Gator GC100 User manual

Quick start guide
Technical Assistance
If you need assistance setting up or using your Gator
product now or in the future, call Gator Support.
Australia
TEL: 03 – 8587 8898
FAX: 03 – 8587 8866
Mon-Fri 9am – 5pm AEST
Please retain this quick start guide for future reference.
If you would like to download a more detailed
function manual, or other Gator manuals/software,
please visit the http://gatordriverassist.com website
and click on ‘Firmware & Manuals” for information on
where to nd the manuals/software.
This manual is considered correct at time of printing
but is subject to change.
For latest manuals and updates refer to the website.

Up Button
(WiFi)
Features

Note: Camera is not waterproof until placed securely
in Waterproof housing
Up Button Locking
Clip
Locking
Mount
Down Button
AccessoriesWaterproof Housing
Charge/Data cable Quick start guide

Thank you for purchasing the Gator GC100. This Quick
Start Guide will help you learn the basics of using the
action camera. For a more detailed manual please refer
to our website at www.gatordriverassist.com
Inserting Micro SD Card
Note: Please choose a branded Micro SD card and
format it on computer before use. The camera
supports up to 32GB, Class 10 (Non Ultra).
Installing and removing battery
1. Slide latch across and lift battery cover up to open.
2. Correctly install battery into camera as indicated by
+/- symbols and direction of arrows marked on the
battery until it’s in place.
3. Replace cover
4. To remove battery pull battery door latch upwards
Charging
1. Charging can be done by either connecting the
camera to a computer or power adapter (not included)
Getting Started
Press & hold the mode button on the front of the
camera for 3 - 5 seconds to turn it on. Press the mode
button to cycle through camera modes.
1. Video mode- to record video
2. Photo mode- to take pictures
3. Playback mode- to view videos and pictures
4. Setup menu.
Video mode
When in recording mode symbol is displayed
on top of screen, press red shutter button to start
and stop recording. A red circle appears next to this
symbol and ashes whilst recording.

Photo mode
When in photo mode symbol is displayed on top
of screen, press red shutter button to take a
picture.
Playback mode
Use the up & down buttons to cycle through video
and picture taken on the device. Press the red
shutter button to select & play. For le storage &
playing after you are done recording, use a the USB
cable provided to export the videos and pictures onto
a computer to play. Or you can take the Micro SD card
out and access the image data with a card reader.

Setup Menu
Press the up and down buttons on the side of the
camera to cycle through setup settings. Press the
shutter button to select setting. Use up and down
arrows to select sub setting and press shutter button
to conrm selection.
Video Resolution:
1080P @ 30 FPS, 720P @ 30 FPS, VGA
Loop Recording:
O, 1 Min, 3 Mins, 5 Mins or 10 Mins
Exposure:
+2/3, +1/3, +0/0, -1/3, -2/3, -1/0, -4/3, -5/3 or -2/0
Picture Resolution:
12M, 10M, 8M, 5M, 3M, 2M, 1.3M & VGA
Record Audio
O/On
Date/Time:
Year/Month/Day
Time
Format
Auto Power o:
O, 1 Min, 3 Mins, 5Mins
Language:
English, Chinese,French, Dutch, Italian, Portuguese,
Russian, Spanish,
Frequency:
50Hz - 60Hz
Screen LCD Saver:
O, 3 Mins, 5Mins
Vehicle:
O/On
Format:
All data will be deleted
Cancel/OK
Default Setting
Return menu setting to defaults
Cancel/OK
Date Stamp
O/On
Delete:
Delete Current
Delete All
Cancel/OK
Protect:
Lock Current
Unlock Current
Lock All
Unlock All
Cancel/OK
Volume:
0-7
Version:
rmware version

Specications
CPU: GP1247
Sensor: GC1024
Lens:
140 degrees
Screen:
1.5” LCD screen
Video/Compression format:
MP4/H.264
Video resolution:
1080P HD @ 30 FPS
720P HD @ 30 FPS
Picture format:
JPG
Picture resolution:
12MP 4032 x 3024
Storage format:
Micro SD card Class 10 Up to 32GB (Non Ultra )
Waterproof:
30M with case
Audio frquency:
Stereo
Battery:
Rechargeable 3.7V/900mAh Li-ion
Battery autonomy: 90 Minutes
Operating system: Windows XP/ Mac OS
Micro SD Cards:
Charging the battery:
