GarrettCom Magnum 6K16-Series User manual

i
www GarrettCom com .. www GarrettCom com ..
Corporate Headquarters
GarrettCom, Inc.
47823 Westinghouse Dr.
Fremont, CA 94539-7437
Phone [phone]
Fax [phone]
Website: http://www.GarrettCom.com
email [e-mail]
Magnum 6K16-Series
Managed Fiber Switch
Hardware
Installation and User Guide
Ma
g
num 6K16V mounted verticall
y
Two 6K16s mounted side-
by
-side on Tra
y

Magnum 6K16-Series Managed Fiber Switch Installation & User Guide (04/06)
i
www GarrettCom com ..
Magnum
 6K16-Series
Managed Fiber Switch
Hardware
Installation and User Guide
Part #: 84-00136 (Rev. B)
Trademarks
Ethernet is a trademark of Xerox Corporation
NEBS is a trademark of Telcordia Technologies
UL is a registered trademark of Underwriters Laboratories
GarrettCom, Magnum and Personal Switch are trademarks and Personal Hub is a
registered trademark of GarrettCom, Inc.
Important: The Magnum 6K16-Series Managed Fiber Switch contains no
user serviceable parts. Attempted service by unauthorized personnel shall
render all warranties null and void. If problems are experienced with Magnum
6K16-Series Switch products, consult Section 6, Troubleshootings, of this User
Guide.
Copyright 2006 GarrettCom, Inc. All rights reserved. No part
of this publication may be reproduced without prior written permission from
GarrettCom, Inc.
Printed in the United States of America.

Magnum 6K16-Series Managed Fiber Switch Installation & User Guide (04/06)
ii
www GarrettCom com ..
Contacting GarrettCom, Inc
Please use the mailing address, phone and fax numbers and email address listed below:
GarrettCom, Inc.
47823 Westinghouse Dr.
Fremont, CA 94539-7437
Phone [phone]
Fax [phone]
Website: http://www.GarrettCom.com
email [email protected]
Federal Communications Commission
Radio Frequency Interference Statement
Radio Frequency Interference Statement
This equipment generates, uses and can radiate frequency energy and if not
installed and used properly, that is in strict accordance with the manufacturer's
instructions, may cause interference to radio communication. It has been tested and
found to comply with the limits for a Class A computing device in accordance with the
specifications in Subpart J of Part 15 of FCC rules, which are designed to provide
reasonable protection against such interference when operated in a commercial
environment. Operation of this equipment in a residential area is likely to cause
interference, in which case the user at his own expense will be required to take whatever
measures may be required to correct the interference.
Canadian Emission
This Class A digital apparatus meets all requirements of the Canadian
Interference-Causing Equipment Regulations.
Cet appareil respecte toutes les exigences du Réglement sur le matériel du
Canada. Cet appareil est Classe A..

Magnum 6K16-Series Managed Fiber Switch Installation & User Guide (04/06)
iii
www GarrettCom com ..
Table of Contents.............................................................................. Page
1.0
SPECIFICATIONS ............................................................................... 1
1.1 Technical Specifications ...................................................................... 1
1.2 Ordering Information........................................................................... 4
2.0 Introduction............................................................................................ 8
2.1 Inspecting the Package and Product .................................................... 8
2.2 Product Description - Magnum 6K16-Series (6K16/6K16V) ............. 9
2.2.1a Magnum 6K16V, Managed Fiber Switch .................................. 10
2.2.1b Magnum 6K16, Managed Carrier Class Switch ........................ 11
2.2.1c Magnum 6K16-Series family (6K16 and 6K16V), At a glance. 12
2.2.2 Eight-port SFF fiber modules , 100Mb fiber ............................. 13
2.2.3 Eight-Port Copper Module, 6K8-RJ45 ...................................... 14
2.2.4 New PoE(Power Pass-through), model P6KP8-RJ45, 10/100Mb 8-port .... 15
2.2.5 Six-Port “4 + 2” Combo Modules,100Mb fiber......................... 15
2.2.6 Four-Port 10 Mb and 100Mb mm Fiber ST Modules .............. 16
2.2.7 Gigabit (1000Mbps) port modules............................................. 17
2.2.8 Packet Prioritization, 802.1p QOS............................................. 17
2.2.9 Frame Buffering and Flow Control............................................ 18
2.2.10 Managed Network Software ( MNS-6K ) for Magnum 6K8-
Series 19
2.3 Features and Benefits......................................................................... 20
2.4 Applications ....................................................................................... 21
3.0 Installation........................................................................................... 25
3.1 Locating Magnum 6K16-Series Switches.......................................... 25
3.2 Connecting Ethernet Media ............................................................... 25
3.2.1 Connecting Fiber Optic ST-type, “twist-lock”.......................... 26
3.2.2 Connecting Fiber Optic SC-type, "Snap-In".............................. 26
3.2.3 Connecting Single-Mode Fiber Optic ........................................ 26
3.2.4 Connecting Twisted Pair ........................................................... 27
3.2.5 Connecting Twisted Pair............................................................ 27
3.2.6 Connecting Gigabit Media Using GBICs .................................. 28
3.3 DIN-Rail Mounting (Magnum 6K16V)............................................. 28
3.3.1 Mounting Dimensions for 6K16Vwith metal brackets .............. 30
3.3.2 Rack-mounting optionS for Telco and ETSI Standard .............. 31
3.4 Powering the Magnum 6K16-Series Managed Fiber Switch............. 32
3.5 Alarm Contacts for monitoring internal power, and Software Traps.... 32
3.6 6K16-Series Port Module (6KPM) Installation ................................. 33
3.6.1 Preparation for Installing and Removing 6KPMs............................ 33
3.6.2 Installing 6KPM Cards in the Magnum 6K16-Series ................ 35
3.6.3 Removing 6KPM Cards ............................................................. 38
3.7 Connecting a Management Console Terminal to Magnum 6K16-
Series 39
3.7.1 RS-232 (DB-9) Console Com port (Serial port) pin assignments.39

Magnum 6K16-Series Managed Fiber Switch Installation & User Guide (04/06)
iv
www GarrettCom com ..
4.0
OPERATION....................................................................................... 40
4.1 Switching Functionality ..................................................................... 40
4.2 Status LEDs ....................................................................................... 41
4.3 Up-link Manual Switches set as (=) , for RJ-45 port only ................. 41
4.4 Auto-Cross(MDIX) and Auto-negotiation, for RJ-45 ports............... 41
4.5 Flow-control, IEEE 802.3x standard ................................................. 43
4.6 Power Budget Calculations for Magnum 6K16 PM’s with Fiber Media
43
5.0 Intro - Magnum 6K16/6K16V Managed Fiber Switch Port Modules45
5.1 Inspecting the Package and Product .................................................. 45
5.2 6KPM Module Description................................................................ 45
5.2.1 6KP6-RJMST, Combo Module.................................................. 46
5.2.1a 6KP6-RJ10ST, Combo Module ................................................. 46
5.2.1b 6KP4-F10ST, 4@10Mb multi-mode FX-ST “twist lock” Module47
5.2.1c 6KP4-FLSTFX, Module ........................................................... 47
5.2.2. 6KP6-RJMSC Fiber connector ....................................................... 48
5.2.3 6KP6-RJSSC connector ............................................................ 48
5.2.4 6KP6-RJSSCL connector.......................................................... 49
5.2.4a 6KP6-RJ10ST connector .......................................................... 49
5.2.5 6KP8-MTRJ, Small-Form-factor.................................................... 50
5.2.5a 6KP6-MT10ST, ST-Fiber port..................................................... 50
5.2.6 6KP8-45MT, FX , MTRJ Small-Form-Factor .......................... 51
5.2.7 6KP8-MLC, LC connector Small-Form Factor ......................... 51
5.2.8 6KP8-45LC, Combo factor ....................................................... 52
5.2.9 6KP8-RJ45 (Twisted Pair), 10/100Mb 8-Port .......................... 52
5.2.10 New PoE(Power Pass-through), P6KP8V-RJ45 (MDIX), 8-port ........ 53
5.2.11 6KP8-45-2MT, FX , MTRJ Small-Form-Factor........................ 54
5.2.12a 6KP8-45-2LC, single-mode FX , LC Small-Form-Factor ..... 54
5.2.13 GBIC-SXSC Gigabit fiber(1000Mb), multi-mode SC Connector55
5.2.13a GBIC-LXSC Gigabit fiber (1000Mb), SC Connector ........... 55
5.2.14 6KM-BLNK............................................................................... 56
6.0 TROUBLESHOOTING...................................................................... 57
6.1 Before Calling for Assistance ............................................................ 57
6.2 When Calling for Assistance ............................................................. 58
6.3 Return Material Authorization (RMA) Procedure ............................. 58
6.4 Shipping and Packaging Information................................................. 59
APPENDIX A: WARRANTY INFORMATION......................................... 59
APPENDIX B : Internal DC Power Supply Options.................................... 59
APPENDIX C: Internal DC Dual-Source Power Option............................. 62

Magnum 6K16-Series Managed Fiber Switch Installation & User Guide (04/06)
v
www GarrettCom com ..
Revisions
04/06: minor updates as PoE modules option added on Sec 5.2.10/11
10/05: minor updates as MDIX support added on all RJ-45 port modules
02/05: minor updates and tweaks on LC port module
07/04 : 6K16 carrier class managed switch has been added with 6K16V
01/04 : Added Section 3.5 (Alarm Contacts) and 3.7.1 (Console Port pins)
12/03: Updated Section 3.3 “DIN-Rail”, and Appendix B “DC Power” 10/03 :
Initial Release with Rev A

Magnum 6K16-Series Managed Fiber Switch Installation and User Guide
04/06)
www GarrettCom com ..
THE MAGNUM LINE
Ethernet connectivity products
"Designed and Manufactured in the USA"
Overview
GARRETTCOM, INC. OFFERS THE PREMIUM-QUALITY MAGNUM
LINE OF ETHERNET LAN CONNECTIVITY PRODUCTS WITH
INDUSTRY-STANDARD FUNCTIONALITY AND BUILT-IN FIBER
CONFIGURABILITY. MAGNUM PRODUCTS ARE DESIGNED FOR USE
IN DEMANDING CARRIER CLASS, INDUSTRIAL GRADE AND OEM
APPLICATIONS WHERE RELIABILITY IS A PRIMARY
CONSIDERATION.
6K-SERIES MANAGED FIBER SWITCHES, GIGABIT, 100 AND 10
MBPS, FIBER AND COPPER PORTS, MIX-AND MATCH. FEATURES
SFF FIBER AND DC POWER IN 1U UNITS.
4K-SERIES SWITCHES, 100 AND 10 MBPS, COPPER PORTS WITH
OPTIONAL FIBER PORT, WITH AUTO-NEGOTIATING FULL
SWITCHING PERFORMANCE.
QUAD-SERIES FIBER SWITCHES, 100 & 10MBPS, FIBER AND
COPPER PORTS, MIXED-SPEED AND MIXED-MEDIA TYPES, FULL
SWITCHING PERFORMANCE.
“OUTDOOR” ETHERNET SWITCH, FOR TEMPERATURE
UNCONTROLLED LOCATIONS
6 10/100 AND 2 100MB FIBER PORTS, CAN BE CONNECTED IN
STRINGS
MIXED-MEDIA FIBER HUB, 16-PORT STACKABLE,10/100 AUTO-
SENSING
DUAL SPEED 8-PORT AND 16-PORT STACKABLES, 10/100 AUTO-
SENSING
STACKABLE HUBS, SNMP OPTIONAL
10MB SERIES AND 100MB SERIES, BOTH W/ OPTIONAL PORT
MODULES
PERSONAL SWITCHES, 10/100MB
8 PORT DUAL SPEED, AUTO-NEGOTIABLE WITH FIBER OPTION
PERSONAL HUBS, 100MB OR 10/100MB
8-PORT, WITH TWO SWITCHED PORTS (1 FIBER BUILT IN)
PERSONAL HUBS, 10MB SERIES
8-PORT + AUI, STACKABLE TO 5 HIGH, + OPTIONAL BNC OF FIBER
PORT

Magnum 6K16-Series Managed Fiber Switch Installation and User Guide
04/06)
www GarrettCom com ..
8 OR 9-PORT AND 4 OR 5-PORT PERSONAL HUBS, W/ MAN. UP-LINK
SW.
MEDIA CONVERTERS, 10MB AND 100MB SERIES
ALL MEDIA COMBINATIONS, INCL. FIBER ST, SC, MM., SINGLE
MODE
THE “X-LINE” OF CONFIGURABLE MIXED MEDIA PRODUCTS:
STACKABLE CONCENTRATORS, SNMP OPTIONAL, 13-PORTS
MINI-CONCENTRATORS, 7 PORTS, REPEATERS, 2-PORTS
REPEATER PORT MODULES (RPMS),6 TYPES FOR ETHERNET
MEDIA
BRIDGE PORT MODULES (BPMS), 4 TYPES, FOR SEGMENT
ISOLATION
TRANSCEIVERS, 10MB SERIES MINI-TRANSCEIVERS AND COAX
MODELS FEB, 05

Magnum 6K16-Series Managed Fiber Switch Installation and User Guide (04/06)
1
www GarrettCom com ..
1.0 SPECIFICATIONS
1.1 Technical Specifications
Performance
Filtering / Forwarding Rate:
Ethernet(10Mb):14,880 pps
Fast Ethernet(100Mb): 148,800 pps
Gigabit Ethernet(1000Mb): 1, 488,000 pps
Switching Processing Type: Store and Forward with IEEE 802.3x full-
duplex flow -control, non-blocking
Data Rate: 10Mbps,100Mbps and 1000Mbps
Address Table Capacity: 4K node, self-learning with address aging
Packet buffer size : 240KB for 10/100 and 120KB for 1000Mb
Latency: 5 s + packet time (100 to 100Mbps)
15 s + packet time (10 to 10 Mbps, and 10 to 100Mbps)
Network Standards and Compliance, hardware
Ethernet V1.0/V2.0 IEEE 802.3: 10BASE-T,
IEEE 802.3u: 100Base-TX, 100BASE-FX
IEEE 802.3z: 1000BASE-TX Ethernet (Auto-Negotiation)
IEEE 802.3ab: 1000BASE-TX Ethernet
IEEE 802.1p: Priority protocol
IEEE 802.1d: Spanning tree protocol
IEEE 802.1q: VLAN Tagging
IEEE 802.3x: Flow Control
Maximum 10 Mbps Ethernet Segment Lengths
Unshielded twisted pair - 100 m (328 ft)
Shielded twisted pair - 150 m (492 ft)
10BASE-FL multi-mode fiber optic - 2 km (6,562 ft)
10BASE-FL single-mode fiber optic - 10 km (32,810 ft)
Maximum Standard Fast Ethernet Segment Lengths:
10BASE-T (CAT 3, 4, 5 UTP) - 100 m (328 ft)
100BASE-TX (CAT 5 UTP) - 100 m (328 ft)
Shielded twisted pair - 150 m (492 ft)
100BASE-FX, half-duplex, multi-mode - 412 m (1350 ft)
100BASE-FX, full-duplex, multi-mode - 2.0 km (6,562 ft)
100BASE-FX, half-duplex, single-mode - 412 m (1350 ft)
100BASE-FX, full-duplex, single-mode - 20.0 km (66K16-Series ft)
100BASE-FX, full-duplex, Long Reach - 40.0 km (122K ft)
Maximum Standard Gigabit Ethernet Segment Lengths:
1000BASE-T (CAT5e or higher is recommended) - 100 m (328 ft)
1000BASE-SX, full-duplex, multi-mode(62.5m cable) - 220m
1000BASE-SX, full-duplex, multi-mode(50m cable) - 550m
1000BASE-LX, full-duplex, single-mode(62.5m cable) -5Km
Fiber Multi-mode connector types supported:
Fiber Port, ST-type (twist-lock):Fiber multi-mode, 10Mb 10BASE-FL
Fiber Port, MTRJ-type (plug-in):SFF Fiber multi-mode100BASE-FX
Fiber Port, SC-type (snap-in):Fiber optic multi-mode, 100BASE-FX
Fiber Port, ST-type (twist-lock): Fiber optic m.-mode, 100BASE-FX
Fiber Port, 1000BASE-FX, GBIC modules

Magnum 6K16-Series Managed Fiber Switch Installation and User Guide (04/06)
2
www GarrettCom com ..
Fiber Single-mode connector types:
Fiber Port, SC-type: Fiber optic single-mode, 100BASE-FX
Fiber Port, LC-type Fiber SFF single-mode, 100BASE-FX
Fiber Port, 1000BASE-FX, GBIC modules
LEDs: Per Port (one set at the port, one set on rear top) 6K16V only
Per Port (one set at the port) 6K16
LK: Steady ON when media link is operational
ACT: ON with receiver port activity
FDX/HDX: ON = Full-Duplex Mode
OFF = Half-Duplex Mode
100/10: ON = 100Mbps speed
OFF = 10 Mbps
Operating Environment
Ambient Temperature:
-40to 140F (-40to 60C) for UL60950 and Component Parts rating
-60to 205F (-50to 95C) for IEC 60068 Type Test short term rating
Storage Temperature: -60to 210F (-50to 100C)
Ambient Relative Humidity: 5% to 95% (non-condensing)
Altitude: -200 to 13,000 ft. (-60 to 4000m)
Conformal Coating (humidity protection) option: Request quote
Alarm Relay Contacts
One NC indicating internal power, one NC software controllable
Packaging
Enclosure: Rugged High strength sheet metal.
Dimensions: 9.5 in. H x 8.75 in. W x 1.75 in. D
24.1 cm H x 22.2 cm W x 4.4 cm D
Cooling method: Convection, designed for vertical mounting, no fans (6K16V)
Cooling method: fan cooling, three rear fans (6K16)
Weight: 4.21 lbs. (1.9 kg)
Management Console connector
DB-9 for RS-232 “null-modem” cable (sometimes called an X-modem cable)
Power Supply (Internal)
AC Power Connector: IEC-type, male recessed at rear of chassis,
Input Voltage: 100 to 240 VAC (auto-ranging)
Input Frequency: 47 to 63 Hz (auto-ranging)
Power Consumption:
50 watts typical (for a fully loaded fiber model)
30 watts typical (for a fully-loaded copper only model)
DC Power Supply (Options)
-48VDC Power Input Voltage : -36 to -70 VDC
24VDC Power Input Voltage : 20 to 36VDC
125VDC Power Input Voltage : 115 to 150VDC
5VDC Power Input Voltage : (+) or (-) 5%
Std. Terminal Block : “ -, GND, + ”
Power Consumption: same as for AC models, see above

Magnum 6K16-Series Managed Fiber Switch Installation and User Guide (04/06)
3
www GarrettCom com ..
For DC internal power supplies at –48VDC, 24VDC and 125VDC,
including Dual Source options (
for continuity of operation when either of the
DC input sources are interrupted) , see Appendices B and C.
Per-port MDI or MDIX on RJ-45
The copper daughter board has MDI-MDIX Auto-crossover on all the RJ-45
ports., and eliminate the use of cross-over cable between the devices. Also
port-specific user settings (such as FDX or HDX, copper 10/100 speed) can
be fixed using software commands.
Mountings:
Vertical mounting only Suitable for wall or DIN-Rail mounting (6K16V)
Horizontal , Rack-mount, 2 units side-by-side on 19” or 21”rack (6K16)
Agency Approvals and Standard Compliance
Magnum 6K16V
UL listed (UL60950), cUL, CE
Emissions meet FCC Part 15 Class A
NEBS Level 3 and ETSI Compliant
IEEE 1613 Environmental Standard for Electric Power Substations
IEC 61850 EMC and Operating Conditions Class C for Power Substations
NEMA TS-2 and TEES for traffic control equipment
Magnum 6K16
UL listed (UL60950), cUL, CE
Emissions meet FCC Part 15 Class B
IEEE 1613 Environmental Standard for Electric Power Substations
IEC 61850 EMC and Operating Conditions Class C for Power Substations
NEBS Level 3 and ETSI Compliant
NEMA TS-2 and TEES for traffic control equipment
Warranty: Three years, per UL 60950 temperature rating Made in USA
Email
[email protected] for details.

Magnum 6K16-Series Managed Fiber Switch Installation and User Guide (04/06)
4
www GarrettCom com ..
1.2 Ordering Information
Magnum Managed Fiber Switch (16 ports max)
MODEL DESCRIPTION
Magnum 6K16V -Magnum 6K16V Managed Fiber Switch, base unit for vertical
mounting. Worldwide AC power. May be configured with a selection of 10/100/1000
fiber and copper port connector types, 16 total ports max. Two metal brackets for vertical
wall or panel mounting. Wire speed filtering and forwarding across all ports, 802.3x flow
control, 802.1p priority packet processing, self-learning 4K-node address table, large
240KB packet buffers for 10/100 and 120KB for 1000Mb. For licensed managed networks
software (MNS-6K and S-ring), See separate data sheets.
Magnum 6K16V -24VDC: Same as 6K16V except the power input is 24VDC
Magnum 6K16V -5VDC: Same as 6K16V except the power input is 5VDC reg &
fused
Magnum 6K16V-48VDC: Same as 6K16V except the power input is –48VDC
Magnum 6K16V-125VDC: Same as 6K16V except the power input is 125VDC
Configuration Options:
Each Magnum 6K16V base unit has TWO port module slots
Magnum 6K16V Port Modules
6KP8V-MTRJ SFF Fiber module, w/eight 100Mb mm FX MT-RJ connectors
6KP8V-MLC SFF Fiber module, w/eight 100Mbps mm FX LC connectors
6KP8V-SLC SFF Fiber module, w/eight 100Mbps sgl-m FX LC connectors
6KP4V-FXSC “2+2” 100Mb Fiber module, w/ four 100Mb 2km FX SC connectors
6KP4V-FXST “2+2” 100Mb Fiber module, w/ four 100Mb 2km FX ST connectors
6KP4V-F10ST “2+2” 10Mb Fiber module, w/ four 10Mb 2km FL ST connectors
6KP4V-FLSTFX “2+2” ST Fiber module, w/ two 100Mb & two 10Mb ports, 2km
6KP8V-45-2MT “6+2” module, w/six RJ-45 ports and two 100Mb 2km FX MTRJ’s
6KP8V-45-2LC “6+2” module, w/six RJ-45 ports and two 100Mb 2km FX LC’
6KP8V-RJ45 TP Module, w/eight 10/100Mbps auto-negotiating RJ-45 ports
6KP8V-45MT “4+4” module, w/four RJ-45 ports and four 2km mm FX MT-RJ’s
6KP8V-45MLC “4+4” module, w/four RJ-45 ports and four 2km mm LC connectors
6KP8V-45SLC “4+4” module, w/four RJ-45 ports and four 2km sgl-m LC connectors
6KP6V-RJMST “4+2” module, w/four RJ-45 ports and two 2km mm FX ST’s
6KP6V-RJMSC “4+2” module, w/four RJ-45 ports and two 2km mm FX SC‘s
6KP6V-RJSSC “4+2” module, w/four RJ-45 ports and two 20km Sgl.m FX SC’s
6KP6V-RJSSCL “4+2” module, w/four RJ-45 ports and two 40km Sgl.m FX SC’s
6KP6V-MT10ST “4+2” module, w/four MTRJ ports and two 10Mb 2km FL ST’s
6KP6V-RJ10ST “4+2” module, w/four RJ-45 ports and two 10Mb 2km FL ST ‘s
6KM-BLNK Blank cover for one 6K16V (A,B) module slot opening in a 6K16V
Gigabit (1000Mb) module option for Magnum 6K16V
6KP5V-G4RJ “G+2” module, w/one GBIC transceiver and four 10/100 RJ-45
connectors
6KP3V-G2SC “G+2” module, w/one GBIC transceiver and two 100Mb 2km FX SC

Magnum 6K16-Series Managed Fiber Switch Installation and User Guide (04/06)
5
www GarrettCom com ..
fiber ports connector
GBPMV-2OTX Two-port Gigabit 6K module for 6K16-Series Switches, provides two
GBIC open transceiver port for a user-selectable GBIC transceiver module
GBPMV-COTX One slot Gigabit 6K module for 6K16-Series Switches, uses one 6K16-
Series slot and provides one GBIC open transceiver port for a user-selectable GBIC
transceiver module
DIN-RAIL-VRM Set of two DIN-Rail holders for a secure vertical mount of a 6K16-
Series unit, with screws to attach to metal mounting brackets and to the 6K16-Series case.
Magnum 6K16 -Magnum 6K16 Managed Carrier Class Switch, base unit for Horizontal
or rack-mounting. Worldwide AC power. May be configured with a selection of
10/100/1000 fiber and copper port connector types, 16 total ports max. Wire speed
filtering and forwarding across all ports, 802.3x flow control, 802.1p priority packet
processing, self-learning 4K-node address table, large 240KB packet buffers for 10/100
and 120KB for 1000Mb. For licensed managed networks software (MNS-6K and S-ring),
See separate data sheets.
Magnum 6K16 -24VDC: Same as 6K16 except the power input is 24VDC
Magnum 6K16-48VDC: Same as 6K16 except the power input is –48VDC
Magnum 6K16-125VDC: Same as 6K16 except the power input is 125VDC
Configuration Options:
Each Magnum 6K16 base unit has TWO port module slots
Magnum 6K16 Port Modules
6KP8-MTRJ SFF Fiber module, w/eight 100Mb mm FX MT-RJ connectors
6KP8-MLC SFF Fiber module, w/eight 100Mbps mm FX LC connectors
6KP8-SLC SFF Fiber module, w/eight 100Mbps sgl-m FX LC connectors
6KP4-FXSC “2+2” 100Mb Fiber module, w/ four 100Mb 2km FX SC connectors
6KP4-FXST “2+2” 100Mb Fiber module, w/ four 100Mb 2km FX ST connectors
6KP4-F10ST “2+2” 10Mb Fiber module, w/ four 10Mb 2km FL ST connectors
6KP4-FLSTFX “2+2” ST Fiber module, w/ two 100Mb & two 10Mb ports, 2km
6KP8-45-2MT “6+2” module, w/six RJ-45 ports and two 100Mb 2km FX MTRJ’s
6KP8-45-2LC “6+2” module, w/six RJ-45 ports and two 100Mb 2km FX LC’s
6KP8-RJ45 TP Module, w/eight 10/100Mbps auto-negotiating RJ-45 ports
6KP8-45MT “4+4” module, w/four RJ-45 ports and four 2km mm FX MT-RJ’s
6KP8-45MLC “4+4” module, w/four RJ-45 ports and four 2km mm LC connectors
6KP8-45SLC “4+4” module, w/four RJ-45 ports and four 2km sgl-m LC connectors
6KP6-RJMST “4+2” module, w/four RJ-45 ports and two 2km mm FX ST’s
6KP6-RJMSC “4+2” module, w/four RJ-45 ports and two 2km mm FX SC‘s
6KP6-RJSSC “4+2” module, w/four RJ-45 ports and two 20km Sgl.m FX SC’s
6KP6-RJSSCL “4+2” module, w/four RJ-45 ports and two 40km Sgl.m FX SC’s
6KP6-MT10ST “4+2” module, w/four MTRJ ports and two 10Mb 2km FL ST’s
6KP6-RJ10ST “4+2” module, w/four RJ-45 ports and two 10Mb 2km FL ST ‘s
6KM-BLNK Blank cover for one 6K16-Series (A,B) module slot opening in a 6K16-
Series

Magnum 6K16-Series Managed Fiber Switch Installation and User Guide (04/06)
6
www GarrettCom com ..
Gigabit (1000Mb) module option for Magnum 6K16V
6KP5-G4RJ “G+2” module, w/one GBIC transceiver and four 10/100 RJ-45
connectors
6KP3-G2SC “G+2” module, w/one GBIC transceiver and two 100Mb 2km FX SC
fiber ports connector
GBPM-2OTX Two-port Gigabit 6K module for 6K16-Series Switches, provides two
GBIC open transceiver port for a user-selectable GBIC transceiver module
GBPM-COTX One slot Gigabit 6K module for 6K16-Series Switches, uses one 6K16-
Series slot and provides one GBIC open transceiver port for a user-selectable GBIC
transceiver module
K16-RMB Set of two rack-mount brackets for one 6K16 unit in a 19” RETMA 1U rack
space, with screws to attach the metal mounting brackets to the case. Can add Model K16-
EXTN-KIT to extend to ETSI and 23” rack width.
K16-2TRAY Rack mount tray fro holding two side-by-side 6K16’s in a 19” 1.5U rack
space, each 6K16 unit individually removable for service. Can add Model K16-EXTN-
KIT to extend to ETSI and 23” rack width.
K16-EXTN-KIT Kit of extender brackets for converting one K16-RMB or one K16-
2TRAY to ETSI and/or to 23” Telco rack.
Gigabit(1000Mb) Transceivers option for Mangum 6K16-Series (6K16V/6K16)
GBIC-SXSC GBIC transceiver module for use in GBPM-xOTX, one 1000BASE-SX
port with mm SC fiber connector
GBIC-LXSC10 GBIC transceiver module for use in GBPM-xOTX, one 1000BASE-
LX/LH port with 1310nm sgl. mode SC(10km) fiber connector
GBIC-LXSC25 GBIC transceiver module for use in GBPM-xOTX, one 1000BASE-
LX/LH port with 1310nm sgl. mode SC(25km) fiber connector
GBIC-ZXSC40 GBIC transceiver module for use in GBPM-xOTX, one 1000BASE-ZX
port with 1550nm, sgl. mode SC(40km) fiber connector
GBIC transceiver module for use in GBPM-COTX, one LX port with mm SC fiber
connector
GBIC-ZXSC70 GBIC transceiver module for use in GBPM-xOTX, one 1000BASE-ZX
port with 1550nm, sgl. mode SC(70km) fiber connector
GBIC-TP GBIC transceiver module for use in GBPM-xOTX, one 802.3ab
1000BASE-T port, RJ-45 connector
CONSOLE CBL Industry standard serial cable, DB-9 connectors for RS-232 “ null-
modem “ connection (sometimes called an X-modem cable), used to connect a PC or a
character terminal to the Management port.
CONSOLE USB Industry standard serial cable, DB-9 connectors for RS-232 “ null-
modem “ connection (sometimes called an X-modem cable) to connect to a managed
switch, and a USB port to connect to a PC
Please see next page for PoE option and Modules

Magnum 6K16-Series Managed Fiber Switch Installation and User Guide (04/06)
7
www GarrettCom com ..
6K PoE Modules with 48VDC Pass-Through
Configuration options: only one A, B or C module slot of 6K-Series switch with
48VDC power input may be configured with a PoE Modules
New P6KP8-RJ45 8 port PoE module for 6ks with 48vdc PS, w/eight PoE power source
10/100 auto-negotiating auto cross RJ-45 ports.
New P6KP8-45RJ “4+4” port PoE module for 6ks with 48vdc PS, w/four PoE power
source and four 10/100 auto-negotiating auto cross RJ-45 ports
New P6KP8-45MT “4+4” port PoE module for 6ks with 48vdc PS, w/four PoE power
source and four 100 Mb 2km mm FX MTRJ connectors
New P6KP8-45MLC “4+4” port PoE module for 6ks with 48vdc PS, w/four PoE power
source and four 100 Mb 2km mm FX LC connectors
New P6KP8-45SLC “4+4” port PoE module for 6ks with 48vdc PS, w/four PoE power
source and four 100 Mb 15km sm FX LC connectors
New P6KP8-45-2MT “6+2” port PoE module for 6ks with 48vdc PS, w/four PoE power
source and two normal RJ-45 10/100 ports +two100 Mb 2km mm FX MTRJ connectors
New P6KP8-452SLC “6+2” port PoE module for 6ks with 48vdc PS, w/four PoE power
source and four 100 Mb 15km Sm FX LC connectors
New P6KP6-RJMST “4+2” port PoE module for 6ks with 48vdc PS, w/four PoE power
source and two 100 Mb 2km mm FX ST connectors
New P6KP6-RJMSC “4+2” port PoE module for 6ks with 48vdc PS, w/four PoE power
source and two 100 Mb 2km mm FX SC connectors
New P6KP6-RJSSC “4+2” port PoE module for 6ks with 48vdc PS, w/four PoE power
source and two 100 Mb 20km sm FX SC connectors
New P6KP6-RJSSCL “4+2” port PoE module for 6ks with 48vdc PS, w/four PoE power
source and two 100 Mb 40km sm FX SC connectors
New P6KP6-RJ10ST “4+2” port PoE module for 6ks with 48vdc PS, w/four PoE power
source and two 10 Mb 2km sm FL ST connectors
GarrettCom, Inc. reserves the right to change specifications, performance
characteristics and/or model offerings without notice.

Magnum 6K16-Series Managed Fiber Switch Installation and User Guide (04/06)
8
www GarrettCom com ..
2.0 Introduction
2.1 Inspecting the Package and Product
Examine the shipping container for obvious damage prior to installing this
product; notify the carrier of any damage that you believe occurred during shipment or
delivery. Inspect the contents of this package for any signs of damage and ensure that
the items listed below are included.
This package should contain:
1 Magnum 6K16-Series Managed Fiber Switch, base unit
(configured with user-selected port module options installed)
1 AC Power Cord (U.S. and other 115 VAC only) if AC version
1 Set of two metal vertical mounting brackets, with screws to the case
1 Installation and User Guide (this manual)
1 Product Registration Card
Remove the items from the shipping container. Be sure to keep the shipping
container should you need to re-ship the unit at a later date. To validate the product
warranty, please complete and return the enclosed Product Registration Card to
GarrettCom, Inc. as soon as possible.
In the event there are items missing or damaged, contact the party from whom
you purchased the product. If the unit needs to be returned, please use the original
shipping container if possible. Refer to Section 6, Troubleshooting, for specific return
procedures.

Magnum 6K16-Series Managed Fiber Switch Installation and User Guide (04/06)
9
www GarrettCom com ..
2.2 Product Description - Magnum 6K16-Series (6K16/6K16V)
Magnum 6K16-Series Managed Switches, available as Magnum 6K16 and
6K16V models, and equipped with 16 modular ports, is specially designed to focus on
two different aspects of Ethernet markets to meet their needs and requirements. 6K16-
Series managed switches provide modularity of fiber and copper ports, a mix and
combination of 10Mb, 100Mb and Gigabit speed ports, with comprehensive management
software in a compact industrial-grade package. Setting a new standard for Industrial and
Carrier Class applications, heavy duty Ethernet Switch jobs are readily accommodated
with an extended temperature rating of -40˚C to 60˚C by the UL Component Parts
method, or -50˚C to 95˚C by the IEC 60068 Type Test method. With options such as all
popular DC power input types, worldwide AC power and DIN-Rail mounting, the
hardened Magnum 6K16-Series is a “multi-purpose” Industrial Ethernet Switch.
The large family of port modules offer the choice of all fiber media (all
connector types, multi- and single-mode) and 10/100 Mb auto-negotiating RJ-45 ports.
Standard GBIC ports can be configured for a variety of Gigabit cabling types and
distances.
The 6K16- Series managed switches also provides PoE option via power –
inside PoE modules on one of A or B slot and allows the users to select a wide option of
combo PoE modules to support 802.3af pd devices. See details for PoE modules in sec
5.2.10. The Power Sourcing Equipment (PSE), and are fully compatible with Powered
Devices (PD)(e.g wireless access points, IP phones) that comply with the IEEE 802.3af
PoE standard. The PoE switch ports have an auto-sensing algorithm, so that they provide
power only to 802.3af, PoE end devices. PoE is managed by a multi-stage handshake
to protect equipment from damage and to manage power budgets .The PoE ports
will discontinue supplying power when the PoE powered devices are disconnected, and
support the 802.3af PoE PSE standard for over-current protection, under-current
detection, and fault protection.
High performance features include non-blocking speed on all ports and 802.1p QoS
Traffic Prioritization. Magnum 6K16-Series switches are “plug-and-play” ready for use
as backbone switches where a mix of bursty data traffic and priority streaming traffic for
VoIP and audio/video “Triple Play” applications are present.
Magnum 6K16-Series Fiber Switches are provided with LAN management
software including SNMP, Tag- and Port-based VLANs, IGMP Snooping and Port

Magnum 6K16-Series Managed Fiber Switch Installation and User Guide (04/06)
10
www GarrettCom com ..
Security with control via Web and command line interface (CLI). For high availability
LANs using ring topologies, Spanning Tree Protocol, Link-Loss-Learn and S-Ring
are available. See the Managed Networks Software (MNS-6K) and S-Ring datasheets for
additional details on the comprehensive set of software programs and options.
Magnum 6K16-Series Managed Fiber Switches have heavy duty
metal cases and auto-ranging power supplies for operation with standard AC power
worldwide. Internal DC power supplies are optional. All DC power input types (5V,
24V, 48V, 125V) are supported, and dual source input is optional on all except 5VDC..
Alarm Relay contacts provided on each Magnum 6K16-Series Switch monitor
the hardware and software providing a loss of power signal and user- defined software
events through traps. See Section 3.5 for details.
The wide selections of port modules are key to the flexibility and adaptability.
2.2.1a Magnum 6K16V, Managed Fiber Switch
The Magnum 6K16V model of 6K16-Series family, is primarily designed to use for
vertical mount applications. Equipped with the multi-media fiber/copper solutions,
multiple speed 10/100/1000Mb support, rich MNS-6K management features , hardware
and software alarms and convection cooling (no fans), the Magnum 6K16V easily
qualifies for use in transportation and traffic control systems, power utilities and
industrial factory-floors. For the fast growing demands of video surveillance systems
with segments requiring Gigabit backbone interconnections, the Magnum 6K16V
managed switches are easy to install and operate.
The next generation of industrial applications will need advanced managed network
software, operation at extended temperatures, fiber ports modularity, support for self-
healing ring structures, redundancy, security and gigabit backbone configurability. The
Magnum 6K16V has all of these, in a very sleek and robust metal case with a wide

Magnum 6K16-Series Managed Fiber Switch Installation and User Guide (04/06)
11
www GarrettCom com ..
choice of popular DC options or industry standard AC internal input.
The plug-n-play Magnum 6K16V managed fiber switch, should be mounted vertically
using the vertical mounting brackets which come with the unit or by using the DIN-
RAIL-KIT (optional) for Din rail mounting.
Loaded with versatile management software (MNS-6K), the 6K16V switch can be easily
managed and monitored.
Dual LEDs on the front and the connector side help the vertically mounted 6K16V to be
monitored easily. The modular designed Magnum 6K16V managed fiber switch can
support of maximum four Gigabit modules (fiber or copper) to meet any demand of
bandwidth required applications. In a on-going demand of diversified designed Ethernet
application the Magnum 6K16V is a finest solution to meet and satisfy those requirement
by the rich modular structure. The Relay contacts for external “ALARM” is another
additional feature which allows the Magnum 6K16V to monitor the internal power
failure and controlled via hardware or software trap control.
2.2.1b Magnum 6K16, Managed Carrier Class Switch
The rack-mountable 6K16 model of 6K16-Series family, is a modular managed Carrier
class Switch, which can be mounted horizontally as rack-mount, shown in the picture
below.
Specially designed to cater the requirements for carrier class Telco applications or
factory floor and office purpose solutions, the Magnum 6K16 can be mount side-by-side
on a 19” rack mount tray to provide the needs of port density. Equipped with three fan at
the rear, the fan-cooled Magnum 6K16, through its modular designed and diversified
support of 10/100 or 1000Mb speed can be a excellent gear for the carrier class and
factory floor applications.
The Multi-media (copper and fiber) support loaded with rich management
feature of MNS-6K easily qualified this carrier class switch to meet any demands and

Magnum 6K16-Series Managed Fiber Switch Installation and User Guide (04/06)
12
www GarrettCom com ..
requirement of this space. Magnum 6K management features not only allow the easy
monitoring of the switch through SNMP, but also protect the network through its security
features of port-security, SNMP3, VLAN etc. The redundant feature through STP, RSTP
and S-ring, LLL also allow to configure and control the switch as a fault tolerant device
or self-healing in a ring topology applications
The NEBS and ETSI compliant Magnum 6K16, rack mountable, and specially
designed to support the popular DC options of (24VDC, -48VDC. AND 125VDC) as
well as AC input, easily qualify and make a popular and reliable contender for the
carrier-class Telco and factory-floor applications.
The rich-choice of modules in various flavors of all fiber connectors, multi or
single mode, combo of copper and fiber, and a diversification option to select 10Mb fiber
or 100Mb copper or 1000Mb copper/Fiber are some of the primary benefits, which allow
the Magnum 6K16 to fulfill all the demands and requirements of carrier-class, office and
factory-floor applications.
The Relay contacts for external “ALARM” is another additional feature which allow the
Magnum 6K16 to monitor the internal power failure and controlled via hardware or
software traps.
2.2.1c Magnum 6K16-Series family (6K16 and 6K16V), At a glance
Comparison chart
Features 6K16 6K16V
Mounting Horizontal, Rack-mount Vertical, Din-Rail Panel
Cooling fan cooled, 3 fans Convection
Temp. Rating Office & Factory Factory & Outdoors
Regular Only “V” suffice modules
Module Model #s e.g 6KP8-RJ45 e.g 6KP8V-RJ45
LEDs Front, with ports Front and rear top
Special Ratings NEBs and ETSI P1613 for substations
Power input 24VDC/-48VDC/125VDC Same
or AC(Regular)
MNS-6K Software Managed, preloaded Same
Redundancy LLL, STP,RSTP, S-Ring Same
Controlled via
Alarm Contact Hardware & Software Same
