Replacing the Gateway 200ARC Keyboard
www.gateway.com
Replacing the Gateway 200ARC
Keyboard
This package includes a replacement keyboard for your Gateway 200ARC
notebook and these printed instructions.
Tools you need
You need a small Phillips and a small flat-blade screwdriver to replace the
keyboard.
Preventing static electricity discharge
The components inside your notebook are extremely sensitive to static
electricity, also known as electrostatic discharge (ESD).
Before replacing the keyboard, follow these guidelines:
■Turn off your notebook.
■Wear a grounding wrist strap (available at most electronics stores) and
attach it to a bare metal part of your workbench or other grounded
connection.
■Touch a bare metal surface on your workbench or other grounded object.
Warning ESD can permanently damage electrostatic
discharge-sensitive components in your notebook.
Prevent ESD damage by following ESD guidelines every
time you replace the keyboard.
Warning To avoid exposure to dangerous electrical voltages and
moving parts, turn off your notebook and unplug the power
cord and modem and network cables and remove the
battery before opening the case.
Warning To prevent risk of electric shock, do not insert any object
into the vent holes of the notebook.

2www.gateway.com
■Unplug the power cord and the modem and network cables.
■Remove the battery. For more information, see “Changing batteries” in
your user’s guide.
■Disconnect all peripheral devices and remove any PC Cards.
Before working with notebook components, follow these guidelines:
■Avoid static-causing surfaces such as carpeted floors, plastic, and packing
foam.
■Remove components from their antistatic bags only when you are ready
to use them. Do not lay components on the outside of antistatic bags
because only the inside of the bags provide electrostatic protection.
■Always hold components by their edges. Avoid touching the edge
connectors. Never slide components over any surface.
Removing the keyboard
To remove the keyboard:
1Follow the instructions under “Preventing static electricity discharge” on
page 1.
2Turn off your notebook.
3Remove any PC Cards.
4Disconnect the AC adapter and modem and network cables.
5Disconnect the optional port replicator.
6Turn your notebook over so the bottom is facing up.
7Remove the battery.

3
Replacing the Gateway 200ARC Keyboard
www.gateway.com
8With a small Phillips screwdriver, remove the two keyboard screws and put
them in a safe place.
9Turn your notebook over so the top is facing up.
10 Open the LCD panel to the normal viewing position.
Screws

4www.gateway.com
11 Insert the small flat-blade screwdriver in front of the keyboard in the
locations shown and gently pull the three spring-loaded tabs toward you.
The keyboard will spring up slightly.
12 While lifting the front of the keyboard, slide the keyboard toward you to
release the five tabs at the back of the keyboard.
Tabs

5
Replacing the Gateway 200ARC Keyboard
www.gateway.com
13 Lift the back edge of the keyboard, then slowly rotate it toward you so it
lies keys-down on top of your notebook. Be careful not to damage the
LCD panel.

6www.gateway.com
14 Using two fingers, slide the plastic keyboard connector clamp forward.
After the keyboard connector clamp is in the forward position, gently pull
the keyboard cable out of the connector. Be careful not to touch or damage
any other components.
Installing the keyboard
To install the keyboard:
1Place the new keyboard keys-down on your notebook with the space bar
away from you.
2Locate the keyboard connector clamp and pull forward on it to verify that
it is in the forward position.
3Slide the end of the keyboard cable into the keyboard connector.
4Using two fingers, press backward on the keyboard connector clamp. This
locks the keyboard cable into the keyboard connector.
5Rotate the keyboard toward the LCD panel until the keyboard is
almost face-up.

7
Replacing the Gateway 200ARC Keyboard
www.gateway.com
6Insert the tabs on the back of the keyboard under the keyboard bezel.
7Gently press the front of the keyboard down until the spring loaded tabs
click into place and the keyboard is flat all the way across. The keyboard
should easily fall into place. Be careful not to damage the LCD panel.
8Close the LCD panel.

8www.gateway.com
9Turn your notebook over so the bottom is facing up.
10 Replace the two keyboard screws.
11 Replace the battery.
12 Connect the power adapter and modem and network cables, then turn on
your notebook.
Technical Support
See your user’s guide for Gateway Technical Support information.
Safety, Regulatory, and Legal Information
See your user’s guide for important safety, regulatory, and legal information.
