Garden Oasis SS-I-138-2NS/4 User manual

OWNER’S
MANUAL
Date of purchase: _____/ _____/ _____
Clayton 4PK
Bar Stools
Product code: D71 M80929
UPC code: 7-6945575880-4
1
Vendor Item: SS-I-138-2NS/4

PARTS
Read through all the instructions before beginning assembly. Unpack and identify all the parts.
Place them on a flat, non-abrasive surface. Assembly by two people is recommended.
A (8)
Stool Leg
B (16)
Crossbar
ACCESSORIES
Da (32 + 1 spare)
Screw
Db (16 + 1 spare)
Bolt
Dc (1)
Long Allen Wrench
Dd (1)
Assembly
Instructions Sheet
2
C (4)
Sling Seat
De (1)
Allen Wrench

ASSEMBLY INSTRUCTIONS
Lay the stool leg (A) on the ground. Attach
the crossbar (B) to the leg by inserting a
screw (Da) through the bracket on the
crossbar and into the leg (B) for each hole
(note: the drainage holes on the crossbar
need to face the ground after assembled).
Do not tighten. Repeat procedure for the
other 3 crossbars. See Fig. 1.
Place another leg (A) on a soft, flat surface
and attach the assembled body onto this leg.
Repeat step 1 for screws assembly. Tighten
screws in a cross pattern method until all
screws are securely tightened. See Fig. 2.
Place the sling seat upside down on a flat
non abrasive surface. Place the assembled legs
and crossbars (A&B) onto the bottom of sling
seat (C) with legs pointing up. Align holes of the
sling seat with holes of the legs. Insert a bolt (Db)
through the leg and into the sling seat for each
hole. Tighten all bolts so the sling fabric is evenly
taut. See Fig. 3.
Turn the stool over. Repeat procedure for the other
three stools.
Your serving stools are ready for use.
1
2
3
4
CARE INSTRUCTIONS
Wash with a mild solution of soap and water; rinse thoroughly. Dry completely. Do not use bleach or solvents.
Cover furniture with outdoor furniture covers when not in use.
3
Fig. 1
Fig. 2
Fig. 3
Made in CHINA
Distributed by Sears, Roebuck and Co., Hoffman Estates, IL 60179
See our extensive assortment of outdoor living products
on-line at www.sears.com and www.kmart.com
For questions or comments about product:
Call toll-free:
800-457-4652
Please refer to part numbers when reordering
