GE Logiq R7 User manual

Your complete animal imaging solution
1. Power
2. Time gain
compensation (TGC)
Move left/right to adjust
Help key
Brings up
searchable
full manual.
15. Soft key knobs/menu
select keys
Function changes on screen
depending on mode.
Reverse
Press to reverse
image, left/
right.
Function keys
13. Utility
Press to enter the set
up function pages and
congure the system.
14.
Alphanumeric
keyboard
Use the
keyboard to
enter patient
information
and
annotations
Further image
optimisation
Steer
Harmonics
Report
Press to
access
patient
report
mode
Follow up
(optional
extra)
6.Exam
3. New
patient
Press to add
new patient
and access
patient
information
screen
M Mode
PW Doppler
4. Gain/Auto
optimization
Rotate the key
to adjust the
Gain.
Press Auto
to activate/
deactivate auto
optimization.
B Mode
9. Depth/
Zoom/Ellipse
Rotate to
alter. Press
to change
between
modes.
Comment
Add
annotations.
10. Switch
between left
and right screen.
11. Freeze
Press to
freeze the
image or
return to
scanning.
Volume
and
brightness
keys
12. Print Keys
P1 Save
P2 Print
P3 Send to
USB
5. Power
Doppler
(PDI)
Needle
enhancement
(optional extra)
7. Colour
Doppler
8. Imaging/
measurement
keys:
Cursor
Clear
Body Mark
Calcs
M/D Cursor
Scan Area
Enter
A G
B F
C E
D
A
B
C
D
E
F
G
GE Logiq R7
Quick Guide

Your complete animal imaging solution
Connecting the Probe
1. Handling the probe carefully, slide the connector
straight into the port whilst the machine is not
imaging (e.g. turned off, patient entry screen or in a
frozen image.
2. Lift the probe latch into place
Entering Patient Data
1. Press the “Patient” Key [3]
2. Enter a name and unique patient ID (required
to store images, this can be set to generate
automatically).
3. Select “Register”
4. Select “Exit” to leave the patient screen
Selecting a Preset
1. Press the “Exam” key [6]
2. Use the pointer arrow to select the appropriate
exam type you will be performing
3. Press the “Enter” key [8-g]
4. The system will then go to the scan screen
Frequency – Is changed using the top left soft key
in B-Mode. A higher frequency setting provides
higher resolution to the image, however, penetration
is reduced. A lower frequency setting improves
penetration ability, however, the resolution is
diminished.
Depth – Is controlled by rotating key [9]. Adjust so that
the region of interest occupies approximately ¾ of the
screen. A depth scale is displayed next to the image.
Gain – Increases or decreases the overall brightness of
the image. Rotating key [4].
Focus – Controlled by the far right soft key in B-Mode.
Rotate to move the focal position up and down the
depth scale. Press and rotate to change the number
of focus points. Press again to return to focus position
control.
Measurements
1. Freeze the image and scroll back through the
paused images using the track ball to select an
appropriate image.
2. Press the “Calcs” key [8-d], a calliper will appear.
3. Place the calliper in the appropriate position and
press “Enter”
4. A second calliper will appear.
5. Place the second calliper in the appropriate
position and press “Enter”. A measurement box
appears with the measurement you have just
completed.
6. Pressing “Calcs” again will bring up another cursor
to make a second measurement. If measurements
are complete press “Clear” [8-b] or “Freeze” to exit
measurements
Annotating an image
1. To add text to an image, begin typing on the
keyboard. The word ll-in function will offer words
while typing. Press the “tab” key on the keyboard to
accept an offered word. Pressing the “Comment”
key [space bar] places a cursor or choose a word
from the comments library with the pointer and
press the “Enter” key
2. To set the text position on the screen, place the
cursor in the desired location and press the “Enter”.
Set text is yellow
3. To edit or move set text, reselect the text with the
cursor. Editable text is green
Colour Flow
1. Press the “Colour” key [7]
2. The colour box appears over the B-Mode image.
3. Use the trackball to move the colour box
4. Press “Scan Area” [8-f] to change the size of the
colour box using the trackball. Press “Scan Area”
again to set the colour box
Power Doppler
1. Press the “PDI” key [5]
2. Adjust as per the colour ow
Split Screen
1. Press the “Start (L)” key [10] to display the left side of
the image live
2. Press the “Stop (R)” key [10]. The left side will freeze
and the right side will be live
3. Toggle between “L” and “R” to obtain desired
4. Press “Freeze” to freeze both images.
Storing Images
1. Press “P1” to store images to the clipboard/ hard
drive
2. Press “P2” to print to a thermal printer (if included)
3. Press “P3” to store JPEG/ AVI to a USB Memory stick
4. Pressing a “P” button on a frozen image stores a still
5. Pressing a “P” button on a moving image stores a
clip
End Exam
1. Press the function key that has been programmed
to “End Exam”
2. This will take you to the data transfer screen to
allow you export DICOM images if required. Insert
a USB drive into the front USB port on the side of the
console – “USB Drive I” should appear in the “To:”
window. Select “export” then highlight the study
you would like to transfer and press the “Transfer”
button to save DICOM images. Select “Exit” to
return to the scanning screen.
GE Logiq R7 Quick Guide
