GAS GAS EC - PART LIST 2009 User manual

EC / SM 4T 2009
Manillar / Handlebar
1

Nº DESCRIPCION / DESCRIPTION EC 2009 SM 2009 Cant.
1 JUEGO DE EMPUÑADURAS / HANDLEBAR GRIP (PAIR) BE250236002 1
2 PUÑO DE GAS / TWIST GRIP BE25724007 1
3 CABLE DE GAS / THROTTLE CABLE BFS450524008 1
4 MANILLAR COMPLETO / STEERING HANDLEBAR SET BE250624001 1
5 TAPABOMBA FRENO / BRAKE PUMPCOVER BC25922210 1
6 TORNILLO TAPABOMBA / BRAKE PUMP SCREW BC25922217 2
7 GOMAANTIESPUMANTE / NO-FOAM RUBBER BC25922216 1
8 TORNILLO ESPECIAL / SPECIALSCREW BC25922212 1
9 MANETA FRENO DELANTERO / FRONT BRAKE LEVER BC250022045 BE250122045SM 1
10 TENSOR MANETA BOMBA/ PUMP LEVER TENSOR BC25922218 1
11 GUARDAPOLVO / DUST COVER BC25922213 1
12 CASQUILLO SILENTBLOCK SILENCIADOR / EXHAUST SILENTBLOCK BUSHING - BE250026000 1
13 ARANDELA LATIGUILLO 10X14X1 / 10X14X1 HOSE WASHER BE25622008 3
14 LATIGUILLO FRENO DELANTERO / FRONT BRAKE HOSE BE250422002 BE250222002SM 1
15 INTERRUPTOR 23.024/1 STOP BOMBANISSIN / NISSIN PUMP STOP 23.024/1 SWITCH BE250034003/2 BE250134003SM 1
16 BRIDA SUJECIÓN MANILLAR INFERIOR / HANDLEBAR CLAMP(LOWER) BE250614013 2
17 KIT PISTÓN BOMBAFRENO “A” / “A” BRAKE PUMP PISTON KIT BC25922219 1
18 TORNILLO ESPECIAL 10 X 45 / SPECIALSCREW 10 X 45 T0201045 2
19 CONMUTADOR ARRANQUE / STARTING COMMMAND BFS450734033 1
20 TUERCAAUTOBLOCANTE BAJAM10 CON ARANDELA/ M10 SELF-LOCKING NUT M01613001 2
21 CONMUTADOR LUZ HALÓGENA / LIGHTSWITCH HALOGEN EFS602004509 1
22 LATIGUILLO EMBRAGUE / CLUTCH HOSE BFS450522003 1
23 DEPÓSITO LÍQUIDO FRENOS SM / SM BRAKE FLUID TANK - BE250110016SM 1
24 TORNILLO REGULACIÓN MANETA/ ADJUSTING LEVER SCREW BT27922046 1
25 SOPORTE BOMBAEMBRAGUE / CLUTCH PUMP CLAMP BE250022211 1
26A MANETA EMBRAGUE CORTA / SHORT CLUTCH LEVER BT27922040 1
26B MANETA EMBRAGUE LARGA(SERIE) / LONG CLUTCH LEVER (STANDARD) E200801 1
27 TUERCA M6 BAJA/ M6 LOW NUT T2006001 1
28 BOMBA EMBRAGUE HIDRÁULICO / HYDRAULIC CLUTCH PUMP BE250522009 1
29 KIT TAPABOMBA FRENO Y EMBRAGUE / CLUTCH AND BRAKE PUMP COVER KIT BE250522210 1
30 ESPEJO RETROVISOR / REAR-VIEW MIRROR L300760 1
31 BRIDA SUJECIÓN MANILLAR SUPERIOR / HANDLEBAR CLAMP(UPPER) BE250614012 2
32 TORNILLO SUJECIÓN BRIDAMANILLAR 8X30 / 8X30 CLAMP SCREW T0308030 4
33 BOMBA FRENO DELANTERO / FRONTBRAKE PUMP BC25922008 1
Chasis 1
GAS GAS

EC / SM 4T 2009
Manillar /
Handlebar
1

Nº DESCRIPCION / DESCRIPTION EC 2009 SM 2009 Cant.
34 KIT REPARACIÓN / REPARATION KIT BE250522208 BE250122008SM 1
35 TUBO LÍQUIDO FRENO ABOMBA / BRAKETO PUMP LIQUID HOSE - BFS400310116SM 1
36 GOMA SUJECIÓN CABLEADO / CABLE-HOLDING BAND BFS450320067 2
37 BRIDA PEQUEÑA/ LITTLE CLAMP BE25634010 1
41 BRIDA / CLAMP BC25922211 R361700 1
42 ABRAZADERA MUELLE / SPRING CLAMP BE25610044 2
43 LATIGUILLO FRENO DELANTERO / FRONT BRAKE HOSE - BFS450322002SM 1
44 PROTECCIÓN MANILLAR / HANDLEBAR STEERING PROTECTION BE250724004 1
45 BRIDAS SERRETA / CLAMP BE25634007 2
Chasis 1
GAS GAS

EC / SM 4T 2009
Eléctrico / Electric
2

Nº DESCRIPCION / DESCRIPTION EC 2009 SM 2009 Cant.
2 SENSOR AGUA / WATER SENSOR MFS400180004 1
3 SENSOR AIRE /AIR SENSOR MFS400180003 1
14 REGULADOR / REGULATOR EFS550004508 1
16 INSTALACIÓN ELÉCTRICA FSE / ELECTRICALINSTALLATION EFS100004508 1
30 BRIDA UNEX 4,8X36 / UNEX CLAMP4.8X36 BE25634007 2
31 BOBINA ELDOR / ELDOR COIL EFS500004508 1
37 CENTRALITA / SWITCHBOARD EFS501004508 1
46 TUERCA RÁPIDAM6 / M6 FASTNUT T2606000 1
47 BATERÍA EC400-4T/ EC400 4T BATTERY BFS400134080/3 1
49 RELÉ ARRANQUE / STARTING RELAY BFS400134075/2 1
50 SOPORTE RELÉARRANQUE / STARTING RELAYSUPPORT BFS400334076 1
51 ULS 6X16 T0506016 1
54 GOMA SUJECCIÓN CDI / CDI ELASTIC BAND BE250034100 1
58 SENSOR GIRO / TURN SENSOR MFS450680005 1
59 ALLEN 5x9 / 5x9 ALLEN SCREW T0505009 2
67 ALLEN 6X16 / 6X16 ALLEN SCREW T0306016 2
68 ARANDELA PLANA6X12X1,5 / PLAIN WASHER 6X12X1.5 T4006012 2
73 SOPORTE ECU /ECU SUPORT EE551002508 1
24 ESPUMA FIJACION CAJABATERIA / BATTERY FOAM BFS450734090 1
Chasis 2
GAS GAS

EC / SM 4T 2009
Eléctrico / Electric
2A

Nº DESCRIPCION / DESCRIPTION EC 2009 SM 2009 Cant.
1 CTO. MULTIFUNCIÓN ENDURO 2003 FSE / 2003 ENDURO MULTIFUNCTION EE600002508 1
10 PASACABLES CTA. KM. ENDURO 2003 / CABLE PASS SPEED COUTER BE250334053 2
11 CERRADURA CONTACTO CIERRE / CONTACT LOCK WITH CATCH BFS450334032 1
12 CAJA INTERMITENCIAS / INTERMITENTBOX BFS450434055 BFS450334055 1
13 SOPORTE CAJAINTERMITENCIAS / INTERMITENT BOX SUPPORT BFS450334057 BFS450334057 1
16A INSTALACIÓN LUZ / LGHT INSTALLATION EFS205004508 EFS205004508 1
18 TAPA INTERMITENTE / INDICATOR COVER BE250634120 4
19 BOMBILLA / LAMP L200118 4
22 TORNILLO 6X14ARAND. INC./ 6X14 SCREW WITH WASHER T0556014 1
23 CLAXON / HORN BIE500134020 1
25 BOMBILLA 12V45- 45W / 12V45 – 45W BULB L300125 1
26 ÓPTICA HALÓGENA/ OPTIC HALOGEN EE200002508 1
27 SOP. INTERMITENTE DELANTERO IZQUIERDO / LEFTFRONT INDICATOR HOLDER BE250134020 1
28 TORNILLO CHAPA6,3X16 / SPECIAL SCREW T0706316 2
17 INTERMITENTE DERECHO DEL. / RIGHT FRONT INDICATOR BE250634018 1
39 INTERMITENTE DERECHO TRASERO / RIGHT REAR INDICATOR BE250634021 1
40 ULS 6X16 NEGRO / 6X16 BLACK ULS T0506016N 2
42 INTERMITENTE IZQUIERDO TRASERO / LEFT REAR INDICATOR BE250634022 1
44 LUZ MATRICULA / BE250734124 1
45 PILOTO TRASERO / REAR LIGHT BE250734015 1
55 INTERMITENTE IZQUIERDO DELANTERO / LEFT FRONT INDICATOR BE250634019 1
60 ULS 6X16 / 6X16 ULS SCREW T0506016 1
61 ARANDELA 6X18X1,5 / 6X18X1,5 WASHER T4006018 2
64 TUERCA M6AUTOBLOCANTE BAJA/ LOWER M6 SELF-LOCKING NUT T2106001 2
70 SOPORTE MULTIFUNCIÓN / MULTIFUNCTION SUPPORT BFS450634045 1
71 PLATINA SOPORTE CONMUTADOR / SWITH SUPPORT BFS450634072 1
72 ALARGO INSTALACIÓN PORTA MATRÍCULA/ PLATE SUPPORT EXTEND INSTALLATION BE250734016 1
41 TUERCA M6 CONARAND./M6 NUT T2206000 3
Chasis 2A
GAS GAS

EC 4T/ 2009
Plásticos / Plastics
3

Nº DESCRIPCION / DESCRIPTION EC Cant.
1 CTO. FARO DELANTERO / FRONT HEADLAMP SET BE90500CT2508 1
2 GUARDABARROS DELANTERO EC2008 / EC2008 FRONT FENDER BE91000CT2509 1
3 TAPALATERAL RADIADOR DERECHO / RIGHT SIDE RADIATOR COVER BE91500CT2509 1
4 TAPALATERAL RADIADOR IZQUIERDO / LEFT SIDE RADIATOR COVER BE92000CT2509 1
5 TAPA CAJA FILTRO DRCHA. BE92600CT2509 1
6 TAPA CAJA FILTRO IZQ. BE93100CT2509 1
7 GUARDABARROS TRASERO / REAR FENDER BE93500CT2509 1
10 GUIA LATIGUILLO / GUIDE COVER BE905502508 1
Nº ADH. EC
8 KIT ADHESIVO BASCULANTE / SET TILTING ADHESIVE BFS95500CT4509 1
9 KIT ADHESIVO PROTECTOR BARRA / SETADHESIVE PROTECTIVE BAR 1
-- KITADHESIVO COMPLETO / SETADHESIVE BE950003009 1
Chasis 3
GAS GAS

EC 4T / 2009
Plásticos / Plastics
3A

Nº DESCRIPCION / DESCRIPTION EC Cant.
1 CTO. FARO DELANTERO / FRONT HEADLAMP SET BE90500RCCT2509 1
2 GUARDABARROS DELANTERO EC2008 / EC2008 FRONT FENDER BE91000RCCT2509 1
3 TAPALATERAL RADIADOR DERECHO / RIGHT SIDE RADIATOR COVER BE91500RCCT2509 1
4 TAPALATERAL RADIADOR IZQUIERDO / LEFT SIDE RADIATOR COVER BE92000RCCT2509 1
5 TAPA CAJA FILTRO DRCHA. BE92600CT2509 1
6 TAPA CAJA FILTRO IZQ. BE93100CT2509 1
7 GUARDABARROS TRASERO / REAR FENDER BE93500RCCT2509 1
10 GUIA LATIGUILLO / GUIDE COVER BE90550RC2509 1
Nº ADH. EC515 EC450
8 KIT ADHESIVO BASCULANTE / SET TILTING ADHESIVE BFS95500RCCT5009 BFS95500RCCT4509 1
9 KIT ADHESIVO PROTECTOR BARRA / SETADHESIVE PROTECTIVE BAR 1
-- KITADHESIVO COMPLETO / SETADHESIVE BFS95000RC4509 1
Chasis 3A
GAS GAS

SM 4T 2009
Plásticos / Plastics
3B

Nº DESCRIPCION / DESCRIPTION SM Cant.
1 CTO. FARO DELANTERO / FRONT HEADLAMP SET BFS90500SMCT4509 1
3 TAPALATERAL RADIADOR DERECHO / RIGHT SIDE RADIATOR COVER BFS91500SMCT4509 1
4 TAPALATERAL RADIADOR IZQUIERDO / LEFT SIDE RADIATOR COVER BFS92000SMCT4509 1
5 TAPA CAJA FILTRO DRCHA. BFS92600SMCT4509 1
6 TAPA CAJA FILTRO IZQ. BFS93100SMCT4509 1
7 GUARDABARROS TRASERO / REAR FENDER BFS93500SMCT4509 1
9 KIT PROTECTOR BARRA/ SET PROTECTIVE BAR 1
10 GUIA LATIGUILLO / GUIDE COVER BEH90550SM1209 1
Nº ADH. SM515 SM450
8 KIT ADHESIVO BASCULANTE / SET TILTING ADHESIVE BFS95500SMCT5009 BFS95500SMCT4509 1
-- KITADHESIVO COMPLETO / SETADHESIVE BFS95000SM4509 1
Chasis 3B
GAS GAS

4
EC 2009
Montaje plásticos /
Assembling plastics

Nº DESCRIPCION / DESCRIPTION EH Cant.
1 OPTICA / OPTIC EE200002508 1
2 GOMA FARO / RUBBER LIGHTHOUSE BE25636015 4
5 TORN. PLASTICO / PLASTIC SECREW BE250420063/2 1
8 CASQUILLO GUARDABARROS VALONA / FRONT FENDER BUSHING BE2500141018 4
9 TORN. ESPECIAL 6X20ARAND. / 6X20 SCREW WASHER T0606020 4
11 CTO. PARAMANOS / JOINTPROTECTOR HANDS BE94500SM2508 1
13 CASQUILLO TAPA RADIADOR / RADIATOR CAP LID BE250032060 2
14 ARANDELA NYLON / NYLON WASHER T06065017 2
15 TORNILLO PLASSTICO 4,6X12 / 4,6X12 PLASTIC SCREW T0804612/2 4
16 ARANDELAALUMINIO / ALUMINIUM WASHER BE250511002 4
17 SILLIN / SEAT BE940002508 1
18 FUNDA SILLIN / SEATCOVER BE940012508 1
19 CTO. PORTAMATRICULAS / REAR LICENSE PLATE HOLDER SET BE250720003CT 1
19A PORTAMATRICULAS / REAR LICENSE PLATE HOLDER BE250720003 1
20 LUZ DE FRENO / BRAKE LIGHT BE250734015 1
21 LUZ MATRICULA / LIGHTOF PLATE BE250734124 1
22 TORN. ESPECIAL 6X20 / 6X20 SCREW T0206020 2
23 TORN. PHILIPS 6X25 / PHILIPS SCREW 6X25 T0706025 1
24 CASQUILLO / CAP BE25610007 1
25 ARANDELA / WASHER BE940502509 1
26 ARANDELA NEGRA/ BLACK WASHER BE250710213 1
Chasis 4
GAS GAS

SM 4T 2009
Plásticos / Plastics
SM 2009
Montaje plásticos /
Assembling plastics
4A

Nº DESCRIPCION / DESCRIPTION SM Cant.
1 OPTICA / OPTIC EE200002508 1
2 GOMA FARO / RUBBER LIGHTHOUSE BE25636015 2
3 SOPORTE FARO SM / SM SUPPORT LIGHTHOUSE BEH90510SM1209 1
5 TORN. PLASTICO / PLASTIC SECREW BE250420063/2 1
9 TORN. ESP. CON CASQUILLO 6X13 / SPECIALSCREW CAP 6X13 T0316013 6
11 CTO. PARAMANOS SM / JOINTPROTECTOR HANDS BEH94500SM1209 1
13 CASQUILLO TAPA RADIADOR / RADIATOR CAP LID BE250032060 2
14 ARANDELA NYLON / NYLON WASHER T06065017 2
15 TORNILLO PLASSTICO 4,6X12 / 4,6X12 PLASTIC SCREW T0804612/2 4
16 ARANDELAALUMINIO / ALUMINIUM WASHER BE250511002 4
17 SILLIN / SEAT BE940002508 1
18 FUNDA SILLIN / SEATCOVER BE940012508 1
19 CTO. PORTAMATRICULAS / REAR LICENSE PLATE HOLDER SET BE250720003CT 1
19A PORTAMATRICULAS / REAR LICENSE PLATE HOLDER BE250720003 1
20 LUZ DE FRENO / BRAKE LIGHT BE250734015 1
21 LUZ MATRICULA / LIGHTOF PLATE BE250734124 1
22 TORN. ESPECIAL 6X20 / 6X20 SCREW T0206020 2
23 TORN. PHILIPS 6X25 / PHILIPS SCREW 6X25 T0706025 1
24 CASQUILLO / CAP BE25610007 1
25 ARANDELA / WASHER BE940502509 1
26 ARANDELA NEGRA/ BLACK WASHER BE250710213 1
25 ARANDELA / WASHER BE940502509 1
26 ARANDELA NEGRA/ BLACK WASHER BE250710213 1
Chasis 4A
GAS GAS
G
A
G
A

EC / SM 4T 2009
Chasis / Frame
5
