GarrettCom Magnum 14E User manual

www GarrettCom com .. www GarrettCom com ..
Corporate Headquarters
GarrettCom, Inc.
213 Hammond Ave.
Fremont, CA 94539
Phone [phone]
Fax [phone]
Website: http://www.GarrettCom.com
email [e-mail]
Magnum 14E Fast Ethernet
Media Converters
(Including SC, ST and MTRJ ports, full/half duplex, mm and sgl. mode, standard Link Pass-through)
$5.00 USD

Magnum14E Media Converters Installation and User Guide(10/02)
i
www GarrettCom com ..
Magnum14E Media Converters
Installation and User Guide
Part #: 84-00065 Rev E
Trademarks
Ethernet is a trademark of Xerox Corporation
NEBS is a trademark of Telcordia Technologies
UL is a registered trademark of Underwriters Laboratories
GarrettCom, Magnum and Personal Switch are trademarks and Personal Hub is a
registered trademark of GarrettCom, Inc.

Magnum14E Media Converters Installation and User Guide(10/02)
ii
www GarrettCom com ..
Important: The Magnum 14E Media Converters contains no user serviceable
parts. Attempted service by unauthorized personnel shall render all warranties
null and void. If problems are experienced with Magnum 14E Media
Converters, consult Section 5, Troubleshooting, of this User Guide.
Copyright 2001 GarrettCom, Inc. All rights reserved. No part
of this publication may be reproduced without prior written permission from
GarrettCom, Inc.
Printed in the United States of America.

Magnum14E Media Converters Installation and User Guide(10/02)
iii
www GarrettCom com ..
Contacting GarrettCom, Inc
Please use the mailing address, phone and fax numbers and email address listed below:
GarrettCom, Inc.
47823 Westinghouse Drive
Fremont, CA 94539
Phone [phone]
Fax [phone]
Website: http://www.GarrettCom.com
email [email protected]

Magnum14E Media Converters Installation and User Guide(10/02)
iv
www GarrettCom com ..
Federal Communications Commission
Radio Frequency Interference Statement
This equipment generates, uses and can radiate frequency energy and if not
installed and used properly, that is in strict accordance with the manufacturer's
instructions, may cause interference to radio communication. It has been tested and
found to comply with the limits for a Class A computing device in accordance with the
specifications in Subpart J of Part 15 of FCC rules, which are designed to provide
reasonable protection against such interference when operated in a commercial
environment. Operation of this equipment in a residential area is likely to cause
interference, in which case the user at his own expense will be required to take whatever
measures may be required to correct the interference.

Magnum14E Media Converters Installation and User Guide(10/02)
v
www GarrettCom com ..
TABLE OF CONTENTS Page
1.0 SPECIFICATIONS.................................................................................... 1
1.1. Technical Specifications................................................................................ 1
1.2 Ordering Information ..................................................................................... 6
2.0 INTRODUCTION ..................................................................................... 7
2.1 Inspecting the Package and Product ............................................................... 7
2.2 Product Description........................................................................................ 9
2.3 Features and Benefits ................................................................................... 14
2.4 Applications ................................................................................................. 16
3.0 INSTALLATION .................................................................................... 20
3.1 Locating the Media Converter Unit.............................................................. 20
3.2 MC14-TRAY for Rack mounting the Magnum 14E .................................... 21
3.3 MC14-TR+PS9 & MC14-TR+PS9X2 19” Rack-mount w/ Power Supply . 23
3.4 Calculating Overall Segment Distances ...................................................... 25
3.4.1 Power budget calculation for fiber media........................................ 25
3.4.2 Segment Distance, full-duplex copper (RJ-45) and fiber................. 27
3.4.3 Segment Distances for half-duplex mode ........................................ 32

Magnum14E Media Converters Installation and User Guide(10/02)
vi
www GarrettCom com ..
TABLE OF CONTENTS (CONTINUED) ...................................... Page
3.4.4 Collision Domain (PDV Calculations) ........................................... 32
3.5 Connecting Fast Ethernet Media ............................................................... 40
3.5.1 Connecting Twisted Pair (RJ-45 Standard) ...................................... 40
3.5.2 Connecting Fiber-FX (SC-type “Snap-In”, and ST, "Twist-Lock") ............. 41
3.5.3 Connecting Fiber-FX (MT-RJ-type Small Form Factor “Snap-In”) ............. 43
4.0 OPERATION........................................................................................... 44
4.1 Power Requirements, Power Supply Types.................................................. 44
4.2 Dual LEDs (Front and Side) Indicators ........................................................ 45
4.3 Up-Link Switch on TX port ......................................................................... 46
4.4 Manual AN/reg (auto-negotiate support, or regular operation) Switch ........ 47
4.5 Standard Link Pass-through feature in all Magnum 14E Models ................ 50
5.0 TROUBLESHOOTING........................................................................... 52
5.1 Before Calling for Assistance....................................................................... 53
5.2 When Calling for Assistance ........................................................................ 54
5.3 Return Material Authorization (RMA) Procedure........................................ 55
5.4 Shipping and Packaging Information ........................................................... 57
APPENDIX A: WARRANTY INFORMATION .................................................. 58

Magnum14E Media Converters Installation and User Guide(10/02)
vii
www GarrettCom com ..
Revisions
Rev E 10/02 :Link-Pass-through feature updated in this revision.
Rev D 09/01 :MC14-TR+PS9 and MC14-TR+PS9X2, 19” Rack-mount with
Power Supply added in this revision.
Rev C 04/01 : Change the company name to GarrettCom, Inc. (Formerly it
was Garrett Communications). There are no changes to the content of the
material at this time.
Rev B 09/00 : Manual AN/reg (auto-negotiate support, or regular operation)
Switch information added.
Rev A 05/00 : This revision is the initial release of the 14E media Converters
user manual.

Magnum14E Media Converters Installation and User Guide (10/02)
1
www GarrettCom com ..
1.0 SPECIFICATIONS
1.1. Technical Specifications
Performance:
Data Rate: 100 Mb/s
Half- or Full-Duplex transparent, F/H auto-negotiation supported
200ns (20 bit-times) Path Delay Value (PDV) for conversion delay
Network Standards:
Fast Ethernet IEEE 802.3u: 100BASE-TX, 100BASE-FX
Operating Environment:
Ambient Temperature: 32ºF to 120ºF (0ºC to 50ºC)
Storage Temperature: -20ºC to 60ºC
Ambient Relative Humidity: 10% to 95% (non-condensing)

Magnum14E Media Converters Installation and User Guide (10/02)
2
www GarrettCom com ..
Maximum Standard Fast Ethernet Segment Lengths:
100BASE-TX (twisted pair): 100 m (328 ft)
100BASE-FX Fiber optic, half-duplex: (multi-mode) 412 m (1350 ft)
100BASE-FX Fiber optic, full duplex: (multi-mode) 2.0 km (6,562 ft)
100BASE-FX Fiber optic, half-duplex: (single-mode) 412 m (1350 ft)
100BASE-FX Fiber optic, full duplex: (single-mode) 25 km (66k ft)
100BASE-FX Long Reach: Fiber optic, full duplex: (single -mode) 40 km (132k ft)
Note: Magnum 14E Media Converters DO NOT support full length
shared Fast Ethernet segments. See Section 3.2 of this manual for
media lengths and shared segment distance calculations.
Power Supply (External):
Power Input: 95 - 125 vac at 60 Hz for "-d" Models,
100 - 240 vac at 50 Hz for "-i" Models which have
IEC power cable connector.
Power Consumption: 4 watts typical
Power Adapter: 9VDC, 1.0 Amps; center positive
Note: Optional –48vdc and 24vdc external power units are available

Magnum14E Media Converters Installation and User Guide (10/02)
3
www GarrettCom com ..
Connectors:
RJ-45 Port: 8-Pin female, with “cross-over” up-link switch
Note: The AN/reg manual switch is for user-selected auto-negotiation support,
or for regular operation. See Section 4.4
Fiber, multi-mode (up to 2Km) :
SC-type (snap-in): Fiber optic multi-mode, 100BASE-FX
ST-type (twist-lock): Fiber optic multi-mode, 100BASE-FX
MT-RJ-type, Small Form Factor (plug in): Multi-mode, 100BASE-FX
Fiber, single-mode (25-Km and up):
SC-type (snap-in): Fiber optic single-mode, 100BASE-FX, 25Km
SC-type (snap-in): “Long-Reach” single-mode, 100BASE-FX, 40Km

Magnum14E Media Converters Installation and User Guide (10/02)
4
www GarrettCom com ..
Packaging:
Enclosure: High strength sheet metal.
Dimensions: 3.5 in H x 3.0 in W x 1.0 in D (8.9 cm x 7.6 cm x 2.5 cm)
**Power Supply: 2.0 in x 2.0 in x 1.5 in (5.1 cm x 5.1 cm x 3.8 cm)
Weight: 4.6 oz. (130 gr); Power Supply 1.0 lb (455 gr)
LED Indicators for the Magnum 14E (Dual, on front and on end) :
PWR Indicates unit is receiving DC power.
Note: Magnum 14E has Link Pass-through feature, see Section 4.5
LINK, Fiber port Steady ON when both attached cable segments are operational
at their respective other ends, blinking when receiving remote
fault from the other end.

Magnum14E Media Converters Installation and User Guide (10/02)
5
www GarrettCom com ..
LINK, Copper port Steady ON when the attached cable segments are
operational at their respective other ends
RX/ACT Activity, blinking indicates port is receiving
Agency Approvals:
UL Listed (UL 1950), cUL , CE Certified
Emissions: Meets FCC Part 15 Class B, cUL, CE
Warranty: Three years, return to factory Made in USA

Magnum14E Media Converters Installation and User Guide (10/02)
6
www GarrettCom com ..
1.2 Ordering Information
GarrettCom, Inc. reserves the right to change specifications, performance
characteristics and/or model offerings without notice.
Model Number Description
Magnum 14E-SC-d Twisted pair to mm fiber SC, ext. 115 vac, 60Hz power supply
Magnum 14E-SC-i Twisted pair to mm fiber SC, ext. 230 vac, 50Hz power supply
Magnum 14E-ST-d Twisted pair to mm fiber ST, ext. 115 vac, 60Hz power supply
Magnum 14E-ST-i Twisted pair to mm fiber ST, ext. 230 vac, 50Hz power supply
Magnum 14E-MT-RJ-d Twisted pair to fiber MT-RJ small form factor, ext. 115 vac, 60 Hz PS
Magnum 14E-MT-RJ-i Same as Magnum 14E-MT-RJ, but with ext.230 vac, 50 Hz PS
Magnum 14E-SSC-d Twisted pair to fiber SC, single-mode std 25Km, ext. 230vac, 50 Hz PS
Magnum 14E-SSC-I Same as Magnum 14E-SSC, but with ext 230vac, 50 Hz PS
Magnum 14E-SSCL-d Twisted pair to fiber ST, single mode 40km “Long Reach”, external 115vac, 60
Hz Power Supply
Magnum 14E-SSCL-i Same as Magnum 14E-SSCl, but with ext 230vac, 50 Hz PS
MC14-TR+ PS9 = 19” Rack-mount tray , support upto 10 units of 100Mbps 14E Fiber Media Converters,Uses 2U
rack space, has space for a few external PS units (which are part of the MC’s)
MC14-TR+PS9X2 = Powered 19” Rack-mount tray for 100Mb, 14E (and 10Mbps, TF14 mix and match) Media
Converters, up to 16 units @ 9vdcs. Uses 2U rack space. Includes common multi-unit Power Supply for universal
AC input, 55 watts at 9vdc, and power cabling for the MC’s

Magnum14E Media Converters Installation and User Guide (10/02)
7
www GarrettCom com ..
2.0 INTRODUCTION
This section describes the Magnum 14E Fast Ethernet Media Converters, including
appearance, features and possible applications.
2.1 Inspecting the Package and Product
Examine the shipping container for obvious damage prior to installing this product;
notify the carrier of any damage which you believe occurred during shipment or delivery.
Inspect the contents of this package for any signs of damage and ensure that the items listed
below are included.
This package should contain:
1 Magnum 14E Media Converter unit
1 External Power Supply, either 115 vac 60 Hz or 230 vac 50 Hz

Magnum14E Media Converters Installation and User Guide (10/02)
8
www GarrettCom com ..
1 Set of two (2) metal mounting clips, with screws
1 VelcroTape section, approximately 3 inches in length
1 User Guide (this manual) and Product Registration Card
Remove the Magnum 14E Media Converter from the shipping container. Be sure to
keep the shipping container should you need to store or to ship the unit at a later date. To
validate the product warranty, please complete and return the enclosed Product Registration
Card to GarrettCom, Inc. within two weeks of purchase.
In the event there are items missing or damaged, contact your supplier. If you need
to return the unit, use the original shipping container. Refer to Section 5, Troubleshooting, for
specific return procedures.

Magnum14E Media Converters Installation and User Guide (10/02)
9
www GarrettCom com ..
2.2 Product Description
Magnum 14E Fast Ethernet Media Converters offer a convenient, cost-effective and
graceful way to incorporate fiber media into a 100BASE-TX Ethernet network. Each Magnum
14E supports both full- and half-duplex mode transparently so that an attached RJ-45 switch or
hub operates at its highest performance level. For support of “N-way” auto-negotiating
switches, a manual AN/reg switch on the Magnum 14E allows the user to manually enable
either (a) “AN” for auto-negotiation, where the 14E transmits applicable auto-negotiation Fast
Link Pulses (FLPs) from the RJ-45 port to the connected 10/100 switch port at Link-enable, or
(b) “reg” regular media converter mode, no auto-negotiation.
Magnum 14E Media Converters are designed for quick and easy installation even in
very tight spaces. Media cables are easily attached. Magnum 14E Media Converters feature an
up-link switch on the TX port to eliminate the need for a special cross-over cable when

Magnum14E Media Converters Installation and User Guide (10/02)
10
www GarrettCom com ..
connecting the TX port to a switch or hub. Because of their compact size, Magnum Media
Converters can be Velcro®-mounted on an office wall or the side of a desk or cabinet. The
external power supply, 115vac 60Hz or 230vac 50Hz, plugs into a nearby AC wall socket or
power strip. Each 14E Media-Converter features a two full sets (front and side) of LEDs that
convey essential status information in any mounting arrangement. See Section 4.1, LED
Indicators, for LED function information.
Magnum 14E Media Converters are designed to operate at high ambient temperatures
over an extended period, making them some of the most reliable in the industry. Their high-
strength fabricated metal packaging shields against Radio Frequency Interference (RFI) and
Electromagnetic Interference (EMI), avoiding interference with other nearby electronic
devices.

Magnum14E Media Converters Installation and User Guide (10/02)
11
www GarrettCom com ..
The Magnum 14E units comply with the IEEE 802.3u (100BASE-TX and 100BASE-
FX) specification for 100 Mb/sec traffic via shielded (STP) or unshielded twisted pair (UTP)
segments.
The Link Pass-Through feature is especially
desirable for use in managed networks, and is
standard in all 14E’s. Magnum 14E-ST models
are equipped with one multi-mode fiber-ST and
one RJ-45 connector for connection into
100BASE-FX segments.
14Es with ST integrates 100BASE-TX and FX networks, with fiber ST connector
Twisted Pair
(100BASE-TX)
Fiber Multi-mode
(ST-type)
(100BASE-FX)
Magnum 14E
Media Converter
TX RX
9VDC .3AMP
UP LINK
Link
RX/ACT
RX\ACT
Link
Pwr
FIBER
TWISTEDPAIR
Link
Rx/Act
Link
An/FF
Act

Magnum14E Media Converters Installation and User Guide (10/02)
12
www GarrettCom com ..
The Magnum 14E-SC comes in three models, with three different fiber transceivers.
Models are 14E-SC (multi-mode, 2Km), 14E-SSC (single-mode, 25Km) or 14E-SSCL (single-
mode Long Reach, 40Km) are
equipped with one fiber SC-type
port and one RJ-45 port for
connection into 100BASE-FX
and 100BASE-TX compliant
Fast Ethernet network segments.
14Es with SC integrate 100BASE-TX and FX networks, with fiber SC connectors.
Magnum 14E
Media Converter
TX RX
9VDC .3AMP
UP LINK
Link
RX/ACT
RX\ACT
Link
Pwr
FIBER
TWISTED P AIR
Link
Rx/Act
Link
An/FF
Act
Twisted Pair
(100BASE-TX)
Multi- or Single mode
(SC-type)
Fiber
(100BASE-FX)
