GasLab CO2Meter SAN-11 User manual

User Manual R1.0 CO2Meter,
Inc.
Personal Safety CO2 Monitor with Data Logging SAN-11

Copyright © GasLab, Inc. All Rights Reserved PAGE 2 of 11
Contents
INTRODUCTION ........................................................................................................................................... 3
FEATURES.................................................................................................................................................... 3
MONITOR...................................................................................................................................................... 3
LCD DISPLAY................................................................................................................................................ 4
OPERATION.................................................................................................................................................. 4
MAINTENANCE............................................................................................................................................. 7
SPECIFICATIONS......................................................................................................................................... 7
TROUBLESHOOTING................................................................................................................................... 8
SUPPORT.................................................................................................................................................... 10
WARRANTY ................................................................................................................................................10
LIABILITY..................................................................................................................................................... 10
RETURNS.................................................................................................................................................... 10
CONTACT US..............................................................................................................................................11
© Copyright 2019, GasLab, Inc. All Rights Reserved. Last modified July 2019
1

Copyright © GasLab, Inc. All Rights Reserved PAGE 3 of 11
INTRODUCTION
Congratulations on your purchase of this CO2Meter SAN-11 Personal CO2 Monitor. CO2Meter
SAN-11 is a smart carbon dioxide (CO2) monitor using NDIR technology to provide long term
stability. The SAN-11 Personal Safety CO2 Monitor with data logging is designed for employees
who work in enclosed areas where carbondioxide buildup may causepersonal harm. It is designed
to alert people in the area with excessive carbon dioxide gas. SAN-11 is shipped fully tested and
calibrated and, with proper use, will provide years of reliable service.
FEATURES
•Audible, visual strobe and vibrating alarms
•Large LCD display
•Rugged design with protective rubber enclosure
•Heavy duty metal clip
•Front facing sensor unit
•Rechargeable Battery 4.2v, 1500mAh
•Micro USB cable and Wall USB charger
•Rechargeable Li-Ion battery –20+ hours per charge
•Man down alarm - leveraging accelerometer technology
•Dual calibration methods: Ambient Air (300-600ppm) and Nitrogen (0-200ppm)
•Automatic atmospheric pressure compensation for CO2 concentrations •No over-
exposure or negative memory effects
•Stable NDIR sensor for CO2 detection.
•CO2, temperature, relative humidity, barometric pressure, and alarm log data logging with time
stamping
•Up to 149,500 time-stamped records in internal memory. Data can be exported via USB
•Has the ability to upgrade firmware online through USB--potential for upgrade after use
MONITOR
1. Visual alarm/strobe
2. Front facing sensor
3. Charging indicator
4. LCD display
5. Power button

Copyright © GasLab, Inc. All Rights Reserved PAGE 4 of 11
6. Temperature units
switching button
7. USB port and charging
inlet
(bottom side)
8. Heavy duty metal clip
9. Factory reset button
LCD DISPLAY
1. Low alarm indicator
2. High alarm indicator
3. Battery indicator
4. CO2 concentration
5. CO2 concentration units (ppm or
% when >9,999 ppm)
6. Calibration icon
7. Man down alarm
8. Air Temperature
9. Temperature unit
(Fahrenheit or centigrade degrees)
10. % Relative Humidity
11. Data logging indicator
OPERATION
1. Power button
1) When the Monitor is turned off, press to turn on the unit.

Copyright © GasLab, Inc. All Rights Reserved PAGE 5 of 11
2) When the Monitor is turned on, press for 3 seconds to turn off the unit.
When the unit is first turned on, it performs 5 seconds countdown for Monitor warm up, then enters
normal displaywith current CO2, temperature,andhumidity readings displayed. The monitor starts
taking measurements when power on and updates readings every 2 seconds.
2. Temperature Units Switching Button
2.1 Temperature Unit
Press shortly to switch two temperature units: °F and °C.
2.2 Menu Status
By pressing the temperature unit switching button for 5seconds, the unit enters into Menu
status. There are six menu items by pressing the temperature unit switching button shortly to
loop switching between AIR, N2, Hx.x, Lx.x, A ON/AOFF, SC, Px, Log and E(exit). The menu
items are described in the following table.
Menu Items
Functional Description
AIR (“ ”)
“AIR” means Ambient Air Calibration. User presses the power button
to implement Ambient Air Calibration (300~600ppm).
N2 (“ ”)
“N2” means Nitrogen Calibration. User presses the power button to
implement Nitrogen Calibration (0~200ppm).
H0.5/H0.5T/H1.
0/H1.5/H3.0
High Alarm Threshold setup.
User presses the power button to switch the high alarm threshold:
H0.5 (5000 ppm), H0.5T (5000 ppm TWA), H1.0 (10000 ppm), H1.5
(15000 ppm), and H3.0 (30000 ppm).
L0.5/L0.5T/L1.0
/L1.5/L3.0
Low Alarm Threshold setup.
User presses the power button to switch the low alarm threshold:
L0.5 (5000 ppm), L0.5T (5000 ppm TWA), L1.0 (10000 ppm), L1.5
(15000 ppm), and L3.0 (30000 ppm).
A ON/ AOFF
(“ ” /
“”)
Setting Man down alarm function on/off.
User presses the power button to switch “A ON” (allowing Man
down alarm) or “AOFF” (prohibiting Man down alarm).
SC (“ ”)
Real time clock setup
User presses the power button to enter the real time clock setup:
a. Press button to switch the time items Year (“ ”), Month (“”),
Day (“ ”), Hour (“ ”), Minute (“ ”), Second (“ ”) and “ ”.

Copyright © GasLab, Inc. All Rights Reserved PAGE 6 of 11
b. In each time item, press button to increase the value until the
correct time. This value is a cyclic change. Press button in “ ”
to save and exit the menu status.
For example, setting the year to 2019 by pressing
button
Setting the month to February by pressing button ”:
Other similar operations.
Px
Data logging period setup
User presses the power button to switch the data logging period:
P30 (30 seconds), P60 (60 seconds), P120 (120 seconds or 2 minutes),
P300 (300 seconds or 5 minutes), P600 (600 seconds or 10 minutes)
and P900 (900 seconds or 15 minutes).
Log (“ ”)
Data logging memory operation
User presses the power button to switch the data logging memory
operation:
EP (Export data logging by USB), RES (Reset the memory), and E (Exit
without operation).
E
User presses the power button to exit the menu status.
3. Alarm Threshold
There are high and low alarm thresholds in SAN-11. Both high and low alarm has five thresholds:
5000 ppm, 5000 ppm TWA, 1.0%, 1.5%, and 3.0%. Obviously, high alarm threshold should not
less than low threshold. They can be same alarm level.
The SAN-11 is equipped with audible, visual and vibration alarms to alert users when the ambient
oxygen concentration exceeds either of the two factory preset alarm levels:
•Danger High Alarm: LED will flash and audible alarm will sound 3x / sec.
•Warning Low Alarm: LED will flash and audible alarm will sound 2x / sec.
4. Automatic Atmospheric Pressure Compensation
The CO2 measurement is affected by atmospheric pressure or altitude changing. When users are
at high altitude, compensation should be madeto assure maximum monitor accuracy. This device
has automatic atmospheric pressure compensation for CO2 concentrations by means of a digital
atmospheric pressure sensor integrated in the unit.
in “
”:
in “

Copyright © GasLab, Inc. All Rights Reserved PAGE 7 of 11
5. Man down alarm
Falling by breathing dangerous gases can cause serious injury and even fatality to workers. If the
Man down alarm function in SAN-11 is set on, SAN-11 can detect falls and send a man down alert
which will activate the audible and visual alarms and alert other people in the area.
The man-down detection uses a three-axis accelerometer to automatically monitor the user’s
movements in order to identify a sudden fall/impact and a lack of movement for a period of 6
seconds.
Once alert, people canturn off the currentman-down alarm by pressing anyone of the two buttons.
6. Reset Button
Users can reset the unit by pushing a reset button through a hole on back of shell.
MAINTENANCE
Calibration
The SAN-11 comes pre-calibrated from the factory. However, the O2 sensor should be calibrated
at least once a year, or as described in your company’s safety procedures. You can perform the
calibration yourself, or you can return it to GasLab for factory calibration at a nominal fee. The
temperature and humidity sensors do not require calibration and should remain accurate for the
life of your unit.
Cleaning and Storage
Apply sparingly with a soft cloth and allow drying completely before using. Do not use soap or
Alcohol cleaning. Do not use aromatic hydrocarbons or chlorinated solvents for cleaning.
SPECIFICATIONS
Method - Dual Beam NDIR (Non-dispersive-Infrared)

Copyright © GasLab, Inc. All Rights Reserved PAGE 8 of 11
Sample Method –Diffusion
Automatic Background Calibration (ABC): Eliminate
Device Specifications
Operating Environment
32°F~122°F (0°C~50°C), <95% RH non-condensing
Storage
14°F~140°F (-10°C~60°C), <99% RH non-condensing
Power Supply
Li-ion battery (4.2V,1500mAh),Micro USB cable w. Wall USB charger
Dimensions
3.9x2.0x1.7 Inch (98x50x42mm)
Weight
4.76 oz. (135 grams)
Out of range of operating conditions will impact the accurate of CO2 measurement.
CO2 Sensor Specifications
Measurement Range
0~65,530ppm(6.55%Vol) display
Display Resolution
1ppm / 0.01%
Accuracy
±40ppm or ±3% of reading
Repeatability
±20ppm @ 400ppm
Temperature Dependence
Typ. ±0.3% of reading per °C or ±4ppm per °C, whichever is greater,
referenced to 25 °C
Pressure Dependence
0.13% of reading per mmHg
Response Time
About 2 min for 90% of step change
Warm-up Time
<5 seconds at 22°C
Measurement interval
2 seconds
Temperature Sensor Specifications
Temperature Range
14~140°F (-10.0~60.0°C) display
Display Resolution
0.1°F (0.1°C)
Display Options
°F/°C switchable
Accuracy
±0.9°F (±0.5°C)
Response Time
5~30 seconds (device must equilibrate with environment)
Relative Humidity Sensor Specifications
Measurement Range
0.0~99.9%RH
Display Resolution
1%RH
Accuracy
±4.5%RH
Response Time
<8 seconds for 63% of step change
TROUBLESHOOTING
Symptom / Issue
Possible Cause / Resolution
Cannot power on
Press the Power Button for more than 5 seconds
Check that the Li-ion battery is charged

Copyright © GasLab, Inc. All Rights Reserved PAGE 9 of 11
If monitor is charged but will not turn on, contact support
Monitor is not recognized
by computer or software
Verify that software and drivers are installed correctly before
attaching monitor to PC.
Verify the software and drivers were installed before the monitor was
plugged into the PC with the USB cable.
Verify that the ftd2xx.dll file is in the same folder as the executable
program.
Try using a different USB cable.
Windows reports
“unknown device” error
Go to Gaslab.com, select the App Notes tab, and follow the
instructions for
AN153: Troubleshooting Software Driver Installation (PDF).
Slow response
The log file stored in the monitor is very large. The monitor needs
time to transfer data to your computer.
Readings do not change
Confirm the monitor is correctly connected to the computer. Make
sure the computer recognizes your monitor and connects with your
monitor successfully.

Copyright © GasLab Inc, All Rights Reserved 10 of 11
SUPPORT
The quickest way to obtain technical support is via email. Please send all support inquires to
[email protected]
Please include a clear, concise definition of the problem and any relevant troubleshooting
information or steps taken so far, so we can duplicate the problem and quickly respond to your
inquiry.
WARRANTY
This meter comes with a 1YEAR (warranty period) limited manufacturer’s warranty, starting from
the date the meter was shipped to the buyer.
During this period of time, GasLab warrants our products to be free from defects in materials and
workmanship when used for their intended purpose and agrees to fix or replace (at our discretion)
any part or product that fails under normal use. To take advantage of this warranty, the product
must be returned to GasLab at your expense. If, after examination, we determine the product is
defective, we will repair or replace it at no additional cost to you.
This warranty does not cover any products that have been subjected to misuse, neglect, accident,
modifications or repairs by you or by a third party. No employee or reseller of GasLab’s products
may alter this warranty verbally or in writing.
For more information visit our website: Gaslab.com/pages/terms-conditions
LIABILITY
All liabilities under this agreement shall be limited to the actual cost of the product paid to GasLab.
In no event shall GasLab be liable for any incidental or consequential damages, lost profits, loss
of time, lost sales or loss or damage to data, injury to person or personal property or any other
indirect damages as the result of use of our products.
RETURNS
If the product fails under normal use during the warranty period, a RMA (Return Material
Authorization) number must be obtained from GasLab. After the item is received GasLab will
repair or replace the item at our discretion.
To obtain a RMA number, call us at [phone]. When requesting a RMA please provide
reason for return and the original order number.

Copyright © GasLab Inc, All Rights Reserved 11 of 11
PAGE
If we determine that the product failed because of improper use (water damage, dropping,
tampering, electrical damage etc.), or if it is beyond the warranty date, we will inform you of the
cost to fix or replace the product.
For additional warranty information visit our website: gaslab.com/pages/faq
CONTACT US
We are here to help!
For information or technical support, please contact us.
[email protected]
Gaslab.com
GasLab, Inc.
131 Business Center Drive, Ste. A3
Ormond Beach, FL 32174 USA
PAGE
