GDS LiteWare User manual

Supplied Items
•1 x RGB Uplighter Unit
•Instruction Leaflet
•Battery Charger
•Mains Lead
•Aerial
RGB Battery Uplighter
with Wireless MX
Introduction
The RGB battery uplighter with wireless MX is a
stand alone light source. The unit can be
controlled by MX transmitted wirelessly and in stand alone operation using 50 preset
colours and 20 preset fade and snap sequences.
Features
• Full RGB with 16 bit dimming curve
• Wireless MX Control
• Up to 24 hour runtime from fully charged battery (12 hours full white)
• 50 preset colours
• 20 preset colour chases
• Charging Cycle Approximately 8 hours
• Wireless Firmware Update
Conformity
The RGB Uplighter conforms to the following standards:
EN 61000-6-3 Light Industrial Emissions
EN 61000-4-2 Heavy Industrial Immunity
Further information can be obtained from techni[email protected]
Manufactured in the UK by Global esign Solutions
www.gds.uk.com [e-mail]

Normal Operation
DM mode
To turn the unit ON or OFF, the Top Button needs to be held for 1.5 Seconds. The
button LE will illuminate to show the unit is awake.
In Stand Alone Mode
To turn the unit ON or OFF, the button needs to be held for 1.5 Seconds. The button
LE will illuminate to show the unit is awake. A short push of the button will dim the
unit to the next level. There are 7 levels. When the button is pushed for the 7th time,
the unit will jump back up to full level.
In either mode when the battery voltage falls below 9.7V, the unit will go to sleep
and pulse the top button LE at a rate of 100mS ON, 1900mS OFF. The unit can’t be
switched back on until it has been recharged.
Address Settings
The address of the unit is set using 2 push buttons on the base. These are labelled UP
and OWN. Pushing the UP button will increment the address, pushing the OWN
button will decrement the address. If the unit is at 001 and you press the OWN
button, it will remain at 001. If you hold one of the buttons the address will slowly
increment/decrement gradually speeding up. When the address reaches 512 it will stop
at the boundary. You must then release the button and push it once again to get to
address 600. These boundaries are intended to make the addressing easier to
navigate. The boundaries are: -
1-512 Wireless MX Mode Address
601-650 Fixed Colour Mode
651-660 Colour Fade Sequence
661-670 Colour Snap Sequence
Any time you push UP or OWN the address will display for 5 seconds before blanking.
The address will be displayed for another 5 seconds upon pressing either button.
Wireless DM Mode (Address 1-512)
In W MX Mode – the unit will simply respond to the MX levels being received.
MX channel allocations are as follows:
Start Address Red Level
Start Address +1 Green Level
Start Address +2 Blue Level
A control channel may be added at a later date.
In W MX mode, the unit will hold the last MX value upon loss of signal or MX. The
unit will store this level when turned off so it can be resumed when it is powered back
up.
If the battery is disconnected, these values will be lost.

Stand-Alone Mode (Address 600+)
601-650 FIXE COLOURS
etailed in table on page 4
651-655 COLOUR FA E SEQUENCE 1
A colour fade sequence with 5 different speeds of transition
656-660 COLOUR FA E SEQUENCE 2
A colour fade sequence with 5 different speeds of transition
661-665 COLOUR SNAP SEQUENCE 1
A colour snap sequence with 5 different speeds of transition
666-670 COLOUR SNAP SEQUENCE 2
A colour snap sequence with 5 different speeds of transition
The top button in this mode will operate as follows: -
Long press >1.5 seconds unit turns ON if OFF, and OFF if ON.
Short press <1.5 seconds If ON then the unit dims current colour to the next level,
there are 7 levels.
Docked Not Charging
When the unit is docked it will go to sleep, if it’s on it will turn off and disable all non-
essential peripherals. The button LE will remain off. You can’t switch the unit on while
it is docked.
Docked and Charging
The unit will detect its charging by monitoring the charge current. The button has no
effect on this mode. The button LE will respond as follows:
Flashing 500ms ON/OFF Unit is ready for use
Constant ON - Unit is charging
WDM Linking
The Uplighter is automatically unlinked from the transmitter when plugged into the
charger. The link status is shown on the LE display on the base of the unit when its
powered on.
Battery Care
The Uplighter contains a Sealed Lead-Acid battery. The battery should not be left in an
discharged state for long periods because it will reduce its capacity.

Fixed Colour Table
ADDRESS COLOUR LEE Ref ROSCO Ref
601 RE
602 GREEN
603 BLUE
604 YELLOW
605 CYAN
606 MAGENTA
607 ORANGE
608 GOL
609 PINK
610 VIOLET
611 AQUA
612 SKY BLUE
613 FULL WHITE
614 COOL WHITE
615 WARM WHITE
616 YELLOW LEE 101
617 STRAW LEE 103
618 ORANGE LEE 105
619 PRIMARY RE LEE 106
620 LIGHT ROSE LEE 107
621 ARK PINK LEE 111
622 MAGENTA LEE 113
623 BLUE LEE 115
624 ME BLUE GREEN LEE 116
625 ARK BLUE LEE 119
626 BRIGHT PINK LEE 128
627 ME IUM BLUE LEE 132
628 GOL EN AMBER LEE 134
629 EEP GOL EN AMBER LEE 135
630 PALE LAVEN ER LEE 136
631 APRICOT LEE 147
632 ARK LAVEN ER LEE 180
633 CHOCOLATE LEE 156
634 JUST BLUE LEE 079
635 SURPRISE PINK LEE 194
636 SCARLET LEE 024
637 SURPRISE PEACH LEE 017
638 FIRE LEE 019
639 ENGLISH ROSE LEE 108
640 MAUVE LEE 126
641 BRIGHT BLUE LEE 141
642 ALICE BLUE ROSCO 378
643 ROSE IN IGO ROSCO 358
644 URBAN BLUE ROSCO 081
645 COOL BLUE ROSCO 066
646 LIGHT SALMON ROSCO 030
647 MAYAN SUN ROSCO 318
648 CHERRY ROSE ROSCO 332
649 FLESH PINK ROSCO 034
650 SKELTON EXOTIC SANGRIA ROSCO 039
