GarrettCom Magnum IPS42 User manual
www GarrettCom com
..
www GarrettCom com
..
Corporate Headquarters
GarrettCom, Inc.
47823 Westinghouse Dr.
Fremont, CA 94539
Phone (510) 438-9071
Fax (510) 438-9072
Website: http://www.GarrettCom.com
Email: [email protected]om
Magnum IPS42 Internal Power Supply
for Edge Switch Family
Installation and User Guide
$5.00 USD
IPS42 Internal Power Supply Installation and User Guide (11/09)
i
www GarrettCom com
..
Magnum™IPS42 Internal Power Supply for
Edge Switch Family
Installation and User Guide
Part #: 84-00181Z Rev. B
Trademarks
GarrettCom is a registered trademark and Magnum, Dymec, DynaStar, Personal
Switch, Link-Loss-Learn, S-Ring, Convenient Switch and Converter Switch
are trademarks of GarrettCom, Inc.
Ethernet is a trademark of Xerox Corporation
NEBS is a trademark of Telcordia Technologies
UL is a registered trademark of Underwriters Laboratories
IPS42 Internal Power Supply Installation and User Guide (11/09)
ii
www GarrettCom com
..
Important: The Magnum IPS42 Series Internal Power Supply for Edge Switches
contains no user serviceable parts. Attempted service by unauthorized personnel shall
render all warranties null and void. If problems are experienced with Magnum IPS42
Internal Power Supply products, consult Section 4, Troubleshooting, of this User Guide.
Copyright ©2009 GarrettCom, Inc. All rights reserved. No part of this publication may
be reproduced without prior written permission from GarrettCom, Inc.
Printed in the United States of America.
GarrettCom, Inc. reserves the right to change specifications, performance characteristics
and/or model offerings without notice.
IPS42 Internal Power Supply Installation and User Guide (11/09)
iii
www GarrettCom com
..
Federal Communications Commission
Radio Frequency Interference Statement
This equipment generates, uses and can radiate frequency energy and if not
installed and used properly, that is in strict accordance with the manufacturer's
instructions, may cause interference to radio communication. It has been tested and
found to comply with the limits for a Class A computing device in accordance with the
specifications in Subpart J of Part 15 of FCC rules, which are designed to provide
reasonable protection against such interference when operated in a commercial
environment. Operation of this equipment in a residential area is likely to cause
interference, in which case the user, at his own expense, will be required to take
whatever measures may be required to correct the interference.
IPS42 Internal Power Supply Installation and User Guide (11/09)
iv
www GarrettCom com
..
Electrical Safety requirements:
1. This product is to be installed Only in Restricted Access Areas
(Dedicated Equipment Rooms, Electrical Closets, or the like).
2. 48VDC products shall be installed with a readily accessible disconnect
device in the building installation supply circuit to the product.
3. This product shall be provided with a maximum 10A DC Listed fuse or
circuit breaker in the supply circuit when connected to a 48V
centralized source.
4. The external power supply for DC units shall be Listed, Direct Plug In
power unit, marked Class 2, or listed ITE Power Supply, marked LPS,
which has suitably rated output voltage (i.e. 24VDC or 48VDC) and suitable
rated output current.
5. Product does not contain user replaceable fuses. Any internal fuses can
ONLY be replaced by GarrettCom personnel through the RMA process.
IPS42 Internal Power Supply Installation and User Guide (11/09)
v
www GarrettCom com
..
Contacting GarrettCom, Inc
Please use the mailing address, phone, fax numbers and email address listed below:
GarrettCom, Inc.
47823 Westinghouse Dr.
Fremont, CA 94539
Phone (510) 438-9071
Fax (510) 438-9072
Website: http://www.GarrettCom.com
Email: [email protected]
IPS42 Internal Power Supply Installation and User Guide (11/09)
vi
www GarrettCom com
..
TABLE OF CONTENTS Page
1.0SPECIFICATIONS ............................................................................... 1
1.1Technical Specifications...................................................................... 1
1.2Summary of models and descriptions for IPS42 Series:...................... 5
2.0INTRODUCTION ................................................................................. 8
2.1Inspecting the Package and the Product............................................... 8
2.2Product Description ............................................................................. 9
2.3Features and Benefits......................................................................... 10
3.0INSTALLATION................................................................................. 11
3.1Locating the IPS42............................................................................. 11
3.1.1Mounting Dimensions for IPS42 with metal brackets............... 12
3.1.2 DIN-Rail mounting option......................................................... 15
3.2Power Cord Installation ..................................................................... 16
3.3Hardware operated Alarm Contact .................................................... 20
4.0TROUBLESHOOTING...................................................................... 21
4.1Before Calling for Assistance............................................................ 22
IPS42 Internal Power Supply Installation and User Guide (11/09)
vii
www GarrettCom com
..
4.2When Calling for Assistance ............................................................. 24
4.3Return Material Authorization (RMA) Procedure............................. 25
4.4Shipping and Packaging Information................................................. 26
APPENDIX A: WARRANTY INFORMATION......................................... 28
Revisions
Rev. B 11/09: Updated DIN Rail mount photo (Sec. 3.1.2)
Rev. A 07/09: Initial Release
IPS42 Internal Power Supply Installation and User Guide (11/09)
1
www GarrettCom com
..
1.0 SPECIFICATIONS
1.1 Technical Specifications
AC/DC Power Supply (Model IPS42-AC/DC):
Power Input: DC: 100-250 VDC
AC: 100-250 VAC, 47 to 63 Hz, auto ranging
Surge Rating: IEC 61000-4-3, Class 3/4 (4KV for DC)
Std. Recessed Terminal Block: “-, GND, +”, UL Listed
Power Consumption: 10 Watts typical for a 4+2 port fiber model
DC Power Supplies for Dual Source DC:
125VDC: Input 100 to 250VDC nominal
48VDC: Input 44 to 57VDC
24VDC: Input 20 to 36VDC
Surge Rating: IEC 61000-4-3, Class 3/4 (4KV for DC)
Std. Terminal Block for DualSRC: A: “-, GND, +”, B: “-, GND, +”
Power Consumption: 10 Watts typical for a 4+2 port fiber model
IPS42 Internal Power Supply Installation and User Guide (11/09)
2
www GarrettCom com
..
AC Power Supply (Model IPS42-AC)
AC Power Connector: standard IEC 320 male, recessed
Power Input: 100-250 VAC, 47 to 63 Hz, auto ranging
Power Consumption: 10 Watts typical for a 4+2 port fiber model
Mechanical Specifications:
Enclosure: Rugged sheet metal (Aluminum).
Dimensions of the IPS42 unit:
6.0 in H x 5.5 in W x 1.7 in D (15.2 cm x 14.0 cm x 4.3 cm)
Weight: all models: 1.5 lbs. (0.68 kg)
Operating Environment:
IEC 60068 “Type Test” exceeds -40° to 185°F (-40° to 85°C)
Storage: -60°to 212°F (-50°to 100°C)
Relative Humidity: 5% to 95% (non-condensing)
Altitude: -200 to 13000FT (-60 to 4000M)
UL 60950 “Component Parts” rating: -40° to 140°F (-40° to 60°C)
Conformal coating (humidity protection): optional
IPS42 Internal Power Supply Installation and User Guide (11/09)
3
www GarrettCom com
..
Cooling Method:
All IPS42 models feature convection cooling for temperature un-controlled locations. All
models have closed cases to withstand dirt and use special thermal techniques to transfer
heat to the outside of the case for cooling.
ALARM RELAY Terminal Block, four screw terminals:
Internal 60VA relay contact: Open for power Off, closed for power On (Hardware).
Mounting options
Metal mounting clips for panel mounting: included
DIN-Rail mounting option: Model # DIN-RAIL-MC2 (see Section 3.1)
Mean Time Between Failure (MTBF) – over 15 years, Telcordia (Bellcore) Method
IPS42 Internal Power Supply Installation and User Guide (11/09)
4
www GarrettCom com
..
Agency Approvals and Standards Compliance:
UL Listed (UL 60950), cUL, CE, Emissions meets FCC Part 15 Class A
IEC 61850 EMC and Operating Conditions Class C Power Substations
IEEE 1613 Env. Standard for Electrical Power Substations
NEBS L3 and ETSI compliant including vibration, shock and altitude
NEMA TS-2 and TEES for traffic control equipment
Warranty: Three years, return to factory Made in USA
IPS42 Internal Power Supply Installation and User Guide (11/09)
5
www GarrettCom com
..
1.2 Summary of models and descriptions for IPS42 Series:
IPS42-AC/DC: Internal Power Supply chassis for use with any ES42H or ES42P
Series Edge Switch. Requires simultaneous ordering of an ES42 (without external power
supply) as a separate line item. Rated 100 to 250 VAC or VDC. Power input via recessed
terminal block, UL Listed and Surge protected.
IPS42-AC/DC
IPS42-125VDC-DualSRC: Internal Power Supply chassis for use with any
ES42H or ES42P Series Edge Switch. Requires simultaneous ordering of an ES42 (without
external power supply) as a separate line item. Rated 100 to 250 VDC, Dual Source.
Power input via recessed terminal block, UL Listed and Surge protected.
IPS42 Internal Power Supply Installation and User Guide (11/09)
6
www GarrettCom com
..
IPS42-48VDC-DualSRC: Internal Power Supply chassis for use with any
ES42H or ES42P Series Edge Switch. Requires simultaneous ordering of an ES42 (without
external power supply) as a separate line item. Rated 44 to 57 VDC, Dual Source. Power
input via recessed terminal block, UL Listed and Surge protected.
IPS42-24VDC-DualSRC: Internal Power Supply chassis for use with any
ES42H or ES42P Series Edge Switch. Requires simultaneous ordering of an ES42 (without
external power supply) as a separate line item. Rated 20 to 36 VDC, Dual Source. Power
input via recessed terminal block, UL Listed and Surge protected.
IPS42-xxVDC-DualSRC
IPS42 Internal Power Supply Installation and User Guide (11/09)
7
www GarrettCom com
..
IPS42-AC: Internal Power Supply chassis for use with any ES42H or ES42P
Series Edge Switch. Requires simultaneous ordering of an ES42 (without external power
supply) as a separate line item. Standard worldwide AC power input via standard IEC320
recessed male connector, UL Listed and Surge protected.
IPS42-AC
Accessories
DIN-RAIL-MC2 = Metal DIN-Rail mounting bracket for one IPS42 Series product
(see Section 3.1)
Conformal Coating (for high humidity and “tropical” applications) - request quote.
IPS42 Internal Power Supply Installation and User Guide (11/09)
8
www GarrettCom com
..
2.0 INTRODUCTION
2.1 Inspecting the Package and the Product
Examine the shipping container for obvious damage prior to installing this
product; notify the carrier immediately of any damage that you believe occurred during
shipment or delivery. Inspect the contents of this package for any signs of damage and
ensure that the items listed below are included.
This package should contain:
1 Magnum IPS42 Series Internal Power Supply for Edge Switch
1 set Metal panel mounting clips and screws (4 each)
1 Power Cord Installation Kit (if applicable)
1 IPS42 User Guide (this manual)
1 ES42 User Guide
IPS42 Internal Power Supply Installation and User Guide (11/09)
9
www GarrettCom com
..
Remove the Magnum IPS42 Series Internal Power Supply from the shipping
container. Be sure to keep the shipping container should you need to ship the unit at a later
date. In the event there are items missing or damaged contact your supplier. If you need to
return the unit, use the original shipping container. Refer to Section 4 Troubleshooting, for
specific return procedures.
2.2 Product Description
The Magnum IPS42 chassis brings big-switch internal power supplies to compact
unmanaged industrial edge switches. The AC/DC model allows the user to connect into
125VDC substation power or into worldwide AC power. Dual-source models operate from
either of two DC power inputs and provide high availability. Any one of the models of the
ES42s may be ordered concurrently with any of the five IPS42 models.
Note: See ES42 User Guide for specifications related to the ES42 Series of Edge Switch.
IPS42 Internal Power Supply Installation and User Guide (11/09)
10
www GarrettCom com
..
2.3 Features and Benefits
100 to 250V range, 4KV surge protected
AC/DC models are rated at 100-250V with a maximum of 4KV surge
suppression. The only High Voltage AC/DC Ethernet unit on the market
that is UL Listed for user safety.
Dual-Source power input
125VDC, 48VDC and 24VDC models are equipped with Dual-Source
inputs for high availability.
For AC models
Worldwide AC power input with standard IEC 320 recessed male power plug
Rugged metal case, Industrial grade
IPS42 Series have a robust design and are packaged in a rugged sheet metal
enclosure to ensure high reliability and durability even when placed in
industrial or outdoor applications.
IPS42 Internal Power Supply Installation and User Guide (11/09)
11
www GarrettCom com
..
3.0 INSTALLATION
This section describes the installation of the Magnum IPS42 Internal Power
Supply, including location, mounting, power cord and media connections.
3.1 Locating the IPS42
The compact and lightweight design of the Magnum IPS42 Series allows it to be
easily installed in almost any location. A Velcro strip may be used for mounting the unit on
a vertical surface such as a wall or cabinet, or for securing the unit on a table-top or shelf.
Alternatively, metal mounting clips and screws are included for a rugged and secure
mounting in any orientation.
IPS42 Internal Power Supply Installation and User Guide (11/09)
12
www GarrettCom com
..
Installation of the Magnum IPS42 Series of products is a simple procedure. The
installation location is dependent upon the physical layout of the Ethernet network and
associated cabling. Make sure the unit is installed in a location that is easily accessible to
an AC power outlet or the appropriate DC source and where cooling is not inhibited. The
green Power (PWR) LED must turn ON when power is applied.
3.1.1 Mounting Dimensions for IPS42 with metal brackets
Each Mangum IPS42-Series is supplied with metal mounting brackets and
screws to mount the unit securely on a panel or wall. It is recommended to mount the units
vertically (see page 14) for proper cooling and long-life reliability. It is also advisable to
mount the unit with space for air movement around the top and the sides, typically a
minimum of 1 inch.
Table of contents
