KVMSwitchTech KVML-4 User manual

PS/2 KVM Switch Installation Guide

KVML
-
4 / KVML
-
8 / KVML
-
16
PS/2 DB
-
15 KVM
Package Content (only for rackmount KVM)
1 KVM switch x 1 pc
2 Screw M3.2 x 4.5mm x 4 pcs
3 Screw M4 x 10mm x 8 pcs
4 Bracket x 1 set
5 User manual x 1 pc
6 Power cord x 1 pc

KVML-4 / KVML-8 / KVML-16
Connection
PS/2 DB-15 KVM
KVML-4
KVML-8
KVML-16

KVML
-
4 / KVML
-
8 / K
VML
-
16
PS/2 DB
-
15 KVM

KVML
-
4 / KVML
-
8 / KVML
-
16
PS/2 DB
-
15 KVM
Cascade
Cascade up to 8 levels, 128 servers
Cascading multiple KVM by KVMCA-6 cable.
KVML
-
16
KVML
-
8
KVMCA
-
6

KVML
-
4 / KVML
-
8 / KVML
-
16
PS/2 DB
-
15 KVM
Cascade
Cascade up to 8 levels, 128 servers
Cascading multiple KVM by KVMCA-6 cable.
KVML
-
16
KVML
-
8
KVMCA
-
6

Specifications
PS/2 DB
-
15 KVM
KVML-4 / KVML-8 / KVML-16


KVM Port
Number of ports: 4, 8 or 16
Connector: DB-15 combo connector
Connectivity: PS/2 3-in-1 KVM cable, up to 6, 10, 15 & 33 feet


Local Console
Graphic connector: 1 x DB-15 VGA
Resolution: Up to 1600 x 1200
Input device: 2 x PS/2 for keyboard & mouse


Management
Multilingual OSD: English, France, German, Spanish, Italian, Russian, Simplified Chin
ese,
Japanese
Hotkey combination: Scroll-lock, Cap-lock, Num-lock, Alt, Ctrl & Win
Security: Password enable & disable, up to 8 users profile for port access
PC Selection: Front button, OSD menu & hotkey


Expansion: Up to 128 servers by 8-level cascade


Compatibility
Multi-platform: Mix PCs, SUNs, IBMs, HPs, DELLs Server
Support: Windows Vista / 2003 / XP / 2000, Linux, Netware, Unix


Power
Input: 100 or 240V AC at 50 or 60 Hz via IEC type cord OR
AC / DC power adapter [email protected] (optional)
Option DC: 12V / 24V / 48V DC input
Consumption: Max. 48 Watt, Standby 5 Watt


Regulatory Approval: FCC, CE


Environmental
Operating: 0 to 50°C
Storage: -5 to 60°C
Relative humidity: 90%, non-condensing
Shock: 50G peak acceleration (11ms, half-sine wave)
Vibration: 58~100Hz / 0.98G (11ms / cycle)


Product Information
Dimension (W x D x H): 446 x 180 x 44 mm / 17.6 x 7.1 x 1.73 inch
Net weight: KVML-4: 3.5 kg / 8 lb
KVML-8 / 1601: 4 kg / 9 lb


Packing Information
Dimension (W x D x H): 510 x 400 x 77 mm / 20.1 x 15.7 x 3 inch
Gross weight: KVML-4: 4 kg / 9 lb
KVML-8 / 1601: 4.5 kg / 10 lb

KVMButton
PS/2 KVM Usage
Power ON


Turn off all servers and KVM switches


Make sure all cables / connectors are properly connected


Recommend Power ON sequence is monitor, KVM switch Þ nally computer
KVML-4)

Password
PS/2 KVM Usage

KVMOSD
PS/2 KVM Usage

KVM Hotkey
PS/2 KVM Usage

Optional Accessories
PS/2 KVM Usage
1. PS/2 3-in-1 KVM cable
1.1 KVMCD-6 6 feet
1.2 KVMCD-10 10 feet
1.3 KVMCD-15 15 feet
1.4 KVMCD-33 33 feet
2. PS/2 KVM cascade cable
2.1 KVMCA-2 2 feet
2.2 KVMCA-6 6 feet
2.3 KVMCA-10 10 feet
2.4 KVMCA-15 15 feet
3. SUN / iMAC USB to PS/2 adapter
3.1 SUN-31 kit
4. Power cord
4.1 IEC power cord
4.2 NEMA 5-15 power cord (US)
4.3 BS 1363 power cord (UK) 4.4
CEE 7/4 power cord (German) 4.5
AS 3112 power cord (Australia)
