Specifications for the
Gateway Profile 5
Specifications are subject to change without notice or obligation.
Processor and core logic
Processor To determine your computer’s processor:
■In Windows XP, click Start, My Computer, then click View System
Information. The processor is listed.
-OR-
■In Windows 2000, click Start, Programs, Accessories, System
Tools, then click System Information. The processor is listed.
Connector Socket 478
Level 2 cache
(depending on processor)
■128 KB
■512 KB
BIOS ■Phoenix BIOS
■512 KB Flash ROM
■ACPI
Bus speed
(depending on processor)
■400 MHz
■533 MHz
■800 MHz
System memory
(depending on memory and
processor)
DDR266/333/400
Two sockets available, which can hold memory upgrades for a
maximum capacity of 2 GB.
To determine your computer’s total memory:
■In Windows XP, click Start, My Computer, then click View System
Information. The memory is listed.
-OR-
■In Windows 2000, click Start, Programs, Accessories,
System Tools, then click System Information. The memory is
listed.

2www.gateway.com
LCD panel ■Maximum color depth: 16.2 million colors
■Supports Video Scaling
■15.0-inch LCD—active matrix TFT XGA (1024 × 768),
0.297 mm × 0.297 mm dot pitch, 70° viewing angle
■17.0-inch LCD—active matrix TFT XGA (1280 × 1024),
0.264 mm × 0.264 mm dot pitch, 70° viewing angle
■19.0-inch LCD: active matrix TFT XGA (1280 × 1024),
0.294 mm × 0.294 mm dot pitch, 88° viewing angle
Video graphics controller
(depending on configuration)
■GeForce FX 5200; 64 MB DDR
■Integrated Intel®Extreme Graphics2 with up to 64 MB memory
(depending on computer’s installed memory)
Audio
Audio chipset Integrated AC97 Link Sound
Sound support ■16-bit stereo
■Full duplex
■Sound Blaster-compatible
Internal speakers Stereo speakers built into front panel
Power rating: 5 W per channel
Audio CODEC Sigmatel STA09758T
Modem (optional) ■Internal V.92 56 Kbps data/fax
■RJ-11
■MDC
Network (optional) ■Integrated LAN
■RJ-45
■Remote Wake Up support
■Managed PC Boot Agent (MBA)
■10/100 or 10/100/1000
Wireless (optional) ■Integrated Broadcom 802.11g
Storage
Hard drive ■IDE or Serial ATA
■3.5 inch (89.0 mm) drive physical size
To find the hard drive capacity:
■Open My Computer, right-click the drive letter, then select
Properties. The drive’s capacityand available space appears. If the
drive has multiple partitions (for example, C: and D:), add the
capacities of each partition to determine the drive’s total capacity.
Diskette drive 3.5-inch, 1.44 MB

3
Specifications for the Gateway Profile 5
www.gateway.com
Optical drive Available drives include:
■CD
■Combination DVD/CD-RW
■DVD-RW
To determine the type of optical drive in a bay, examine the drive tray's
plastic cover. A CD Compact Disc logo indicates a CD drive, a DVD
logo in combination with a CD-RW logo indicates a DVD drive that also
is a recordable/rewritable CD drive, and a DVD-RW logo indicates a
recordable/rewritable DVD drive.
Input/Output (I/O)
Keyboard and mouse Standard: PS/2 keyboard, 2-button USB wheel mouse
Optional: Wireless keyboard, wireless wheel mouse
PCMCIA (PC Card) One Type II 32-bit PC Card slot
Controller: TI 4510
I/O ports and connections ■One Type II PC Card slot
■Modem (RJ-11) (optional)
■Network (RJ-45, Integrated LAN) (optional)
■1 IEEE 1394 port (4-pin)
■1 IEEE 1394 port (6-pin)
■Serial
■VGA out
■VGA in
■Parallel/printer (supports ECP, EPP)
■Microphone in
■Audio line in
■Audio line out
■Headphones/speakers out (front/rear)
■PS/2 mouse
■PS/2 keyboard
■USB 2.0 (6)
■DC power
Power
AC adapter ■12 VDC, 180 W or 200 W maximum continuous output
■Automatic voltage adjustment between 110 and 220 VAC 50-60 Hz
Power management ACPI V2.0 support
Security
Passwords Power-on password (2-level password support)

4www.gateway.com
Many products for Gateway and its subsidiaries are custom engineered by our
suppliers to Gateway specifications and may vary from similarly marketed
products.
System software (optional)
Operating system ■Microsoft®Windows®XP Professional
■Microsoft®Windows®XP Home Edition
■Microsoft®Windows®2000
System management ■SMBIOS 2.1 BIOS support
■Intel®LANDesk®Client Manager 6.3
■Wired for Management V1.1a-enabled
■Support for Wake on LAN
■Alert on LAN with limited functionality
■ACPI power management
Physical specifications
Dimensions System without cord cover installed (W × H × D):
■15-inch LCD—13.86 inches × 15.49 inches × 6.95 inches
(352 mm × 393.5 mm × 176.5 mm)
■17-inch LCD—15.28 inches × 17.32 inches × 7.24 inches
(388 mm × 440 mm × 184 mm)
■19-inch LCD—16.93 inches × 18.86 inches × 7.72 inches
(430 mm × 479 mm × 188 mm)
Display Tilt angle: –5° through +15°
Weight System without AC power adapter:
■15-inch LCD—20.28 lbs. (9.2 kg)
■17-inch LCD—22.71 lbs. (10.3 kg)
■19-inch LCD—25.35 lbs. (11.5 kg)
Environmental specifications
Operating temperature 32° to 95°F (0° to 35°C)
Operating humidity 20% to 80%, no condensation
Storage humidity 15% to 98%, no condensation
8509443 - MAN US PFL5 SPEC R0 10/03
