Garmin StreetPilot GPS User manual

owner’s
manual
and
reference
guide
12 parallel channel receiver
StreetPilotTM GPS

© 1999-2000 GARMIN Corporation
GARMIN International, Inc.
1200 E 151
st
Street, Olathe, Kansas 66062 U.S.A.
Tel. [phone] or 800/800.1020
Fax. [phone]
GARMIN (Europe) Ltd.
Unit 5, The Quadrangle, Abbey Park Industrial Estate,Romsey, SO51 9AQ U.K.
Tel. [phone]
Fax.[phone]
GARMIN (Asia) Corp.
No. 68, Jangshu 2nd Road, Shijr, Taipei County, Taiwan
Tel. [phone]
Fax. [phone]
All rights reserved. Except as expressly provided herein, no part of this manual may be reproduced, copied, transmitted, disseminated, downloaded or
stored in any storage medium, for any purpose without prior written consent of GARMIN Corporation. GARMIN Corporation hereby grants permission to
download a single copy of this manual onto a hard drive or other electronic storage medium to be viewed for personal use, provided that such electronic or
printed copy of this manual contains the complete text of this copyright notice and provided further that any unauthorized commercial distribution of this
manual is strictly prohibited.
Information in this manual is subject to change without notice. GARMIN Corporation reserves the right to change or improve its products and to make
changes in the content without obligation to notify any person or organization of such changes. Visit the GARMIN website for downloadable upgrades to the
operating software and the Owner’s Manual. The website also contains information concerning the use and operation of other GARMIN products.
Website address: www.garmin.com
GARMIN
®
, AutoLocate
®
, and TracBack
®
are registered trademarks, StreetPilot
TM
, MapSource
TM
and MetroGuide
TM
are trademarks of GARMIN Corpora-
tion and may not be used without the express permission of GARMIN Corporation.
June 2000 Part Number 190-00120-00 Rev. C Printed in Taiwan

Introduction
i
About This Manual
Warnings, Notes and Additional Information
Throughout the manual you will find
statements containing important information
about using the StreetPilot.
Warnings - provide you with information
about safe use of the StreetPilot.
Notes - provide you with information for
better understanding and efficient use of the
StreetPilot features.
Additional Information - provides you with
easy methods of operation once you have
become familiar with the StreetPilot’s operating
features.
Thank you for choosing the GARMIN StreetPilot. The StreetPilot represents GARMIN’s
continuing commitment to provide quality navigation information in a versatile and user-friendly
design you will enjoy for years. To get the most value from your new GPS, please take time to read
through this owner’s manual in order to understand the operating features of the StreetPilot. This
manual is organized into four sections for your convenience.
The Introduction section provides FCC and safety information and the Table of Contents.
The Quick-Start section introduces you to the basic features of the unit and provides a
quick-start orientation to the StreetPilot.
The Reference section provides details about the complete feature setup of the StreetPilot by topic.
The Appendices section contains information on items such as accessories, specifications, a
trouble shooting guide and an index by subject.
Before getting started with your GPS, check to see that your GARMIN StreetPilot package
includes the following items. If you are missing any parts, please contact your GARMIN dealer
immediately.
Standard Package:
!StreetPilot Unit with Detachable Antenna
!Six AA Batteries
!Owner’s Manual
!Quick Start Guide
!Dash Mount Kit with Installation Instructions
!Data transfer Cable
SECTION 1

ii
Introduction
Cautions and Warnings
CAUTION: The Global Positioning System (GPS) is operated by the government of the United
States, which is solely responsible for its accuracy and maintenance. The system is subject to changes
that could affect the accuracy and performance of all GPS equipment. Although the StreetPilot is a
precision NAVigation AID (NAVAID), any NAVAID can be misused or misinterpreted and, therefore,
become unsafe.
WARNING: For use in vehicles, it is the sole responsibility of the owner/operator of the StreetPilot
to place and secure the GPS unit so that it will not interfere with the vehicle operating controls and
safety devices, obstruct the driver’s view of driving conditions, or cause damage or personal injury in
the event of an accident. Do not mount the StreetPilot over airbag panels or in the field of airbag
deployment. Airbags expand with a rapid force that can propel objects in their path towards the vehicle
driver or passengers causing possible injury. Refer to airbag safety precautions contained in the vehicle
owner’s manual. Do not mount the StreetPilot in a place where the driver or passengers are likely to
impact it in an accident or collision. The mounting hardware provided by GARMIN is not warranted
against collision damage or the consequences thereof.
WARNING: When used in vehicles, it is the sole responsibility of the driver of the vehicle to
operate the vehicle in a safe manner, maintain full surveillance of all driving conditions at all times, and
not become distracted by the StreetPilot to the exclusion of safe driving practices. It is unsafe to operate
the controls of the StreetPilot while you are driving. Failure by the driver of a vehicle equipped with a
StreetPilot to pay full attention to operation of the vehicle and road conditions while the vehicle is in
motion could result in an accident or collision with property damage and personal injury.
NOTE: The StreetPilot Bean Bag Dash Mount
Accessory is designed to stabilize the unit during normal
operation of a vehicle. It will not, however, secure the unit
to the vehicle dash in the event of emergency braking or
sharp turns. If you desire the added safety of a secure
mount, use the StreetPilot Dash Mount Bracket and
permanent adhesive supplied with the bracket.
Do Not Mount Over
Airbag Panels Do Not Mount
in Front of an
Airbag Field
of Deployment
Do Not Mount Where Drivers
Field of Vision is Blocked
Do Not Place Unsecured
on the Vehicle Dash

Introduction
iii
Cautions
MAP DATA INFORMATION: One of the goals of GARMIN is to provide customers with the most
complete and accurate cartography that is available to us at a reasonable cost. We use a combination of
governmental and private data sources, which we identify as required in product literature and
copyright messages displayed to the consumer. Virtually all data sources contain inaccurate or incom-
plete data to some degree. This is particularly true outside the United States, where complete and
accurate digital data is either not available or prohibitively expensive.
CAUTION: IT IS THE USER’S RESPONSIBILITY TO USE THIS PRODUCT PRUDENTLY. THIS
PRODUCT IS INTENDED TO BE USED ONLY AS A TRAVEL AID AND MUST NOT BE USED FOR
ANY PURPOSE REQUIRING PRECISE MEASUREMENT OF DIRECTION, DISTANCE, LOCATION,
OR TOPOGRAPHY. THIS PRODUCT SHOULD NOT BE USED TO DETERMINE GROUND PROXIM-
ITY FOR AIRCRAFT NAVIGATION
Software License Agreement
BY USING THE STREETPILOT, YOU AGREE TO BE BOUND BY THE TERMS AND CONDI-
TIONS OF THE FOLLOWING SOFTWARE LICENSE AGREEMENT. PLEASE READ THIS AGREE-
MENT CAREFULLY.
GARMIN Corporation (“GARMIN”) grants you a limited license to use the software embedded in
this device (the “Software”) in binary executable form in the normal operation of the product. Title,
ownership rights and intellectual property rights in and to the Software remain in GARMIN.
You acknowledged that the Software is the property of GARMIN and is protected under the
United States of America copyright laws and international copyright treaties. You further acknowledge
that the structure, organization and code of the Software are valuable trade secrets of GARMIN and that
the Software in source code form remains a valuable trade secret of GARMIN. You agree not to
decompile, disassemble, modify, reverse assemble, reverse engineer or reduce to human readable form
the Software or any part thereof or create any derivative works based on the Software.
You agree not to export or re-export the Software to any country in violation of the export
control laws of the United States of America.

iv
Introduction
FCC Compliance
The GARMIN StreetPilot has been tested to comply with FCC Standards for home and office
use. It complies with Part 15 of the Federal Communications Commission (FCC) limits for Class B
digital devices. This equipment generates, uses, and can radiate radio frequency (RF) energy and, if
not installed and used in accordance with instructions, may cause harmful interference to radio
communications.
There is no guarantee that interference will not occur in a particular installation. If this device
does cause harmful interference to other equipment, which can be determined by turning this device
off and on, you are encouraged to try and correct the interference by increasing the separation
between this device and other equipment or reorienting or relocating the receiving antenna.
Consult an authorized dealer or other qualified service technician for additional help if these
remedies do not correct the problem. Operation is subject to the following conditions: (1) This device
cannot cause harmful interference, and (2) this device must accept any interference received, including
interference that may cause undesired operation.
Specifically when operating inside an automobile, interference is possible from AM/FM radios,
cassette or CD players, or mobile telephones, among other electronic devices. If you suspect the unit is
experiencing harmful interference (as evidenced by poor satellite reception), try relocating the
StreetPilot in the automobile to remedy the situation.
The StreetPilot does not contain any user-serviceable parts. Repairs should only be made by an
authorized GARMIN service center. Unauthorized repairs or modifications could void your warranty
and your authority to operate this device under Part 15 regulations.

Introduction
v
Limited Warranty GARMIN Corporation warrants this product to be free from defects in materials and manufac-
ture for one year from the date of purchase. GARMIN will, at its sole option, repair or replace any
components that fail in normal use. Such repairs or replacement will be made at no charge to the
customer for parts or labor. The customer is, however, responsible for any transportation costs. This
warranty does not cover failures due to abuse, misuse, accident or unauthorized alteration or repairs.
THE WARRANTIES AND REMEDIES CONTAINED HEREIN ARE EXCLUSIVE AND IN LIEU
OF ALL OTHER WARRANTIES EXPRESS OR IMPLIED OR STATUTORY, INCLUDING ANY LIABIL-
ITY ARISING UNDER ANY WARRANTY OF MERCHANTABILITY OR FITNESS FOR A PARTICULAR
PURPOSE, STATUTORY OR OTHERWISE. THIS WARRANTY GIVES YOU SPECIFIC LEGAL
RIGHTS, WHICH MAY VARY FROM STATE TO STATE.
IN NO EVENT SHALL GARMIN BE LIABLE FOR ANY INCIDENTAL, SPECIAL, INDIRECT OR
CONSEQUENTIAL DAMAGES, WHETHER RESULTING FROM THE USE, MISUSE, OR INABILITY
TO USE THIS PRODUCT OR FROM DEFECTS IN THE PRODUCT. SOME STATES DO NOT
ALLOW THE EXCLUSION OF INCIDENTAL OR CONSEQUENTIAL DAMAGES, SO THE ABOVE
LIMITATIONS MAY NOT APPLY TO YOU.
To obtain warranty service, call the GARMIN Customer Service department (913-397-8200) for
a returned merchandise tracking number. The unit should be securely packaged with the tracking
number clearly marked on the outside of the package and sent freight prepaid and insured to a
GARMIN warranty service station. A copy of the original sales receipt is required as the proof of
purchase for warranty repairs. GARMIN retains the exclusive right to repair or replace the unit or
software or offer a full refund of the purchase price at its sole discretion. SUCH REMEDY SHALL BE
YOUR SOLE AND EXCLUSIVE REMEDY FOR ANY BREACH OF WARRANTY.

vi
Introduction
Table of Contents
Section One - INTRODUCTION
About This Manual..............................i
Cautions & Warnings............................ii
Software License Agreement...............iii
FCC Compliance.................................iv
Limited Warranty................................v
“How To” Index.................................vii
StreetPilot Unit...............................viii
Section Two - QUICK-START
Battery/Data Card Installation...............1
Keypad Usage...................................2
Turning the Unit On and Off..............3
Screen Brightness/Contrast.............4
Dash Mounting and External Power....5
Finding Your Location.....................6
Using the Simulator ..............................8
Main Page Sequence............................9
Map Zooming and Panning.................10
The Trip Computer OPTION Key.......11
Making Keypad Entries.....................12
Using Find and Goto.........................14
Finding HighwayExits..........45
Finding a Point of Interest......46
Finding an Address................48
Finding an Intersection..........51
Section Three - REFERENCE
The Map Page...................................15
Zooming.............................16
Driving Status.....................17
Navigation Information..........17
Map Panning.......................18
Personal Waypoints..............19
Goto a Waypoint....................20
Map Page Options...............21
Customizing the Map ............22
The Dashboard Page..........................26
The Trip Computer............27
Satellite Status.....................30
System Setup....................................32
‘General’ File Tab.................34
‘Alarms’ File Tab..................35
‘Time’ File Tab.....................36
‘Comm Port’ File Tab...........37
Marking Your Location ....................39
Find Functions.................................41
Finding a City.....................41
Finding a Personal Waypoint..44
Deleting Personal Waypoints..45
Navigating on a Direct Goto............52
Routes.................................................54
Creating a Route....................54
Editing an Existing Route.......56
Selecting or Deleting a Route.58
Copying a Route....................59
Driving on a Route..............................60
Section Four - APPENDICES
AAccessories....................................63
BSpecifications................................65
CWiring/Interfaces.............................67
DMaintenance.................................69
EMessages...............................70
FNavigation Terms.............................71
GUTC Offset Tables...........................72
HIndex.........................................73

Introduction
vii
“How To” Index
The list below is provided to help you quickly find some of the more important
procedures you will use on your new StreetPilot.
TO DO THIS: SEE PAGE(S):
Access the System Setup Menu..........................................................................................................32
Adjust screen contrast or backlighting..................................................................................................4
Change the displayed time...............................................................................................................12
Change the Map Page display...............................................................................................................20
Create and use a route......................................................................................................54
Find an address or intersection.........................................................................................................48-51
Find nearest cities or waypoints.....................................................................................14, 41-44
Initialize the GPS receiver (first time use)....................................................................................................16
Install batteries.........................................................................................................................1
Learn about the Map Page...................................................................................................................15-25
Learn how to operate the unit’s function keys.......................................................................................2-12
Load Map Data Cards.......................................................................................................................................1
Mark your present location as a waypoint........................................................................39
Pan using the map arrow..........................................................................................10, 18
Select a destination (Goto)....................................................................................................52
Turn the unit on or off......................................................................................................................3
Zoom in or out on the Map Page......................................................................................................10-16

viii
Introduction
StreetPilot Unit LCD Display
4-level Grayscale Display
with Backlighting
(Map Page shown)
Compartment Door
Insert AA Batteries and optional
Map Data Cards here.
Antenna
Rotate upright for best
satellite reception
Keypad
Refer to Page 2 for
Key descriptions

Quick-Start
1
Battery/Map Card
Installation
Battery/Map Data Cartridge Installation
The StreetPilot operates on six (6) AA batteries, which are installed in the left end of the unit, as
viewed from the front. Alkaline, rechargeable NiCad, or Lithium batteries may be used. For extended
operation, use the cigarette lighter adapter to conserve batteries. The on-screen battery level indicator
may be calibrated for alkaline or NiCad batteries, but will not be totally accurate when using Lithium
batteries.
To install batteries and a map data card:
1. Lift up the metal D-ring at the end of the unit rotating ¼ turn anticlockwise to open the
compartment door.
2. Install the batteries (picture at right). It is very important to install ALL batteries with the proper
polarity, positive (+) and negative (-) orientation, as indicated by the markings molded into the
rubber base of the unit and inside the battery compartment door. Do not mix new batteries with
used batteries. Do not mix Alkaline with Lithium or NiCad rechargeable batteries.
3. If you are using an optional Map Data Card with detailed map data or if you plan to
transfer map data from a MapSource®CD-ROM, plug a blank card into the slot next to
the battery compartment, with the label facing toward the front of the StreetPilot (picture at right).
4. Close the battery compartment door and lock in place by turning the D-ring ¼ turn clockwise,
then return the ring to the flush position.
Battery life may vary due to a variety of factors, including ambient temperature and use of
backlighting. You may find that Lithium batteries provide longer life in colder conditions. Data is
retained in memory by an internal Lithium battery when the AA batteries are removed.
Refer to Appendix A for detailed information about MapSource
TM
CD-ROM’s and Data Cards.
Warning
Improper battery installation may cause
personal injury or property damage and/or
battery leakage.
Caution
Make certain the connector end of the Map
Data Card is inserted into the cartridge slot,
NOT the extractor handle end. Improper
installation can result in internal damage to
your StreetPilot Unit. When properly inserted,
the cartridge will protrude slightly from the slot
(not flush).
Compartment Door
Map Data
Card
AA Batteries
SECTION 2

2
Quick-Start
Keypad Usage The POWER Key
Turns the unit on and off. A momentary press while the power is on activates the backlight/contrast
adjustment window. Press and hold to turn the StreetPilot off.
The PAGE Key
Changes between the main pages and returns the display from an option window back to a main page.
The QUIT Key
Returns the display to a previous page. When entering data, restores the previous value (cancels data entry).
The ENTER Key
Confirms a highlighted menu option. When entering data, it allows you to initiate entry, and then to
accept the selected value(s). It also marks the location of the panning arrow on the Map Page.
The ROCKER Keypad
Used to select (highlight) menu options and enter data. Also controls movement of cursor on the Map Page.
The Zoom OUT Key
Adjusts the map scale to show a larger area with less detail.
The Zoom IN Key
Adjusts the map scale to show a smaller area with more detail.
The FIND Key
Searches database for nearby Cities, Interstate Exits, and Personal Waypoints. If optional MetroGuide
®
Map Data is installed, it also searches for Points of Interest, Addresses, or Intersections. Allows listed
items to be viewed on a map or selected as a destination.
The Option Key
Displays a menu of available options for the current page. Press twice to display System Setup options.
The Route Key
Used to create a new route or edit an existing route. Also provides a selection to start or stop navigating a route.
The MARK Key
Captures your present location and saves it as a Personal Waypoint.
POWER Key
PAGE Key
QUIT Key ENTER Key
FIND Key
IN Key
OPTION Key
ROUTE Key
MARK Key
OUT Key ROCKER
Keypad

Quick-Start
3
Turning the Unit On and Off
Turning the StreetPilot On and Off
To turn the StreetPilot on:
1. Press and hold the red POWER key until the power tone sounds.
2. The Title Page will be displayed for a few seconds while the unit conducts a self-test (top right
picture).
3. If there is an optional Map Data Card installed in the StreetPilot, a page showing the
Mapping Region and the effective date is displayed on the screen (bottom right picture).
Press the ENTER key to acknowledge this page.
4. Once the self-test is complete, a warning page is displayed. Read the warning and press the
ENTER key to acknowledge it.
To turn the StreetPilot off:
Press and hold the red POWER key until the screen goes blank.
Title Page
Map Data Page

4
Quick-Start
Screen Brightness/Contrast Adjusting Screen Brightness and Contrast
The StreetPilot screen lighting may set to a variety of levels for different lighting conditions and
personal preferences.
To adjust the screen brightness:
1. Press the POWER key for a moment. A window appears on the screen with a brightness control
and a Contrast control (picture at left).
2. Press the UP or DOWN areas of the ROCKER keypad to adjust the screen brighter or dimmer as
desired.
Contrast allows you to adjust the screen for optimum viewing in all lighting conditions. Moving
the control to the left causes the screen to appear more faint, while moving the control to the right
causes all areas of the screen (including pixels that are intended to be off) to appear darker. When
operating the StreetPilot at extreme temperatures, you may find that minor adjustments are needed to
obtain the best screen clarity.
To adjust the screen contrast:
1. Press the POWER key for a moment.
2. Press the UP or DOWN areas of the ROCKER keypad to adjust the screen contrast lighter or
darker as desired.
Screen Brightness/Contrast Adjustment
Additional Information
After adjusting the screen brightness or contrast, you may press the PAGE, QUIT, or ENTER key
to remove the screen adjustment window immediately.

Quick-Start
5
Dash Mounting and
External Power Connection
Your StreetPilot is designed to be portable, allowing you to easily transport the unit from vehicle
to vehicle or take it with you once you reach your destination. A Dash Mount Kit consisting of a
mounting bracket, mounting base, required hardware and adhesive pads is included in the StreetPilot
package. This provides a semi-permanent method of installing the unit at the best viewing location for
the driver or passenger(s). The dash mount bracket may be either permanently or temporarily
mounted using the included adhesive materials. Follow instructions for installing the mounting
bracket on the StreetPilot as explained in the instruction sheet provided with the Dash Mount Kit
which also includes specific instructions for installation of all kit components. General instructions are
included here for your convenience.
To install the cigarette lighter adapter, locate the connector on the rear of the StreetPilot unit
(behind the rubber weather cap). The connector is “keyed” with a notch located between two pins.
Mate the plug on the cigarette lighter adapter to this connector by aligning the notches and pushing
the plug into the connector until fully seated (picture at right). Use care when routing the adapter
cable being certain that it does not interfere with vehicle operation in any way.
Carefully choose the placement
of the base on the dash and
install using either the temporary
or permanent adhesive.
Slide the StreetPilot and
mounting bracket into the
base until it snaps into
place.
Slide the locking lever to the right to lock
the unit, preventing it from sliding off
the base.
To remove the unit from the base, slide the
lever to the left, depress
the release tab, slide the unit to
the right, and lift from the base.
Cigarette
Lighter
Adapter
Rubber
Weather
Cap

6
Quick-Start
Finding Your Location Finding Your Location
The first time you use your StreetPilot to navigate, take it outside or properly mount it on the
dashboard of a vehicle in an open area with a clear view of the sky. Make certain the antenna is pointing
up. The StreetPilot also has the option of using a Simulator Mode which does not require reception of
GPS satellite signals. Refer to page 8.
When stationary, your Street Pilot should be able to calculate your position within five (5)
minutes after being turned on with a clear view of the sky.
The Global Positioning System (GPS) is a system of 24 satellites that circle the Earth twice a day
in a very precise orbit and transmit information to Earth. The StreetPilot must continuously receive
signals from at least three of these satellites to calculate your location and track your movement. At
times, additional satellites may be needed to determine your location.
Your GPS receiver can only receive signals from satellites which are above the horizon, so it
needs to know what satellites to look for at any given time. In order to determine which satellites are
above the horizon, your GPS needs to either be told its general location (“initialized”) or given the
opportunity to find itself. Once you initialize the unit to a location, it will typically compute a position
within a few minutes.
Initialization is only necessary under the following conditions:
!The first time you use your StreetPilot (new from the factory).
!After the StreetPilot has been moved more than 500 miles (with the power off) since the
last time you used it.
!If the StreetPilot’s memory has been cleared and all internally stored data has been lost.
Once the StreetPilot has calculated your location, you will have anywhere from three to 12
satellites in view. The receiver will then continuously select the best satellites in view to update your location.

Quick-Start
7
If the StreetPilot is unable to calculate your location after a few minutes:
1. A ‘Poor Satellite Reception’ box appears on the screen (top right picture).
2. If you are indoors, or would otherwise like to simulate GPS location and motion, use the
ROCKER keypad to highlight Start Simulator and press the ENTER key. The Simulator Mode
starts, and the StreetPilot returns to the page it was showing beforehand.
If the StreetPilot is brand new, or if the StreetPilot unit has been moved hundreds of miles since
the last time it tracked a GPS location, use the ROCKER keypad to highlight Set New
Location and press the ENTER key.
If neither of the above applies, and you would like the StreetPilot to continue looking for GPS
satellites, use the ROCKER keypad to highlight Continue Acquiring and press the ENTER key.
The StreetPilot will return to the page is was showing beforehand.
3. If you chose Set New Location, a new box appears asking what method you would like to use
for aiding the StreetPilot in determining your location.
4. If you know the general area of the continent where you are located, you can speed up the
calculation of your location by pointing to that area on a map. Use the ROCKER keypad to
highlight Use Map (top right picture) and press the ENTER key.
Otherwise, use the ROCKER keypad to select AutoLocate and press the ENTER key. The
StreetPilot will determine where you are located. This process is fully automatic and under
normal circumstances will calculate your position in 3-5 minutes when the unit has a good view
of the sky and is stationary.
Using the Map to Set Location
5. If you chose Use Map, a continental map is displayed with an arrow pointer on it (lower right
picture). Use the ROCKER keypad to move the arrow pointer to your approximate location and
press the ENTER key. Remember, you do not need to be exact. The StreetPilot only needs an idea
where you are within a few hundred miles.
Choosing ‘Use Map’
Finding Your Location

8
Quick-Start
You can start the Simulator Mode if you are indoors where the StreetPilot is unable to receive
signals from GPS satellites. It is useful to do this when planning a trip or finding cities, and (if using
MetroGuide Map Data) addresses, intersections, or businesses.
To start the Simulator Mode:
1. Press the OPTION key twice. The StreetPilot displays the System Setup menu. The ‘General’ file
tab should be displayed, and the cursor should be on the ‘Simulator’ field. If not, use the
ROCKER keypad to select the ‘Simulator’ field (see left picture).
2. Press the ENTER key and use the ROCKER keypad to select On (see left picture).
3. Press the ENTER key again to start the Simulator Mode.
4. Press the PAGE key or QUIT key to return to the page the StreetPilot was previously displaying.
Simulator “On” Selection
Using the Simulator

Quick-Start
9
Main Page Sequence
Road Sign Page (If Navigating)
Dashboard Page
Map Page
QUIT
PAGE
The StreetPilot features two main pages, the Map Page and the Dashboard Page. Press the
PAGE or QUIT key to switch back and forth between the two main pages.
If the StreetPilot is navigating to a destination, there is a third page called the Road Sign Page.
The diagram below shows the relationship between the main pages when this is the case. You could
say that the Road Sign Page is inserted “between” the Map Page and the Dashboard Page while
navigating to a destination.

10
Quick-Start
Map Zooming and Panning
Small Area - More Detail
Large Area - Less Detail
Once the StreetPilot calculates your location, you may find it enjoyable just to view the Map Page
and watch your movement along roads and streets. There will be time later to learn about the ‘Find’ and
‘Route’ functions.
If you are not already looking at the Map Page, press the PAGE key until the map is shown on
the screen (top left picture). If the StreetPilot is still trying to determine your position, there will be a
flashing question mark (?) in the center of the map . Otherwise, the StreetPilot is ready to follow as you
drive.
Now, take time to experiment with the Zoom IN and OUT keys. Notice that the further you
zoom in, the more map features that are shown, to the point where every street in the memory is
displayed. If you zoom out to some of the larger views of the map, it is possible to view most of a
continent at one time (bottom left picture). In addition, you can use the rocker keypad to pan from your
current location to other places on the map.
To change the map scale:
Press the IN key to see a smaller area with more detail.
Press the OUT key to see a larger area with less detail.
To pan the map:
1. Press the ROCKER keypad anywhere and an arrow appears. Use the ROCKER keypad to move
the arrow around the map, even to areas not currently shown on the map.
2. When you are finished panning, press the QUIT key. The panning arrow disappears.
