Lambda GENESYS 10KW User manual

TECHNICAL MANUAL FOR
GENESYSTM 10KW/15KW
Programmable DC Power Supplies
Document: 83-530-000 Rev E
LAMBDA AMERICAS
405 Essex Road, Neptune, NJ 07753
Tel: [phone]
Fax: [phone]
Web: www.lambda-hp.com

83-530-000 Rev. E
1
WARRANTY
This Lambda Americas product is warranted against defects in materials and workmanship for a period
of five years from date of shipment. During the warranty period, Lambda Americas will, at its option,
either repair or replaces products, which prove to be defective.
LIMITATION OF WARRANTY
The warranty shall not apply to defects resulting from improper or inadequate usage or maintenance by
the buyer, buyer supplied products or interfacing. The warranty shall not apply to defects resulting from
unauthorized modifications, or from operation exceeding the environmental specifications of the prod-
uct, or if the QA seal has been removed or altered by anyone other than Lambda Americas authorized
personnel. Lambda Americas does not warrant the buyer’s circuitry or malfunctions of Lambda
Americas products resulting from the buyer’s circuitry. Furthermore, Lambda Americas does not war-
rant any damage occurring as a result of the buyer’s circuitry or the buyer’s - supplied products.
No other warranty is expressed or implied.
WARRANTY SERVICE
This product must be returned to an authorized Lambda Americas service facility for repairs or other
warranty service. For products returned to Lambda Americas for warranty service, the buyer shall pre-
pay shipping charges to Lambda Americas and Lambda Americas shall pay the shipping charges to
return the product to the buyer.
DISCLAIMER
The information contained in this document is subject to change without notice. Lambda Americas shall
not be liable for errors contained in this document or for incidental or consequential damages in con-
nection with the furnishing, performance or use of this material. No part of this document may be
photocopied, reproduced or translated into another language without the prior written consent of
Lambda Americas.
TRADEMARK INFORMATION
GenesysTM power supply is a trademark of Lambda Americas.
MicrosoftTM and WindowsTM are trademarks of Microsoft Corporation.
THE FCC WANTS YOU TO KNOW
This equipment has been tested and found to comply with the limits for a Class A digital device, pursu-
ant to Part 15 of the FCC rules. These limits are designed to provide reasonable protection against
harmful interference when the equipment is operated in a commercial environment.
This equipment generates uses and can radiate radio frequency energy and, if not installed and used in
accordance with the instructions, may cause harmful interference to radio communications.
Operation of this equipment in a residential area is likely to cause harmful interference, in which case
the user will be required to correct the interference at his own expense.
FCC WARNING
Modifications not expressly approved by manufacturer could void the user authority to operate the
equipment under FCC Rules.

Page: 83-530-000 Rev E
2
SAFETY INSTRUCTIONS
CAUTION
The following safety precaution must be observed during all phases of operation, service and repair of
this equipment. Failure to comply with the safety precautions or warnings in this document violates
safety standards of design, manufacture and intended use of this equipment and may impair the built-in
protections within.
Lambda Americas shall not be liable for user’s failure to comply with these requirements.
INSTALLATION CATEGORY
The GenesysTM power supply series has been evaluated to INSTALLATION CATEGORY II. Installation
category (over voltage category) II: local level, appliances, portable equipment etc. With smaller tran-
sient over voltage than Installation Category (over voltage category) III.
GROUNDING
This product is a Safety Class 1 instrument. To minimize shock hazard, the instrument chassis must be
connected to an electrical ground. The instrument must be connected to the AC power supply mains
through a three conductor power cable, with the ground wire firmly connected to an electrical ground
(safety ground) at the power outlet.
For instruments designed to be hard-wired to the supply mains, the protective earth terminal must be
connected to the safety electrical ground before another connection is made. Any interruption of the
protective ground conductor or disconnection of the protective earth terminal will cause a potential
shock hazard that might cause personal injury.
FUSES
Fuses must be changed by authorized Lambda Americas service personnel only. For continued protec-
tion against risk of fire, replace only with the same type and rating of fuse.
INPUT RATINGS
Do not use AC supply, which exceeds the input voltage and frequency rating of this instrument. The
input voltage and frequency rating of the GenesysTM power supply series has three input ranges de-
pending on the model type ordered. Ranges are 180-253 Vac/360-440 Vac/432-528 Vac, 50-60Hz. For
safety reasons, the mains supply voltage fluctuations should not exceed above voltage range.
LIVE CIRCUITS
Operating personnel must not remove the instrument cover. No internal adjustment or component re-
placement is allowed by non-Lambda Americas qualified personnel. Never replace components with
power cable connected. To avoid injuries, always disconnect power, discharge circuits and remove ex-
ternal voltage source before touching components.
PARTS SUBSTITUTIONS & MODIFICATIONS
Parts substitutions and modifications are allowed by authorized Lambda Americas service personnel
only. For repairs or modifications, the instrument must be returned to an authorized Lambda Americas
service facility.
WARNING OUTPUT TERMINALS GROUNDING
There is a potential shock hazard at the RS232-485 and the IEEE ports when using power supplies
with rated or combined voltage greater than 400V and the Positive Output of the Power Supply is
grounded. Do Not connect the Positive Output to ground when using the RS232/485 or IEEE.

83-530-000 Rev. E
3
SAFETY INSTRUCTIONS
ENVIRONMENTAL CONDITIONS
The GenesysTM power supply series safety approval applies to the following operating conditions:
*Indoor use *Ambient temperature: 0°C to 50°C
*Maximum relative humidity: 80% (no condensation) *Altitude: up to 3000m
*Pollution degree 2
ATTENTION Observe Precautions for handling Electrostatic Sensitive Devices.
CAUTION Risk of Electrical Shock
Instruction manual symbol. The instrument will be marked with this symbol when it is
necessary for the user to refer to the instruction manual.
Indicates hazardous voltage.
Indicates ground terminal.
Protective Ground Conductor Terminal must be connected to Earth Ground.
Off (Supply)
On (Supply)
The WARNING sign denotes a hazard. An attention to a procedure is called. Not
following procedure correctly could result in personal injury.
A WARNING sign should not be skipped and all indicated conditions must be
fully understood and met.
The CAUTION sign denotes a hazard. An attention to a procedure is called. Not follow-
ing procedure correctly could result in damage to the equipment. Do not proceed be-
yond a CAUTION sign until all indicated conditions are fully understood and met.
FCC COMPLIANCE NOTICE:
Note: This equipment has been tested and found to comply with the limits for a Class A
digital device, pursuant to part 15 of the FCC Rules. These limits are designed to pro-
vide reasonable protection against harmful interference when the equipment is oper-
ated in a commercial environment. This equipment generates uses, and can radiate
radio frequency energy and, if not installed and used in accordance with the instruction
manual, may cause harmful interference to radio communications. Operation of this
equipment in a residential area is likely to cause harmful interference in which case the
user will be required to correct the interference at his own expense.

Page: 83-530-000 Rev E
4
WARRANTY .........................................................................................................1
CHAPTER 1 GENERAL INFORMATION.............................................................6
1.1 USER MANUAL CONTENT.................................................................................6
1.2 INTRODUCTION...................................................................................................6
1.3 ACCESSORIES....................................................................................................8
1.4 MODEL NUMBER FORMAT.................................................................................9
CHAPTER 2 SPECIFICATIONS.......................................................................10
CHAPTER 3 INSTALLATION..........................................................................14
3.1 GENERAL ...........................................................................................................14
3.2 PREPARATION FOR USE..................................................................................14
3.3 INITIAL INSPECTIONS.......................................................................................14
3.4 RACK MOUNTING.............................................................................................14
3.5 LOCATON, MOUNTING AND COOLING...........................................................15
3.6 AC SOURCE REQUIREMENTS.........................................................................15
3.7 AC INPUT POWER CONNECTION....................................................................15
3.8 TURN-ON CHECKOUT PROCEDURE ..............................................................17
3.9 CONNECTING THE LOAD................................................................................19
3.10 LOCAL AND REMOTE SENSING ....................................................................22
CHAPTER 4 FRONT AND REAR PANEL CONTROLS AND CONNECTORS25
4.1 INTRODUCTION.................................................................................................25
4.2 FRONT PANEL CONTROLS AND INDICATORS..............................................25
4.3 REAR PANEL CONTROLS AND INDICATORS................................................29
4.4 REAR PANEL SW1 SETUP SWITCH ...............................................................29
4.5 REAR PANEL J1 PROGRAMMING AND MONITORING CONNECTOR..........30
CHAPTER 5 LOCAL OPERATION ....................................................................33
5.1 INTRODUCTION.................................................................................................33
5.2 STANDARD OPERATION ..................................................................................33
5.3 OVER VOLTAGE PROTECTION (OVP) ............................................................34
5.4 UNDER VOLTAGE LIMIT (UVL).........................................................................35
5.5 FOLDBACK PROTECTION ................................................................................35
5.6 OUTPUT ON/OFF CONTROL ............................................................................35
5.7 OUTPUT SHUT-OFF (SO) CONTROL VIA REAR PANEL J1 CONNECTOR...35
5.8 ENABLE/DISABLE CONTROL VIA REAR PANEL J1 CONNECTOR ..............36
5.9 CV/CC SIGNAL...................................................................................................36
5.10 PS_OK SIGNAL ................................................................................................36
5.11 SAFE START AND AUTO-RESTART MODES................................................37
5.12 OVER TEMPERATURE PROTECTON (OTP) .................................................37
5.13 LAST SETTING MEMORY................................................................................37
5.14 SERIES OPERATION.......................................................................................37
5.15 PARALLEL OPERATION..................................................................................40
5.16 DAISY-CHAIN CONNECTION..........................................................................41
5.17 FRONT PANEL LOCKING................................................................................41
CHAPTER 6 REMOTE ANALOG PROGRAMMING.........................................42
6.1 INTRODUCTION.................................................................................................42
6.2 LOCAL/REMOTE ANALOG INDICATION..........................................................42
6.3 LOCAL/REMOTE ANALOG INDICATION..........................................................42
6.4 REMOTE VOLTAGE PROG OF OUTPUT VOLTAGE AND CURRENT LIMIT..43
6.5 RESISTIVE PROG OF OUTPUT VOLTAGE AND CURRENT LIMIT ................44
6.6 REMOTE MONITORING OF OUTPUT VOLTAGE AND CURRENT................45

83-530-000 Rev. E
5
CHAPTER 7 RS232 & RS485 REMOTE CONTROL .......................................46
7.1 INTRODUCTION................................................................................................46
7.2 CONFIGURATION .............................................................................................46
7.3 REAR PANEL RS232/485 CONNECTOR.........................................................47
7.4 CONNECTING POWER SUPPLIES TO RS232 BUS........................................48
7.5 COMMUNICATION INTERFACE PROTOCOL .................................................49
7.6 ERROR MESSAGES .........................................................................................50
7.7 COMMAND SET DESCRIPTION.......................................................................50
7.8 GLOBAL OUTPUT COMMANDS.......................................................................53
7.9 SINGLE BYTE COMMANDS .............................................................................53
7.10 STATUS, ERROR AND SRQ REGISTERS......................................................58
7.11 SERIAL COMMUNICATION TEST SET-UP.....................................................61
CHAPTER 8 ISOLATED ANALOG PROGRAMMING OPTION.......................63
8.1 INTRODUCTION.................................................................................................63
8.2 SPECIFICATIONS...............................................................................................63
8.3 ISOLATED PROGRAMMING & MONITORING CONNECTOR.........................64
8.4 SETUP AND OPERATING INSTRUCTIONS .....................................................64
CHAPTER 9 MAINTENANCE...........................................................................66
9.1 INTRODUCTION.................................................................................................66
9.2 UNITS UNDER WARRANTY..............................................................................66
9.4 ADJUSTMENTS AND CALIBRATION................................................................66
9.5 PARTS REPLACEMENT AND REPAIRS...........................................................66
9.6 TROUBLESHOOTING........................................................................................66

Page: 83-530-000 Rev E
6
CHAPTER 1 GENERAL INFORMATION
1.1 USER MANUAL CONTENT
This User’s Manual contains the operating instructions, installation instructions and specifications of the
GenesysTM 15KW and 10KW power supply series. The instructions refer to the standard power sup-
plies, including the built-in RS232/485 serial communication. For information related to operation with
the optional IEEE programming, refer to User’s Manual for Power Supply IEEE/IEMD Programming In-
terface. For information related to operation with the optional LAN programming, refer to the User’s
Manual for Power Supply LAN Programming Interface.
1.2 INTRODUCTION
1.2.1 General Description
GenesysTM power supplies are wide output range, high performance switching power supplies. The
GenesysTM series is power factor corrected and operates from specified AC voltage range continuously.
Output voltage and current are continuously displayed and LED indicators show the complete operating
status of the power supply. The Front panel controls allow the user to set the output parameters, the
protections levels (Over-Voltage protection, Under-Voltage limit and Foldback) and preview the set-
tings. The rear panel includes the necessary connectors to control and monitor the power supply opera-
tion by remote analog signals or by the built-in serial communication (RS232/485). GPIB programming
and Isolated-Analog programming/monitoring are optional
1.2.2 Features and options
∗Constant Voltage / Constant Current with automatic crossover.
∗Embedded Microprocessor Controller.
∗Built-in RS-232/RS-485 Interface.
∗Voltage & Current high resolution adjustment by digital encoders.
∗High accuracy programming/readback.
∗Last Setting Memory.
∗Independent Remote ON/OFF (opto-isolated) and remote Enable/Disable.
∗Remote sensing to compensate for voltage drop of power leads.
∗External Analog Programming and Monitoring standard (0-5V or 0-10V, user selectable).
∗Zero stacking-no ventilation required at the top and bottom surface of the power supply.
∗Optional GPIB interface (SCPI compatible).
∗Optional Isolated Analog programming/monitoring (0-5V or 0-10V, user selectable and 4-20mA).

83-530-000 Rev. E
7
1.2.3 Control via the serial communication port
The following parameters can be programmed via the serial communication port:
1. Output voltage setting.
2. Output current setting.
3. Output voltage measurement.
4. Output On/Off control.
5. Output current measurement.
6. Foldback protection setting
7. Over-voltage protection setting and readback.
8. Under-Voltage limit setting and readback.
9. Power-supply start up mode (last setting or safe mode).
1.2.4 Analog voltage programming and monitoring
Analog inputs and outputs are provided at the rear panel for analog control of the power supply. The
output voltage and the current limit can be programmed by analog voltage or by resistor, and can be
monitored by analog voltage. The power supply output can be remotely set to On or Off and analog
signals monitor the proper operation of the power supply and the mode of operation (CV/CC).
1.2.5 Parallel operation
GenesysTM power supplies of the same output voltage and current rating can be paralleled in master-
slave configuration with automatic current sharing to increase power available.
1.2.6 Output connections
Output connections are made to rear panel via bus-bars up to 300V. For greater than 300Vovia stud
terminals. Either the positive or negative terminal may be grounded or the output may be floated. Con-
tact factory for assistance with higher float voltage applications. Local or remote sense may be used. In
remote sense, the voltage drop on the load wires should be minimized. Refer to the specifications for
the maximum voltage drop value.
1.2.7 Cooling and mechanical construction
The GenesysTM series is cooled by internal fans. At the installation, care must be taken to allow free
airflow into the power supply via the front panel and out of the power supply via the rear panel.
CAUTION
Observe all torque guidelines within this manual. Over torqueing may damage
unit or accessories. Such damage is not covered under manufacturer’s war-
ranty

Page: 83-530-000 Rev E
8
1.3 ACCESSORIES
1.3.1 General
Accessories are delivered with the power supply or separately upon ordering. The list below shows the
possible accessories and ordering numbers.
1.3.2 Serial Link Cable
Serial link cable for linking power supplies by RS485 communication can be purchased separately.
1.3.3 Misc. hardware
∗DB25 plug (AMP, 745211-2). Output terminal shroud, input terminal cover and hardware are pro-
vided with the power supply.

83-530-000 Rev. E
9
WARNING IEEE 488/RS232 OPTION
There is a potential shock hazard at the RS232-485 and the IEEE ports when using
power supplies with rated or combined voltage greater than 400V and the Positive
Output of the Power Supply is grounded. Do Not connect the Positive Output to ground
when using the RS232/485 or IEEE.
1.4 MODEL NUMBER FORMAT
The model numbering system for GenesysTM power supply includes symbols for features and op-
tions. They are separated by dashes.
The following chart explains the model number for the GEN Power Supply Family.
*
Factory Installed. Limit one (1) per Power Supply.
Note 1: See Specifications for Input Range.
Note 2: CE Mark with IEMD to 400VDC Output, without IEMD to 600VDC
Note 3: All 3φare four wire input = 3φ+ GND (No Neutral).
Note 4: Analog Meters are NOT available.
Note 5: IS510, IS420 or IEMD may not be installed together.
EXAMPLES: GEN10-1000-3P208
GEN10-1000-IEMD-3P400

Page: 83-530-000 Rev E
10
CHAPTER 2 SPECIFICATIONS
All specifications are subject to change without notice.
Contact factory for specific model availability.
1.1 STANDARD MODELS - 10kW
1.Rated output voltage V 7.5 10 12.5 20 25 30 40 50 60 80 100 125 150 200 250 300 400 500 600
2.Rated Output Current A 1000 1000 800 500 400 333 250 200 167 125 100 80 66 50 40 33 25 20 17
3.Rated output power kW 7.5 10.0 10.0 10.0 10.0 10.0 10.0 10.0 10.0 10.0 10.0 10.0 9.9 10.0 10.0 9.9 10.0 10.0 10.2
1.1 STANDARD MODELS - 15kW
1.Rated output voltage V N/A N/A N/A N/A N/A N/A N/A N/A 60 80 100 125 150 200 250 300 400 500 600
2.Rated Output Current A 250 187.5 150 120 100 75 60 50 37.5 30 25
3.Rated output power kW 15.0 15.0 15.0 15.0 15.0 15.0 15.0 15.0 15.0 15.0 15.0
2.INPUT CHARACTERISTICS
V 7.5 10 12.5 20 25 30 40 50 60 80 100 125 150 200 250 300 400 500 600
1. Input voltage/freq.(range) ---
2.No of phase --- 3 Phase (Wye or Delta) 4 wire total (3 Phase and 1 protective earth ground)
3. Dropout voltage V
4. Input current 180/360/432Vac A 10kw - 45/23/20 15kW - 64/32/27 All at full rated output power.
5. Power Factor ---
6. Efficiency at Low Line,100% load %
7. Inrush current A
8. Leakage current mA
9. Input Protection ---
10. Fuse --- 400/480 Input Only
11. Input Overvoltage Protection
12. Phase Imbalance %
3. STATIC CHARACTERISTICS
V 7.5 10 12.5 20 25 30 40 50 60 80 100 125 150 200 250 300 400 500 600
1. Max. line regulation c.v ---
2. Max. line regulation c.c ---
3. Max load regulation c.v ---
4. Max load regulation c.c ---
5. Temp. drift c.v --- +/-0.05% of Full Scale Over 8 hours, after 30 minute warm up, constant Line, Load & Temperature
6. Temp. drift c.c --- +/-0.05% of Full Scale Over 8 hours, after 30 minute warm up, constant Line, Load & Temperature
7. Stability c.v PPM/C 200 (0.02% Full Scale)/Degree C
8. Stability c.c PPM/C 300( 0.03% Full Scale)/ Degree C
9. Output noise p-p(20MHz) c.v mV 60 60 60 60 60 60 60 75 75 100 100 125 135 135 200 200 200 300 350
10.Rippler.m.s5Hz~1MHzc.v mV202020202020 20 202025252525353560606060
11. Ripple r.m.s 5Hz~1MHz c.c (10kW) mA 5100 5100 2600 2600 1700 1700 100 80 67 50 40 32 20 20 16 13 10 8 7
12. Ripple r.m.s. 5Hz~1MHz c.c (15kW) mA – – – – – – – – 100 100 100 50 50 20 20 20 10 10 10
13. Rem. sense compensation/wire V 1 1 1 1 1 1.5 2 3 3 4 5 5 5 5 5 5 5 5 5
4.PROTECTIVE FUNCTIONS
V 7.5 10 12.5 20 25 30 40 50 60 80 100 125 150 200 250 300 400 500 600
1. OCP % 0~100
2. OCP type --- Constant current
3. Knee point protection --- None. No damage at knee point operation
4. Short circuit protection --- Yes
5. Short circuit burn-in --- Yes
6. Foldback protection ---
7. Foldback response time S Less than 1
8. OVP type ---
9. OVP programming accuracy % 5% Full Scale
10. OVP adjustment method ---
11. OVP trip point V
12. OVP response time mS
13. Max. OVP reset time S
14. Output under voltage limit --- Preset by front panel or communication port. Prevents from adjusting Vout below limit.
Raises the Output good signal in case of output voltage is below limit.
15. Input under voltage protection --- Yes. Power supply shut down below low line.
16. Over temp. protection ---
17. Phase Loss Protection
208VAC (180-253); 400VAC (360-440); 480VAC (432-528), all 47-63Hz.
175/355/425
0.1% of FS from Io min. to Io max 0.01% of FS from lo min. to lo max
0.05% of FS from lo min. to lo max
Unit shall not be damaged by line overvoltage with max. duration of 100uSec. Up to 120% of nominal AC input voltage.
0.88 Passive
Less than 10mS for Output to begin to drop.
0.1% of FS from Io min. to Io max
0.1% of FS from Vo min. to Vo max
0.1% of FS from Vo min. to Vo max 0.02% of FS lo min. to lo max
0.75% of FS from Vo min. to Vo max
77min for 7.5KW, 83 min for 10kW; 88 min for 15kW
Not to exceed full rated Input current See Para. 2.4
*Ripple and Noise at Full Rated Voltage & Load at 25C, Nominal Line. For models not listed use the ripple limit of the next higher voltage model. Per EIJ RC9002A
3.5 (EN60950-1) max.
208 Circuit Breaker, 400/480 - Line Fuse
7 from Turn On.
Yes
1. OUTPUT RATING (Duty Cycle Continuous Duty).
Inverter shut-down, manual reset by On/Off recycle or by OUT button
Adjust by front panel Voltage encoder and comm port.
0.05 to (1.02-1.05) x Rated Output Voltage
Unit shall shut down when internal temperature exceeds safe operating levels. (Latched in Safe mode and
unlatched in auto mode).
= < 5% on Three Phase Input
Output shut down , manual reset by front panel OUT button.

83-530-000 Rev. E
11
5. DYNAMIC CHARACTERISTICS
V 7.5 10 12.5 20 25 30 40 50 60 80 100 125 150 200 250 300 400 500 600
1. Up-prog. response time, 0~Vomax full-
load mS 100 100 100 100 100 100 100 100 100 100 100 100 100 100 100 100 100 100 100
2. Down-prog response time full-load mS 100 100 100 100 100 100 100 100 100 100 100 100 100 100 100 100 100 100 100
3. Transient response time (cv mode) mS
Note:
4. Time for Ouput Stable S
5. Output fall and rise ---
6.Start-up delay S Less than 7 (without IEEE option)
6. REMOTE ANALOG CONTROL AND SIGNALS
1. Vout voltage programming --- 0~100%, 0~5V or 0~10V, user selectable. Accuracy & Linearity +/-1% of Rated Vo.
2. Iout voltage programming --- 0~100%, 0~5V or 0~10V, user selectable. Accuracy & Linearity+/-1% of Rated Io.
3. Vout resistor programming --- 0~100%, 0~5/10kohm full scale, user selectable. Accuracy & Linearity +/-1% of Rated Vo.
4. Iout resistor programming --- 0~100%, 0~5/10kohm full scale, user selectable. Accuracy & Linearity +/-1% of Rated Io.
5. On/Off control (rear panel) ---
6. Output current monitor --- 0~5V or 0~10V , accuracy:1% , user selectable
7. Output voltage monitor --- 0~5V or 0~10V , accuracy:1% , user selectable
8. Power supply OK signal --- Yes. TTL high-OK, 0V (500ohm impedance)-Fail
9. Parallel operation ---
available on digital interface and displayed on front panel of Master unit.
10. Series operation --- Possible (with external diodes) , up to identical 2 units with total output not to exceed +/-600V from chassis ground.
11. CV/CC signal --- CV: TTL high (4~5V) source: 10mA, CC: TTL low (0~04V):10mA
12. Enable/Disable ---
13. Remote/Local selection ---
14. Remote/Local signal --- Signals operating mode in use.
7.FRONT PANEL
1. Control functions --- Vout/ Iout manual adjust by separate encoders
--- OVP/UVL manual adjust by Volt. Adjust encoder
---
---
---
---
--- Foldback control (CV to CC)
--- RS232/485 and IEEE488.2 selection by IEEE or LAN enable switch and DIP switch
---
--- Re-start modes (auto , safe)
--- Front Panel Lock/Unlock
---
S = Slave
2. Display --- Vout: 4 digits , accuracy: 0.5% of rated Vout+/-1count , Green LED's , Size:10mm
--- Iout: 4 digits , accuracy: 0.5% of rated Iout+/-1count , Green LED's , Size:10mm
3. Indications --- CC/CV : GREEN LED's. ALRM (OVP,OTP,FOLD,AC FAIL): RED LED
Properties 5.1-5.6 with Resistive Load.
2 maximum from enable output until output stable.
rated output set-point: less than 3.
Address selection by Voltage adjust encoder. No of addresses:31
AC On/Off
Overshoot limited to 125% Rated Output. Voltage at No-Load, Full-Load, Resistive load.
H3 = One Master, Two Slaves H4 = One Master, Three Slaves,
Up to Four (4) identical units may be connected in Master/Slave Mode with 'Single' wire connection.
In Advanced parallel feature, the current of Master Unit, multiplied by number of units connected in parallel, is made
Remote analog current monitor of the Master is scaled to output current of the Master unit (only).
Go to Local
Dry contact. Open:off , Short: on. Max. voltage at Enable/Disable Contacts 6V
Selects Remote or Local operation by elect. Voltage: 0~0.6V/2~15V, <0.6V = Local 2-15V = Remote
Voltmeter is user selectable to read either local voltage (at power supply) or remote voltage (at the load).
Baud rate selection by Current adjust encoder.
Output On/Off
Parallel Master Slave: H1 = One Master, Zero Slave, H2 One Master, One Slave
ADDR., OVP/UVL , V/A , FOLD, REM./LOCAL, OUT ON/OFF, LFP/UFP, IEEE, LAN, Hx (Parallel Master) or S (Slave).
Time for the output voltage to recover within 2% of its rated output voltage for a load change of 50~100% or 100~50% of
By Voltage: 0.6V = Disable, 2-15V = enable (default) or dry contact, user selectable logic

Page: 83-530-000 Rev E
12
1. Functions: 1. Voltage/current setting
2. OVP/UVL setting
3. Actual voltage/current readback
4. Voltage/current setting readback
5. OVP/UVL setting readback
6. Output On/Off
7. Foldback protection setting
8. Status readback (cc/cv , ovp , otp , foldback, ac fault)
9. Model identification readback
11. Calibration (not user access.) (DAC-Zero and max points , Display-Zero and max)
12. Last setting recall (at power off).
13. Re-start mode setting
14. Front Panel Lock/Unlock
2. Application software: 1.Drivers to LabView and LabWindows
2. Simple operating program
9. DIGITAL PROGRAMMING AND READBACK
1. Vout programming accuracy ---
2. Iout programing accuracy ---
3. Vout programming resolution --- 0.02% of full scale (To be confirmed)
4. Iout programming resolution --- 0.04% of full scale (To be confirmed)
5. Vout readback accuracy ---
6. Iout readback accuracy ---
7. Vout readback resolution ---
8. Iout readback resolution ---
OV Response time mS
Other Functions
10. MECHANICAL CONSTRUCTION
V 7.5 10 12.5 20 25 30 40 50 60 80 100 125 150 200 250 300 400 500 600
1. Cooling ---
2. Weight Kg/Lb
3. Dimensions ---
4. Types of connectors ---
5.Front panel material & finish ---
6. Mounting method --- Sandard 19" Rack Mount, provision for standard slides. Side/Rear Support is required; do not mount by F/P only.
7. Mounting positions --- Horizontal.
8. Output ground connection ---- M5 Stud
9. Color and finish ---
10. Output Terminal covers ---
11. ENVIRONMENTAL CONDITIONS
1. Operating temp C
0~50 C,100% load. No operation > 50C
2. Start up temp. C 0
3. Storage temp C
4. Operating humidity % 20~80% RH Non-condensing
5. Storage humidity %
6. Altitude --- Operating:
7. Vibration & Shock (208/400VAC) G
8. Audible Noise db
RAL7035 Textured finish.
50º C up to 7500 ft., (2500m) 45º C from 7501 to 10,000ft (2501m - 3000m)
Non Operating 40,000 ft (12,000m)
2) Output: Iout =>50A: bus-bars, Iout<37.5 a threaded stud terminal.
6) IEMD Option, refer to IEMD Option Spec 08-030-100.
-20C to +70C
10~90% RH Non-condensing
4) RS232/RS485, STD Phone Jack connector.
Standard for all models with bus-bars. Closed connection for models with output connector.
5) Isolated analog option: refer to Isolated Analog option spec. 08-030-200
connector 747321. Standard 25 pin D connector.
Chassis Top/Sides/Bottom Yellow iridite. Front Panel RAL 7035 painted.
ASTM D4169, Standard Practice for Performance Testing of Shipping Containers and Systems, Shipping Unit: Single Package
Assurance Level: Level II; Acceptance Criteria: Criterion 1 - No product damage Criterion 2 - Package is intact Distribution Cycle: Cy
Air (intercity) and motor freight (local, single package up to 100 lbs.) (Note: for packages over 100 lbs, distribution cycle 12 - Air
(intercity) and motor freight (local), unitized is used)
+/-0.5% of rated output current for units with Io <187.5 +/-0.7% of rated output current for Io <187.5
43/97
0.1%+0.4% of rated output current Accuracy same as IEEE Programming Accuracy
0.02% of full scale
Fan driven, Airflow from Front to Rear. Supplemental vents on side that shall not be blocked. EIA Rack mounting,
0.1%+0.2% of rated output voltage Accuracy same as IEEE Programming Accuracy
10. Self test.
8. SOFTWARE SPEC.
+/-0.5% of rated output voltage
stackable. "Zero Stackable" top and bottom. Slides or suitable rear support required.
0.02% of full scale
20 mS maximum between output V exceeding IEEE limit and supply inhibit turning on.
65dBA at Full Load, measured 1m from Front Panel
Set Over-Voltage Limit, Set Local/Remote
Operating parameters and status available for display via host computer.
H:3U ,W: 19" Rack, See 02-530-000 for outline drawing.
1) Input: Threaded Studs and terminal cover. Strain relief optional.
3) Analog programming: DB25, plastic connector, AMP, 747461-5, Female on Power Supply, Male on Mating

83-530-000 Rev. E
13
1. 208 Volts Input Models
1. ESD ---
2. Fast transients ---
3. Surge immunity ---
4. Conducted immunity ---
5. Radiated immunity ---
6. Power Frequency Magnetic Field
7. Conducted emission ---
8. Radiated emission ---
2. 400 Volts Input Models CE Mark
1. ESD ---
2. Fast transients ---
3. Surge immunity ---
4. Conducted immunity ---
5. Radiated immunity ---
6. Power Frequency Magnetic Field ---
7. Voltage Dips, Short Interruptions and ---
Voltage Variations Immunity Tests
(400VAC Input Only)
8. Conducted emission ---
9. Radiated emission ---
13. RELIABILITY SPECS
1. Electrolytic capacitors life Yrs. More than 3yrs at 40C ambient , 100% load
2. Grade ---
3. MTBF Hrs.
4. Warranty Yrs. 5 years
5. Shelf life Yrs.
1. applicable standards ---
2. Insulation resistance --- 100Mohm at 500Vdc
1. MOV protection ---
2. Customized color/logo --- Provision for customized logo to be made in the front panel design.
3. No micro-controller option ---
(No micro-controller) +A326 option
4. Semi F47 --- Provision for Optional Semi F47 Conformance
5. Interfaces ---
J1-1 ENA_IN Enable/Disable Dry Contact with J1-14
J1-2 IF_COM Isolated Interface Common. Return for SO, PS_OK
J1-3 IF_COM Isolated Interface Common. Return for SO, PS_OK
J1-4 N/C
J1-5 N/C
J1-6 N/C
J1-7 N/C
J1-8 LOC/REM Input for selecting between Local or Remote analog programming
J1-9
V
PGM Input for remote analog voltage/resistance programming of the Output Voltage
J1-10 IPGM Input for remote analog voltage/resistance programming of the Output Current
J1-11
V
MON Output Voltage Monitor
J1-12 COM Control Common for VMON & IMON
J1-13 CV/CC Output for Constant Voltage/ Constant Current mode indication
J1-14 ENA_OUT Enable/Disable Dry Contact with J1-1
J1-15 SO Input for Shut-Off control of the output.
J1-16 PS_OK Output for indication of the power supply status
J1-17 N/C
J1-18 N/C
J1-19 N/C
J1-20 N/C
J1-21 LOC/REM Signal Output for indicating if the unit is in Local or Remote analog programming mode.
J1-22
V
PGM_RTN Return for VPGM J1-9; connected to Neg Output
J1-23 IPGM_RTN Return for IPGM J1-10; connected to Neg Output
J1-24 IMON Output for Current Monitor
J1-25 P Output for Current Balance in Parallel Operation (One wire - Reference to Negative Output)
EN55011A, FCC part 15J-A
12. EMC
EN61000-4-4 (IEC 1000-4-3)
EN55011A, FCC part 15J-A
EN61000-4-5 (IEC 1000-4-5)
EN61000-4-6 (IEC 1000-4-6)
EN61000-4-3 (IEC 1000-4-3)
EN61000-4-3 (IEC 1000-4-3)
EN55011A, FCC part 15J-A
EN61000-4-2 (IEC 801-2) Air-disch.+/-8kV , contact disch.+/-4kV
EN61000-4-4 (IEC 1000-4-3)
EN61000-4-8
EN61000-4-6 (IEC 1000-4-6)
EN61000-4-2 (IEC 801-2) Air-disch.+/-8kV , contact disch.+/-4kV
Provision for Optional IEEE or ISOL, LAN, or USB Interface. (IEEE not available with No-microcontroller option)
switch between V & I (3 1/2 digit). Over Temperatuare protection is non-latching.
16. J1 Connector
count Reliabililty, Generic FaIlure rates, 25C
UL/cUL60950-1, EN60950-1 recognized. All Outputs are Hazardous. (Units with IEMD or ISOL option are Recognized up
to 400 volts output). CE Mark 208 & 400VAC input only (CB Scheme).
15. OEM FEATURES/OPTIONS Some options may affect performance specified. Refer to specification of
5 years , electrolytic caps shall be reformed after 2 years
Provision to be made on the PCB and chassis. Line-Line; Output to Chassis
Provision for Optional Front Panel Display without micro-controller.(Poteniometers (2) V & I (10 turn), One meter with
Specials for detailed information.
IEC 61000-4-11
14. SAFETY
EN55011A, FCC part 15J-A
40,000 minimum based on reliability estimation per MIL-HDBK-217F,Section 5.2, ground benign GB,Parts (EIAJ RCR-9102A)
G-2 , Lambda Group derating criteria & EIAJ RCR-9102A
EN61000-4-5 (IEC 1000-4-5)
EN61000-4-8
CE Mark

Page: 83-530-000 Rev E
14
CHAPTER 3 INSTALLATION
3.1 GENERAL
This Chapter contains instructions for initial inspection, preparation for use and repackaging for ship-
ment. Connection to PC, setting the communication port and linking GenesysTM power supplies are de-
scribed in Chapter 7.
3.2 PREPARATION FOR USE
In order to be operational the power supply must be connected to an appropriate AC source. The AC
source voltage should be within the power supply specification. Do not apply power before reading
Section 3.6 and 3.7.
Table 3-1 below, describes the basic setup procedure. Follow the instructions in Table 3-1 in the se-
quence given to prepare the power supply for use.
Step no. Item Description Reference
1 Inspection Initial physical inspection of the power supply Section 3.3
2 Installation Installing the power supply,
Ensuring adequate ventilation. Section 3.4 Section 3.5
3 AC source AC source requirements
Connecting the power supply to the AC source Section 3.6
Section 3.7
4 Test Turn-on checkout procedure. Section 3.8
5 Load connection Wire size selection. Local/Remote sensing.
Single or multiple loads. Section 3.9
6 Default setting The power supply setting at shipment. Section 7.2.4
4.4.1, 3.9.4
Table 3-1: Basic setup procedure
3.3 INITIAL INSPECTIONS
Prior to shipment this power supply was inspected and found free of mechanical or electrical defects.
Upon unpacking of the power supply, inspect for any damage, which may have occurred in transit.
The inspection should confirm that there is no exterior damage to the power supply such as broken
knobs or connectors and that the front panel and meters face are not scratched or cracked. Keep all
packing material until the inspection has been completed. If damage is detected, file a claim with carrier
immediately and notify the Lambda sales or authorized service facility nearest you.
3.4 RACK MOUNTING
The GenesysTM power supply series is designed to fit in a standard 19” equipment rack.
3.4.1 To install the Power Supply in a rack:
1. Use the front panel rack-mount brackets to install the power supply in the rack.
2. Use a support bar to provide adequate support for the rear of the power supply. Do not obstruct the
air exhaust at the rear panel of the unit.
GenesysTM power supplies generate magnetic fields, which
might affect the operation of other instruments. If your equip-
ment is susceptible to magnetic fields, do not position it adja-
cent to the power supply.

83-530-000 Rev. E
15
Some components inside the power supply are at AC/DC
voltage even when the On/Off switch is in the “Off” position. To
avoid electric shock hazard, disconnect the line and load and
wait 15 minutes before removing cover.
There is a potential shock hazard if the power supply chassis
(with cover in place) is not connected to an electrical safety
ground via the safety ground in the AC input stud terminals.
3.5 LOCATON, MOUNTING AND COOLING
This power supply is fan cooled. The air intake is at the front panel and the exhaust is at the rear panel.
Upon installation allow cooling air to reach the front panel ventilation inlets. Unrestricted air space at
the front and the rear of the unit is necessary for proper cooling of power supply.
3.6 AC SOURCE REQUIREMENTS
The GenesysTM series can be operated from a nominal 208V, 400V or 480V three phase, 4 wire, 47i63
Hz. The input voltage range and current required for each model is specified in Chapter 2. Ensure that
under heavy load, the AC voltage supplied to the power supply does not fall below the specifications
described in Chapter 2.
3.7 AC INPUT POWER CONNECTION
The customers AC line connects to the power supply through four stud type terminals. Only use a
power cable with the correct voltage and current ratings. The recommended wire gauge is listed in the
table in section 3.7.1. The ground wire must be equal to or larger than the recommended gauge for
phase. The power supply must be permanently connected to an approved AC distribution box with
suitably rated overcurrent protection (60Amp UL Listed fuse for 208V input, and 40 Amp UL listed fuse
for 400/480 input).
Connection of this power supply to an AC power source should
be made by an electrician or other qualified personnel. Do not
exceed the torque specified on input stud terminals.

Page: 83-530-000 Rev E
16
Input Terminal Block
with cover.
Input Terminal Block
Input Rating
Label
NOTE: The figure shows input
connection from left side.
For connection from right side
reverse the input cover.
Figure 3.1
3.7.1 Recommended Cable Size for Input Connection
INPUT VOLTAGE CURRENT RMS AMPS
PER PHASE RECOMMENDED COPPER WIRE SIZE
208 75 4 AWG
400 45 6 AWG
The AC input current and voltage rating is marked on the rear terminal of the power supply.
The Protective Earth Ground must be connected
before applying AC Line Power to the power supply.

83-530-000 Rev. E
17
3.8 TURN-ON CHECKOUT PROCEDURE
3.8.1 General
The following procedure ensures that the power supply is operational and may be used as a basic in-
coming inspection check. Refer to Fig. 4-1 and Fig. 4-2 for the location of the controls indicated in the
procedure.
3.8.2 Prior to Operation
1. Ensure that the power supply is configured to the default setting:
-On/Off switch at off position.
-Dip switch: All positions at Down (“Off”) position.
-Sense connector: Configured to Local Sense as shown in Fig.3-4:
3-4: sense connector default connection
-For units equipped with IEEE option, ensure that the IEEE_En switch is in Up (default) position
(Refer to Fig. 4-2, Item 9 for location), if checkout is to be done in IEEE mode.
2. Connect the unit to an AC source as described in Section 3.7.
3. Connect a DVM with appropriate cables for the rated voltage to the output terminals.
4. Turn the front panel ON/OFF switch to ON.
3.8.3 Constant Voltage Check
1. Turn on the output by pressing OUT pushbutton so the OUT LED illuminates.
2. Observe the power supply VOLT display and rotate the Voltage encoder. Ensure that the output
voltage varies while the VOLT encoder is rotated. The minimum control range is from zero to the
maximum rated output for the power supply model.
Compare the DVM reading with the front panel VOLT display to verify the accuracy of the VOLT
display. Ensure that the front panel VOLT LED is on.
3. Turn off the front panel AC power switch.
3.8.4 Constant Current Check
1. Ensure that the front panel switch is at Off position and the DVM connected to the output terminals
shows zero voltage.
2. Connect a DC shunt across the output terminals. Ensure that the shunt and the wires current rat-
ings are higher than the power supply rating. Connect a DVM to the shunt.
3. Turn the front panel switch to On position,
4. Turn on the output by pressing OUT pushbutton so the OUT LED illuminates.
5. Observe the power supply CURRENT display and rotate the CURRENT encoder. Ensure that the
output current varies while the CURRENT encoder is rotated. The minimum control range is from
zero to the maximum rated output for the power supply model.
Compare the DVM reading with the front panel CURRENT display to verify the accuracy of the
CURRENT display. Ensure that the front panel CURRENT LED is on.
6. Turn off the front panel ON/OFF switch.

Page: 83-530-000 Rev E
18
7. Remove the shunt from the power supply output terminals.
3.8.5 OVP Check
Refer to Section 5.3 for explanation of the OVP function prior to performing the procedure below.
1. Turn the front panel AC power switch to On position and turn on the output by pressing OUT
pushbutton.
2. Using the VOLT encoder, adjust the output voltage to approx. 10% of the unit voltage rating.
3. Momentarily press the OVP/UVL button so that the CURRENT display shows “OUP”. The
VOLTAGE display will show the last setting of the OVP level.
4. Rotate the VOLT encoder CCW to adjust the OVP setting to 50% of the unit voltage rating.
5. Wait a few seconds until the VOLT display returns to show the output voltage.
6. Adjust the output voltage toward its maximum and check that the output voltage cannot be in-
creased more than the OVP +1.05 setting.
7. Adjust OVP limit to the maximum by repeating Step 3 and rotating the VOLT encoder C.W.
3.8.6 UVL Check
Refer to Section 5.4 for explanation of the UVL function prior to performing the procedure below.
1. Press the OVP/UVL button TWICE so that the CURRENT display shows “UUL”. The VOLTAGE dis-
play will show the last setting of the UVL level.
2. Rotate the VOLT encoder to adjust the UVL level to approx. 10% of the unit voltage rating.
3. Wait a few seconds until the VOLT display returns to show the output voltage.
4. Adjust the output voltage toward its minimum and check that the output voltage cannot be de-
creased below the UVL x 1.05 setting.
5. Adjust the UVL limit to the minimum by repeating Sep 1 and rotating the VOLT encoder CCW.
3.8.7 Foldback Check
Refer to Section 5.5 for explanation of the FOLD function prior to performing the procedure below.
1. Ensure that the output voltage is set to approx. 10% of the unit rating.
2. Adjust the CURRENT encoder to set the current limit to approx. 10% of the unit rating.
3. Momentarily press the FOLD button. Ensure that the FOLD LED illuminates. The output voltage re-
mains unchanged.
4. Short the output terminals momentarily (approx. 0.5 sec.). Ensure that the output voltage falls to
zero, the VOLT display shows “Fb” and the ALARM LED blinks.
5. Press the FOLD button again to cancel the protection. The output voltage remains zero.
6. Press OUT button. Ensure that the output voltage returns to its last setting.
7. Turn the output off by pressing the OUT button. Ensure that the VOLT display shows “OFF”.
3.8.8 Address Setting
1. Press and hold the REM/LOC button for approx. 3 sec. The VOLT display will show the communi-
cation port address.
2. Using the VOLT adjust encoder; check that the address can be set within the range of 0 to 30.
3.8.9 Baud Rate Setting (RS-232 and RS-485 only)
1. Press and hold the REM/LOC button for approx. 3 sec. The CURRENT display will show the com-
munication port Baud Rate.
2. Using The CURRENT adjust encoder, check that the Baud Rate can be set to 1200, 2400, 4800,
9600 and 19200.
Shorting the output may expose the user to hazardous
voltages. Observe proper safety procedures.
