GPSMAP®67
Quick Start Manual

Getting Started
WARNING
See the Important Safety and Product
Information guide in the product box for
product warnings and other important
information.
GPSMAP 67 Device Overview
GNSS antenna
Status LED
Power button
Buttons
USB port (under weather cap)
Flashlight
microSD® card slot (under weather
cap)
Mounting spine
Charging the GPSMAP 67 Device
NOTICE
To prevent corrosion, thoroughly dry
the USB port, the weather cap, and
the surrounding area before charging or
connecting to a computer.
NOTE: The device does not charge when
it is outside the approved temperature
range (page10).
1Lift the weather cap .
2 Quick Start Manual

2Plug the small end of the power
cable into the charging port on the
device.
3Plug the other end of the power cable
into a compatible AC power adapter.
4Plug the AC power adapter into a
standard wall outlet.
The device displays the current
battery charge level.
Turning On the Device
Press and hold .
Buttons
FIND
Select to open the search
menu.
Hold to mark your current
location as a man overboard
(MOB) location and activate
navigation.
MARK Select to save your current
location as a waypoint.
QUIT
Select to cancel or return to
the previous menu or page.
Select to scroll through the
main pages.
Quick Start Manual 3

ENTER
Select to choose options and
acknowledge messages.
Select to control the current
activity recording (from the
Map, Compass, Altimeter, and
Trip Computer pages).
MENU
Select to open the options
menu for the page that is
currently open.
Select twice to open the main
menu (from any page).
PAGE Select to scroll through the
main pages.
Select , , , or to select
menu options and move the
map cursor.
Select to zoom in on the map.
Select to zoom out on the map.
Adjusting the Backlight
1Select to open the status page.
2Use and to adjust the
brightness.
Acquiring Satellite Signals
It may take 30 to 60 seconds to acquire
satellite signals.
1Go outdoors to an open area.
2If necessary, turn on the device.
3Wait while the device searches for
satellites.
flashes while the device determines
your location.
in the status bar shows the
satellite signal strength.
When the device acquires satellite
signals, it automatically starts recording
your path as an activity.
GPS and Other Satellite Systems
Using GPSand another satellite system
together offers increased performance
in challenging environments and faster
position acquisition than using GPS only.
However, using multiple systems can
reduce battery life more quickly than
using GPS only.
Your device can use these Global
Navigation Satellite Systems (GNSS).
Multi-band systems use multiple
frequency bands and allow for
more consistent track logs, improved
positioning, improved multi-path errors,
and fewer atmospheric errors when using
the device in challenging environments.
4 Quick Start Manual

GPS: A satellite constellation built by the
United States.
GPS multi-band: A satellite constellation
built by the United States, using the
enhanced L5 signal.
GLONASS: A satellite constellation built
by Russia.
GALILEO: A satellite constellation built by
the European Space Agency.
GALILEO multi-band: A satellite
constellation built by the European
Space Agency, using the enhanced L5
signal.
QZSS multi-band: A satellite
constellation built by Japan, using the
enhanced L5 signal.
IRNSS (NavIC): A satellite constellation
built by India, using the enhanced L5
signal.
Turning On Expedition Mode
You can use expedition mode to prolong
the battery life. In expedition mode, the
screen shuts off, the device enters low
power mode, and the device collects
fewer GPS track points.
1Select Setup > Expedition Mode.
2Select an option:
• To enable the device to prompt
you to turn on expedition mode
when you turn off the device,
select Prompted.
• To automatically turn on
expedition mode after two
minutes of inactivity, select Auto.
• To never turn on expedition mode,
select Never.
In expedition mode, the green LED
flashes occasionally.
Connected Features
Connected features are available for
your GPSMAP 67 device when you
connect the device to a wireless network
or a compatible smartphone using
Bluetooth® technology. Some features
require you to install the Garmin Connect™
app or Garmin Explore™ app on your
smartphone. Go to garmin.com/apps for
more information.
Bluetooth sensors: Allows you to connect
Bluetooth compatible sensors, such
as a heart rate monitor.
Connect IQ™: Allows you to extend your
device features with widgets, data
fields, and apps using the Connect IQ
app.
Quick Start Manual 5

EPO Downloads: Allows you to download
an extended prediction orbit file to
quickly locate GPS satellites and
reduce the time it takes to get
an initial GPS fix using the Garmin
Connect app or when connected to a
Wi‑Fi® network.
BirdsEye imagery: Allows you to
download BirdsEye Satellite Imagery
directly to your device when
connected to a Wi‑Fi network.
Garmin Explore: The Garmin Explore app
syncs and shares waypoints, tracks,
and routes with your device. You
can also download maps to your
smartphone for offline access.
Live Geocache Data: Provides paid or
subscription-free services to view live
geocache data from www.geocaching
.com using the Garmin Connect app
or when connected to a Wi‑Fi network.
LiveTrack: Allows friends and family to
follow your activities in real time. You
can invite followers using email or
social media, allowing them to view
your live data on a Garmin Connect
tracking page.
Phone notifications: Displays phone
notifications and messages on your
GPSMAP 67 device using the Garmin
Connect app.
Software Updates: Allows you to receive
updates for your device software
using the Garmin Connect app or
when connected to a Wi‑Fi network.
Active Weather: Allows you to view
current weather conditions and
weather forecasts using the Garmin
Connect app or when connected to a
Wi‑Fi network.
Pairing a Smartphone with Your Device
1Bring your compatible smartphone
within 10m (33ft.) of your device.
2From the main menu on your device,
select Setup > Bluetooth.
3On your compatible smartphone,
enable Bluetooth technology, and
open the Garmin Connect or Garmin
Explore app.
4From the app, select the devices
option and follow the on-screen
instructions to pair your device.
Navigation
Waypoints
Waypoints are locations you record and
store in the device. Waypoints can mark
where you are, where you are going,
6 Quick Start Manual

or where you have been. You can add
details about the location, such as name,
elevation, and depth.
Creating a Waypoint
You can save your current location as a
waypoint.
1Select MARK.
2If necessary, select a field to make
changes to the waypoint.
3Select Save.
Navigating to a Waypoint
1Select FIND > Waypoints.
2Select a waypoint.
3Select Go.
By default, your route to the waypoint
appears as a straight, colored line on
the map.
Routes
A route is a sequence of waypoints or
locations that leads you to your final
destination.
Creating a Route
1Select Route Planner > Create Route
> Select First Point.
2Select a category.
3Select the first point in the route.
4Select Use.
5Select Select Next Point to add
additional points to the route.
6Select QUIT to save the route.
Navigating a Saved Route
1Select FIND > Routes.
2Select a route.
3Select Go.
By default, your route appears as a
straight, colored line on the map.
Recordings
Your device records your path as an
activity. Activities contain information
about points along your recorded path,
including time, location, and elevation for
each point.
Viewing the Current Activity
By default, the device automatically
starts recording your path as an activity
when it is turned on and has acquired
satellite signals. You can pause and start
recording manually.
1Select Recording Controls.
2Select and to view an option:
• To control the current activity
recording, select .
Quick Start Manual 7

• To view data fields for the activity,
select .
• To view the current activity on the
map, select .
• To view the elevation plot for the
current activity, select .
Map
represents your location on the map.
As you travel, moves and displays
your path. Depending on your zoom level,
waypoint names and symbols may appear
on the map. You can zoom in on the
map to see more detail. When you are
navigating to a destination, your route is
marked with a colored line on the map.
Changing the Map Orientation
1From the map, select MENU.
2Select Map Setup > Orientation.
3Select an option:
• Select North Up to show north at
the top of the page.
• Select Track Up to show your
current direction of travel at the
top of the page.
• Select Automotive Mode to show
an automotive perspective with
the direction of travel at the top.
Compass
When navigating, points to your
destination, regardless of the direction
you are moving. When points toward
the top of the electronic compass,
you are traveling directly toward your
destination. If points any other
direction, turn until it points toward the
top of the compass.
Calibrating the Compass
Before you can calibrate the electronic
compass, you must be outdoors, away
from objects that influence magnetic
fields, such as cars, buildings, or
overhead power lines.
The device has a 3-axis electronic
compass. You should calibrate the
compass after moving long distances or
experiencing temperature changes.
1From the compass, select MENU.
2Select Calibrate Compass > Start.
3Follow the on-screen instructions.
Trip Computer
The trip computer displays your current
speed, average speed, trip odometer,
and other helpful statistics. You can
customize the trip computer layout,
dashboard, and data fields.
8 Quick Start Manual

Device Information
Product Updates
On your computer, install Garmin
Express™ (www.garmin.com/express). On
your phone, install the Garmin Explore
app.
This provides easy access to these
services for Garmin® devices:
• Software updates
• Map updates
• Data uploads to Garmin Explore
• Product registration
Setting Up Garmin Express
1Connect the device to your computer
using a USBcable.
2Go to garmin.com/express.
3Follow the on-screen instructions.
Installing a Memory Card
You can install a microSD memory card,
up to 32 GB, for additional storage or
pre-loaded maps.
1Lift the weather cap on the side of the
device .
2Insert the memory card with the
gold contacts facing the front of the
device.
Attaching the Carabiner Clip
1Position the carabiner clip in the
slots on the mounting spine of the
device.
Quick Start Manual 9

2Slide the carabiner clip up until it
locks in place.
Removing the Carabiner Clip
Lift up on the bottom of the carabiner
clip, and slide the carabiner clip off
the mounting spine.
Specifications
Operating temper‐
ature range
From -20° to 60°C
(from -4° to 140°F)
Charging tempera‐
ture range
From 0° to 40°C
(from 32° to 104°F)
Compass-safe
distance 17.5cm (7in.)
Wireless
frequency/
protocol
2.4GHz @ 14.9dBm
nominal
Getting More Information
You can find more information about this
product on the Garmin website.
• Go to support.garmin.com for
additional manuals, articles, and
software updates.
• Go to buy.garmin.com, or contact
your Garmin dealer for information
about optional accessories and
replacement parts.
Getting the Owner's Manual
The owner's manual includes instructions
for using device features and accessing
regulatory information.
Go to garmin.com/manuals
/gpsmap67.
10 Quick Start Manual

support.garmin.com
© 2022 Garmin Ltd. or its subsidiaries
Garmin®, the Garmin logo, ANT+®, and GPSMAP® are trademarks of Garmin Ltd. or its subsidiaries, registered in the USA
and other countries. Connect IQ™, Garmin Connect™, Garmin Explore™, and Garmin Express™ are trademarks of Garmin
Ltd. or its subsidiaries. These trademarks may not be used without the express permission of Garmin.
The BLUETOOTH® word mark and logos are owned by the Bluetooth SIG, Inc. and any use of such marks by Garmin
is under license. microSD® and the microSDHC logo are trademarks of SD-3C, LLC. Wi‑Fi® is a registered mark of Wi-Fi
Alliance Corporation. Other trademarks and trade names are those of their respective owners.
Printed in Taiwan
July 2022
190-02336-4N_0A
