INSTALLATION INSTRUCTIONS
AC BELLS
Use this product according to this instruction manual. Please keep this instruction manual for future reference.
GENERAL:
Wheelock’s 43T Bell Series is UL Listed under Standard 464 for Audible Signal Appliances. The 43T Bell Series is also ULC
Listed under Standard CAN/ULC-S525-99 for Audible Signaling Appliances. The Bell's design features low power
consumption with a high sound output, and includes suppression to minimize the RFI generated by the contacts. The Bells are
available in either an AC model, for indoor or outdoor use in vibrating modes. Models are available with a 6" or 10" gong as
shown below. The various mounting options available for the Bell Series makes for a convenient and economical installation.
NOTE: All CAUTIONS and WARNINGS are identified by the symbol . All warnings are printed in bold capital letters.
WARNING: PLEASE READ THESE INSTRUCTIONS CAREFULLY. FAILURE TO COMPLY WITH ANY OF
THE FOLLOWING INSTRUCTIONS, CAUTIONS AND WARNINGS COULD RESULT IN IMPROPER
APPLICATION, INSTALLATION AND/OR OPERATION OF THESE PRODUCTS IN AN EMERGENCY
SITUATION, WHICH COULD RESULT IN PROPERTY DAMAGE, SERIOUS INJURY OR DEATH TO YOU
AND/OR OTHERS.
WARNING: THE 43T HORN APPLIANCE IS A “FIRE ALARM DEVICE – DO NOT PAINT.”
SPECIFICATIONS:
Table 1: Ratings Per UL/ULC
dBA at 10 FeetModel
Number Type
Gong
Size
Rated
Voltage
(VRMS)
UL Voltage
Range
(VRMS)
Maximum RMS
Current ULC
Anechoic
UL 464
Reverberant
Mounting
Options
43T-G6-24 6" 24 16-33 0.666A 85 85
A,B,C,D
43T-G6-115 AC 6" 115 96-132 0.117A 85 85
A,B,C,D
43T-G10-24 Vibrating 10" 24 16-33 0.666A 88 88
A,B,C,D
43T-G10-115 10" 115 96-132 0.117A 88 88
A,B,C,D
WARNING: FOR UL/ULC APPLICATIONS THESE APPLIANCES WERE TESTED TO THE OPERATING
VOLTAGE LIMITS OF 16-33 VOLTS FOR 24V MODELS OR 96-132V FOR 115V MODELS. DO NOT APPLY 80%
AND 110% OF THESE VOLTAGE VALUES FOR SYSTEM OPERATION.
WARNING: MAKE SURE THAT THE TOTAL RMS CURRENT REQUIRED BY ALL APPLIANCES THAT ARE
CONNECTED TO THE SYSTEM’S PRIMARY AND SECONDARY POWER SOURCES DO NOT EXCEED THE
POWER SOURCES’ RATED CAPACITY OR THE CURRENT RATINGS OF ANY FUSES ON THE CIRCUITS TO
WHICH THESE APPLIANCES ARE WIRED. OVERLOADING POWER SOURCES OR EXCEEDING FUSE
RATINGS COULD RESULT IN LOSS OF POWER AND FAILURE TO ALERT OCCUPANTS DURING AN
EMERGENCY, WHICH COULD RESULT IN PROPERTY DAMAGE AND SERIOUS INJURY OR DEATH TO YOU
AND/OR OTHERS.
When calculating the total currents: Use Table 1 to determine the highest value of “RMS Current” for an individual bell (across
the expected operating voltage range of the bell), then multiply these values by the total number of bells; be sure to add the
currents for any other appliances, powered by the same source and include any required safety factors.
Copyright 2005 Wheelock, Inc. All rights reserved.
P10352 T
Sheet 2 of 3
WIRING DIAGRAM:
TO NEXT SIGNAL OR
END OF LINE RESISTOR
(EOLR)
+
-
+
-
FIRE ALARM CONTROL
PANEL(FACP)
POS.
+
PRECEDING SIGNAL OR
- Remove bell shell (Do not mix shells from other units.)
- Connect Wiring (Refer to Wiring Diagram.)
- Mount Bell To Backbox Using Screws Supplied With Unit.
- Reinstall Bell Shell (Note keyhole alignment.)
MOUNTING OPTIONS:
BASIC UNITS ARE SUPPLIED
WITH (4) SCREW TERMINALS
FOR CONNECTION TO THE
POWER SOURCE,
FOR MOUNTING.
PROVIDED WITH EACH
(2) #8-32 SCREWS ARE
BASIC BELL
GUIDE PIN
BELL SHELL MOUNTING
BASIC BELL
ALIGN PIN HOLE
6" OR 10"
BELL SHELL
WITH
MOUNTING
BOLT
GUIDE PIN
WITH GUIDE PIN
SEMI-FLUSH MOUNTING
STANDARD 4" SQUARE
BACKBOX TO BE
#8-32 SCREWS
A
SEMI-FLUSH PLATE
MOUNTED IN WALL
WITH #8-32 SCREWS
BASIC BELL
GUIDE PIN
AWG #18 AWG #16 AWG #14 AWG #12
MAXIMUM NUMBER OF CONDUCTORS
4 4 4 4
B
SURFACE MOUNTING
STANDARD 4"
SQUARE BACKBOX
TO BE MOUNTED
ON WALL SURFACE
#8-32 SCREWS
BASIC BELL
GUIDE PIN
AWG #18 AWG #16 AWG #14 AWG #12
MAXIMUM NUMBER OF CONDUCTORS
4 4 4 4
EXISTING BOX
IN WALL
ADAPTOR PLATE WITH
#8-32 & #6-32
SCREWS & BUSHING
CONCEALED CONDUIT MOUNTING
C
#8-32 SCREWS
BASIC BELL
GUIDE PIN
AWG #18 AWG #16 AWG #14 AWG #12
MAXIMUM NUMBER OF CONDUCTORS
4 4 4 4
WEATHER RESISTANT MOUNTING
#8-32 SCREWS
D
1/2" CONDUIT
ENTRANCE
WEATHER RESISTANT
BACKBOX TO BE
MOUNTED ON
BASIC BELL
GUIDE
PIN
AWG #18 AWG #16 AWG #14 AWG #12
MAXIMUM NUMBER OF CONDUCTORS
4 4 4 4
WALL SURFACE
ON TOP
MOUNTING PROCEDURES:
1. For weather resistant installation, use outdoor mounting option. Outdoor backbox must be mounted vertically with "TOP"
as marked to allow any moisture or condensation to drain properly through drain holes on bottom of backbox.
2. Each bell mechanism is adjusted to operate only with the shell provided. Do not mix shells and mechanisms during
installation. Do not readjust bell mechanisms during installation.
3. Each input terminal accepts one lead for in-out wiring of 12-22 AWG wire. Strip wire leads approximately 1/2" for
connection to terminals. Break wire run to provide electrical supervision.
4 All bells will operate on "coded systems" up to 2 on-off cycles per second.
5. The polarity shown in the wiring diagram is for proper operation of the appliances in alarm mode. For supervision mode,
the polarity should be reversed.
6. Anechoic dB ratings are for "free field" (anechoic) conditions. Typical indoor sound output is usually higher than rated
anechoic dB.
7. Backboxes for all bells should be securely mounted. Looseness may degrade sound output. Conduit entrance to backboxes
should be selected to insure sufficient wiring clearance.
P10352 T
Sheet 3 of 3
ANY MATERIAL EXTRAPOLATED FROM THIS DOCUMENT OR FROM WHEELOCK MANUALS OR OTHER
DOCUMENTS DESCRIBING THE PRODUCT FOR USE IN PROMOTIONAL OR ADVERTISING CLAIMS, OR FOR
ANY OTHER USE, INCLUDING DESCRIPTION OF THE PRODUCT'S APPLICATION, OPERATION, INSTALLATION
AND TESTING IS USED AT THE SOLE RISK OF THE USER AND WHEELOCK WILL NOT HAVE ANY LIABILITY
FOR SUCH USE.
IMPORTANT: READ SEPARATE "GENERAL INFORMATION" SHEET FOR INFORMATION ON THE PLACEMENT,
LIMITATIONS, INSTALLATION, FINAL CHECKOUT, AND PERIODIC TESTING OF NOTIFICATION APPLIANCES.
Limited Warranty
Wheelock products must be used within their published specifications and must be PROPERLY specified, applied, installed,
operated, maintained and operationally tested in accordance with these instructions at the time of installation and at least twice a
year or more often and in accordance with local, state and federal codes, regulations and laws. Specification, application,
installation, operation, maintenance and testing must be performed by qualified personnel for proper operation in accordance
with all of the latest National Fire Protection Association (NFPA), Underwriters' Laboratories (UL), Underwriters' Laboratories
of Canada (ULC), National Electrical Code (NEC), Occupational Safety and Health Administration (OSHA), local, state, county,
province, district, federal and other applicable building and fire standards, guidelines, regulations, laws and codes including, but
not limited to, all appendices and amendments and the requirements of the local authority having jurisdiction (AHJ). Wheelock
products when properly specified, applied, installed, operated, maintained and operationally tested as provided above are
warranted against mechanical and electrical defects for a period of three years from date of manufacture (as determined by date
code). Correction of defects by repair or replacement shall be at Wheelock's sole discretion and shall constitute fulfillment of all
obligations under this warranty. THE FOREGOING LIMITED WARRANTY SHALL IMMEDIATELY TERMINATE IN THE
EVENT ANY PART NOT FURNISHED BY WHEELOCK IS INSTALLED IN THE PRODUCT. THE FOREGOING LIMITED
WARRANTY SPECIFICALLY EXCLUDES ANY SOFTWARE REQUIRED FOR THE OPERATION OF OR INCLUDED IN A
PRODUCT. WHEELOCK MAKES NO REPRESENTATION OR WARRANTY OF ANY OTHER KIND, EXPRESS, IMPLIED OR
STATUTORY WHETHER AS TO MERCHANTABILITY, FITNESS FOR A PARTICULAR PURPOSE OR ANY OTHER
MATTER.
USERS ARE SOLELY RESPONSIBLE FOR DETERMINING WHETHER A PRODUCT IS SUITABLE FOR THE USER'S
PURPOSES, OR WHETHER IT WILL ACHIEVE THE USER'S INTENDED RESULTS. THERE IS NO WARRANTY AGAINST
DAMAGE RESULTING FROM MISAPPLICATION, IMPROPER SPECIFICATION, ABUSE, ACCIDENT OR OTHER
OPERATING CONDITIONS BEYOND WHEELOCK'S CONTROL.
SOME WHEELOCK PRODUCTS CONTAIN SOFTWARE. WITH RESPECT TO THOSE PRODUCTS, WHEELOCK DOES NOT
WARRANTY THAT THE OPERATION OF THE SOFTWARE WILL BE UNINTERRUPTED OR ERROR-FREE OR THAT THE
SOFTWARE WILL MEET ANY OTHER STANDARD OF PERFORMANCE, OR THAT THE FUNCTIONS OR PERFORMANCE
OF THE SOFTWARE WILL MEET THE USER'S REQUIREMENTS. WHEELOCK SHALL NOT BE LIABLE FOR ANY
DELAYS, BREAKDOWNS, INTERRUPTIONS, LOSS, DESTRUCTION, ALTERATION, OR OTHER PROBLEMS IN THE USE
OF A PRODUCT ARISING OUT OF OR CAUSED BY THE SOFTWARE.
THE LIABILITY OF WHEELOCK ARISING OUT OF THE SUPPLYING OF A PRODUCT, OR ITS USE, WHETHER ON
WARRANTIES, NEGLIGENCE, OR OTHERWISE, SHALL NOT IN ANY CASE EXCEED THE COST OF CORRECTING
DEFECTS AS STATED IN THE LIMITED WARRANTY AND UPON EXPIRATION OF THE WARRANTY PERIOD ALL SUCH
LIABILITY SHALL TERMINATE. WHEELOCK IS NOT LIABLE FOR LABOR COSTS INCURRED IN REMOVAL,
REINSTALLATION OR REPAIR OF THE PRODUCT BY ANYONE OTHER THAN WHEELOCK OR FOR DAMAGE OF ANY
TYPE WHATSOEVER, INCLUDING BUT NOT LIMITED TO, LOSS OF PROFIT OR INCIDENTAL OR CONSEQUENTIAL
DAMAGES. THE FOREGOING SHALL CONSTITUTE THE SOLE REMEDY OF THE PURCHASER AND THE EXCLUSIVE
LIABILITY OF WHEELOCK.
IN NO CASE WILL WHEELOCK'S LIABILITY EXCEED THE PURCHASE PRICE PAID FOR A PRODUCT.
Limitation of Liability
WHEELOCK'S LIABILITY ON ANY CLAIM OF ANY KIND, INCLUDING NEGLIGENCE AND BREACH OF WARRANTY,
FOR ANY LOSS OR DAMAGE RESULTING FROM, ARISING OUT OF, OR CONNECTED WITH THIS CONTRACT, OR
FROM THE MANUFACTURE, SALE, DELIVERY, RESALE, REPAIR OR USE OF ANY PRODUCT COVERED BY THIS
ORDER SHALL BE LIMITED TO THE PRICE APPLICABLE TO THE PRODUCT OR PART THEREOF WHICH GIVES RISE
TO THE CLAIM. WHEELOCK'S LIABILITY ON ANY CLAIM OF ANY KIND SHALL CEASE IMMEDIATELY UPON THE
INSTALLATION IN THE PRODUCT OF ANY PART NOT FURNISHED BY WHEELOCK. IN NO EVENT SHALL WHEELOCK
BE LIABLE FOR ANY CLAIM OF ANY KIND UNLESS IT IS PROVEN THAT OUR PRODUCT WAS A DIRECT CAUSE OF
SUCH CLAIM. FURTHER, IN NO EVENT, INCLUDING IN THE CASE OF A CLAIM OF NEGLIGENCE, SHALL WHEELOCK
BE LIABLE FOR INCIDENTAL OR CONSEQUENTIAL DAMAGES. SOME STATES DO NOT ALLOW THE EXCLUSION OR
LIMITATION OF INCIDENTAL OR CONSEQUENTIAL DAMAGES, SO THE PRECEDING LIMITATION MAY NOT APPLY
TO ALL PURCHASERS.
5/05

This manual suits for next models
