GPSMAP185 Sounder
Three-In-One Performance Packed In A Midsize Case
Split screen displays GPS/plotter and sounder data simultaneously.
Big, 4-level grayscale display measures 5.5" diagonally.
Exclusive See-ThruTM technology separates black fish returns from
thermoclines and structure.
Graphic whiteline display with Depth Controlled Gain (DCG™)
presents a clear image of bottom hardness, structure and thermoclines.
One-touch instant zoom rescales entire screen, while 2X and 4X
oversampling provides greater detail of the bottom.
200 KHz frequency fishfinder is transmitted at 400 watts RMS.
A built-in worldwide basemap is supplemented with micro G-chartTM
cartridges for detailed inland water and Navionics offshore cartography.
Outstanding saltwater sounder performance to 1200 feet.
The GARMIN GPSMAP 185 Sounder offers unique functionality to the
fisherman who wants it all. It boasts a generous display. A small footprint for
space-challenged installations. Powerful 12 parallel channel GPS perfor-
mance. Detailed digital chartplotting. And a 200 KHz sounder/fishfinder.
As for the Sounder, dual frequency operation lets you keep an eye on
both deep and shallow water. A variable zoom window shows details at the
touch of a button. And an exclusive underwater waypoint capability allows
you to store the position and depth of objects below the water’s surface.
GARMIN’s reputation as a navigation leader is evidenced in the GPSMAP
185 Sounder. Accurate 12 parallel channel GPS position information is dis-
played on a big built-in basemap. GARMIN micro G-chartTM cartridges give
you even greater map details for inland or offshore operations.
Despite all the capabilities of the GPSMAP 185 Sounder, it remains easy
to use. Uncluttered and intuitive, it has the distinct look and feel of a winner.

GPSMAP 185 SOUNDER
GPSMAP185 Sounder
M01-10078-000698
Depth Sounder Features
Display Options: Auto bottom tracking, auto ranging,
4 zoom levels, split screen feature,
and 3-level fish ID
Alarms: Fish and shallow/deep water
Physical
Size: 6.18"H x 6.30"W x 2.64"D
(157mm x 160mm x 67mm)
Weight: 28.8 oz. (.816 kg)
Display: 5.5" diagonal (141mm)
high-contrast, 4-level gray LCD
with backlighting (160 x 240 pixels)
Case: Fully gasketed, high-impact plastic alloy,
waterproof to IEC 529-IPX-7
Temp. Range: 5ºF to 158ºF (-15ºC to 70ºC)
Accessories
Standard: GPSMAP 185 Chartplotting Depth Sounder
Standard Transom-Mount Transducer**
Remote Antenna with 30' Cable
Power/Data Cable
Surface/Flush Mount Bracket with Knobs
User’s Manual
Quick Reference Guide
Optional: PC Kit
Micro G-chartTM Cartography Cartridges
Transducers in a Wide Variety of
Transom and Through-Hull Mounts
Specifications are preliminary and subject to change without notice.
* Subject to accuracy degradation to 100m 2DRMS under the United
States Department of Defense imposed Selective Availability Program.
** Also available without a transducer.
Navigation Features
Waypoints:
Total: 250 alphanumeric
Nearest: 9 (automatic)
Proximity: 9 (definable)
Routes: 20 reversible routes with
up to 30 waypoints each, plus
MOB and TracBackTM modes
Track Log: Approx. 2,000 points
Map Datums: 106
Coordinates: Lat/lon, UTM/UPS, plus
7 grids, including Maidenhead
Performance
GPS Receiver: Differential-ready 12 parallel
channel receiver tracks all
satellites in view
Depth Sounder:
Frequency: 200 KHz
Transmit Power: 400 watts (RMS)
3200 watts (peak to peak)
GPS Acquisition Times:
Warm: Approx. 15 seconds
Cold: Approx. 45 seconds
AutoLocateTM: Approx. 5 minutes
Update Rate: 1/second, continuous
Accuracy:
Position: 15 meters (49 feet) RMS*
1-5 meters (3-15 feet) RMS
with GARMIN GBR 21
DGPS receiver (optional)
Velocity: 0.1 knot RMS steady state
Dynamics: 6g’s
Interfaces: NMEA 0180, 0182, 0183 and
RTCM 104 DGPS corrections
Antenna: GA 28 Remote Marine Mount
with 30' cable
Plotter/Moving Map Features
Database: Built-in basemap to 64 nm
(32 nm U.S.) with coasts, rivers,
lakes, political boundaries, plus
major cities and highways
Data Cartridges: Micro G-chartTM cartridges with
inland water and Navionics
offshore cartography for
seamless, detailed mapping
and worldwide coverage
(optional)
Plotting Scales: 1/8 to 4096 nm with dedicated
push-button zoom control
Power
Source: 10-40 volts DC
Usage: 15 watts (max)
GARMIN International
1200 East 151st Street
Olathe, Kansas 66062, U.S.A.
913/397.8200 FAX [phone]
GARMIN (Europe) Ltd.
Unit 5, The Quadrangle, Abbey Park Industrial Estate
Romsey, SO51 9AQ, U.K.
44/1794.519944 FAX [phone]
GARMIN (Asia) Corporation
3rd Floor, No. 1, Lane 45, Pao-Hsing Road
Hsin Tien, Taipei, Taiwan
886/2.2917.3773 FAX [phone]
www.garmin.com
© 1998 GARMIN Corporation
