX converted from supported MPEG-4 video codec
using Dr. DivX 2 for Mac OS)
•MP4: MP4V + MP4A (AAC) only support non-hinted MP4
•AVI audio codec: MP3, AC3, PCM, WMA, Ogg
Subtitles:
SUB (MicroDVD format), SRT (SubRIP format), SMI (SAMI
format), SSA (Sub Station Alpha format), Embedded Multiple
Subtitle support
Audio:
•MPEG-1 Layer 1 (MP1, MPA)
•MPEG-1 Layer 2 (MP2)
•MPEG-1 Layer 3 (MP3)
•Ogg Vorbigs (OGG)
•AC3 5.1 (AC3)
•Microsoft PCM Wave (WAV)
•Advance Audio Coding AAC, ADIF, ADTS (AAC)
•Apple MPEG4 AAC Audio (M4A)
•Microsoft Windows Media Audio version 1&2 (WMA, ASF)
•Microsoft Windows Media Audio Professional WMA Pro
(ASF)
Photo:
•JPG baseline and progressive up to 8 mega pixel
•GIF
•PNG
- 13 -

Supported USB
devices Mass Storage class devices using FAT12, FAT16 or
FAT32, including USB hard drives, card readers and
USB memory sticks.
UPnP Version v1.0
Output Interfaces Video NTSC/PAL:
•Composite Video
•S-Video
•Analogue Component Video up to 720p or 1080i
•SCART RGB (optional cable)
•VGA up to 1024x768 (optional cable)
Audio:
•Dual Stereo Analogue Audio
•SPDIF optical output
Power Supply External Power Adapter universal auto-switching (UL, cUL)
Input: AC 100-240V, 1.2A, 50-60Hz
Output: DC +12V/1A
FAQ
Q: My TV screen is blank and I can not see the IPTV-DMG main screen!
A: Make sure the cables are connected firmly and the TV is set to the proper (A/V)
channel. Turn on the IPTV-DMG and wait for about 10-20 seconds. If you still do not see
anything, press the TV Mode button on your remote control to change the video output
until you see the screen.
Q: I can not access the internet!
A: Make sure that the IPTV-DMG is connected to your network and that your internet
security is setup properly. Press the SETUP key and confirm the IP configuration and DNS
server. If the automatic function does not work, switch to manual mode and enter the IP
addresses by yourself. To access the internet, the DNS server needs to be accurate and
running.
Q: My file names and bookmarks are scrambled!
A: Go to the setup menu and change the encoding to your language.
- 14 -

Remote Control Key Functions
Item Button Browser Mode Playback Mode
1 Power Power OFF Power OFF
2 1 1 - .:/@ Go to 10%
3 2 2 - ABC Go to 20%
4 3 3 - DEF Go to 30%
5 4 4 - GHI Go to 40%
6 5 5 - JKL Go to 50%
7 6 6 - MNO Go to 60%
8 7 7 - PQRS Go to 70%
9 8 8 - TUV Go to 80%
10 9 9 - WXYZ Go to 90%
11 0 0 - Space Go to 0%
12 CLEAR Backspace N/A
13 SELECT Caps/Num N/A
14 TV MODE Toggle video output N/A
15 SETUP Go to setup page Go to setup page
16 MUTE Mute sound Mute sound
17 VOLUME Scroll up/down Volume +/-
18 UP Up Previous clip
19 DOWN Down Next clip
20 LEFT Left Rewind by %
21 RIGHT Right Forward by %
22 ENTER Enter/Select N/A
23 RETURN Return to previous screen N/A
24 MENU Tab (select next menu) N/A
25 A-B Go to home Go to home
26 PREV Photo page (MyHome) Previous clip
27 PLAY Select icon Play
28 NEXT Internet page (MyHome) Next clip
29 REPEAT Go to main screen N/A
30 REV Video page (MyHome) Rewind
31 STOP Stop download Stop playback
32 FWD Music page (MyHome) Forward
33 INFO Go to setup page Display file info
34 SLOW REV N/A N/A
35 PAUSE/STEP N/A Play/Pause
36 SLOW FWD N/A Slow motion (MPEG)
37 EDIT/PROGRAM Go to URL Go to by time search
38 TITLE N/A N/A
39 SUBTITLE N/A Subtitle encoding or OFF
40 AUDIO N/A Stereo/mono audio output
41 SHUFFLE Refresh Repeat mode
42 ANGLE/ROTATE N/A Rotate photo
43 SEARCH N/A N/A
44 ZOOM N/A Zoom mode (movie/photo)
- 15 -

About this Manual
This manual covers both the wired and wireless option for the IPTV-DMG. Images and
descriptions may therefore slightly vary between this manual and the actual product you
have.
© Copyright 2006 by GMG Inc. all Rights Reserved
The information contained in this manual is believed to be accurate and reliable. GMG Inc. assumes no
responsibility for any errors contained in this manual and reserves the right to make changes in the
specifications and/or design of this product without prior notice. The diagrams contained in this manual may
also not fully represent the product that you are using and are there for illustration purposes only. GMG Inc.
assumes no responsibility for any differences between the product mentioned in this manual and the product
you may have.
- 16 -
Table of contents
Popular Gateway manuals by other brands

SMC Networks
SMC Networks EZ Connect Commercial Cable Modem Gateway... Technical specifications

Nexo
Nexo FXS-128s user manual

CTS
CTS FWR5-3105SFP-CW-AC-DR Series manual

Panduit
Panduit ATLONA AT-VGW-HW-3 installation guide

Kodaro
Kodaro Niagara 4 installation guide

HOOC
HOOC Connect H LT Base REG quick start guide
